Napoleon EPI 1101 User manual

W415-1469 / A / 06.14.16
EN
FR
PG
35
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
This wood appliance needs periodic inspection and repair for proper operation. It is against United States federal
regulation to operate this wood appliance in a manner inconsistent with operating instructions in this manual.
INSTALLATION AND
OPERATING INSTRUCTIONS
1.27D
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
Phone [phone] • Fax [phone] • www.napoleonfireplaces.com • [email protected]
SAFETY INFORMATION
!WARNING
If the information in these instructions is not followed exactly, a
fire or explosion may result causing property damage, personal
injury or death. Improper installation, adjustment, alteration,
service or maintenance can cause injury or property damage,
bodily injury or even death. Please read entire manual before
you install and use your appliance.
This appliance has not been tested with an unvented gas log
set. To reduce risk of fire or injury, do not install an unvented
gas log set into the appliance.
- This appliance can be very hot when burning.
- Combustible materials such as firewood, wet clothing, etc. placed too close
can catch fire.
- Children and pets must be kept from touching the appliance when it is hot.
- The chimney must be sound and free of cracks. Before installing this unit,
contact the local building or fire authority and follow their guidelines.
- Operate only with the door tightly closed.
- Burn wood behind the log retainer directly on the firebricks.
- Do not use an elevated grate or otherwise raise the fire.
- At least 14 square inches (90.3 square centimeters) of outside air must be
admitted to the room or directly to the unit through a 4” (101.6mm) diameter
pipe.
- This appliance is designed to burn natural wood only. Higher efficiencies and
lower emissions generally result when burning air dried seasoned hardwoods,
as compared to softwoods or to green or freshly cut hardwoods.
- Do not start a fire with chemicals or fluids such as gasoline, engine oil, etc.
- Do not burn trash or garbage, lawn clippings / waste, rubber, waste petroleum
products, paints or paint thinners / solvents, plastic, materials containing
asbestos, construction debris, railroad ties or treated wood, manure or animal
remains, salt water driftwood or salted materials, unseasoned wood, coal,
charcoal, coloured paper, cardboard, plywood or particleboard.
- Do not let the appliance become hot enough for any part to glow red.
- KEEP THE STOVE TOP TEMPERATURE BELOW 700°F (371°C). Attempts to
achieve heat output rates that exceed design specifications can result in steel
distortion and damage.
$10.00
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS UNTIL
COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
!
WARNING
MODEL 1101 & 1402 MEET THE 2015 U.S ENVIRONMENTAL PROTECTIONAGENCY (E.P.A.) CRIB WOOD EMISSION LIMITS FOR WOOD STOVES SOLD
AFTER MAY 15, 2015, 40 C.F. R. PART 60. THESE STOVES HAVE BEEN TESTED AND LISTED BY INTERTEK TESTING SERVICES TO STANDARDS:
ULC S628, UL 1482.
EPI 1101 & 1402
WOOD INSERT
1402 Illustrated

W415-1469 / A / 06.14.16
2
EN
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
TABLE OF CONTENTS
1.0 INSTALLATION OVERVIEW 3
2.0 INTRODUCTION 4
2.1 DIMENSIONS 5
2.1.1 1101 DIMENSIONS (COMPLETE WITH FLASHING) 5
2.1.2 1402 DIMENSIONS (COMPLETE WITH FLASHING) 5
2.2 SPECIFICATIONS 5
2.3 GENERAL INSTRUCTIONS 6
2.4 GENERAL INFORMATION 6
2.5 RATING PLATE INFORMATION 8
3.0 INSTALLATION PLANNING 9
3.1 MINIMUM CLEARANCE TO COMBUSTIBLES 9
4.0 INSTALLATION 10
4.1 TYPICAL EXISTING MASONRY 11
4.2 FACTORY BUILT FIREPLACE 12
4.3 LOW CLEARANCE FLUE CONNECTOR (1402) 12
5.0 FINISHING 13
5.1 BRICKS AND BAFFLES INSTALLATION 13
5.2 DOOR REMOVAL / INSTALLATION 14
5.3 DOOR HANDLE INSTALLATION 14
5.4 FLASHING INSTALLATION 15
6.0 OPERATION 16
6.1 OPTIMUM BURN METHOD 17
6.2 BLOWER 17
6.3 AIR CONTROL 18
6.4 FIRE EXTINGUISHERS / SMOKE & CARBON MONOXIDE DETECTORS 18
6.5 FUEL 19
6.6 LIGHTING A FIRE 20
6.6.1 FLASH FIRE 20
6.6.2 EXTENDED FIRE 20
6.7 SMOKING 20
7.0 MAINTENANCE 21
7.1 ASH REMOVAL PROCEDURES 21
7.2 CREOSOTE FORMATION AND REMOVAL 21
7.3 RUNAWAY OR CHIMNEY FIRE 22
7.4 CHIMNEY CLEANING 22
7.5 GLASS REPLACEMENT 23
7.6 GASKET REPLACEMENT 23
7.7 CARE OF GLASS 24
7.8 CARE OF PLATED PARTS 24
7.9 BLOWER SERVICE OR REPLACEMENT (1101) 25
7.10 BLOWER SERVICE OR REPLACEMENT (1402) 25
8.0 REPLACEMENTS 27
9.0 TROUBLESHOOTING 29
10.0 WARRANTY 30
11.0 SERVICE HISTORY 31

W415-1469 / A / 06.14.16
3
EN
Rating plate, see
“RATING PLATE
INFORMATION”
section. Blower, see “BLOWER INSTALLATION”
section.
Door, see “DOOR AND
HANDLE INSTALLATION”
section.
Flashing, see “FLASHING
INSTALLATION” section.
Draft, see “AIR CONTROL” section. Brick and Baffles, see
“BRICK AND BAFFLES
INSTALLATION” section.
1.0 INSTALLATION OVERVIEW
1402 Illustrated

W415-1469 / A / 06.14.16
4
EN
2.0 INTRODUCTION
3.17G
!
WARNING
• THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED.
• ANY CHANGES OR ALTERATIONS TO THIS APPLIANCE OR ITS CONTROLS CAN BE DANGEROUS
AND IS PROHIBITED.
• Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance
according to operating instructions could cause fire or injury.
• Before installing this appliance, contact the local building or fire authority and follow their guidelines.
• This appliance must be installed by a qualified installer.
• Risk of burns. The appliance should be turned off and cooled before servicing.
• Do not operate without fully assembling all components.
• Do not let the appliance become hot enough for any part to glow red.
• Do not install damaged, incomplete or substitute components.
• Risk of cuts and abrasions. Wear protective gloves and safety glasses during installation. Sheet metal edges
may be sharp.
• Children and adults should be alerted to the hazards of high surface temperature and should stay away to
avoid burns or clothing ignition.
• Young children should be carefully supervised when they are in the same room as the appliance. Toddlers,
young children and others may be susceptible to accidental contact burns. Aphysical barrier is recommended if
there are at risk individuals in the house. To restrict access to an appliance or stove, install an adjustable safety
gate to keep toddlers, young children and other at risk individuals out of the room and away from hot surfaces.
• Clothing or other flammable material should not be placed on or near the appliance. Objects placed in front of
the appliance must be kept a minimum of 48” (1219.2mm) away from the front face of the appliance.
• Due to high temperatures, the appliance should be located out of traffic and away from furniture and draperies.
• Ensure you have incorporated adequate safety measures to protect infants/toddlers from touching hot surfaces.
• Even after the appliance is out, the glass and/or screen will remain hot for an extended period of time.
• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children from hot
surfaces. These screens and guards must be fastened to the floor.
• Any safety screen or guard removed for servicing must be replaced prior to operating the appliance.
• Under no circumstances should this appliance be modified.
• This appliance must not be connected to a chimney flue pipe servicing a separate solid fuel burning appliance.
• Do not operate the appliance with the glass door removed, cracked or broken. Replacement of the glass should
be done by a licensed or qualified service person.
• Do not strike or slam shut the appliance glass door.
• Only doors / optional fronts certified with the unit are to be installed on the appliance.
• Keep the packaging material out of reach of children and dispose of the material in a safe manner. As with all
plastic bags, these are not toys and should be kept away from children and infants.
• If the appliance is not properly installed, a house fire may result. Do not expose the appliance to the elements
(ex. rain, etc.) and keep the appliance dry at all times. Wet insulation will produce an odour when the appliance
is used.
• The chimney must be sound and free of cracks. Clean your chimney a minimum of twice a year and as required.
• Do not start a fire with chemicals or fluids such as gasoline, engine oil, etc.
• Your appliance requires periodic maintenance and cleaning. Failure to maintain your appliance may lead to
smoke spillage in your home.
• Lower emissions generally result when burning air dried seasoned hardwoods, as compared to softwoods or too
green or freshly cut hardwoods. Burning wet unseasoned wood can cause excessive creosote accumulation.
When this is ignited it can cause a chimney fire that may result in a serious house fire.
• This appliance is designed to burn natural wood only. Do not burn trash or garbage, lawn clippings / waste,
rubber, waste petroleum products, paints or paint thinners / solvents, plastic, materials containing asbestos,
construction debris, railroad ties or treated wood, manure or animal remains, salt water driftwood or salted
materials, unseasoned wood, coal, charcoal, coloured paper, gift wrapping, cardboard, plywood or particleboard.
Burning these materials may result in release of toxic fumes or render the appliance ineffective and cause
smoke.
• Burn wood directly on the firebricks. Do not elevate grate or otherwise raise the fire.
• Do not store wood within appliance installation clearances or within the space required for re-fueling and ash
removal.
• Ashes must be disposed in a metal container with a tight lid and placed on a non-combustible surface well
away from the home or structure until completely cool.
• Ensure clearances to combustibles are maintained when building a mantel or shelves above the appliance.
Elevated temperatures on the wall or in the air above the appliance can cause melting, discolouration or
damage to decorations, a T.V. or other electronic components.
• If equipped, the catalyst must be installed and in good working order. It is recommended that the catalyst is
inspected at least 3 times per heating season.

