NAPCO GEM-PIR User manual

GENERAL DESCRIPTIONGENERAL DESCRIPTION
TheGEM-PIRisanadvancedPIRsensordesignedforuse
with Napco’s GEM-Series wireless receivers. The unit is
powered by two 3-volt Type DL123A lithium batteries (sup-
plied)forlongservicelife.Whenbatteryvoltagedropsbelow
normal, a low-battery report will be sent to the receiver.
Coding switches are not used in the GEM-PIR. Each
transmitter has a unique factory-programmed RF ID code
(printed on the unit) that distinguishes itself to the receiver.
(Note:Note: See control-panel instructions for entering this six-
digit hexadecimal code and checksum digit into the panel;
be sure to enter all numbers and/or letters, including lead-
ing zeros, if any.)
SPECIFICATIONSSPECIFICATIONS
PIR Coverage (l x w):PIR Coverage (l x w): 50’ x 50’ (15.2m x 15.2m) at 20°C
(68°F), typical.
Operating Temperature:Operating Temperature: 0° to +50°C (32° to 122°F)
Mounting:Mounting: Wall or corner, 10’ (3m) max.
Dimensions:Dimensions: 4.5’’ x 2.5’’ x 1.7’’ (11.4cm x 6.4cm x
4.3cm) (HxWxD)
Shipping Weight:Shipping Weight: 6.4oz (181gm)
STANDARD LENSSTANDARD LENS
FEATURESFEATURES
•Signal Selective Processing for reliable operation
•Unique circuit design protects against false alarms due
to radio-frequency interference
•Vertical and horizontal aiming capabilities
•Dual-element sensor
•Lens Bank of optional accessory lenses
•Large lens area assures high sensitivity
•Small size with ample wiring space
•Corner mountable
•Built-in Tamper microswitch
REPLACING THE LENSREPLACING THE LENS
The lens is ‘‘sandwiched’’ between the front case and a
Lens Support insert, which also serves to hold the LED
jewel in place. To install one of the accessory lenses,
proceed as follows.
1. To open the case, insert a small screwdriver in the slot
atthebottomandpushupslightly.Removethefrontcover.
2. Push up on the lower edge of
the Lens Support until it is clear of
its retainers, then pull out the sup-
port from the bottom. Be careful
not to dislodge the LED jewel.
Note:Note: If the LED jewel pops out,
reinsert it with the small index key
positioned at the top.
3. Slide out the lens and install
the replacement.
4. Replace the Lens Support:
Slipthe LensSupportunderthetopguideswithitstwotabs
straddling the LED jewel, then push in at the bottom until
the Lens Support snaps into place.
INSTALLATIONINSTALLATION
Anassortmentof ‘‘push-thru’’ holesisprovidedintherear
case for wall or corner mounting. Install the two lithium
batteries as shown in the illustration below.
LoosentheHeightLockScrew andsettheboard’sheight
scaletothemountedheightoftheunit.Retightenthescrew.
To reduce range if necessary, set height scale at a higher
number than actual mounting height of unit. Do not point
the unit at sources of heat, such as radiators, space heat-
ers, etc.
Note:Note: In UL burglary installations, the burglary output
must be programmed for all protective devices.
WALK TESTINGWALK TESTING
The LED will light in the Walk-Test Mode only. Allow at least
3 minutes for the unit to settle. Press the Walk-Test Button to
access the Walk-Test Mode for 5 minutes.
Walkout to the maximum range and walk across the field
of coverage. The LED will light whenever motion is de-
tected. Check for environmental disturbances with all dis-
ruptivedevices(heaters,airconditioners)onandnohuman
activity within the coverage area. Adjust beams laterally by
removing the Lens Support (see REPLACING THE LENS)
and sliding the lens slightly left or right. To block a problem
zone, apply a piece of lens foil (supplied) to the inside
segment of the lens representing that zone.
SETTING THE OPERATING MODESETTING THE OPERATING MODE
The GEM-PIR comes set for operation in the Signal Se-
lective Processing (SSP) Mode. To change to the fixed
2-pulse bipolar mode for use with the Long-Range Lens*
(LENS840), Barrier Lens* (LENS818) or other lens with a
limited number of beams, remove the Response-Mode
Jumper, J1.
Standard Lens coverage pattern for 6’ mounting height.Standard Lens coverage pattern for 6’ mounting height.
GEM-PIR, front cover removed.GEM-PIR, front cover removed.
Removing Lens Support.Removing Lens Support.
NapcoNapco
GEM-PIRGEM-PIR
Wireless PIR TransmitterWireless PIR Transmitter
© NAPCO 1996 WI749C 12/96

*Coverage pattern furnished with lens.
NAPCO SECURITY SYSTEMS, INC.NAPCO SECURITY SYSTEMS, INC.
333 BAYVIEW AVENUE, AMITYVILLE, NEW YORK 11701333 BAYVIEW AVENUE, AMITYVILLE, NEW YORK 11701
FOR SALES, REPAIRS & TECHNICAL SERVICE, CALL TOLL FREE: [phone]FOR SALES, REPAIRS & TECHNICAL SERVICE, CALL TOLL FREE: [phone]
FOR A DIRECT LINE TO TECHNICAL SERVICE CALL TOLL FREE: [phone]FOR A DIRECT LINE TO TECHNICAL SERVICE CALL TOLL FREE: [phone]
