NAPCO GEMC-WL-WD2 User manual

1
GENERAL DESCRIPTION
The GEMC-WL-WD2 is a 2-point window/door transmitter designed
for use in Napco Gemini C-Series wireless systems, and with Napco's
GEMC-RECV series wireless receivers (see WI1682). When used
with the supplied magnet, the transmitter functions as a window/door
sensor. Terminals are provided for supervised external contacts so
that one or more additional contacts may be used in conjunction with,
or instead of, the internal reed switch. A jumper (J1) allows the use of
external contacts (such as UL Listed door/window magnets or ball
contacts, fire alarm pull stations, thermal detectors, waterflow tamper
switches, etc.), instead of the internal reed switch within the same
room (maximum 20' wire length for Burglary installations, maximum 3'
wire length for Fire installations*; 22-18AWG) for Fire and Burglary
sensors. In addition, the GEMC-WL-WD2 includes a rear tamper to
protect against the removal of the transmitter from the wall.
The GEMC-WL-WD2 is powered by a 3-volt lithium battery that will
power the transmitter for up to 5 years. When battery voltage drops
below normal, a low-battery report will be sent to the receiver (replace
battery with a Duracell 3V lithium battery DL123A, Varta/Power-One
model CR123A or Panasonic CR123A only; use of another battery
may present a risk of fire or explosion).
Each transmitter has a unique factory-programmed code (printed on
the battery holder and also on the rear case) that distinguishes itself to
the receiver. (Note: See control-panel instructions for entering this
six-digit hexadecimal code and its checksum digit into the panel; be
sure to enter all numbers and/or letters, including leading zeros, if
any).
Note: When connected for use with a Fire system, and a fire condi-
tion sends a fire alarm signal, this signal will be sent until the condition
clears.
SPECIFICATIONS
Electrical Ratings
Input Power: Powered by a 3-volt lithium battery. Two zone inputs.
Loop voltage: 3V nominal
180K End of line resistor part #: EOL180K (for loop 1 only)
GEMC-WL-WD2
Commercial / Residential Window / Door Transmitter
with Rear Tamper
INSTALLATION INSTRUCTIONS
WI1743B 08/10
R
333 Bayview Avenue
Amityville, New York 11701
For Sales and Repairs, [phone]
For Technical Service, [phone]
Publicly traded on NASDAQ Symbol: NSSC
© NAPCO 2010
Use only one device when used with Fire initiating devices.
Maximum Zone Wiring Length: 20 feet maximum for Burglary in-
stallations, 3 feet maximum for Fire installations* (#18-22 AWG)
Maximum Loop Resistance: 300 ohms
Operating Frequency: 319.5Mhz
Maximum Distance from Receiver: Up to 1000 feet, depending on
local environment
INSTALLATION
Note: The transmitter and magnet may be mounted in any position
with no degradation in performance. Thus, if a left-handed reed
switch is required, the unit may be mounted upside down. However,
for reference purposes in this text, the transmitter will be considered
oriented with the antenna at the top, as shown in these illustrations.
1. Remove the cover. Remove the GEMC-WL-WD2 transmitter
cover by inserting a small screwdriver into the slot at the bottom
and twisting while applying upward pressure. See Fig. 2 below.
2. Insert the battery. Observe battery polarity. Insert battery with
positive (+) terminal toward terminal block. See Fig. 3. The
battery will not make contact if inserted backwards.
3. Identify transmitter parts. Refer to Fig. 4.
4. Select transmitter location. Avoid mounting the transmitter near
the floor. Low level mounting can reduce transmission range and
may subject the transmitter to damage.
5. Remove transmitter and magnet mounting plates.
Transmitter: Use a small screwdriver to push in retaining tab (Fig.
6) and slide cover upward. Magnet: Insert small screw driver into
slot at either end of magnet cover. Push in and twist to pop off
cover. If using external contacts, skip to Step 7.
6. Attach mounting plates. Note: While use of the transmitter
mounting plate is recommended, mounting holes in the rear case
allow mounting without the plate. Use #6 flat-head screws to affix
the mounting plates, observing alignment marks shown in Fig. 6.
Mount the magnet within ½" from the transmitter. Place the tam-
per spring that emerges from the transmitter rear cover into the
top of the oval hole in the transmitter mounting plate. Move the
transmitter down until it snaps onto its mounting plate; snap the
magnet onto its mounting plate. For internal contacts, skip to Step
9.
7. (For external contacts only). Install contact or sensor and
transmitter mounting plate (if used). Mount the external contact or
sensor as described in its instructions. For recessed wiring, drill
an access hole for the wire.
8. (For external contacts only). Connect to terminals. Connect
two wires from an external sensor having normally-closed
contacts (or a normally-closed loop) to Point-1 (Terminals 1–2).
Similarly, if required, connect a sensor (or loop) to Point-2
(Terminals 2–3).
