Napoleon GD15-N User manual

1
WS-415-179/01.07.00
GAS - DIRECT VENT MILLIVOLT SYSTEM
INSTALLATION AND OPERATION INSTRUCTIONS FOR
VENTED GAS FIREPLACE
NATURAL GAS MODEL GD15 - N
PROPANE GAS MODEL GD15 - P
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI / AGA / CGA METHODS
INSTALLER:THESEINSTRUCTIONSMUSTBECONVEYEDTOANDREMAINWITHTHEHOMEOWNER.
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS, CSA 2.22, AND ANSI Z21.50 RESPECTIVELY FOR VENTED GAS FIREPLACE.
WARNING: If the information in these instructions is not followed exactly, a fire or
explosionmayresultcausingpropertydamage,personalinjuryordeath.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapours and liquids in the vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Donot try to light anyappliance.
• Donot touch any electrical switch.
• Donotuseanyphone in your building.
Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
Fax:[phone] Email:[email protected]
Web:www.napoleon.on.ca
Wolf Steel Ltd., RR#1, 9 Napoleon Rd.,
Barrie, ON., Canada L4M 4Y8 [phone]
R-2000
• Immediatelycall your gas supplier from
a neighbour's phone. Follow the gas sup-
plier's instructions.
• If you cannot reach your gas supplier,
callthe fire department.
fire-parts.com

2
WS-415-179/01.07.00
TABLE of CONTENTS
PG 2-4 INTRODUCTION
Warranty
General Instructions
General Information
Care of Glass & Plated Parts
5-7 VENTING
Venting Lengths
Special Installation Example
Air Terminal Locations
8-12 INSTALLATION
Wall & Ceiling Protection
Using Flexible Vent Components
Using Rigid Vent Components
Mobile Home Installation
Gas Installation
Framing
PG13 FINISHING
Door, Louvre & Trim Removal & Installation
Log Placement
14 OPTIONAL BLOWER
15-16 OPERATION / MAINTENANCE
Operating Instructions
Maintenance
16 ADJUSTMENTS
Pilot Burner Adjustment
Venturi Adjustment
17-18 REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
Accessories
Vent Kits
Terminal Kits
19-20 TROUBLE SHOOTING GUIDE
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
WARNING
••
••
• Donotburnwoodorothermaterialsinthisfireplace.
• Adultsandespeciallychildrenshouldbealertedtothehazardsofhighsurfacetemperaturesandshouldstayaway
toavoidburnsorclothingignition.Superviseyoungchildrenwhentheyareinthesameroomasthefireplace.
• Duetohightemperatures,thefireplaceshouldbelocatedoutoftrafficandawayfromfurnitureanddraperies.
• Clothingorotherflammablematerialshouldnotbeplacedonornearthefireplace.
• Anysafetyscreenorguardremovedforservicingmustbereplacedpriortooperatingthefireplace.
• Itisimperativethatthecontrolcompartments,burnersandcirculatingbloweranditspassagewayinthefireplace
andventingsystemarekeptclean.Thefireplace anditsventingsystemshouldbeinspectedbeforeuseandat
leastannuallybyaqualifiedserviceperson.Morefrequentcleaningmayberequiredduetoexcessivelintfrom
carpeting,beddingmaterial, etc.Thefireplace areamustbe keptclearand freefromcombustiblematerials,
gasolineandotherflammablevapoursandliquids.
• Undernocircumstancesshouldthisfireplacebemodified.
• Thisfireplacemustnotbeconnectedtoachimneyfluepipeservingaseparatesolidfuelburningappliance.
• Donotusethisfireplaceifanyparthasbeenunderwater.Immediatelycallaqualifiedservicetechniciantoinspect
thefireplaceandtoreplaceanypartofthecontrolsystemandanygascontrolwhichhasbeenunderwater.
• Donotoperatethefireplacewiththeglassdoorremoved,crackedorbroken.Replacementoftheglassshouldbe
donebyalicensedorqualifiedserviceperson.Useonlywithaglassdoorcertified withthefireplace.
• Donotstrikeorslamshutthefireplaceglassdoor.
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
fire-parts.com

3
WS-415-179/01.07.00
NAPOLEON gas fireplaces are manufactured under the strict Standard of the world recognized
ISO9002 Quality Assurance Certificate.
NAPOLEON products are designedwith superior componentsand materials, assembled bytrained craftsmen who
take great pride in their work. The burner and valve assembly are leak and test-fired at a quality test station. The
complete fireplace is again thoroughly inspected by a qualified technician before packaging to ensure that you, the
customer, receives the quality product that you expect from NAPOLEON.
NAPOLEON GAS FIREPLACE PRESIDENT'S LIFETIME LIMITED WARRANTY
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your new NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON gas fireplace are warranted against defectsgas fireplace are warranted against defects
gas fireplace are warranted against defectsgas fireplace are warranted against defects
gas fireplace are warranted against defects
for as long as you own the fireplace. This covers: combustion chamber, heat exchanger, stainless steel burner,for as long as you own the fireplace. This covers: combustion chamber, heat exchanger, stainless steel burner,
for as long as you own the fireplace. This covers: combustion chamber, heat exchanger, stainless steel burner,for as long as you own the fireplace. This covers: combustion chamber, heat exchanger, stainless steel burner,
for as long as you own the fireplace. This covers: combustion chamber, heat exchanger, stainless steel burner,
phazer™ logs and embers, ceramic glass (thermal breakage only), gold plated parts against tarnishing, porcelainizedphazer™ logs and embers, ceramic glass (thermal breakage only), gold plated parts against tarnishing, porcelainized
phazer™ logs and embers, ceramic glass (thermal breakage only), gold plated parts against tarnishing, porcelainizedphazer™ logs and embers, ceramic glass (thermal breakage only), gold plated parts against tarnishing, porcelainized
phazer™ logs and embers, ceramic glass (thermal breakage only), gold plated parts against tarnishing, porcelainized
enamelled components and aluminum extrusion trims.enamelled components and aluminum extrusion trims.
enamelled components and aluminum extrusion trims.enamelled components and aluminum extrusion trims.
enamelled components and aluminum extrusion trims.
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves, thermal switch,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves, thermal switch,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves, thermal switch,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves, thermal switch,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves, thermal switch,
switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are covered andswitches, wiring, remote controls, ignitor, gasketing, and pilot assembly are covered and
switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are covered andswitches, wiring, remote controls, ignitor, gasketing, and pilot assembly are covered and
switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are covered and NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON will providewill provide
will providewill provide
will provide
replacement parts free of charge during the first year of the limited warranty.replacement parts free of charge during the first year of the limited warranty.
replacement parts free of charge during the first year of the limited warranty.replacement parts free of charge during the first year of the limited warranty.
replacement parts free of charge during the first year of the limited warranty.
Labour related to warranty repair is covered free of charge during the first year. Repair work, however, requiresLabour related to warranty repair is covered free of charge during the first year. Repair work, however, requires
Labour related to warranty repair is covered free of charge during the first year. Repair work, however, requiresLabour related to warranty repair is covered free of charge during the first year. Repair work, however, requires
Labour related to warranty repair is covered free of charge during the first year. Repair work, however, requires
the prior approval of an authorized company official. Labour costs to the account ofthe prior approval of an authorized company official. Labour costs to the account of
the prior approval of an authorized company official. Labour costs to the account ofthe prior approval of an authorized company official. Labour costs to the account of
the prior approval of an authorized company official. Labour costs to the account of NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON are based on aare based on a
are based on aare based on a
are based on a
predetermined rate schedule and any repair work must be done through an authorizedpredetermined rate schedule and any repair work must be done through an authorized
predetermined rate schedule and any repair work must be done through an authorizedpredetermined rate schedule and any repair work must be done through an authorized
predetermined rate schedule and any repair work must be done through an authorized NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON dealer.dealer.
dealer.dealer.
dealer.
CONDITIONS AND LIMITATIONS
NAPOLEON warrants its products against manufacturing defects to the original purchaser only -- i.e., the individual or legal entity (registered customer) whose name appears on the
warrantyregistration cardfiledwith NAPOLEON--provided thatthepurchase was madethroughan authorizedNAPOLEONdealer andissubject to thefollowingconditions andlimitations:
Thisfactory warrantyis nontransferable andmay notbe extended whatsoeverby anyofour representatives.
Thegas fireplacemust be installedby alicenced, authorized servicetechnician orcontractor.Installation mustbe done inaccordance withthe installation instructionsincluded withthe
productand alllocal and nationalbuilding and firecodes.
Thislimited warrantydoesnot coverdamagescaused by misuse,lack of maintenance,accident, alterations, abuseorneglect andparts installed fromothermanufacturers willnullifythis
warranty.
This limited warranty further doesnot cover anyscratches, dents, corrosion ordiscolouring caused by excessiveheat, abrasive and chemicalcleaners nor chipping onporcelain enamel
parts,mechanical breakageof PHAZER™ logsand embers,nor any ventingcomponents usedinthe installationof thefireplace.
NAPOLEONwarrants itsstainlesssteel burnersagainstdefects inworkmanshipand materialforlife, subject tothe following conditions:Duringthe first10years NAPOLEONwillreplace
or repair the defective parts at our option free of charge. From 10 years to life, NAPOLEON will provide replacement burners at 50% of the current retail price.
Inthe firstyearonly,thiswarranty extendstothe repairorreplacement ofwarranted parts whichare defective inmaterial orworkmanship providedthatthe producthas been operatedin
accordancewith theoperationinstructions andundernormal conditions.
After the first year, with respect to this President's Limited Lifetime Warranty, NAPOLEON may, at its discretion, fully dischargeall obligationswithrespect tothis warrantyby refunding
tothe originalwarranted purchaserthewholesale priceof anywarrantedbut defectivepart(s).
After thefirst year, NAPOLEON willnot beresponsible forinstallation, labouror any othercosts orexpenses relatedto thereinstallation ofawarranted part,and such expensesare not
coveredby thiswarranty.
Notwithstandingany provisionscontained in thisPresident's LimitedLifetimeWarranty,NAPOLEON’Sresponsibility underthiswarrantyis definedasabove anditshall notin any event
extendto anyincidental,consequential orindirectdamages.
This warrantydefines theobligations andliability of NAPOLEONwithrespect tothe NAPOLEONgas fireplaceand anyother warrantiesexpressedor impliedwithrespect to thisproduct,
itscomponents oraccessories areexcluded.
NAPOLEON neither assumes,nor authorizesany third partyto assume,on itsbehalf, anyother liabilitieswith respect tothe saleof this product.NAPOLEON willnot beresponsible for:
over-firing,downdrafts, spillagecausedby environmentalconditions such asrooftops, buildings, nearbytrees, hills, mountains,inadequate ventsorventilation, excessiveventingconfigu-
rations, insufficient makeup air, or negative air pressures which may or may not be caused by mechanical systems such as exhaust fans, furnaces, clothes dryers, etc.
Any damages to fireplace, combustion chamber, heat exchanger, brass trim orother component due to water, weather damage, long periods of dampness, condensation, damaging
chemicals or cleaners will not be the responsibility of NAPOLEON.
Thebill ofsale or copywill berequiredtogether witha serial numberand amodelnumber whenmaking any warrantyclaims fromyourauthorized dealer.The warranty registrationcard
mustbe returnedwithin fourteendaysto registerthe warranty.
NAPOLEONreserves theright tohave its representativeinspect anyproduct orpartthereof priorto honouringany warranty claim.
ALLSPECIFICATIONS AND DESIGNSARE SUBJECTTOCHANGEWITHOUT PRIORNOTICEDUE TOON-GOING PRODUCTIMPROVEMENTS.NAPOLEON® ISAREGISTERED
TRADEMARK OF WOLF STEEL LTD. PATENTS U.S. 5.303.693.801 - CAN. 2.073.411, 2.082.915. © WOLF STEEL LTD.
fire-parts.com