W415-1469 / A / 06.14.16
5
EN
* As tested using test method 28
** Figures will vary considerably with individual conditions.
***Wolf Steel Ltd. estimated realistic BTU/hr with hardwood logs and regular refueling.
Specifications 1101 1402
CHAMBER (D.W.H) 13 1/2x18x12" (343mmx-
457mmx305mm) 18x18x12" (457mmx457mmx-
305mm)
CAPACITY 1.7 ft32.25 ft3
APPROX. AREA HEATED** 600-1600 ft2800-2000 ft2
MAXIMUM HEAT OUTPUT*** 55,000 BTU/Hr 70,000 BTU/Hr
HEAT OUTPUT* 11,700 - 42,200 BTU/Hr 11,400 - 41,300 BTU/Hr
DURATION LOW FIRE** 7 Hours 9 Hours
WEIGHT W/O BRICKS 185 lbs (84kg) 250 lbs (113kg)
WEIGHT OF BRICKS 110 lbs (50kg) 145 lbs (66kg)
IDEAL FUEL SIZE 12" (305mm) 16" (406mm)
MINIMUM DEPTH 16 1/2" (419mm) 14" (356mm)
MAXIMUM DEPTH 21" (533mm) 14" (356mm)
2.1 DIMENSIONS
2.1.1 1101 DIMENSIONS (COMPLETE WITH FLASHING)
2.1.2 1402 DIMENSIONS (COMPLETE WITH FLASHING)
44 1/2" 1130mm
19 3/4"
502mm
31 3/4"
806mm
21 1/2"
546mm
20 3/4"
527mm
14"
356mm
9 1/16"
231mm
24 1/2" 622mm
25 1/2" 648mm
5 1/2"
139mm
25 1/2" 648mm
21 11/16" 551mm
20 1/2"
521mm
31 3/4"
806mm
44 1/2" 1130mm
21 1/4"
540mm
16 1/2"
419mm
-
21"
533mm
28" 711mm
24" 610mm
11"
279mm
25 1/2" 648mm
21 11/16" 551mm
20 1/2"
521mm
2.2 SPECIFICATIONS

W415-1469 / A / 06.14.16
6
EN
2.3 GENERAL INSTRUCTIONS
• Before beginning your installation, consult with your local building code agency or fire officials and
insurance representative to ensure compliance.
• Non-toxic smoke will be emitted during the paint curing process, to help dissipate the smoke open a
window near the appliance.
• Remove any dust or debris off the top of the appliance before firing the appliance as the paint will
become soft as the appliance heats up and will harden as the appliance cures. To cure the paint on
your appliance burn your appliance moderately hot during the first few fires.
• To keep the gasket from sticking to the appliance as the paint is curing, periodically open the door
every 5-10 minutes.
• For the first two weeks, use generous amounts of fuel and burn the appliance with the damper wide
open for an hour as the appliance goes through a process of eliminating moisture in the steel and
firebricks. The initial heat output will be reduced while the moisture is bring drawn from the appliance
and it will be necessary to build several hot fires to remove this moisture. DURING THIS PROCESS
DO NOT OVERFIRE THE APPLIANCE. REDUCE THE AMOUNT OF AIR COMING INTO THE
APPLIANCE IF THE APPLIANCE OR CHIMNEY BECOMES RED.
4.7
ALL WIRING SHOULD BE DONE BY A QUALIFIED ELECTRICIAN AND SHALL BE IN COMPLIANCE WITH
LOCAL CODES. IN THE ABSENCE OF LOCAL CODES, USE THE CURRENT CSA22.1 CANADIAN
ELECTRIC CODE IN CANADA OR THE CURRENT NATIONAL ELECTRIC CODE ANSI/NFPA NO. 70 IN
THE UNITED STATES.
THIS APPLIANCE HAS NOT BEEN TESTED WITH ANY VENTED OR UNVENTED GAS LOG SET. TO
REDUCE RISK OF FIRE OR PREVENT INJURY, DO NOT INSTALL A VENTED OR UNVENTED GAS LOG
SET INTO THE APPLIANCE.
BURNING YOUR UNIT WITH THE ASH DUMP DOOR OPEN OR AJAR CREATES A FIRE HAZARD THAT
MAY RESULT IN DISCOLOURATION TO THE GOLD PLATED DOOR, INTERNAL DAMAGE TO THE
APPLIANCE OR A HOUSE CHIMNEY FIRE.
DO NOT CONNECT THIS APPLIANCE TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE.
THIS APPLIANCE AND IT’S COMPONENTS ARE DESIGNED TO BE INSTALLED AND OPERATED AS A
SYSTEM. ANY ALTERATION TO OR SUBSTITUTION FOR ITEMS IN THIS SYSTEM, UNLESS ALLOWED
BY THESE INSTALLATION INSTRUCTIONS, WILL VOID THE LISTING AND MAY VOID THE PRODUCT
WARRANTY. IT MAY ALSO CREATE A HAZARDOUS INSTALLATION. READ THROUGH THESE
INSTRUCTIONS THOROUGHLY BEFORE STARTING YOUR INSTALLATION AND FOLLOW THEM
CAREFULLY THROUGHOUT YOUR PROJECT.
!
WARNING
Your appliance was specifically designed to meet the 1990 U.S.A. EPAparticulate emission standards and has
been extensively tested in Canadian and American laboratories. This system is the most efficient, simple and
trouble free we know and works as follows:
Your appliance is the exact duplication of the clean-burning technology found in all Napoleon EPAcertified freestanding
stoves and in particular that of the EPA1100 and 1400. External modifications have been made to allow its installation
as a “functional insert” with a heat circulating blower system and a means of enclosing the solid fuel burning fireplace
cavity for greater heating efficiency.
2.4 GENERAL INFORMATION

W415-1469 / A / 06.14.16
7
EN
The 1101 insert must be installed into a solid fuel burning fireplace that is at least 16 1/2” (419mm) deep, 28 1/2"
(724mm) wide and 22" (559mm) high with an approved lined chimney at least 15' (4.6m) high and a hearth of 16”
(406mm).
Your 1402 insert must be installed only into a solid fuel burning fireplace that is at least 14 1/2" (368mm) deep, 26"
(660mm) wide and 22" (559mm) high with an approved lined chimney at least 15' (4.6m) high and a hearth of 16”
(406mm). This minimum recess can only be achieved if the opening height is sufficient enough to allow the connector
to fit under the non-combustible facing. The appliance and chimney must be constructed in accordance with all
national and local building code standards.
The chimney vent system used on your wood burning appliance should be designed with the least amount of
restriction possible to enable the exhaust products to easily flow through it. Chimney vent systems that are too short
or too long can also have an adverse affect on the flow of exhaust through it. The wood burning appliance and
chimney vent system also require a sufficient supply of combustion air not only to support the combustion in the
combustion chamber but to replace the exhaust leaving it so it can flow freely up through the vent system and out
into the atmosphere. It is the correct balance of combustion air and the chimney vent system that will ensure the
appliance provides you with its optimum performance.
Combustion air enters through two holes in the bottom covered by a single draft control. Air from the front
hole goes up on either side of the door into a preheating
airwash located across the top and then down the
window to feed the fire and also to ensure that the glass
remains clean. Air from this hole also feeds directly into
the combustion chamber at hearth level. Secondary air
from the rear hole travels up the back in the secondary
air housing to the manifold located at the top and shoots
out laterally to oxidize the gases below the smoke exit.
The combustion chamber is lined with high temperature
firebrick on 2 sides, the back and across the bottom,
with a layer of fibre baffles at the top to maintain a
high temperature in the combustion chamber so that
gases mixing with the preheated air from the secondary
air manifold tube are easily ignited and burned. The
appliance sides and back are shielded to direct the heat
upwards and forwards into the room.
Be sure to provide sufficient combustion air. There are
many other appliances in your home competing for air
such as: a kitchen range hood, forced air heating devices or a bathroom exhaust fan.
Expansion / contraction noises during heating up and cooling down cycles are normal and to be expected.
After extended periods of non-operation such as following a vacation or a warm weather season, the appliance
may emit a slight odour for a few hours. This is caused by dust particles on the firebox burning off. Open a
window to sufficiently ventilate the room.
CALIFORNIA PROP 65 WARNING:
Use of this product may produce smoke which
contains chemicals known to the State of
California to cause cancer, birth defects, or other
reproductive harm.
If you experience smoking problems, you may
need to open a door, a window or otherwise
provide some method of supplying combustion
air to the appliance.
HINT FOR INSTALLING PORCELAIN ENAMEL INSERTS:
Ensure the base of the porcelain side panels are protected from rubbing against the hearth when sliding your
insert into the masonry fireplace.
HOT SECONDARY AIR
FIBRE BRICKS
REFRACTORY
2 SIDES, BACK
& BOTTOM
SECONDARY AIR
PRIMARY AIR
FLUE GLASS
CERAMIC
GLASS
AIR CONTROL
COMBUSTION AIR
INTAKE
OPEN CLOSED
We suggest that our woodburning hearth products
be installed and serviced by professionals who are
certified in the U.S. by the National Fireplace
Institue® (NFI) as NFI Woodburning Specialists or
who are certified in Canada by
Wood Energy Technical
Training (WETT).

