Naomi Home Jade Side Table User manual

Assembly Instructions
Product Dimensions:
27.75” L x 11” D x 34” H
Please take a moment to read through the entire instruction booklet before assembly to
familiarize yourself with this product. Once you feel ready to start, follow the instructions
step by step and this should make this process as easy as we could make it for you.
If you need help or have damaged or missing parts, contact customer service at
www.NaomiHome.com.
Page 1 of 8
NAOMI
Jade Side Table
HOME
©
2019 Naomi Home, Inc. - All Rights Reserved.

Page 2 of 8
ADULT ASSEMBLY REQUIRED
CHOKING HAZARD
•
USE, MAINTENANCE & ASSEMBLY
PARENTAL SUPERVISION IS REQUIRED
WARNING CAUTION
SAFETY WARNINGS
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
This product includes small parts, sharp points and sharp edges in its unassembled state.
Keep unassembled parts away from children under 3 years of age, and animals.
Follow the information on the warnings appearing on table and on the
carton. Do not remove warning label from table.
Do not allow children under 3 years of age to use the table.
Do not use substitute parts. Contact the manufacturer or dealer for replacement parts.
Parents or Guardians should supervise use under the intended age specifically regarding
children that may have access to it and climb on the unit.
Do not allow horseplay on, under, or behind the unit and prohibit jumping on the table.
If used improperly, your table may be pulled over or fall, creating risk of injury or
damage. Children should not be permitted to climb or pull on the table.
Periodically check and ensure that the components are in their proper position, free from
damage, and that all connectors are tight.
Use on level surfaces only. Assemble on a soft level surface to avoid damage to unit or floor.
Do not use this item if any components are missing or damaged.
Do not use substitute parts. Contact the manufacturer or dealer for replacement parts.
Only clean using damp cloth and mild detergent, do not use bleach or abrasive cleaners.
Check you have all components and tools listed on page 4
Do not stand or put weight on this product during assembly, this could cause damage.
Remove all hardware from the plastic bags and separate them into groups.
Assemble the item as close to its final position (in the same room) as possible.
Certain assembly steps may be easier with 2 people.
Dispose of all packaging carefully and responsibly.
We do not recommend power screwdrivers. Only use hand screwdrivers to prevent
damage to unit.
•
Enfants morts suite au basculement d’un meuble.
Afin de limiter le risque de basculement de meuble:
TOUJOURS utiliser les fixations anti-basculement.
NE JAMAIS installer de TV sur ce produit.
NE JAMAIS laisser d’enfants se tenir debout sur les tiroirs,
portes ou etageres, y grimper ou s’y suspendre.
NE JAMAIS ouvrir plus d’un tiroir a la fois.
TOUJOURS placer les choses les plus lourdes dans les tiroirs du bas.
Han muerto ninos por el vuelco de meubles.
Para limitar el riesgo de vuelco de los meubles:
Utilisar SIEMPRE las fijaciones antivuelco que suministran.
NUNCA instalar un TV sobre este producto.
NUNCA permitar que los ninos se pongan de pie, trepen o
se cuelguen de los cajones, puertas o baldas.
NUNCA abrir mas de un cajon a la vez.
Colocar los objetos mas pesados en los cajones inferiores.
•
•
•
•
•
•
•
•
•
•
!
FURNITURE TIP-OVER HAZARD
•
•
•
•
•
Children have died from furniture tip-over.
To reduce the risk of furniture tip-over:
ALWAYS install tip-over restraint especially if used by a wall or in the open.
NEVER put a TV on this product
NEVER allow children to stand, climb or hang on drawers, doors, or shelves.
NEVER open more than one drawer at a time.
ALWAYS place heaviest items in lowest drawers.
Keep these instructions for future reference.
•

This drawing is to give you an overall idea only of how this assembly will go together and does
not replace the assembly instructions.
Please take a moment to read through the whole instruction booklet before assembly to familiarize
yourself withthisproduct . Once you feel ready to start, follow the instructionsstep by step and thisshould
mak e thisprocess as easy as we could make it for you.
ASSEMBLY AT A GLANCE
Page 3 of 8
1
2
3
4

ASSEMBLY HARDWARE
1
2
3
5
COMPONENT PARTS
Please check that you have all the parts listed below
Medium Long Bolt
M6x50mm x 6
Screw
FE G
x 1
Allen Wrench
H
1. Top Shelf x 1
2. Left Panel x 1
3. Right Panel x 1
4. Bottom Shelf x 1
5. Power Receptacle ×1
Wood Dowel Pin
B
ACD
Page 4 of 8
4
15x11mm x 4
CAM Lock CAM Bolt
10x10mm x 6 2.5x12mm x 2
6x35mm x 4 8x30mm x 4
Ø
Knob X 6
Tools RequiredTools Required
Hex Screwdriver
(included)
Phillips Screwdriver
(Medium) (not included)
*Do Not Use Power
Screwdriver or Drill.

1
4
H
E
E
E
E
C
C
D
D
D
D
D
D
ASSEMBLY INSTRUCTIONS
2
1
Select 1, 4, B x4, D x2. Turn
down the panel 1,insert B x4
into the four corners of the
panel 1. Insert D x2 into the
both sides middle hole of
the panel 4.
Page 5 of 8
B
B
B
B
Select 2, 3, 4, C×2,
D×4,E×4,H×1.Insert E×2 into
the left side of panel 4.Insert
D ×2 into the top side of the
panel 2 with H
Allen Wrench
into the left side of panel
4.Insert C×1 into the end of
the middle hole of the panel
2.Repeat the C×1,D×2 for
panel 3.Repeat E×2, D×2 for
panel 4.
4
3
2

1
1
H
E
E
D
4
4
3
3
2
2
ASSEMBLY INSTRUCTIONS
4
3
Select A×4.Insert
A×2 into the end
of the panel 3.
Repeat A×2 for
panel 2.
Install panel 1
into top of the
panel 2 and panel
3. Insert E×2 into
the inner sides of
the panel 1. Insert
D×2 into the
panel 3 into the
panel 1.
Page 6 of 8
A
A
A

1
G
G
G
G
G
43
2
1
H
D
3
5
ASSEMBLY INSTRUCTIONS
5
6
Select G×6.Insert
G ×4 into the
panel 3 into
panel 1,4. Insert
G × 2 into the
end of the panel
2 into the panel
4.
Page 7 of 8
Select 5×1.Insert 5 Power Receptacle into the
empty of the panel 3.

ASSEMBLY COMPLETE
Page 8 of 8
www.NaomiHome.com