4
WS-415-179/01.07.00
FIGURE1
GENERAL INSTRUCTIONS
THIS GAS FIREPLACE SHOULD BE INSTALLED AND
SERVICED BY A QUALIFIED INSTALLER to conform with
local codes. In absence of local codes, install to the cur-
rent National Fuel Gas Code, ANSI Z223.1, or the current
CAN/CGA B149, Installation Codes. Mobile home installa-
tion must conform with local codes or in the absence of
local codes, install to the current standard for gas equipped
mobile housing CAN/CSA ZA240 MH Series in Canada or
the Manufactured Home Construction and Safety Stand-
ard, Title 24 CFR, Part 3280, or the Fire Safety Criteria for
Manufactured Home Installations, Sites, and Communi-
ties Standard ANSI/NFPA 501A in the United States.
The fireplace and its individual shutoff valve must be dis-
connected from the gas supply piping system during any
pressure testing of that system at test pressures in excess
of 1/2 psig (3.5 kPa). The fireplace must be isolated from
the gas supply piping system by closing its individual
manual shutoff valve during any pressure testing of the
gas supply piping system at test pressures equal to or
less than 1/2 psig (3.5 kPa).
When the fireplace is installed directly on carpeting, vinyl
tile or other combustible material other than wood flooring,
the fireplace shall be installed on a metal or wood panel
extending the full width and depth.
If the optional blower is installed, the receptacle / junction
box must be electrically connected and grounded in ac-
cordance with local codes. In the absence of local codes,
usethecurrent CSA C22.1 CANADIAN ELECTRICAL CODE
in Canada or the ANSI/NFPA 70-1996 NATIONAL ELEC-
TRICAL CODE in the United States.
GENERAL INFORMATION
FOR YOUR SATISFACTION, THIS FIREPLACE HAS BEEN
TEST-FIRED TO ASSURE ITS OPERATION AND QUAL-
ITY! Maximum input is 15,000 BTU/hr for natural gas and
14,000 BTU/hr propane when installed at elevations up to
4,500ft. When the fireplace is installed at elevations above
4,500ft, and in the absense of specific recommendations
from the local authority having jurisdiction, the certified high
altitude input rating shall be reduced at the rate of 4% for
each additional 1,000ft. Maximum output for natural gas is
10,500BTU/hr at an efficiency of 70% with the fan on, and
10,000 BTU/hr for propane at an efficiency of 71% with the
fan on.
Minimum inlet gas supply pressure is 4.5 inches water
column for natural gas and 11 inches water column for
propane. Maximum inlet gas pressure is 7 inches water
column for natural gas and 13 inches water column for
propane. Manifold pressure under flow conditions is 3.5
inches water column for natural gas and 10 inches water
column for propane.
This fireplace is approved for bathroom, bedroom and bed-
sitting room installations and is suitable for mobile home
installation. The natural gas model can only be installed in
a mobile home that is permanently positioned on its site
and fueled with natural gas.
CARE OF GLASS, AND PLATED
PARTS
Do not use abrasive cleaners to clean plated parts. Buff
lightly with a clean dry cloth. The glass is 3/16" tempered
glass available from your Napoleon / Wolf Steel Ltd. dealer.
DO NOT SUBSTITUTE MATERIALS. Clean the glass after
the first 10 hours of operation with a recommended gas
fireplace glass cleaner. Thereafter clean as required. DO
NOT CLEAN GLASS WHEN HOT! If the glass is not kept
clean permanent discolouration and / or blemishes may
result.
Noexternalelectricity(110voltsor24 volts)isrequired
for the gas system operation.
Expansion / contraction noises during heating up and
coolingdowncyclesare normalandaretobe expected.
Provide adequate ventilation air. Provide adequate ac-
cessibilityclearanceforservicingandoperatingthefire-
place.Neverobstructthefrontopening of thefireplace.
Purge all gas lines with the glass door of the fireplace
removed. Assure that a continuous gas flow is at the
burnerbeforeinstallingthedoor.
Under extreme vent configurations, allow several min-
utes(5-15)for theflametostabilizeafter ignition.
Six inches is the minimum bend radius allowed for the
7"diameterflexibleliner.
Objects placed in front of the fireplace must be kept a
minimum of 48" from the front face of the unit.
Use only accessories designed for and listed with the
GD15 model.
fire-parts.com