W415-1469 / A / 06.14.16
8
EN
2.5 RATING PLATE INFORMATION
SIZE 6" 11 250"
LISTEDSOLIDFUELBURNINGFIREPLACEINSERT/
ENCASTRÉ ÀCOMBUSTIBLESOLIDEHOMOLOGUÉ
TESTEDTO /TESTÉSELON :
ULCS628 /UL1482
FROM HEATER / DU POÊLE
RESIDENTIAL/ RÉSIDENTIEL
S4
16IN/PO (406 mm)
12IN/PO (305 mm)
6IN/PO (152 mm)
USINGDOUBLEWALLCONNECTOR/
UTILISATIOND’UNCONDUITDE
RACCORDEMENTÀ DOUBLE PAROI MAISON/MOBILEHOME*
S4 1400
16IN/PO (406 mm) 10IN/PO (254 mm)
6IN/PO (152 mm) 6IN/PO (152 mm)
4IN/PO (102 mm) 4IN/PO (102 mm)
EPI1402
INSTALLAND USE ONLY IN
ACCORDANCE WITH THE
MANUFACTURER’S
INSTRUCTIONS AND LOCAL
BUILDING CODES.
MINIMUM CEILING HEIGHT:
7FT (2.13m)
HEARTH EXTENSION /
COMBUSTIBLE FLOOR
PROTECTION: IF INSTALLED
ON ACOMBUSTIBLE FLOOR,
UNIT MUST BE PLACED ONA
NON-COMBUSTIBLE FLOOR
PROTECTOR EXTENDING 18”
(455mm) IN FRONTAND 8”
(205mm) TO THE SIDES AND
BACK.
CHIMNEY TYPE: MINIMUM 6”
(152mm) DIAMETER
APPROVED RESIDENTIAL
TYPE FOR MOBILE HOME USE
A CHIMNEY LISTED TO ULC
S629 IN CANADA OR UL103HT
IN THE USA.
CHIMNEY CONNECTOR: 6”
(152mm) DIAMETER MINIMUM
24 GAUGE STEEL MINIMUM
CLEARANCE FROM
HORIZONTAL CONNECTOR
AND CEILING 18” (455mm).
DO NOT OBSTRUCT SPACE
UNDER HEATER.
SPECIAL METHODS ARE
REQUIRED WHEN PASSING A
CHIMNEY THROUGH A WALL
OR CEILING. SEE INSTRUC-
TIONS AND BUILDING CODES.
DO NOT CONNECT THIS UNIT
TOA CHIMNEYFLUE SERVING
ANOTHER APPLIANCE.
FUEL: FOR USE WITH WOOD
ONLY. DO NOT USE GRATE OR
ELEVATE FIRE. BUILD WOOD
FIRE DIRECTLY ON HEARTH.
WARNING: RISK OF SMOKE
SPILLAGE. OPERATE ONLY
WITH DOOR FULLY CLOSED.
REPLACE GLASS ONLY WITH
CERAMIC GLASS.
DO NOT OVERFIRE. IF
HEATER OR CHIMNEY
CONNECTORS GLOW, YOU
ARE OVERFIRING. INSPECT
AND CLEAN CHIMNEY
FREQUENTLY. UNDER
CERTAIN CONDITIONS OF
USE CREOSOTE BUILD-UP
MAY OCCUR RAPIDLY.
OPTIONAL BLOWER KIT:
EP-62, 115V, 60HZ, 0.82AMP.
ROUTE CORD AWAY FROM
UNIT.
DANGER: RISK OF
ELECTRICAL SHOCK.
DISCONNECT POWER
BEFORE SERVICING UNIT.
INSERT: INSTALLAND USE
ONLY IN SOLID FUEL
BURNING FIREPLACES. DO
NOT REMOVE BRICKS OR
MORTAR FROM SOLID FUEL
BURNING FIREPLACE.
INSTALL WITH A POSITIVE
FLUE CONNECTORAND
FACEPLATE.
POUR INSTALLATION ET
UTILISATION CONFORM
ÉMENT AUX
INSTRUCTIONS DU FABRICANT ET
AUX CODES LOCAUX DU BÂTIMENT.
HAUTEUR DE PLAFOND MINIMAL
7PI (2,13m).
PROLONGEMENT
D’ÂTRE/PROTECTION DU
PLANCHER COMBUSTIBLE: SI
INSTALL É SUR UN PLANCHER
COMBUSTIBLE, L’APPAREIL DOIT
ÊTRE PLAC É SUR UNE PLAQUE
PROTECTRICE INCOMBUSTIBLE
S’ÉTENDANT SUR 18” (455mm)
À
L’AVANT ET 8” (205mm) À L’ARRIÈRE
ET SUR LES CÔTÉS.
TYPE DE CHIMNÉE: DIAMÈTRE
MINIMAL DE 6” (152mm)
APPROUVÉE POUR USAGE
RÉSIDENTIEL. MAISON MOBILE
EMPLOYEZ UNE CHEMINÉE
HOMOLOGUÉE ULC S629 AU
CANADA OU UL103HT AUX
ÉTATS-UNIS.
RACCORD DE CHEMINÉE:
DIAMÈTRE DE 6” (152mm) D’ACIER
DE CALIBRE 24 MINIMUM. 18”
(455mm) DE DÉGAGEMENT MINIMAL
ENTRE LE RACCORD HORIZONTAL
ET LE PLAFOND.
NE RIEN ENTREPOSER SOUS
L’APPAREIL.
DES MÉTHODES SPÉCIALES SONT
REQUISES LORSQU’UNE CHEMINÉE
TRAVERSE UN MUR OU UN
PLAFOND. VOIR LES INSTRUC-
TIONS ET LES CODES DU
BÂTIMENT.
NE PAS RACCORDER À LA
CHEMINÉE D’UN AUTRE APPAREIL.
COMBUSTIBLE: POUR USAGE AVEC
LE BOIS SEULEMENT. N’UTILISEZ
PAS DE CHENET OU NE
SURÉLEVEZ PAS LE BOIS.
PRÉPAREZ LE FEU DIRECTEMENT
SUR L’ÂTRE.
AVERTISSEMENT: RISQUE
D’ÉCHAPPEMENT DE FUMÉE. TENIR
LA PORTE FERMÉE LORSQUE LE
POÊLE FONCTIONNE. REMPLACEZ
LA VITRE PAR UNE VITRE EN
CÉRAMIQUE SEULEMENT.
NE SURCHAUFFEZ PAS L’APPAREIL.
SI L’APPAREIL OU LES RACCORDS
ROUGEOIENT, L’APPAREIL
SURCHAUFEE. INSPECTEZ ET
NETTOYEZ LACHEMINÉE
FRÉQUEMMENT. DANS CERTAINES
CONDITIONS, DES DÉPÔTS DE
CRÉOSOTE PEUVENT SE FORMER
RAPIDEMENT.
SOUFFLERIE OPTIONNELLE: EP-62,
115V, 60HZ, 0,82A. TENEZ LE
CORDON ÉLECTRIQUE LOIN DE
L’APPAREIL.
DANGER: RISQUE DE SECOUSSE
ÉLECTRIQUE. DÉBRANCHEZ AVANT
DE PROCÉDER À L’ENTRETIEN.
ENCASTRÉ: INSTALLEZ ET UTILISEZ
SEULEMENT DANS UN FOYER À
COMBUSTIBLE SOLIDE. NE RETIREZ
PAS DE MORTIER, NI BRIQUES DU
FOYER À COMBUSTIBLE SOLIDE.
INSTALLEZ AVEC UNE GAINE
CONFORME ET UNE PLAQUE DE
RECOUVREMENT.
CONTACT LOCAL BUILDING FIRE OFFICIALSABOUT RESTRICTIONS AND
INSTALLATION INSPECTION IN YOURAREA. MODEL 1400 IS SUITABLE FOR USE
IN MOBILE HOMES WHEN USED WITH OUTSIDE AIR INSTALLATION KIT (111KT).
A MINIMUM CLEARANCE OF 18” (457mm)TO THE CHIMNEY CONNECTOR MAY
BE REQUIRED BY THEAUTHORITY HAVING JURISDICTION.
RENSEIGNEZ-VOUS AUPR
ÈS DES AUTORITÉS LOCALES DU BÂTIMENT ET DU
SERVICE DES INCENDIESAU SUJET DES RESTRICTIONS ET DES INSPECTIONS
D’INSTALLATION DANS VOTRE RÉGION. LES MODÈLES 1400 PEUVENT ÊTRE
INSTALLÉS DANS UNE MAISON MOBILE SI INSTALLÉS CONJOINTEMENTAVEC UNE
PRISE D’AIR EXTÉRIEUR (111KT). UN DÉGAGEMENT MINIMAL DE 18” (457mm)
JUSQU’AU RACCORD DE LA CHEMINÉE PEUTÊTRE EXIGÉ PAR L’AUTORITÉAYANT
JURIDICTION.
8" 8"
18"
8"
ALCOVE
A"
B"
C
BACK WALL (M/A)
45°
SIDE WALL (M/L)
BACK WALL (M/A)
SIDE WALL (M/L)
B
A
IF THE STOVE IS TO BE INSTALLED ON ACOMBUSTIBLE FLOOR, IT MUST BE
PLACED ON ANAPPROVED NON-COMBUSTIBLE HEARTH PAD,THAT
EXTENDS 8” (200mm) BEYOND THE STOVE SIDESAND BACK, AND 18”
(455mm) TO THE FRONT.
SI LE PO Ê LE EST INSTALL É SUR UN PLANCHER COMBUSTIBLE, IL DOIT ÊTRE PLACÉ
SUR UNE BASE DE PROTECTION INCOMBUSTIBLE CERTIFÉE QUI DOIT DÉPASSER
LES CÔTÉS ET L’AMÉRE DU
PO Ê LE DE 8” (200mm) ET SE PROLONGER DE 18”
(455mm) SUR LE DEVANT.
MINIMUM CLEARANCE TO COMBUSTIBLE MATERIALWITH SINGLE WALL
CHIMNEY CONNECTOR / D ÉGAGEMENTS MINIMAUX AUX MATÉRIAUX
COMBUSTIBLES AVEC RACCORD DE CHEMINÉE À PAROI SIMPLE:
* MODELS 1400 AND S4 MAY BE INSTALLED INTOA MOBILE HOME IN THE
UNITED STATES ONLY.
* LE MODÈLES 1400 ET S4 NE PEUT ÊTRE INSTALLÉ QUE DANS UNE MAISON
MOBILE AUX ÉTATS-UNIS SEULEMENT.
HOTWHILE IN OPERATION. DONOT TOUCH. KEEPCHILDREN,
CLOTHINGANDFURNITUREAWAY.CONTACTMAYCAUSE
SKINBURNS.
QUAND L’APPAREIL FONCTIONNE, LASURFACE DEVIENT
CHAUDE. NE PAS TOUCHER. TENIR LES ENFANTS, LES
VÊTEMENTS ET LES MEUBLES À L’ÉCART. LE CONTACT PEUT
CAUSER DES BRÛLURES À LA PEAU.
CAUTION:
ATTENTION:
W385-2031 / A
EPA1400
1400 1400L 1402 1450 S4
WOLF STEEL LTD.
24NAPOLEON ROAD, BARRIE,ON, L4M 0G8CANADA
1400C
9700539 (WSL)
4001657 (NGZ)
4001658 (NAC)
4001659 (WUSA)
LISTED SOLID FUEL BURNING SPACE HEATER / POÊLE À COMBUSTIBLE SOLIDE
HOMOLOGUÉ TESTED TO: / TESTÉ SELON : UL1482 / ULC S627
MODEL / MODÈLE - EPA 1400
U.S. ENVIRONMENTAL PROTECTION AGENCY
U.S.ENVIRONMENTAL PROTECTIONAGENCY
Certified to comply with 2015 particulate emissions standards. Not approved for sale
Certified to complywith 2015 particulateemissions standards. Notapproved forsale
after May 15, 2020. Certifié conforme à la norme d’ émanation de particles de 2020. Non approuvé pour la vente après le 15 mai, 2020.
afterMay 15, 2020. Certifiécon
forme àlanormed’émanationdeparticles de 2020. Non approuvé pourlaventeaprès le1
5mai,2020.
40 CFR Part 60,Subpart AAA.
40 CFR Part60,Subpart AAA.
1400
12IN/PO (305 mm)
12IN/PO (305 mm)
6IN/PO (152 mm)
1400
10IN/PO (254 mm)
6IN/PO (152 mm)
4IN/PO (102 mm)
S4
16IN/PO (406 mm)
6IN/PO (152 mm)
4IN/PO (102mm)
CEILING / PLAFOND
C
DBA
FLOOR / PLANCHER
CLEARANCES TO COMBUSTIBLE CONSTRUCTION /
D ÉGAGEMENTS AUX MATÉRIAUX COMBUSTIBLES:
(MEASURED TO UNIT / ÀPARTIR DE L’APPAREIL)
A SIDE FACING / CÔTÉ 1 IN/PO (25mm) *
B TOPFACING / DESSUS 28 IN/PO (710mm)
C MANTEL /TABLETTE 28 IN/PO (710mm)
D SIDE WALL/ MUR LATÉRAL 17 IN/PO (430mm)
* CLEARANCE TO EDGE OF FLASHING / DÉGAGEMENTAU
BORD DE LA FAÇADE
3.5 Grams Per Hour / 2015 Crib Wood / 3.5 Grammes par heure / Crib Wood 2015
3.5 GramsPer Hour/2
015 Crib Wood / 3.5 Grammes par heure /CribWood2015
MANUFACTURE DATE: / DATE DE FABRICATION:
YEAR: 2016 2017 2018
MONTH: 2019 2020
24
36
5871091211
1
THIS WOOD APPLIANCE NEEDS PERIODIC INSPECTIONAND REPAIR FOR
PROPER OPERATION. CONSULT THE OWNER'S MANUALFOR FURTHER
INFORMATION. IT ISAGAINST UNITED STATES FEDERAL REGULATIONS TO
OPERATE THIS WOODAPPLIANCE IN AMANNER INCONSISTENT WITH THE
OPERATING INSTRUCTIONS IN THE OWNER'S MANUAL.
CETAPPAREILAU BOIS DOIT FAIRE L'OBJECT D'UNE INSPECTION ET D'UN
ENTRETIEN PÉRIODIQUES POUR UN FONCTIONNEMENTADÉQUAT. CONSULTEZ
LE MANUEL D'INSTRUCTIONS POUR PLUS D'INFORMATION. LES RÈGLEMENTS
FÉDÉRAUX DE L'ÉTATS-UNIS INTERDISENT D'UTILISER CETAPPAREIL DE
CHAUFFAGE D'UNE MANIÈREALLANT À L'ENCONTRE DES INSTRUCTIONS DE
FONCTIONNEMENT CONTENUES DANS CE MANUEL.
1400 SERIES RATING PLATE ILLUSTRATED
For rating plate location, see
“INSTALLATION OVERVIEW” section.
This illustration is for reference
only. Refer to the rating plate on the
appliance for accurate information.
NOTE: The rating plate must remain
with the appliance at all times. It
must not be removed.
SAMPLE
S
FROM HEATER / DU PFROM HEATER / DU
PL
RESIDENTIAL/ RÉSESIDENTIAL/ RÉ
PL
USINGDOUBLEWALLCONNECUSINGDOUBL
MP
UTILISATIOND’UNCONDUTILISATIO
MP
RACCORDEMENTÀ DOURACCORDEMEN
MP
11
ITH
FF
NEYEY
GLOW, YOUGLOW, YOU
RING. INSPECTG. INSPECT
N CHIMNEYNEY
ENTLY. UNDERER
AIN CONDITIONS OFNS OF
E CREOSOTE BUILD-UPD-UP
MAY OCCUR RAPIDLY.AY OCCUR
OPTIONAL BLOWER KIT
:OPTIONAL BLOWER KIT:
SA
EP-62, 115V, 60HZ, 0.82AMP.
EP-62, 115V, 60HZ, 0.82AMP.
ROU
TE
CO
RD AWAY FR
O
M
ROUTE CORD AWAY FROM
U
NIT.
U
D
ANGER
:DANGER:
RI
S
K
O
F
RISK OF
SA
ELE
C
TRI
C
AL
S
H
OC
K.
ELECTRICAL SHOCK.
DI
SCO
NNE
C
T P
O
WER
DISCONNECT POWER
BEFORE SERVICING UNIT.BEFORE SERVICING UNI
INSERT
:INSERT:
INSTALLAND USINSTALLAND U
S
ONLY IN SOLID FUELY IN SOLID FUEL
BURNING FIREPLACRNING FIREPLAC
OT REMOVE BROT REMOVE BR
TAR FROM
FR
NG FI
NÉENÉE
RUC-
UU
ER À LAR À LA
AUTRE APPAREIL.UTRE APPAREIL.
E:
P
OU
R
US
A
G
E AVE
C
UR USAGE AVEC
M
EULEMENT. N’UTILISEZT. N’UTILISEZ
CHENET OU NECHENET OU NE
LEVEZ PAS LE BOIS.LEVEZ PAS LE BOIS.
ÉPAREZ LE FEU DIRECTEMENTÉPAREZ LE FEU DIRECTEMENT
SUR L’ÂTRE.UR L’ÂTRE.
AVERTISSEMENT:
ERTISSEMENT:
R
IS
Q
U
ERISQUE
AM
D
’É
C
HAPPEMENT DE F
U
MÉE. TENIR
APPEMENT DE FUMÉE. TENIR
LA PORTE FERMÉE LORS
Q
UE LE
E FERMÉE LORSQUE LE
PO
ÊLE F
O
N
C
TI
O
NNE. REMPLA
C
EZ
NCTIONNE. REMPLACEZ
LA VITRE PAR
U
NE VITRE EN
UNE VITRE EN
C
ÉRAMI
Q
UE SEULEMENT.
CÉRAMIQUE SEULEMENT.
NE SURCHAUFFEZ PAS L’APPANE SURCHAUFFEZ PAS L’APPA
SI L’APPAREIL OU LES RACCSI L’APPAREIL OU LES RAC
ROUGEOIENT, L’APPAREIROUGEOIENT, L’APPAR
SURCHAUFEE. INSPECRCHAUFEE. INSPE
NETTOYEZ LA CHEMNETTOYEZ LA CHEM
FRÉQUEMMENT. DFRÉQUEMMENT.
CONDITIONS, DCONDI
CRÉOSOTECRÉ
RAPIDEMRAP
SOUFFSOUF
A
115V115
COC
XI
E
E
E
E
E
E
E
AL
CO
V
EALCOVE
A
"
A"
B"
B
E
E
E
E
E
E
E
E
E
E
E
E
SIDE WASIDE W
MPLE
STALLED ON ACOMBUSTIBLE FLOOR, IT MUST
ON A COMBUSTIBLE FLOOR, IT MUS
ED NON-COMBUSTIBLE HEARTH PAD, THATUSTIBLE HEARTH PAD, THAT
BEYOND THE STOVE SIDESAND BACK, AND 1E SIDES AND BACK,AND
ONT.
NSTALLNSTA
É SUR UN PLANCHER COMBUSTIBLE, IL DOOMBUSTIBLE, IL D
DE PROTECTION INCOMBUSTIBLE CERTIFÉE QUI DE PROTECTION INCOMBUSTIBLE CERTIFÉE QUI
T L’AMÉRE DUL’AMÉRE DU
P
OPO
Ê
LE DE 8” (200mm) ET SE PROLm) ET SE PRO
UR LE DEVANT.E DEVANT.
M CLEARANCE TO COMBUSTIBLE MATERIALANCE TO COMBUSTIBLE MATERIAL
PL
NEY CONNECTOR / DEY CONNECTOR / D
ÉGAGEMENTS MINIMAUÉGAGEMENTS MINIMAU
PL
PL
MBUSTIBLES AVEC RACCORD DE CHEMINÉE ÀMBUSTIBLES AVEC RACCORD DE CHEMINÉE À
PL
**
MODELS 140MODEL
UNITED STAUNITED ST
*
LE MOLE MO
MOBI
14
000
12IN/PO (305 mm)5 mm)
12IN/PO (305 mm
6IN/PO (152 m
14
001400
10IN/P
O
(
254 mm
)10IN/PO (254 mm)
6IN/PO (152 mm)6IN/PO (152 mm)
4IN/PO (102 mm4IN/PO (102 mm
THTH

