C100 SAFARI
standard
wide angle
lens












The C100-SAFARI is a combination of NAPCO’s field-proven dual technology C100ST
microwave/passive infrared detector within a new ruggedized, sealed outdoor
enclosure with flexible dual mounting brackets for optimal field-
of-view aiming, vertically and horizontally. With a wide operating
temperature of -20 to +50 degrees C (-4 º to 122º F), weather-shielded
enclosure and white-light filtering fresnel lens, the compact unit will
reliably provide outdoor motion detection with a range of 15.2m x
12.2m (50 x40’) @ 25° C.
Providing full vertical (up-down) and horizontal (side-to-side) coverage
pattern rotation, the unit is supplied with two locking swivel
mounting brackets, for use in applications with or without an
electrical junction box (as shown below). An innovative detector,
the microprocessor-controlled unit incorporates NAPCO’s patented
“smart” dual technology that actively analyzes incoming signals
comparatively and automatically makes continuous adjustments to
counteract false alarm sources detected in its environments minute-by-
minute. This perpetual environmental evaluation and correction cycle
enables the unit to increase and/or decrease sensitivity as needed,
always assuring both optimal stability and intruder “catch”
detection. For further integrity, C100-SAFARI performs periodic
active self-tests on both the PIR and Microwave channels of its
RFI/EMI-shielded circuitry.
Weatherproof Outdoor Adaptive®
15.2m Dual Technology
Ruggedized Microwave/PIR
Detectors with swivel mount,
automatically adjust to their
environment, minute by minute,for
the ultimate false alarm
immunity and reliability

FEATURES
• Broad 15.2m x 12.2m (50 x40’)* detection range and models
for installations worldwide (*Range at 25° C.): C100-SAFARI68
10.687GHz for United Kingdom; C100-SAFARI52 10.525GHz for
Europe; C100-SAFARI99 9.99GHz for France.
• Ruggedized, outdoor 180º swivel brackets supplied (2) for full
vertical (up-down) and horizontal (left-right) coverage pattern
aiming, for use with or without electrical junction box. Enables full
rotation during installation and locking in the optimal field-of-view in
any avaliable outdoor location.
• Custom white-light-filtered aspheric optics for outdoors. Napco’s
fresnel lenses are carefully designed to provide the ideal wide
angle lens array; additionally, SAFARI models have extra white-light
filtering pigmentation for outdoor extremes.
• Forgiving, wide, operating temperature of -20 to +50 degrees
C (-4 º to 122º F) and temperature compensated circuitry for
dependable use even in outdoor extremes.
• Patented Adaptive ® technology continuously monitors and
dynamically self-adjusts the sensor to its environment. This
ensures intruder “catch” sensitivity is optimized minute-by-minute,
while “phantom” false alarm sources, such as pets/animals, fans,
sunlight, HVAC, are simultaneously counteracted.
• Smart microprocessor-based false alarm discrimination. The
on-board A to D conversion microprocessor (Analog-to-Digital)
analyzes all incoming microwave and PIR detected signals against its
built in library of waveform signatures of known false alarm sources,
like heaters, fans, blowing drapes/blinds and animals. The product
of decades of sensor engineering and expertise, this inherent signal
processing intelligence, enables Adaptive® Detectors provides
unsurpassed false alarm discrimination the reliability and accuracy
will save both time and money.
• 12 automatically selected, dynamic Adaptive® detection modes
for optimal “intruder catch” and stability. (Modes 1-12: 1 most
sensitive, 12 most stable).
• Dual technology microwave and PIR signal verification. The
detector combines the strengths of both heat- and motion-sensitive
detection technologies to dually verify alarm conditions for ideal
false alarm discrimination.
• Active, automatic self-testing of all key components and circuits-
The unit will internally generate both a PIR signal and a microwave
signal, in intervals of 11- 16 hours, which will fully test both channels
independently. Any failure or internal trouble will be reported to
the system for quick remedy, avoiding any false sense of security or
breach thereof.
• Superior RFI-/EFI-/lightning shielded protection. Key components
and resilient SMD circuitry are electronically-shielded to 30V/m. This
protects the unit’s proper performance from nuisance interference
due to static discharge, power surges, electric spikes, etc.
• Critical Range Control - the detector enables manual, customizable
range with a calibrated adjustable potentiometer to fine-tune range
during walk-test, if desired.
NAPCO Product Availability – Email us at [e-mail]
• Secured cover and tamper supervision defeats acts to sabotage
or vandalize the unit by reporting them to the system if opening
the detector is attempted.
• Added False Alarm Prevention Features. The unit employs
myriad features to ensure only valid alarms are reported in the
system. This includes properties of its circuitry and fresnel optics,
which include integral extra white light protection, a Napco-
pioneered innovation.
SPECIFICATIONS
• Microprocessor: 2K ROM with A-D Converter
• Operating temperature*: -20 to +50 º C (-4 º to 122º F)
• Output relay: Form A; normally closed
• Relay time: Approx. 3 seconds
• Alarm Relay: 100mA, 24Vdc with internal 10 ohm current limiting resistor
• Multi-mode Trouble Output (Open collector)
• Self-Test Interval: 11 - 16 hrs.
• Power supply requirements: Filtered 10.6 to 16VDC nominal with battery backup
form the control panel.
• Current drain: 28mA (idle/alarm) at 12VDC (nominal)
• Detector (only) dimensions: 11.4 x 6.4 x 5.7cm (HxWxD) (4.5”H x 2.5”W x 2.25”D)
• Dimensions on mounting bracket(lg), overall: 12.7 x 8.6x 14.6cm (HxWxD) (5H x
3.4W 5.75”D)
• Shipping weight: .567 kg (1.25lb.)
NAPCO SECURITY GROUP
In North America 1-800-645-9445 • 631-842-9400
333 Bayview Avenue, Amityville, New York 11701 USA
www.napcosecurity.com
International
224 Europa Blvd, Gemini Business Park
Warrington WA5 7TN England UK
44 (0) 1925242428
Two decades of NAPCO sensor
engineering expertise combines to provide
its sensors with unsurpassed false alarm
prevention and intruder catch detection.
A493