5
WS-415-179/01.07.00
VENTING LENGTHS AND AIR TERMI-
NAL LOCATIONS
Use only Napoleon or Simpson Dura-Vent Model DV-GS
venting components. Minimum and maximum vent lengths,
for both horizontal and vertical installations, and air termi-
nal locations for these installations, are set out in this
manual and must be adhered to. For Simpson Dura-Vent,
follow the installation procedure provided with the venting
components. All vent pipe connections must be sealed
when using any of these vent systems.
When using Napoleon venting components, use only ap-
proved Wolf Steel Ltd. rigid / flexible vent components with
the following termination kits: WALL TERMINAL KIT GD222,
or 1/12 TO 7/12 PITCH ROOF TERMINAL KIT GD110, 8/12
TO 12/12 ROOF TERMINAL KIT GD111, FLAT ROOF TER-
MINAL KIT GD112 or PERISCOPE KIT GD201 (forwallpen-
etration below grade). With flexible venting, in conjunction
with the various terminations, use either the 5 foot vent kit
GD220 or the 10 foot vent kit GD330. These vent kits allow
for either horizontal or vertical venting of the fireplace. FIG-
URES 2, 3, & 5.
The maximum allowable vertical vent length is 40 feet.
For optimum flame appearance and fireplace performance,
keep the vent length and number of elbows to a minimum.
The air terminal must remain unobstructed at all times.
Examine the air terminal at least once a year to verify that it
is unobstructed and undamaged.
Horizontal runs may have a 0 inch rise per foot in all
cases using Simpson Dura-Vent or Napoleon rigid or
flexibleventingcomponentswhenventingasillustrated
in Figures 2a, 2b and 2c.
For optimum performance, it is recommended that all
horizontal runs have a minimum ¼ inch rise per foot.
Whenventing,thehorizontalrunmustbekepttoamini-
mumof12inches oramaximumof24inches.Ifagreater
horizontalrunisrequired,thefireplacemusthaveamini-
mumverticalriseof24inches.Withthisconfiguration,the
horizontalruncanbebetweenaminimumof13inchesand
amaximumof96inches. FIGURE2FIGURE2
FIGURE2FIGURE2
FIGURE2cc
cc
c.....Whenterminating
vertically,theverticalriseisaminimum36inchestoamaxi-
mum40feetfromthecentreofthefireplaceflueoutlet.
FIGURES3FIGURES3
FIGURES3FIGURES3
FIGURES3a-ba-b
a-ba-b
a-b..... Themaximumhorizontalrun,whenter-
minatingvertically,is7feet.
SPECIAL INSTALLATION EXAMPLE
FIGURES2a -d
VENTING
FIGURE3a-b
fire-parts.com

6
WS-415-179/01.07.00
CC
CC
C
BB
BB
B
AA
AA
A
When a horizontal offset is
required in a through-the-
roof installation, the follow-
ing procedure for vent
length calculations must be
followed:
In an installation as shown
in FIGURE 4, lengths A and
C are known based on room
height and roof require-
ments. Any 90° and 45° el-
bows must be calculated
as 5 feet of venting each
except for the one imme-except for the one imme-
except for the one imme-except for the one imme-
except for the one imme-
diately at the fireplacediately at the fireplace
diately at the fireplacediately at the fireplace
diately at the fireplace
which is excludedwhich is excluded
which is excludedwhich is excluded
which is excluded .
The allowable horizontal run can be calculated using these
parameters. In this example, the total vertical height is 20
feet (length "A" is required to be 11 feet while length "C"
needs to be 9 feet). The maximum vertical length is 40 feet
and all runs and elbows must be subtracted from this maxi-
mum vertical length.
The maximum allowable horizontal run that "B" can be is:
40 ft. (maximum vertical run length)
-11 ft. (through the roof vertical rise "A")
-10 ft. (2 - 90° elbow)
- 9 ft. (vertical run "C")
10 ft. (maximum allowable horizontal length for "B")
The length of "B" must never be greater than the length
of "A" and "C" combined.
Minimum clearance to combustible construction
from fireplace and vent surfaces:
sides, back, bottom and top 0 inches
sides, and bottom of the vent pipe 1 inch **
**
*
top of the vent pipe 2 inches **
**
*
recessed depth 12 inches
*A clearance to combustibles of 2" at the vent pipe top
must be maintained for the first 12" of venting. The firestop
spacer GA-010-612 supplied with the unit must be used to
maintain this clearance. Thereafter a 1" clearance to
combustibles may be maintained using the firestop spacer
GD-500.96 for use with flexible venting or firestop spacer
GD-500.136 for use with rigid venting.
Forsafeandproperoperationofthefireplacefollowthe
ventinginstructionexactly.
Deviation from the minimum or the maximum vertical
ventlengthcan create difficulty in burnerstart-upand/
orcarboning.
Vent lengths that pass through unheated spaces (at-
tics, garages, crawl spaces) should be insulated with
the insulation wrapped in a protective sleeve to mini-
mizecondensation.
Provideameans forvisuallycheckingthevent connec-
tiontothefireplace after the fireplace is installed.
Donotallowtheinsidelinertobunchuponhorizontalor
vertical runs and elbows. Keep it pulled tight. A 1-1/4"
air gap between the inner and outer liner all around is
required for safe operation.
Usea firestop,ventpipeshield oratticinsulationshield
whenpenetratinginterior walls, floor orceiling.
Aterminal shallnotterminatedirectlyaboveasidewalk
or paved driveway which is located betweeen two sin-
gle family dwellings and serves both dwellings. Local
codesor regulations mayrequiredifferent clearances.
The fireplace must be installed against finished walls.
Donotinstall against a vapourbarrierorexposedinsu-
lation.
FIGURE4
fire-parts.com

7
WS-415-179/01.07.00
FIGURE5
AIRAIR
AIRAIR
AIR TERMINTERMIN
TERMINTERMIN
TERMINAL INSTAL INST
AL INSTAL INST
AL INSTALLAALLA
ALLAALLA
ALLATIONS:TIONS:
TIONS:TIONS:
TIONS:
**
**
* Recommended to prevent condensation on windows and thermal breakage
****
****
** It is recommended to use a heat shield and to maximize the distance to vinyl clad soffits.
******
******
*** The periscope GD-201 requires a minimum 18 inches clearance from an inside corner.
********
********
**** This is a recommended distance. For additional requirements check local codes.
††
††
† Three feet above if within 10 feet horizontally.
‡‡
‡‡
‡ A vent shall not terminate directly above a sidewalk or paved driveway that is located between two single family
dwellings and serves both dwellings.
††††
††††
†† Permitted only if the veranda, porch, deck or balcony is fully open on a minimum of two sides beneath the floor.
†*†*
†*†*
†* Recommenced to prevent recirculation of exhaust products. For additional requirements check local codes.
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
12INCHES
9INCHES
12INCHES*
18INCHES**
12INCHES**
0INCHES
0 INCHES***
2 INCHES***
3FEET****
3FEET****
9INCHES
3FEET†
7FEET****
12INCHES****
16INCHES
2FEET†*
Clearanceabove grade,veranda porch,deck orbalcony.
Clearancetowindows ordoorsthat open.
Clearanceto permanently closedwindows.
Verticalclearancetoventilated soffitlocatedabovetheterminal within
a horizontal distance of 2 feet from the centerline of the terminal.
Clearanceto unventilatedsoffit.
Clearancetoan outsidecorner wall.
Clearance to an inside non-combustible corner wall or protruding
non-combustible obstructions (chimney, etc.).
Clearance to an inside combustible corner wall or protruding com-
bustible obstructions ( vent chase, etc.).
Clearanceto each sideof thecenterline extended abovethe meter
/ regulator assembly.
Clearanceto a serviceregulator ventoutlet.
Clearance to a non-mechanical air supply inlet to the building or a
combustion air inlet to any other appliance.
Clearance to a mechanical air supply inlet.
Clearance above a paved sidewalk or paved driveway located on
public property unless fitted with a heat shield kit GD-301.
Clearanceunder a veranda,porch, deckor balcony.
Clearanceabove theroof.
Clearancefrom anadjacent wall includingneighbouring buildings.
CANADIAN U.S.A.
12INCHES
12INCHES
12INCHES*
18INCHES**
12INCHES**
0INCHES
0 INCHES***
2 INCHES***
3FEET
6FEET
12INCHES
6FEET
7FEET‡
12INCHES††
16INCHES
2FEET†*
INSTALLATIONS
fire-parts.com