W415-1469 / A / 06.14.16
9
EN
3.0 INSTALLATION PLANNING
Clean all ashes out of the inside of the existing fireplace opening. Make sure that the chimney and fireplace are
free of cracks, loose mortar, creosote deposits, blockage or other signs of deterioration. If necessary, have any
repair work done by a qualified professional before installing the insert.
Do NOT remove bricks or mortar from the fireplace. In case of an outside air inlet or ash dump, fill with
fiberglass insulation. Adhere to minimum clearances as illustrated.
Do NOT place any combustible materials (furniture, firewood, etc.) within 48"(1219mm) in front of 36" (914mm) at
the sides of the insert.
Combustible material must not protrude more than 1" (25mm) to the side of the insert or between the mantel
and the top of the insert.
SIDEWALL
COMBUSTIBLE MANTEL
NON-COMBUSTIBLE
FACING
AF
GE
C
B
D
NON-COMBUSTIBLE
HEARTH AND THERMAL
FLOOR PROTECTOR
NON-COMBUSTIBLE
FACING
COMBUSTIBLE MANTEL
NON-COMBUSTIBLE
HEARTH AND THERMAL
FLOOR PROTECT
OR
H
N
JK
L
I
O
P
M
MINIMUM CLEARANCES
1101 1402
ASidewall 17" (432mm) 17" (432mm)
BMantel 28" (711mm) 28" (711mm)
CTop facing 28" (711mm) 28" (711mm)
DSide facing 1" (25mm) 1" (25mm)
EHearth (front) Canada 18"
(455mm)
US 16" (406mm)
Canada 18"
(455mm)
US 16"(406mm)
FHearth (side) 8" (203mm) 8" (203mm)
GObjects in
front of insert 48" (1219mm) 48" (1219mm)
MINIMUM FIREPLACE SIZE
HWidth (rear) 24" (610mm) 25" (635mm)
IWidth (front) 28.5" (724mm) 26" (660mm)
JHeight (front) 22" (558mm) 22" (558mm)
KHeight (rear) 22" (558mm) 22" (558mm)
LDepth 16 1/2" (419mm) to
21" (533mm) 14 1/2" (368mm)
MHearth width 39" (990mm) 39" (990mm)
NFacing width 46 1/2" (1181mm) 46 1/2" (1181mm)
OFacing height 48 1/2" (1232mm) 47 3/4" (1213mm)
PMantel 48 1/2" (1232mm) 47 3/4" (1213mm)
3.1 MINIMUM CLEARANCE TO COMBUSTIBLES
HEARTH EXTENSION / FLOOR PROTECTION:
Must be non-combustible and extend in front of
the insert and 8" (203mm) on both sides with a
minimum thickness of 1/2" (13mm) and a thermal
conductivity factor (K) 0.84.