9. Complete transmitter setup. Install Jumper J2 (see Fig. 4) to
enable the holdoff timer (after triggering, unit waits 3 minutes
before retriggering). For example, if used on doors in heavy traffic
areas, this will prevent multiple alarms and thus conserve battery
life. Note: If J2 is installed, both points will be delayed 3 minutes
before retriggering. If internal reed switch is used, remove Jumper
J1 (see Fig. 4) and short Point-1 (Terminals 1–2). An external
contact may be connected to point 2.
10. Close the transmitter case. Close the case by engaging the
hooks at the top, then snap the bottom together.
11. Program the panel. Enter (a) the zone number to which the
transmitter will be mapped; (b) the 6-digit ID code with checksum
digit; and (c) the wireless point number. Refer to the programming
instructions for the control panel and keypad in use. Note: In UL
burglary installations, program the burglary alarm output for all
protective devices.
Fig. 1. GEMC-WL-WD2 Component Parts
REAR COVER MOUNTING PLATE
MOUNTING PLATE
FRONT COVER
MAGNETTRANSMITTER
PC BOARD FRONT COVER
(RETAINING TAB)
Fig. 3. Installing the batteryFig. 2. Open the case
1. Push up
2. Twist
*In Fire installations, leads extending from the GEMC-WL-WD2 located within
7 feet of the floor must be run inside the wall or protected by conduit, etc.

2
Fig. 5. Typical Transmitter Locations
Fig. 6. Removing Mounting Plate and Magnet Cover
RETAINING TAB
1. PUSH IN HERE
2. SLIDE REAR CASE UPWARD
WIRE
ENTRY
HOLE
REED SWITCH & MAGNET
ALIGNMENT MARKS
1. PUSH IN
(AT EITHER END)
2. TWIST
Fig. 4. Location of Parts
J1 SETTING FUNCTION
External Contacts Enabled for both point 1 and 2. (DEFAULT)
Internal Contact Enabled for point 1. External contacts may be used for point 2.
Loop 1 supervised, loop 2 unsupervised.
REED SWITCH
HOLDOFF TIMER JUMPER J2
(INSTALL TO PREVENT MULTIPLE ALARMS
JUMPER J1
TAMPER SWITCH COVER
EXTERNAL CONTACTS
ANTENNA
BATTERY
J1
J2

3
1 2 3
N.C. EXTERNAL
CONTACT(S)
ON POINT 1
N.C. EXTERNAL
CONTACT(S)
ON POINT 2
REED
SWITCH
WIRING
The GEMC-WL-WD2 may be wired in any of the following configurations; refer to the diagrams below: Note: For Commercial and Resi-
dential Fire installations, only ONE initiating device may be connected to this transmitter (only normally open contacts used for Fire). For
Commercial Burglary installations, multiple initiating devices may be used as long as the devices all serve the same function (i.e. door, win-
dow, motion, etc.).
Notes: 1. Caution: Changes or Modifications not approved by Napco may void the user's authority to operate the equipment.
2. This device may not cause interference.
3. This device must accept any interference, including interference that may cause undesired operation of the device.
4. Only loop 1 is supervised.
J1 JUMPER INSTALLED FUNCTION
External Contacts Enabled for both point 1 and 2. (DEFAULT)
1.
2. J1 JUMPER NOT INSTALLED FUNCTION
Internal Contact Enabled for point 1. External contacts may be used for point
1 or point 2.
1 2 3
180K EOL
N.O. EXTERNAL
CONTACT TYPE
DEVICES SUCH
AS PULL STA-
TIONS, THERMAL
DETECTORS,
WATERFLOW
SUPERVISION
SWITCHES, ETC.
SHORT
POINT 2
1 2 3
180K
EOL
SHORT
POINT 2
REED
SWITCH
1 2 3
180K
EOL
REED
SWITCH
N.C. EXTERNAL
CONTACT(S) ON
POINT 2
180K RESISTOR
COLOR CODE (FROM LEFT TO RIGHT):
BROWN (1), GRAY (8), YELLOW (0), GOLD (5%)
1 2 3
N.C. EXTERNAL
CONTACT(S)
ON POINT 1
N.C. EXTERNAL
CONTACT(S)
ON POINT 2
A. FIRE Class B, Style A, B B. BURGLARY
A. BURGLARY B. BURGLARY C. BURGLARY
180K EOL
180K EOL
SUPERVISED
LOOP
UNSUPERVISED
LOOP
(DO NOT USE)
SUPERVISED
LOOP
UNSUPERVISED
LOOP
SUPERVISED
LOOP
UNSUPERVISED
LOOP
SUPERVISED
LOOP
UNSUPERVISED
LOOP
SUPERVISED
LOOP
UNSUPERVISED
LOOP

4
To terminate more than two conductors or
conductors of different wire sizes to a terminal,
use the "pigtail" type wiring method as shown at
right. Use insulated wire for the pigtail, and firmly
secure the conductors to the pigtail using an ap-
propriate wire nut or crimp connector for the num-
ber and gauge of conductors used.