8
WS-415-179/01.07.00
INSTALLATION
WALL AND CEILING PROTECTION
For optimum performance, it is recommended
that all horizontal runs have a minimum ¼ inch
rise per foot.
For safe and proper operation of the fireplace,
follow the venting instructions exactly.
HORIZONTAL INSTALLATION:
This application occurs when
venting through an exterior wall.
Figures 2a-d. Having deter-
mined the air terminal location,
cut and frame a hole in an exte-
rior wall with a minimum open-
ing of 9½" x 10½". (As an alter-
native to framing, a vent pipe
shield may be installed, ensur-
ing the correct clearance to
combustibles.)
1. Mark and cut the vent pipe shield to the determined
depth of the combustible wall. Apply a bead of caulking
(not supplied) to the framework or to the shield plate (in the
case of a finished wall) and secure the shield through the
opening to the interior wall. The final location of the vent
pipe shield should maintain the required clearance to the
7" vent pipe / liner. Do not fill this cavity with any type of
material. Apply a bead of caulking all around and place a
firestop spacer over the vent shield to restrict cold air from
being drawn into the room or around the fireplace. Ensure
that both spacer and shield maintain the required clear-
ance to combustibles. Once the vent pipe / liner is installed
in its final position, apply sealant between the pipe / liner
and the firestop spacer.
VERTICAL INSTALLATION:
This application occurs
when venting through a
roof.FIGURE 3. Installa-
tion kits for various roof
pitches are available
from your Napoleon
dealer. See Accesso-
ries to order the specific
kit required.
1. Determine the air terminal location, cut and frame 9½
inch openings in the ceiling and the roof to provide the
minimum clearance between the fireplace pipe / liner and
any combustible material. Try to center the exhaust pipe
location midway between two joist to prevent having to cut
them. Use a plumb bob to line up the center of the open-
ings.
Do not fill this space with any type of material.
A vent pipe shield will
prevent any materials
such as insulation,
from filling up the 1" air
space around the pipe.
Nail headers between
the joist for extra sup-
port.
2. Apply a bead of caulking (not supplied) to the frame-
work or to the Wolf Steel vent pipe shield plate or equiva-
lent (in the case of a finished ceiling), and secure over the
opening in the ceiling. A firestop must be placed on the
bottom of each framed opening in a roof or ceiling that the
venting system passes through. Apply a bead of caulking
all around and place a firestop spacer over the vent shield
to restrict cold air from being drawn into the room or around
the fireplace. Ensure that both spacer and shield maintain
the required clearance to combustibles. Once the vent
pipe / liner is installed in its final position, apply sealant
between the pipe / liner and the firestop spacer.
3. In the attic, after the pipe / liner has been installed,
slide the vent pipe collar down to cover up the open end of
the shield and tighten. This will prevent any materials, such
as insulation, from filling up the 1" air space around the
pipe.
FIGURE7
OR
FIGURE9
FIGURE10
VENT PIPE
SHIELD
VENT
PIPE
COLLAR
FIGURE8
10½"
9½"
FIGURE6
fire-parts.com

9
WS-415-179/01.07.00
VERTICAL VENTING INSTALLATION
1. Fasten the roof support to the roof using the screws
provided. The roof support is optional. The venting is to be
adequately supported using either an alternate method suit-
able to the authority having jurisdiction or the optional roof
support.
2. Stretch the 4" diameter aluminum flexible liner to the
required length. Slip the liner a minimum of 2" over the
inner sleeve of the air terminal and secure with 3 #8 screws.
Seal using a heavy bead of the high temperature sealant.
3. Repeat using 7" diameter aluminum flexible liner.
4. Thread the air terminal pipe
assembly down through the roof.
The air terminal must be located
vertically and plumb. Attach the air
terminal assembly to the roof sup-
port, ensuring that a minimum 16"
of air terminal will penetrate the
roof when fastened.
DONOT CLAMP THEFLEXIBLE
ALUMINUMLINER.
EXTENDED HORIZONTAL AND COR-
NER AIR TERMINAL INSTALLATION
A 45° corner installation must have 6 inch minimum rise
between the fireplace combustion air collar and the air ter-
minal.FIGURE 2d. In this case, vent lengths must be kept to
a maximum of 24". For longer vent lengths, a minimum
vertical rise of 24" is required. FIGURE 2c. Use the GD220
vent kit and couplers for this application.
If more than one length of liner needs to be used to reach
the fireplace, couple them together as illustrated below.
Seal the joints using the same procedure as described in
point 2. The vent system must be supported approximately
every 3 feet for both vertical and horizontal runs. Use Napo-
leon support ring assemblies, GA-GD-010.370 or equiva-
lent noncombustible strapping to maintain the minimum
clearance to combustibles as well as to prevent sagging.
Spacers are attached to the 4" inner flex liner at prede-
termined intervals to maintain a 1-1/4" air gap to the 7"
outer liner. These spacers must not be removed.
For optimum performance, it is recommended
that all horizontal runs have a minimum ¼ inch
rise per foot.
For safe and proper operation of the fireplace,
follow the venting instructions exactly.
HORIZONTAL AIR TERMINAL IN-
STALLATION
1. Stretch the 4" diameter aluminum flexible liner to the
required length taking into account the additional length
needed for the finished wall surface. Apply a heavy bead of
the high temperature sealant, supplied with the unit, to the
inside of the 4" liner approximately 1" from the end. Slip the
liner a minimum of 2" over the fireplace vent collar and
secure with 3 #8 screws.
2. Using the 7" diameter flexible aluminum liner, apply
sealant, slide a minimum of 2" over the fireplace combus-
tion air collar and secure with 3 #8 screws.
3. Insert the liners through the firestop. Position and
secure the fireplace using the nailing tabs (2 per side)
and/or secure to the floor using screws inserted through
the two ¼" diameter holes in the front left and right corners
of the base. The liners should be flush with the exterior
wall.
The air teminal plate may be recessed into the exterior
wall or siding by 1½", the depth of the return flange.
4. From outside, apply a bead of the high temperature
sealant to the inside of both liners, approximately 1" from
the end of each liner.
5. Holding the air terminal (lettering in an upright, read-
able position), insert into both liners with a twisting motion
to ensure that both the terminal sleeves engage into the
liners / sealant. Secure the terminal to the exterior wall and
make weather tight by sealing with caulking (not supplied).
FIGURE13
FIGURE11
FIGURE12
INSTALLATION
USING FLEXIBLE VENT COMPONENTS
fire-parts.com