W415-1469 / A / 06.14.16
10
EN
4.0 INSTALLATION
68.3C
!
WARNING
WEAR GLOVES AND SAFETY GLASSES FOR PROTECTION.
CAREFULLY FOLLOW THE INSTRUCTIONS FOR ASSEMBLY OF THE PIPE AND OTHER PARTS NEEDED TO INSTALL THE
APPLIANCE. FAILURE TO DO SO MAY RESULT IN A FIRE, ESPECIALLY IF COMBUSTIBLES ARE TOO CLOSE TO THE
APPLIANCE OR CHIMNEY AND AIR SPACES ARE BLOCKED, PREVENTING THE FREE MOVEMENT OF COOLING AIR.
DO NOT DRAW OUTSIDE AIR FROM GARAGE SPACES. EXHAUST PRODUCTS OF GASOLINE ENGINES ARE HAZARDOUS.
DO NOT INSTALL OUTSIDE AIR DUCTS SUCH THAT THE AIR MAY BE DRAWN FROM ATTIC SPACES, BASEMENTS OR
ABOVE THE ROOFING WHERE OTHER HEATING APPLIANCES OR FANS AND CHIMNEYS EXHAUST OR UTILIZE AIR.
THESE PRECAUTIONS WILL REDUCE THE POSSIBILITY OF APPLIANCE SMOKING OR AIR FLOW REVERSAL. THE
OUTSIDE AIR INLET MUST REMAIN CLEAR OF LEAVES, DEBRIS ICE AND/OR SNOW. IT MUST BE UNRESTRICTED WHILE
APPLIANCE IS IN USE TO PREVENT ROOM AIR STARVATION WHICH CAN CAUSE SMOKE SPILLAGE AND AN INABILITY
TO MAINTAIN A FIRE. SMOKE SPILLAGE CAN ALSO SET OFF SMOKE ALARMS.
NEGATIVE PRESSURE WITHIN YOUR HOME MAY INADVERTENTLY AFFECT YOUR APPLIANCE.
TO PREVENT CONTACT WITH SAGGING OR LOOSE INSULATION, THE APPLIANCE MUST NOT BE INSTALLED
AGAINST VAPOUR BARRIERS OR EXPOSED INSULATION. LOCALIZED OVERHEATING COULD OCCUR AND A FIRE
COULD RESULT.
DO NOT USE MAKESHIFT COMPROMISES DURING INSTALLATION. DO NOT BLOCK OR RESTRICT AIR, GRILLE OR
LOUVRE OPENINGS. DO NOT ADD A HOOD.
TO PREVENT PERSONAL INJURY KEEP HAND TOOLS IN GOOD CONDITION, SHARPEN CUTTING EDGES AND
MAKE SURE TOOL HANDLES ARE SECURE.
ALWAYS MAINTAIN THE MINIMUM AIR SPACE REQUIRED TO THE ENCLOSURE TO PREVENT FIRES.
Chimney and liner must be in good condition and kept clean.