IMPORTANT WIRING METHODS
Incorrect
Correct -- Use pigtail and wire nut / crimp connector
PIGTAIL
WIRE NUT OR
CRIMP
CONNECTOR
PIGTAIL
For single-conductor terminal
blocks (like the type shown at
left), to terminate more than one
conductor to a terminal, use the
wiring methods shown at right:
WIRE NUT OR
CRIMP
CONNECTOR
PIGTAIL
Correct -- Single incoming and/or pigtail with wire nut / crimp connectors
In
For "barrier" type terminal
blocks (like the type shown at
left), to terminate two conductors
to a terminal, use the wiring meth-
ods shown at right: Correct -- Separate incoming and outgoing conductors
In Out
Incorrect
Incorrect
In Out
NAPCO SECURITY SYSTEMS, INC. (NAPCO) warrants its products
to be free from manufacturing defects in materials and workmanship
for thirty-six months following the date of manufacture. NAPCO will,
within said period, at its option, repair or replace any product failing to
operate correctly without charge to the original purchaser or user.
This warranty shall not apply to any equipment, or any part thereof,
which has been repaired by others, improperly installed, improperly
used, abused, altered, damaged, subjected to acts of God, or on
which any serial numbers have been altered, defaced or removed.
Seller will not be responsible for any dismantling or reinstallation
charges.
THERE ARE NO WARRANTIES, EXPRESS OR IMPLIED, WHICH
EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF.
THERE IS NO EXPRESS OR IMPLIED WARRANTY OF
MERCHANTABILITY OR A WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE. ADDITIONALLY, THIS WARRANTY IS IN
LIEU OF ALL OTHER OBLIGATIONS OR LIABILITIES ON THE
PART OF NAPCO.
Any action for breach of warranty, including but not limited to any
implied warranty of merchantability, must be brought within the six
months following the end of the warranty period. IN NO CASE SHALL
NAPCO BE LIABLE TO ANYONE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER
WARRANTY, EXPRESS OR IMPLIED, EVEN IF THE LOSS OR
DAMAGE IS CAUSED BY THE SELLER'S OWN NEGLIGENCE OR
FAULT.
In case of defect, contact the security professional who installed and
maintains your security system. In order to exercise the warranty, the
product must be returned by the security professional, shipping costs
prepaid and insured to NAPCO. After repair or replacement, NAPCO
assumes the cost of returning products under warranty. NAPCO shall
have no obligation under this warranty, or otherwise, if the product
has been repaired by others, improperly installed, improperly used,
abused, altered, damaged, subjected to accident, nuisance, flood, fire
or acts of God, or on which any serial numbers have been altered,
defaced or removed. NAPCO will not be responsible for any
dismantling, reassembly or reinstallation charges.
This warranty contains the entire warranty. It is the sole warranty and
any prior agreements or representations, whether oral or written, are
either merged herein or are expressly cancelled. NAPCO neither
assumes, nor authorizes any other person purporting to act on its
behalf to modify, to change, or to assume for it, any other warranty or
liability concerning its products.
In no event shall NAPCO be liable for an amount in excess of
NAPCO's original selling price of the product, for any loss or damage,
whether direct, indirect, incidental, consequential, or otherwise arising
out of any failure of the product. Seller's warranty, as hereinabove set
forth, shall not be enlarged, diminished or affected by and no
obligation or liability shall arise or grow out of Seller's rendering of
technical advice or service in connection with Buyer's order of the
goods furnished hereunder.
NAPCO RECOMMENDS THAT THE ENTIRE SYSTEM BE
COMPLETELY TESTED WEEKLY.
Warning: Despite frequent testing, and due to, but not limited to, any
or all of the following; criminal tampering, electrical or communications
disruption, it is possible for the system to fail to perform as expected.
NAPCO does not represent that the product/system may not be
compromised or circumvented; or that the product or system will
prevent any personal injury or property loss by burglary, robbery, fire
or otherwise; nor that the product or system will in all cases provide
adequate warning or protection. A properly installed and maintained
alarm may only reduce risk of burglary, robbery, fire or otherwise but it
is not insurance or a guarantee that these events will not occur.
CONSEQUENTLY, SELLER SHALL HAVE NO LIABILITY FOR ANY
PERSONAL INJURY, PROPERTY DAMAGE, OR OTHER LOSS
BASED ON A CLAIM THE PRODUCT FAILED TO GIVE WARNING.
Therefore, the installer should in turn advise the consumer to take any
and all precautions for his or her safety including, but not limited to,
fleeing the premises and calling police or fire department, in order to
mitigate the possibilities of harm and/or damage.
NAPCO is not an insurer of either the property or safety of the user's
family or employees, and limits its liability for any loss or damage
including incidental or consequential damages to NAPCO's original
selling price of the product regardless of the cause of such loss or
damage.
Some states do not allow limitations on how long an implied warranty
lasts or do not allow the exclusion or limitation of incidental or
consequential damages, or differentiate in their treatment of
limitations of liability for ordinary or gross negligence, so the above
limitations or exclusions may not apply to you. This Warranty gives
you specific legal rights and you may also have other rights which
vary from state to state.
NAPCO LIMITED WARRANTY