10
WS-415-179/01.07.00
5. Remove nails
from the shingles,
above and to the sides
of the chimney. Place
the flashing over the air
terminal and slide it
underneath the sides
and upper edge of the
shingles. Ensure that
the air terminal is properly centered within the flashing,
giving a 3/4" margin all around. Fasten to the roof. Do not
nail through the lower portion of the flashing. Make weather-
tight by sealing with caulking. Where possible, cover the
sides and top edges of the flashing with roofing material.
6. Apply a heavy
bead of weatherproof
caulking 2 inches
above the flashing.
Slide the storm collar
around the air termi-
nal and down to the
caulking. Tighten to
ensure that a
weather-tight seal be-
tween the air terminal and the collar is achieved. Attach the
other storm collar centered between the air intake and the
air exhaust slots onto the air terminal. Tighten securely.
Attach the vertical rain cap.
FIGURE15
FIGURE14 Spacers are attached to the 4" inner flex liner at prede-
termined intervals to maintain a 1-1/4" air gap to the 7"
outer liner. These spacers must not be removed.
7. If more liner needs to be used to reach the fireplace,
follow the same procedure as found in EXTENDED HORI-
ZONTAL ANDCORNERAIRTERMINALINSTALLATION.The
vent system must be supported approximately every 3 feet
for both vertical and horizontal runs. Use Napoleon sup-
port ring assembly GA-GD-010.370 or equivalent noncom-
bustible strapping to maintain the minimum clearance to
combustibles as well as to prevent sagging.
FIREPLACE VENT CONNECTION
1. Install the 4 inch diameter aluminum flexible liner to
the fireplace. Secure with 3 screws and flat washers. Seal
the joint and screw holes using the high temperature seal-
ant provided.
2. Install the 7 inch diameter aluminum flexible liner to
the fireplace. Attach and seal the joints.
3. Move the fireplace into position and secure using the
nailing tabs (2 per side). The two holes in the fireplace
base located behind the lower louvre assembly may be
used to attach the fireplace to the floor using screws.
INSTALLATION
USING RIGID VENT COMPONENTS
FORSAFEANDPROPER OPERATIONOFTHEFIREPLACE,
FOLLOWTHE VENTINGINSTRUCTIONSEXACTLY.
FOROPTIMUMPERFORMANCE,ITISRECOMMENDEDTHAT
ALL HORIZONTAL RUNS HAVE A MINIMUM ¼ INCH RISE
PERFOOT.
The vent system must be supported approximately every 3
feet for both vertical and horizontal runs. Use Napoleon
vent spacers WS-615-33 or equivalent every 3 feet and
either side of each elbow to maintain the minimum 1¼"
clearance between the outer and inner vent pipes. Use
Napoleon support ring assembly GA-GD-010.370 or
equivalent noncombustible strapping to maintain the mini-
mum clearance to combustibles for both vertical and hori-
zontal runs.
HORIZONTAL AIR TERMINAL IN-
STALLATION
1. Movethefireplaceinto position. Measure the vent length
required between terminal and fireplace taking into account
the additional length needed for the finished wall surface
and any 1¼" overlaps between venting components.
2. Apply high temperature sealant to the outer edge of
the 4" inner collar of the fireplace. Attach the first vent com-
ponent and secure using 3 self tapping screws. Repeat
using 7" piping.
3. Holding the air terminal (lettering in an upright, read-
able position), insert into both vent pipes with a twisting
motion to ensure that both the terminal sleeves engage
into the vent pipes and the sealant. Secure the terminal to
the exterior wall and make weather tight by sealing with
caulking (not supplied).
THEAIRTERMINALMOUNTINGPLATE MAYBE RECESSED
INTOTHEEXTERIORWALLORSIDINGBY1½",THEDEPTH
OFTHERETURNFLANGE.
FIGURE16
fire-parts.com

11
WS-415-179/01.07.00
7.Remove nails from the shingles, above and to the
sides of the chimney. Place the flashing over the air termi-
nal and slide it underneath the sides and upper edge of
the shingles. Ensure that the air terminal is properly
centered within the flashing, giving a 3/4" margin all around.
Fasten to the roof. Do NOT nail through the lower portion of
the flashing. Make weather-tight by sealing with caulking.
Where possible, cover the sides and top edges of the flash-
ing with roofing material.
8. Apply a heavy bead of waterproof caulking 2 inches
above the flashing. Slide the storm collar around the air
terminal and down to the caulking. Tighten to ensure that a
weather-tight seal between the air terminal and the collar
is achieved. Attach the other storm collar centered between
the air intake and air exhaust slots onto the air terminal.
Tighten securely. Attach the rain cap.
9. Continue adding rigid venting sections, sealing and
securing as above. Attach a 4" collapsed telescopic pipe to
the last section of rigid piping. Secure with screws and
seal. Repeat using a 7" telescopic pipe.
10. Run a bead of high temperature sealant around the
outside of the 4" elbow. Pull the adjustable pipe a mini-
mum 2" onto the elbow. Secure with 3 screws. Repeat with
the 7" telescopic pipe.
11. In the attic, slide the vent pipe collar down to cover up
the open end of the shield and tighten. This will prevent any
materials, such as insulation, from filling up the 1" air space
around the pipe.
MOBILE HOME INSTALLATION
In Canada, mobile home installation may be vented hori-
zontally or vertically. In the United States, it may only be
installed vertically. See "Vertical Venting" for installation.
The fireplace is equipped with two 1/4" diameter holes lo-
cated in the front left and right corners of the base. For
mobile home installations, the fireplace must be fastened
in place. Use screws, inserted through the holes in the
base to secure. It is recommended that the fireplace be
secured in all installations.
Always turn off the pilot and the fuel supply at the
source, prior to moving the mobile home.
After moving the mobile home and prior to lighting the
fireplace,ensurethatthelogsarepositionedcorrectly.
GAS INSTALLATION
Proceed once the vent installation is complete.
1. Route a 3/8" N.P.T. black iron gas line, 1/2" type-L cop-
per tubing or equivalent to the fireplace.
2. For ease of accessibility, an optional remote wall switch
or millivolt thermostat may be installed in a convenient lo-
cation. Route 2-strand (solid core) millivolt wire through
the electrical hole located at the bottom left side of the unit.
The recommended maximum lead length depends on wire
size: WIRESIZE MAX. LENGTH
14gauge 100 feet
16gauge 60 feet
18gauge 40 feet
EXTENDED HORIZONTAL AND COR-
NER AIR TERMINAL INSTALLATION
A 45° corner installation
can have 0 inch rise
between the fireplace
combustion air collar
and the air terminal. In
this case, vent lengths
must be kept to a maxi-
mum of 24". For longer
vent lengths, a mini-
mum vertical rise of 24"
is required. FIGURE 2c.
1. Follow the instructions for "Horizontal Air Terminal In-
stallations".
2. Continue adding components alternating inner and
outer venting. Ensure that all 4" venting and elbows have
sufficient vent spacers attached and each component is
sealed and securely fastened to the one prior. Attach the 4"
telescopic sleeve to the vent run. Repeat using a 7" tel-
escopic sleeve. Seal and secure as before. To facilitate
completion, attach 4" and 7" couplers to the air terminal.
3.Install the air terminal. See item 3 above. Extend the 4"
telescopic sleeve; apply sealant and connect to the air ter-
minal assembly. Fasten with self tapping screws. Repeat
using the 7" telescopic sleeve.
VERTICAL VENTING INSTALLATION
1. Attach 4" and 7" elbows to
the fireplace. Apply high tem-
perature sealant and secure the
joints with 3 screws.
2. Move the fireplace into posi-
tion.
3. Fasten the roof support to the
roof using the screws
provided.The roof support is op-
tional. The venting is to be ad-
equately supported using either
an alternate method suitable to the authority having juris-
diction or the optional roof support.
4. Apply high temperature sealant to the outer edge of
the inner sleeve of the air terminal. Slip a 4" diameter cou-
pler a minimum of 2" over the sleeve and secure using 3
screws.
5.Apply high temperature sealant to the outer edge of
the of the outside sleeve of the air terminal. Slip a 7" diam-
eter coupler over the sleeve and secure as before. Trim the
7" coupler even with the 4" coupler end.
6.Thread the air terminal pipe assembly down through
the roof support and attach, ensuring that a minimum 16"
of air terminal will penetrate the roof when fastened.
FIGURE 13. If the attic space is tight, we recommend
threading the Wolf Steel vent pipe collar or equivalent
loosely onto the air terminal assembly as it is passed
through the attic. FIGURE 10. The air terminal must be
located vertically and plumb.
FIGURE18
TELESCOPIC SLEEVE
VENTING
20"
COUPLER
AIR TERMINAL
FIGURE17
fire-parts.com