W415-1469 / A / 06.14.16
11
EN
You can install your appliance using your existing masonry chimney. To do
so, follow the guidelines below. If you are using a masonry chimney, it
is important that it be built in compliance with the specifications of the
Building Code in your region. It must normally be lined with fire clay
bricks, metal or clay tiles sealed together with fire cement. (Round
flues are the most efficient).
62.2
FOLLOW MANUFACTURER’S
INSTRUCTIONS FOR
MAXIMUM LINER EXTENSION
ABOVE CHIMNEY
FLOOR
PROTECTOR
DAMPER PLATE
REMOVED OR
FASTENED IN OPEN
POSITION
SEAL WITH NON-
COMBUSTIBLE
MATERIAL
MASONRY
CHIMNEY MUST
HAVE
STRUCTURAL
INTEGRITY LISTED
CHIMNEY
LINER
A. Remove the fireplace damper or fasten it permanently open.
* We recommend the following method of sealing off the damper area around the liner.
B. * Measure the throat of the fireplace and mark this shape on a piece of 24 gauge sheet metal (flue
cover); cut a six-inch (6 3/4" / 171mm) hole to lie directly below the fireplace flue opening.Allow two
inches of material for a flange on all sides and cut to these measurements. Bend down the flanges. If you
have never done this before, it might be a good idea to make a cardboard pattern and test it first. Fasten
this flue cover in position as high as possible with two masonry screws per side through the flanges into
the fireplace.
In Canada: Install a listed 6" (152mm) diameter flexible stainless steel liner from the top of the chimney to the
insert flue collar. Attach a stainless steel liner connector or elbow to the liner and insert onto the flue collar. Fasten
with three screws. Secure the top of the liner to the chimney cap using a liner support and chimney flashing. Cap
the top of the chimney liner assembly using an approved rain cap.
In the United States: While it is not required, it is recommended that a chimney liner be installed that is continu-
ous from the insert to the top of the chimney, particularly when the insert is installed in a basement. For this type
of connection, use the “In Canada” installation instructions above.
If a continuous liner is not installed, a “direct flue connection” must be made. The direct flue connection requires a
non-combustible connector that extends from the insert into the chimney flue liner and also that the installed flue
cover be sealed below the entry point of the connector to prevent dilution of combustion products in the chimney
flue with air from inside the house. Cap the top of the chimney using an approved rain cap.
DO NOT CONNECT THIS APPLIANCE TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE. DO
NOT CONNECT TO ANY AIR DISTRIBUTION DUCT OR SYSTEM.
!
WARNING
4.1 TYPICAL EXISTING MASONRY

W415-1469 / A / 06.14.16
12
EN
An optional low clearance flue connector is available to facilitate hook up into a tight fitting fireplace. Consult your
local dealer for details.
NOTE: This kit should be used in conjunction with a dripless connector between the flue collar and flex
liner.
A. Having ensured that the chimney is thoroughly
clean, install the flex liner. Insert a dripless con-
nector into the flue collar. Attach the flex liner to
other end of the adapter. Secure using 6 - #8
screws.
B. Coil the rope gasket around the insert flue collar
sealing the gap between the collar and the insert
top. Using 4 - #8 screws, attach the collar flange,
squeezing the gasket tightly into place.
C. Move the insert into place in the fireplace. Ma-
neuver the insert clips into the two slots located
on the insert top by reaching through the insert
flue collar from inside the insert.
D. Thread the #10 - 24 screw through the slot located on the insert top and into the threaded hole on the
flue connector, allowing the flue connector to be drawn forward into place.
NOTE: Check for a good seal between the insert top and the flue connector (by holding a flashlight up
through the insert collar, etc.).
The following installation requirements must be observed when installing solid fuel burning inserts into factory
built fireplaces.
A. The factory built fireplace must be listed per UL 127 or ULC S610.
B. Clearances to any combustible material surrounding this insert as identified must be followed. These
clearance requirements supersede any pre-existing facing material clearances listed for the factory
built fireplace.
C. Installation must include a full height listed chimney liner meeting HT requirements (2100°F/1149°C)
as required in UL 1777 (U.S.) or ULC S635 (Canada). The liner must be securely attached to the insert
flue collar and the chimney top.
D. Means must be provided to prevent room air passage to the chimney cavity of the fireplace. This may
be accomplished by sealing the damper area around the chimney liner, or sealing the appliance front.
E. The air flow within and around the appliance shall not be altered by the installation of the insert (i.e.
no louvres or cooling air inlet or outlet ports are blocked), unless specifically tested as such for each
factory built fireplace manufacturer and model line. NOTE: Using a louvered face plate (surround)
complies with this requirement.
F. Alteration of the appliance in any manner is not permitted with the following exceptions;
A. External trim pieces which do not affect the operation of the appliance may be removed providing
they can be stored on or within the fireplace for reassembly if the insert is removed.
B. The chimney damper may be removed to install the chimney liner.
G. Circulating air chambers (i.e. in a steel fireplace liner or metal heat circulator) shall not be blocked.
H. Means must be provided for removal of the insert to clean the chimney flue.
I. Inserts that project in front of the fireplace must be supplied with appropriate support means.
J. A permanent metal warning label must be attached to the back of the fireplace stating that the fireplace
must be restored to its original condition for safe use without the insert. 80.2B
4.2 FACTORY BUILT FIREPLACE
4.3 LOW CLEARANCE FLUE CONNECTOR (1402)

W415-1469 / A / 06.14.16
13
EN
5.0 FINISHING
A. Install (1101) four (A) bricks and one (C) brick or (1402) six (A) bricks along both sides of the
appliance. Before installing the back bricks, loosen the screw holding the retainer and ensure that it
has been moved forward. Install the four (A) bricks and two (D) bricks along the back wall by pivoting
the bricks up under the brick retainer. Retighten the screw. NOTE: Center (D) bricks have been
notched.
B. Carefully pivot fibre baffle (G) and (H) up onto the top of the side brick. Slide it over onto the flange
of the manifold. Ensure that the top baffles are pushed all the way to the rear of the firebox, leaving a
minimum of a 1" (25mm) gap along the front. This will allow the flue gases to escape the firebox.
C. Install the bottom (1101) four (A) bricks and two (B) bricks or (1402) six (A) bricks and two (B) bricks,
working from the back of the appliance forward.
D. Install the two (B) bricks, one (E) brick and one (F) brick along the front as illustrated.
NOTE: Do not operate if baffle and manifold shield are not in position.
5.1 BRICKS AND BAFFLES INSTALLATION
!
WARNING
OPERATION OF THE APPLIANCE WITHOUT THE BAFFLES CAN RESULT IN EXCESSIVE
TEMPERATURES THAT COULD DAMAGE THE APPLIANCE, CHIMNEY AND THE SURROUNDING
ENCLOSURE.
1101 1402
A
A
A
E
F
A
AA
A
A
A
A
A
A
AD
D
A
A
A
AI
J
A
B
B
G
H
(Fibre Baes)
W018-0078 X2
BRICK
RETAINERS
A
A
A
A
A
AA
A
A
A
A
A
AA
A
A
D
D
B
B
C
CE
F
I
J
G
F
E
NOTE: BRICKS
E & F ARE
NOTCHED AT
REAR.
H
(Fibre Baes)
W018-0077 X2
BRICK
RETAINERS
A
A
A
FIREBRICK
DIMENSIONS PART # FIREBRICK DIMENSIONS PART #
1101 1402 1101 1402
A4 1/2” x 9”
(114mm x 229mm) W090-0001 X15 W090-0001 X21 F4 1/2” x 9”
(Notched)
(114mm x 229mm)
W090-0208
X1 W090-0208 X1
B3” x 9” (Molded)
(6mm x 229mm) W090-0002 X2 W090-0002 X2 G2 1/4” x 9” (57mm x 229mm) W090-0018 X1 W090-0018 X1
C4 1/2” x 4 1/2”
(114mm x 144mm) W090-0003 X2 N/A H2 1/4” x 6 1/8” (64mm x 121mm) W090-0019 X1 W090-0019 X1
D3” x 9”
(76mm x 229mm) W090-0166 X2 W090-0166 X2 I2 1/2” x 4 1/2” (64mm x 114mm) W090-0016 X1 W090-0016 X1
E4 1/2” x 9”
(Notched)
(114mm x 229mm)
W090-0207
X1 W090-0207 X1 J1 1/2” x 4 1/2” (38mm x 114mm) W090-0017 X1 W090-0017 X1
All Firebricks are 1 1/4” (32mm) Thick