12
WS-415-179/01.07.00
To install the fireplace face flush with the finished wall,
position the framework to accomodate the thickness of the
finished wall. For corner installation, allow a minimum rise
of 6 inches between the fireplace and the air terminal us-
ing Napoleon flexible venting components / 0 inch rise
when using Napoleon rigid venting or Simpson Dura-vent
components. FIGURE 2d. Pull out the four nailing tabs, at-
tached on either side of the fireplace and secure to the 2x4
framing to facilitate drywall installation and/or screw the fire-
place to the floor using screws inserted through the two ¼"
diameter holes in the front left and right corners of the base.
Attach the two leads to terminals 1 and 3 located on the
gas valve.
Donotconnecteither thewallswitch,thermostatorgas
valveto electricity (110 volts).
3. Install rigid black pipe, 1/2" type-L copper tubing or, if
local codes permit, a 3/8" flex connector and shutoff valve
to the gas line and the fireplace gas valve. Seal and tighten
securely. An adapter fitting is required between the gas
valve and the copper tubing or flex connector.
DONOTKINK FLEXIBLECONNECTOR.
4. Check for gas leaks by brushing on a soap and water
solution.
Do not use open flame.
Purge all gas lines with the glass door of the fireplace
removed. Assure that a continuous gas flow is at the
burnerbeforere-installingthedoor.
FRAMING
It is best to frame your fireplace after it is positioned and
the vent system is installed. Use 2x4's and frame to local
building codes.
P
I
P
I
3
1
2
L
O
T
N
O
L
O
T
H
I
L
O
F
F
O
FIGURE19
FIGURE20
Combustible materials must be installed flush with the
front of the fireplace but must not cover any of the black
face-area of the fireplace. Non-combustible material (brick,
stone or ceramic tile) may protrude past the face of the
fireplace.
It is not necessary to install a hearth extension with this
fireplace system. Objects placed in front of the fireplace
should be kept a minimum of 48" away from the front face.
Mantle clearance can vary according to the mantle depth.
Use the graph to help evaluate the clearance needed.
FIGURE21
FIGURE22
FIGURES23
OUTSIDE
CHASE
INSIDE
CHASE
FIGURES24
fire-parts.com

13
WS-415-179/01.07.00
FINISHING
Sit the notch at the bottom of log #2 against the left outer-
most grate post and position the top of the log into the
pocket provided on the rear log (#1).
Position the notches located in logs #3 and #4 against the
grate posts.
Place the bottom of log #5 against the right outermost grate
post and the top into the pocket provided on the center log
(#4). Tear the glowing embers into pieces and place onto
the small carry-over ports only. Care should be taken to
shred the embers into thin, small irregular pieces as only
the exposed edges of the fibre hairs will glow when ex-
posed to direct flame; however care should be taken to not
block the burner ports. Blocked ports can cause an incor-
rect flame pattern, carbon deposits and delayed ignition.
Randomly place the charcoal embers behind the grate
posts and around the logs in a realistic manner but not in
contact with the flames. Keep ember dust away from burner
ports to avoid plugging them.
FIGURES27
Place log #1 onto the burner, centering it onto the burner
tray and pushing it as close to the rear wall of the firebox as
possible.
LOG PLACEMENT
Blocked burner ports can cause an incorrect flame pattern,
carbon deposits and delayed ignition. PHAZERTM logs glow
when exposed to direct flame and provide a unique and
realistic glowing effect. Use only certified PHAZERTM logs
available from your Napoleon / Wolf Steel Ltd. dealer.
Positioning the logs improperly will cause flame im-
pingement and carboning.
Log colours may vary. During the initial use of the fireplace,
the colours will become more uniform as colour pigments
burn in during the heat activated curing process.
LOWER LOUVRES
FIGURE26
DOOR AND LOUVRE REMOVAL & IN-
STALLATION
Ensure that the door is properly clipped onto
the steel lip to prevent overheating, glass
breakage and/or discolouration of the upper
trim.
Remove the three screws securing the bottom of the door.
Lift up and out. To re-install, repeat in reverse order.
Retighten screws snugly. DO not over-tighten.
The louvre assemblies are installed as illustrated. Ensure
that the upper louvres snap into place. This will ensure
proper air flow. Optional plated door trim and the arched
door facia are available at your local Napoleon/Wolf Steel
dealer.
DOOR
STEEL LIP
UPPERLOUVRES
FIGURES25
LOUVRE SNAPPED
INTO PLACE
1
#1
2
#2
3
#3 #4
4
#5
SMALL CARRY-OVER PORTS
fire-parts.com

14
WS-415-179/01.07.00
To ease installation of blower, install the blower
before installing junction box.
INSTALLATION TO BE DONE BY A QUALIFIED IN-
STALLER and must be electrically connected and grounded
in accordance with local codes. In the absence of local
codes,use the current CSA C22.1 CANADIAN ELECTRICAL CODE in
Canada or the ANSI/NFPA 70-1996 NATIONAL ELECTRICAL CODE
in the United States.
If the fireplace was not previ-
ously equipped with a blower:
route a grounded 2-wire, 60hz
power cable to the receptacle /
junction box. At this point, it must
be strain relieved and insulated.
The three slots on the
blower mounting
bracket allow ease of
adjustment when
attaching the blower.
For a quiet running
blower, do not allow the
assembly to sit on the
firebox base.
Slide the vibration reducing pad (A) into the clip (C) and up
against the threaded stud (B) at the other end. The blower
must be able to be positioned entirely onto the pad.
Tilt the blower onto its side. Slide it past the controls and
into the clip (C). Secure to the threaded stud using the lock
washer and wing nut provided. Ensure that the blower
does not touch the fireplace base or the firebox.
SLOTS
ELONGATED
Attach the connectors from the black and white wires to the
thermodisc and secure the thermodisc bracket to the se-
curing stud at the bottom left of the unit using a lock washer
and wing nut. Ensure that the thermodisc touches the fire-
box wall.
Attach the connectors from the black and red wires to the
blower.
Attach and secure the variable speed switch using the nut
provided. Plug the harness cord into the receptacle.
The wire harness provided in this kit is a universal
harness. When installed, ensure that any excess
wire is contained, preventing it from making con-
tact with moving or hot objects.
Because the blower is thermally activated, when
turned on, it will automatically start approximately
10 minutes after lighting the fireplace and will run
forapproximately30-45minutesafterthefireplace
has been turned off. Use of the fan increases the
output of heat.
FIGURE29
red
white
black
FIGURE28
FIGURE33
RECEPTACLE /
THERMODISC
GROUND
SCREW
JUNCTION BOX
FIGURE32
FIGURE31
FIGURE30
OPTIONAL BLOWER INSTALLATION
A
B
C
fire-parts.com

15
WS-415-179/01.07.00
WHATTO DOIF YOU SMELLGAS:
• Turn off all gas to the fireplace.
• Open windows.
• Do not try to light any appliance.
• Do not touch any electric switch; do not use any phone
in your building.
• Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire de-
partment.
P
I
N
O
L
O
T
F
F
O
FLAME
ADJUSTMENT
KNOB
O
T
P
I
L
L
O
I
H
T
P
I
L
O
N
O
F
F
O
PILOT
ON/OFF
KNOB
GAS KNOB
OPERATION / MAINTENANCE
PURGE THE GAS LINE WITH THE GLASS DOOR REMOVED.
OPERATING INSTRUCTIONS
Whenlitforthefirst time, the fireplace will emit aslight
odour for a few hours. This is a normal temporary con-
dition caused by the curing of the logs and the "burn-
in" of internal paints and lubricants used in the manu-
facturing process and will not occur again.
After extended periods of non-operation such as fol-
lowing a vacation or a warm weather season, the fire-
place may emit a slight odour for a few hours. This is
causedbydust particlesintheheat exchangerburning
off. In both cases, open a window to sufficiently venti-
latetheroom.
FORYOURSAFETYREADBEFORELIGHTING:
A. This fireplace is equipped with a pilot which must be lit
by hand while following these instructions exactly.
B. Before operating smell all around the fireplace area for
gas and next to the floor because some gas is heavier
than air and will settle on the floor.
C. Use only your hand to turn the gas control knob. Never
use tools. If the knob will not turn by hand, do not try to
repair it. Call a qualified service technician. Force or
attempted repair may result in a fire or explosion.
D. Do not use this fireplace if any part has been under
water. Immediately call a qualified service technician to
inspect the fireplace and replace any part of the control
system and any gas control which has been under water.
LIGHTINGINSTRUCTIONS
WARNING: The gas valve has an interlock device which
will not allow the pilot burner to be lit until the thermocou-
ple has cooled. Allow approximately 60 seconds for the
thermocouple to cool.
When lighting and re-lighting, the gas knob cannot be
turned from pilot to off unless the knob is depressed
slightly.
1. Stop! Read the above safety information on this label.
2. Turn off all electric power to the fireplace.
3. Turn the gas knob clockwise to off.
4. Wait five (5) minutes to clear out any gas. If you smell
gas including near the floor. Stop! Follow "B" in the above
safety information on this label. If you don't smell gas go
the next step.
5. Turn gas knob counter-clockwise to pilot.
6. Depress slightly and hold gas knob while lighting the
pilot with the push button ignitor. Keep knob depressed
for one minute, then release. If pilot does not continue to
burn, repeat steps 3 through 5.
7. With pilot lit, depress and turn gas knob counter-clock-
wise to on.
8. If equipped with remote on-off switch/thermostat, main
burnermay not come on when you turnvalve to on. Remote
switch must be in the on position to ignite burner.
9. Turn on all electric power to
the fireplace.
TOTURNOFFGAS
1. Turn off all electric power to the fireplace if service is to
be performed. 2. Push in gas control knob slightly and turn clock- wise to off. Do not force.
TURNTHE CONTROLVALVE TOTHEOFF POSITIONWHEN HEATERIS NOTIN USE.
fire-parts.com