W415-1469 / A / 06.14.16
14
EN
5.2 DOOR REMOVAL / INSTALLATION
Hang the door using the hinge pins supplied.
Twist the large wire handle over the end of the handle rod. Twist the smaller wire handle over the end of the air damper
rod below the door.
1402
ILLUSTRATED
5.3 DOOR HANDLE INSTALLATION
!
WARNING
BURNING YOUR APPLIANCE WITH THE DOORS OPEN OR AJAR CREATES A FIREE HAZARD THAT
MAY RESULT IN A HOUSE AND/OR CHIMNEY FIRE.
DO NOT STRIKE OR SLAM DOOR.
NEVER REMOVE THE DOOR WHEN THE APPLIANCE IS HOT.
DOOR
HANDLE
DOOR HANDLE
LATCH LOCK
NUT
DOOR
SPACER
FRONT VIEW
NOTE: Position of
door handle latch.
98.1
NOTE: DOOR MAY NOT BE AS
ILLUSTRATED
SPRING
WASHER

W415-1469 / A / 06.14.16
15
EN
5.4 FLASHING INSTALLATION
The top flashing has been shipped flat. To install the flashing, rest the bottom against the top of the appliance
and secure using the tabs as illustrated below.
Slide the trim over the flashing.
1402 illustrated. For 1101 flashing instructions, please refer to the leaflet provided within the flashing kit.

W415-1469 / A / 06.14.16
16
EN
6.0 OPERATION
Your Napoleon EPA listed product is designed with the most advanced technology. The appliance is extremely
airtight. It has an exclusive direct outside air supply (optional kit), a safety feature designed to prevent spillage,
and to keep your house free of carbon monoxide, in case of a down drafting chimney or an internal negative
pressure.
The first fire(s) in your appliance will be difficult to get going and keep going with little amount of heat being
generated. This is a result of the moisture being driven out of the fire brick. During the break-in period (the
first 2 or 3 fires) create only small, fires using kindling; this will allow the firebrick to cure. Do not be alarmed if
small hairline cracks develop in the firebrick. This is a normal occurrence and does not pose a safety hazard.
The paint may also smell a little for the first few fires as it cures and you may wish to open a door or window to
alleviate the smell.
To start, a brisk fire is required. Place loosely crumpled paper on the floor of the appliance and cover with dry
kindling. Open the draft control fully by pulling the lever forward. Light the paper and leave the door slightly
ajar (one inch) until all kindling is burning. To maintain a brisk fire, a hot coal bed must be established and
maintained.
Slowly add larger wood (2x4 size pieces). Lay the pieces lengthwise from side to side in the hot coal bed with
a shallow trench between, so that the primary air can flow directly into this trench and ignite the fuel above.
When the fire seems to be at its peak, medium sized logs may be added. Once these logs have caught fire,
carefully close the door. (Closing the door too quickly after refuelling will reduce the firebox temperature and
result in an unsatisfactory burn.) Remember it is more efficient to burn medium sized wood, briskly, and refuel
frequently than to load the appliance with large logs that result in a smouldering, inefficient fire and dirty glass.
As soon as the door is closed, you will observe a change in the flame pattern. The flames will get smaller and
lazier because less oxygen is getting into the combustion chamber. The flames, however, are more efficient.
The flames will remain lazy but become larger again as soon as the firebricks have been heated thoroughly
and the chimney becomes heated and provides a good draft. At this point, the roaring fire that you see when
the door is opened is wastefully drawing heated room air up the chimney -- certainly not desirable. Always
operate with the door fully closed once the medium sized logs have caught fire.
!
WARNING
ALWAYS OPERATE THIS APPLIANCE WITH THE DOOR CLOSED AND LATCHED EXCEPT DURING
START UP AND RE-FUELING. ALWAYS WEAR GLOVES TO PREVENT INJURY. DO NOT LEAVE THE
FIRE UNATTENDED WHEN THE DOOR IS UNLATCHED AS UNSTABLE WOOD COULD FALL OUT OF
THE FIRE CHAMBER CREATING A FIRE HAZARD TO YOUR HOME.
NEVER LEAVE CHILDREN UNATTENDED WHEN THERE IS A FIRE BURNING IN THE APPLIANCE.
NEVER USE GASOLINE, GASOLINE-TYPE LANTERN FUEL, KEROSENE, CHARCOAL LIGHTER
FLUID, OR SIMILAR LIQUIDS TO START OR ‘FRESHEN UP’A FIRE IN THIS APPLIANCE. KEEP ALL
SUCH LIQUIDS WELL AWAY FROM THE APPLIANCE WHILE IT IS IN USE.
OBJECTS PLACED IN FRONT OF THE APPLIANCE SHOULD BE KEPT A MINIMUM OF 48”
FROM THE FRONT FACE.
ANY MODIFICATION OF THE APPLIANCE THAT HAS NOT BEEN APPROVED IN WRITING BY THE
TESTING AUTHORITY IS CONSIDERED BREACHING CSA B365 (CANADA) AND ANSI NFPA 211
(USA).
OPEN AIR CONTROL (AND DAMPER WHEN FITTED) BEFORE OPENING FIRING DOOR.
HOT WHILE IN OPERATION, KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. CONTACT MAY
CAUSE SKIN BURNS. WEAR GLOVES TO OPERATE YOUR APPLIANCE.
BURNING YOUR APPLIANCE WITH THE DOORS OPEN OR AJAR CREATES A FIRE HAZARD
THAT MAY RESULT IN A HOUSE AND OR CHIMNEY FIRE.
THIS WOOD APPLIANCE HAS A MANUFACTURER-SET MINIMUM LOW BURN RATE THAT MUST
NOT BE ALTERED. IT IS AGAINST FEDERAL REGULATIONS IN THE UNITED STATES TO ALTER THIS
SETTING OR OTHERWISE OPERATE THIS WOOD APPLIANCE IN A MANNER INCONSISTENT WITH
OPERATING INSTRUCTIONS IN THIS MANUAL.

W415-1469 / A / 06.14.16
17
EN
You can now add larger pieces of wood and operate the appliance normally. Once the appliance is entirely hot,
it will burn very efficiently with little smoke from the chimney. There will be a bed of orange coals in the firebox
and secondary flames flickering just below the top firebrick. You can safely fill the firebox with wood to the top
of the door and will get best burns if you keep the appliance pipe temperatures between 250°F (120°C ) and
450°F (270°C ). A surface thermometer placed on the front top will help regulate this.
Without an appliance thermometer, you are working blindly and have no idea of how the appliance is operating!
An appliance thermometer offers a guide to performance.
Can’t get the fire going?
Use more kindling and paper. Assuming the chimney and vent are sized correctly and there is sufficient
combustion air, the lack of sufficiently dry quantities of small kindling is the problem. Thumb size is a good
gauge for small kindling diameter.
Can’t get heat out of the appliance?
One of two things may have happened. The appliance door may have been closed prematurely and the
appliance itself has not reached optimum temperature. Reopen the door and/or draft control to re-establish a
brisk fire. The other problem may have been wet wood. The typical symptom is sizzling wood and moisture
being driven from the wood.
For optimal emissions performance and efficiency follow these simple guidelines when using your appliance:
A. Maintain a 2" (51mm) deep, hot, glowing red coal bed.
B. Burn dry seasoned wood with less than 20% moisture content and burn so that the glass door remains
clean.
C. A stove thermometer should indicate 350°F (176°C) as an average temperature.
D. Maintain a minimal trace of smoke coming from the chimney when the appliance is burning as
intended.
E. Inspect and replace all necessary components such as gaskets, manifolds, glass and other
components which may affect the overall appliance performance.
F. Ensure an adequate draft to control burn rate and temperature.
Refer to “OPERATION” and “MAINTENANCE” sections for detailed information.
6.1 OPTIMUM BURN METHOD