16
WS-415-179/01.07.00
VENTURI ADJUSTMENT
Natural gas models have air shutters set at
1
/
32
(.031) inch
open. Propane gas models have air shutters set at
5
/
8
(.625)
inch open. Closing the air shutter will cause a more yellow
flame, but can lead to carboning. Opening the air shutter
will cause a more blue flame, but can cause flame lifting
from the burner ports. The flame may not appear yellow
immediately; allow 15 to 30 minutes for the final flame col-
our to be established.
AIR SHUTTER ADJUSTMENT MUST ONLY BE DONE BY A
QUALIFIEDGASINSTALLER!
FLAME MUST ENVELOP
UPPER 3/8" TO 1/2" OF
THERMOCOUPLE &
THERMOPILE
PILOT
THERMOPILE BURNER
ELECTRODE
THERMO-
COUPLE
FIGURE35
P
I
P
I
PILOT SCREW
L
O
T
N
O
L
O
T
H
I
L
O
F
F
O
FIGURE34
FIGURE36
MAINTENANCE TURN OFF THE GASTURN OFF THE GAS
TURN OFF THE GASTURN OFF THE GAS
TURN OFF THE GAS
AND ELECTRICAL POWER BEFORE SERV-AND ELECTRICAL POWER BEFORE SERV-
AND ELECTRICAL POWER BEFORE SERV-AND ELECTRICAL POWER BEFORE SERV-
AND ELECTRICAL POWER BEFORE SERV-
ICING THE FIREPLACE.ICING THE FIREPLACE.
ICING THE FIREPLACE.ICING THE FIREPLACE.
ICING THE FIREPLACE.
CAUTION: Label all wires prior to disconnection when serv-
icing controls. Wiring errors can cause improper and dan-
gerous operation. Verify proper operation after servicing.
This fireplace and its venting system should be inspected
before use and at least annually by a qualified service per-
son. The fireplace area must be kept clear and free of com-
bustible materials, gasoline or other flammable vapours
and liquids. The flow of combustion and ventilation air must
not be obstructed.
1. In order to properly clean the burner and pilot assembly,
remove the logs to expose both assemblies.
2. Keep the control compartment, logs, burner, air shutter
opening and the area surrounding the logs clean by vacu-
uming or brushing, at least once a year.
3. Check to see that all burner ports are burning. Clean out
any of the ports which may not be burning or are not burn-
ing properly.
4. Check to see that the pilot flame is large enough to
engulf the thermocouple and thermopile and reaches to-
ward the burner with the third jet.
5. Replace the cleaned logs.
6. Check to see that the main burner ignites completely on
all openings when the gas knob for the burner is turned on.
A 5 to 10 second total light-up period is satisfactory. If igni-
tion takes longer, consult your Napoleon dealer / distribu-
tor.
7. Check that the gasketing on the sides, top and bottom of
the door is not broken or missing. Replace if necessary.
ADJUSTMENTS
PILOT BURNER ADJUSTMENT
Adjust the pilot screw to provide properly sized flame. Turn
in a clockwise direction to reduce the gas flow.
fire-parts.com

17
WS-415-179/01.07.00
REPLACEMENTS
ORDERING REPLACEMENT PARTS
Contact your dealer or the factory for questions concerning
prices and policies on replacement parts. Normally all parts
can be ordered through your Napoleon dealer or distributor.
When ordering replacement parts always give the follow-
ing information:
1. MODEL &SERIAL NUMBER OF FIREPLACE
2. INSTALLATION DATE OF FIREPLACE
3. PART NUMBER
4. DESCRIPTION OF PART
5. FINISH
REPLACEMENT PARTS FORFOR
FORFOR
FOR WW
WW
WARRANTYARRANTY
ARRANTYARRANTY
ARRANTY REPLAREPLA
REPLAREPLA
REPLACEMENTCEMENT
CEMENTCEMENT
CEMENT PP
PP
PARAR
ARAR
ARTSTS
TSTS
TS,,
,,
, AA
AA
A PHOPHO
PHOPHO
PHOTT
TT
TOCOPYOCOPY
OCOPYOCOPY
OCOPY OFOF
OFOF
OF
THETHE
THETHE
THE
ORIGINALORIGINAL
ORIGINALORIGINAL
ORIGINAL INVOICEINVOICE
INVOICEINVOICE
INVOICE WILLWILL
WILLWILL
WILL BEBE
BEBE
BE REQUIREDREQUIRED
REQUIREDREQUIRED
REQUIRED TOTO
TOTO
TO HONOURHONOUR
HONOURHONOUR
HONOUR THETHE
THETHE
THE CLAIMCLAIM
CLAIMCLAIM
CLAIM..
..
.
PART NO. DESCRIPTION
GD-225.061 BLACK DOOR FRAME
GD-010.525 BLACK DOOR C/WGLASS & GASKET
GD-010.502 GLASS C/WGASKET
GD-020.084 PKG OF 3 DOOR SCREWS
WS-660-5 ON/OFF TOGGLE SWITCH
GD660 STANDARD WALL SWITCH & 20FT OF WIRE
GA-010-694 BURNER
WS-010-586 PILOT TUBE C/WFITTINGS
WS-455-053 NATURAL GAS PILOT ORIFICE
WS-455-052 PROPANE GAS PILOT ORIFICE
WS-455-056 #50 NATURAL GAS MAIN ORIFICE
WS-455-057 #58 PROPANE GAS MAIN ORIFICE
WS-725-25 NATURAL GAS VALVE
WS-725-26 PROPANE GAS VALVE
WS-010-575 PROPANE GAS PILOT ASSEMBLY
WS-010-574 NATURAL GAS PILOT ASSEMBLY
WS-357-01 PIEZO IGNITER
WS-680-04 THERMOPILE
WS-680-008 THERMOCOUPLE
WS-573-008 HIGH TEMPERATURE SEALANT - 3 OZ
GL-626 LOG SET C/WGLOWING EMBERS
GD-361.16 GLOWING EMBERS
GA-GI-550.01 CHARCOAL EMBERS
GA-135.080 LOG #1
GA-135.079 LOG #2
GA-135.078 LOG #3
GA-135.077 LOG #4
GA-135.081 LOG #5
WS-385-33 NAPOLEONLOGO
GA-010-612 FIRESTOP SPACER
P
I
P
I
L
O
T
N
O
I
L
O
T
H
L
O
F
F
O
#2 - GA-135.079 #5 - GA-135.081
#1 - GA-135.080
#3 - GA-135.078
#4 - GA-135.077
fire-parts.com