W415-1469 / A / 06.14.16
18
EN
Draft is the force which moves air from the firebox up through
the chimney. The amount of draft in your chimney depends on
the length and diameter of chimney, local geography, nearby
obstructions and other factors including the amount of heat
generated by the fire which can be measured by an appliance
thermometer.
Adjusting the air control regulates the temperature. The draft can
be adjusted from a low burn rate with the handle in fully, to a fast
burn rate with the handle fully out.
Inadequate draft may cause back-puffing into the room through
the appliance and chimney connector points and may cause plugging of the chimney. Too much draft may
cause an excessive temperature in the appliance, glowing red appliance parts or chimney connectors or an
uncontrollable burn which can lead to a chimney fire or permanent damage to the appliance.
Do not operate your appliance for longer than 30 minutes with the draft control on “HIGH” (fully open).
ASH LIP
91.1A
All homes with a solid fuel burning appliance should have at least one fire extinguisher in a central location,
known to all, at least one smoke detector and carbon monoxide (CO) detector in the room containing the
appliance. If the smoke detector sounds an alarm, correct the cause but do not de-activate or relocate the
smoke detector. If the carbon monoxide detector sounds an alarm, immediately vent the area, evacuate and
call your local fire department.
NOTE: Always check your smoke and CO detectors are working properly.
!
WARNING
THIS WOOD APPLIANCE HAS A MANUFACTURER-SET MINIMUM LOW BURN RATE THAT MUST
NOT BE ALTERED. IT IS AGAINST FEDERAL REGULATIONS IN THE UNITED STATES TO ALTER THIS
SETTING OR OTHERWISE OPERATE THIS WOOD APPLIANCE IN A MANNER INCONSISTENT WITH
OPERATING INSTRUCTIONS IN THIS MANUAL.
!
WARNING
Drywall dust will penetrate into the blower bearings, causing irreparable damage. Care must be taken to
prevent drywall dust from coming into contact with the blower or its compartment. Any damage resulting from
this condition is not covered by the warranty policy. Use of the blower increases the output of heat.
The 1402 inserts comes equipped with two blowers, while the 1101 has one blower. These blowers are
thermally activated and will not operate until the thermal switch reaches temperature (approximately 15-30
minutes depending on the intensity of the fire). The thermal switch for the 1402 is located on the right hand
side of the unit and the 1101 has a thermal switch located at the back on the blower access door. When first
starting the fire, the switch may be impeded by a large log or an unevenly burning fire, causing the blowers to
cycle on and off. To control this, either build your fire up evenly or turn down the blowers until the right side of
the firebox is hot.
RISK OF FIRE AND ELECTRICAL SHOCK.
TURN OFF THE ELECTRICAL POWER BEFORE SERVICING THIS APPLIANCE.
USE ONLY WOLF STEEL APPROVED OPTIONAL ACCESSORIES AND REPLACEMENT PARTS WITH
THIS APPLIANCE. USING NON-LISTED ACCESSORIES (BLOWERS, DOORS, LOUVRES, TRIMS, ETC.)
COULD RESULT IN A SAFETY HAZARD AND WILL VOID THE WARRANTY AND CERTIFICATION.
ENSURE THAT THE BLOWER’S POWER CORD IS NOT IN CONTACT WITH ANY SURFACE OF THE
APPLIANCE TO PREVENT ELECTRICAL SHOCK OR FIRE DAMAGE. DO NOT RUN THE POWER
CORD BENEATH THE APPLIANCE.
6.2 BLOWER
6.3 AIR CONTROL
6.4 FIRE EXTINGUISHERS / SMOKE & CARBON MONOXIDE DETECTORS

W415-1469 / A / 06.14.16
19
EN
6.5 FUEL
87.1D
When loading the appliance, ensure that the upper fibre baffle is situated properly. For maximum efficiency, when the appliance is
thoroughly hot, load it fully to the top of the door opening and burn at a medium low setting. The whiteness of the bricks and the
cleanliness of the glass are good indicators of your operating efficiency. Not enough heat is produced when only a few pieces of
wood are burned or the wood may not burn completely.
Fuel for the appliance must not be stored closer than the required clearances to combustibles (heat sensitive material).NEVER
STORE WOOD IN THE ASH PAN COMPARTMENT (if applicable).
NOTE: When loading the appliance, ensure to keep fuel back from the glass. If coals are to accumulate on the front lip,
there is a chance they will fall out when the door is opened.
Burn only dry, clean unpainted wood that has been seasoned. It produces more
heat and less soot or creosote. Freshly cut wood contains about 50% moisture
while after proper seasoning only about 20% of the
water remains. As wood is burned, this water boils
off consuming energy that should be used in heating.
The wetter the wood, the less heat is given off and
the more creosote is produced. Dry firewood has
cracks in the end of the grain.
Both hardwood and softwood burn equally well in this
appliance but hardwood is denser, will weigh more
per cord and burn a little slower and longer.
Firewood should be split and stacked in a manner that air can get to all parts of it and covered in early spring to be ready for
burning that fall. Dry firewood has cracks in the end grain.
Cut the wood so that it will fit horizontally, front to back, making for easier loading and less of a likelihood that the wood will roll
onto the glass.
Manufactured firelogs made by compressing 100% natural wood fibre can be safely used as fuel. Do not use manufactured
firelogs if they contain additives such as paraffin, wax, binders etc. Never burn more than two manufactured firelogs at a time.
DO’S
• Build a hot fire.
• Verify with a moisture meter that wood contains no
more than 20% moisture content.
• Several pieces of medium sized wood are better
than a few big pieces.
• Clean chimney regularly.
• Refuel frequently using medium sized wood.
• “Fine Tune” the air settings for optimum
performance.
DONT’S
• Take ash out immediately. Let it accumulate to a
depth of at least one inch. Agood ash layer provides
for a longer lasting and better burning fire.
• Burn wet wood with more than 20% moisture content.
• Close the door too soon or damper down too quickly.
• Burn one large log rather than two or three smaller,
sized logs.
• Burn at continually “low setting”, if glass door is
constantly blackened. This means the firebox
temperature is too low.
!
WARNING
THIS APPLIANCE IS DESIGNED TO BURN NATURAL WOOD ONLY. DO NOT BURN TREATED
WOOD, COAL, CHARCOAL, COLOURED PAPER, CARDBOARD, SOLVENTS OR GARBAGE. THIS
APPLIANCE HAS NOT BEEN TESTED WITH AN UNVENTED GAS LOG SET. TO REDUCE RISK OF FIRE
OR INJURY, DO NOT INSTALL AN UNVENTED GAS LOG SET INTO THE APPLIANCE.
HIGHER EFFICIENCIES AND LOWER EMISSIONS GENERALLY RESULT WHEN BURNING AIR DRIED
SEASONED HARDWOODS, AS COMPARED TO SOFTWOODS OR TOO GREEN OR FRESHLY CUT
HARDWOODS.
BURNING WET UNSEASONED WOOD CAN CAUSE EXCESSIVE CREOSOTE ACCUMULATION. WHEN
IGNITED IT CAN CAUSE A CHIMNEY FIRE THAT MAY RESULT IN A SERIOUS HOUSE FIRE.
DO NOT STORE FUEL WITHIN THE CLEARANCE TO COMBUSTIBLES, OR IN THE SPACE REQUIRED
FOR RE-FUELING AND ASH REMOVAL.

W415-1469 / A / 06.14.16
20
EN
93.1
A flash fire is a small fire burned quickly when you don't need much
heat. After your kindling has "caught", load at least 3 pieces of wood,
stacked loosely. Burn with the draft control fully open or closed only
slightly.
82.1
Load your larger pieces of wood compactly, packed close enough to prevent the flames from penetrating
it completely. After approximately 30 minutes, depending on the size of the load, close the draft control
completely making sure that the fire is not extinguished.
DO NOT OVERFIRE THE APPLIANCE!
Overfiring can occur by:
A. Burning large amounts of smaller wood pieces such as furniture scraps, skids or treated wood;
B. Vigorously burning large loads of wood with the draft control on “HIGH” (fully open) for long periods of
time (one or two hours).
C. Operating the appliance with the ash dump door blocked open or a poor gasket seal on the main door.
• Has a direct flue connection been used rather than a chimney liner continuous from cap to appliance
flue collar.
83.1A
A properly installed appliance should not smoke. If yours does, check the following:
• Has the chimney had time to get hot?
• Is the smoke passage blocked anywhere in the appliance, chimney connector or chimney?
• Is the room too airtight and the air intake not connected to the outside? Try with a window partly open.
• Is the smoke flow impeded by too long a horizontal pipe or too many bends?
• Is it a weak draft perhaps caused by a leaky chimney, a cold outside chimney, too large a diameter of a
chimney, too short a chimney, or a chimney too close to trees or a higher roof?
• Is the moisture content of the wood greater than 20%?
• Has the catalyst bypass been closed or closed prematurely?
6.6 LIGHTING A FIRE
6.6.1 FLASH FIRE
6.6.2 EXTENDED FIRE
6.7 SMOKING