18
WS-415-179/01.07.00
ACCESSORIES Use only accessories designed
for and listed with the GD15 model.
PART NO. DESCRIPTION
GD-101 WINDSHIELD KIT
GD-301 HEAT GUARD
GD-303 VINYL SIDING SHIELD
GD10.370 WALL SUPPORT ASSEMBLY
GZ550-1KT BLOWER KIT
GD230-K WEBBED ARCH DOOR FACIA - BLACK
GD2-33PB 2" TRIM KIT - POLISHED BRASS
GD4-33PB 4" - 3D TRIM KIT - POLISHED BRASS
GD200-PB TOP/BOTTOM DOOR TRIM KIT - POLISHED BRASS
WS-175-053 DURA-VENT ZERO CLEARANCE ADAPTOR
WS175-13 7" COUPLER
WS175-1 4" COUPLER
KB35 VARIABLE SPEED SWITCH
WS-500-33 V.S.S. MOUNTING PLATE FOR WALL SWITCH
WS-585-072 VENT PIPE SHIELD
WS-690-1 MILLIVOLTTHERMOSTAT
WS-660-010 REMOTE CONTROL - ADVANTAGE
WS-660-011 REMOTE CONTROL - ADVANTAGE PLUS
WS-660-2 HAND HELD WIRELESS REMOTE SWITCH
WS-585-071 VENT PIPE COLLAR
WS-573-008 HI-TEMPERATURE SEALANT 3 OZ
GA-010-612 FIRE STOP SPACER
GA-010-701 BLACK PAINTED LOWER LOUVRE ASSEMBLY
GD-010-519 POLISHED BRASS LOWER LOUVRE ASSEMBLY
GD-715.214P BLACK PAINTED UPPER LOUVRE
GD-715.213 POLISHED BRASS UPPER LOUVRE
FLEXIBLE VENT KITS
GD220 (5 FT)
PART NO. DESCRIPTION
GD-010.397 4" FLEX ALUMINUM LINER-(5 FT) C/WSPACERS
WS-410-17 7" FLEX ALUMINUM LINER -(5 FT)
GD330 (10 FT)
PART NO. DESCRIPTION
GS10.300 4" FLEX ALUMINUM LINER - (10 FT) C/WSPACERS
WS-410-0187" FLEX ALUMINUM LINER -(10 FT)
GD10.370 WALL SUPPORT ASSEMBLY
TERMINAL KITS
PERISCOPE - GD-201
WALL TERMINAL KIT - GD-222
ROOF TERMINAL KITS:
1/12 TO 7/12 PITCH - GD-110
8/12 TO 12/12 PITCH - GD-111
FLAT ROOF - GD112
PART NO. DESCRIPTION
GD-010.569 AIR TERMINAL
GD-120.036 VERTICAL CAP
WS-170-063 STORMCOLLAR
GD-010.567 ROOF SUPPORT
WS-263-054 / WS-263-055 / WS-263-056 ROOF FLASHING
GZ550-1KT
fire-parts.com

19
WS-415-179/01.07.00
Pilot will not light. - check if pilot can be lit by a match
- check that the wire is connected to the push button ignitor.
- check if the push button ignitor needs tightening.
- replace the wire if the wire insulation is broken or frayed.
- replace the electrode if the ceramic insulator is cracked or broken.
- replace the push button ignitor.
No spark at pilot burner
PILOT
THERMOPILE BURNER
ELECTRODE
THERMO-
COUPLE
- fill the tank.Out of propane gas
Spark gap is incorrect - spark gap should be 0.150" to 0.175" (5/32" to 11/64" approx.) from
the electrode tip and the pilot burner. To ensure proper electrode
location, tighten securing nut (finger tight plus 1/4 turn).
No gas at the pilot burner - check that the manual valve is turned on.
- check the pilot orifice for blockage.
- replace the valve.
- call the gas distributor.
TROUBLE SHOOTING GUIDE
TEST SOLUTIONSYMPTOM PROBLEM
Main burner goes
out; pilot stays on. Pilot flame is not large enough or not engulfing the
thermopile
- turn up pilot flame.
- replace pilot assembly.
Thermopile shorting - clean thermopile connection to the valve. Reconnect.
- replace thermopile / valve.
Remote wall switch wire is
too long; too much resist-
ance in the system.
- shorten wire to correct length or wire gauge.
Faulty thermostat or switch. - replace.
B EFORE ATTEMPTING TO TROUBLESHOOT , PURGE YOUR UNIT AND INITIALLY LIGHT THE PILOT AND THE MAIN BURNER WITH THE GLASS DOOR REMOVED .
Pilot goes out
while standing;
Main burner is in
'OFF' position.
Gas piping is undersized. - turn on all gas appliances and see if pilot flame flutters, dimin-
ishes or extinguishes, especially when main burner ignites. Moni-
tor appliance supply working pressure.
- check if supply piping size is to code. Correct all undersized
piping.
Pilot goes out when
the gas knob is re-
leased.
The gas valve has
an interlock device
whichwill notallow
the pilot burner to
be lit until the ther-
mocouple has
cooled. Allow ap-
proximately 60
seconds for the
thermocouple to
cool.
System is not correctly
purged. - purge the gas line with the glass door removed.
Out of propane gas. - fill the tank.
Pilot flame is not large
enough - turn up the pilot flame.
- gently twist the pilot head to improve the flame pattern around the
thermocouple.
Pilot flame is not engulfing
the thermocouple.
Thermocouple shorting /
faulty. - loosen and tighten thermocouple. - clean thermocouple and valve connection.
- replace thermocouple.
- replace valve.
Faultyvalve. - replace.
Pilot burning; no
gas to main
burner; gas knob
is on 'HI'; wall
switch / thermostat
is on.
Themostat or switch is de-
fective. - connect a jumper wire across the wall switch terminals; if main
burner lights, replace switch / thermostat.
Mainburnerorificeisplugged. - remove stoppage in orifice.
Faultyvalve. - replace.
Wall switch wiring is defec-
tive. - disconnect switch wires from valve & connect a jumper wire across
terminals 1 & 3; if the main burner lights, check the wires for defects
and / or replace wires.
fire-parts.com

20
WS-415-179/01.07.00
White / grey film
forms. Sulphur from fuel is being deposited on glass, logs or
combustion chamber sur-
faces.
- clean the glass with a gas fireplace glass cleaner. DO NOT CLEAN
GLASS WHEN HOT.
If deposits are not cleaned off regularly, the glass may become
permanently marked.
Flames are con-
sistently too large
or too small.
Carboning occurs.
- check pressure readings:
Inlet pressure can be checked by turning screw (A) counter-clock-
wise 2 or 3 turns and then placing pressure gauge tubing over the
test point. Gauge should read 7" (minimum 4.5") water column for
natural gas or 13" (11" minimum) water column for propane. Check
that main burner is operating on "HI".
Outlet pressure can be checked the same as above using screw (B).
Gauge should read 3.5" water column for natural gas or 10" water
column for propane. Check that main burner is operating on "HI".
AFTER TAKING PRESSURE READINGS, BE SURE TO TURN
SCREWS CLOCKWISE FIRMLY TO RESEAL. DO NOT
OVERTORQUE.
Leak test with a soap and water solution.
Unit is over-fired or under-
fired.
P
I
AB
P
I
L
O
T
N
O
L
O
T
H
I
L
O
F
F
O
TEST SOLUTION
PROBLEMSYMPTOM
Main burner goes
out; pilot goes out. Refer to "MAIN BURNER GOES OUT; PILOT STAYS ON"
Vent is blocked
Vent is re-circulating
- check for vent blockage.
- check joint seals and installation.
4" flexible vent has become
disconnected from fireplace. - re-attach to fireplace.
Remote wall
switch is in "OFF"
position; main
burner comes on
when gas knob is
turned to "ON" po-
sition.
Wall switch is mounted up-
side down - reverse.
Faultyvalve. - replace.
- replace.Remote wall switch is
grounding.
- check for ground (short); repair ground or replace wire.Remote wall switch wire is
grounding.
Main burner flame
is a blue, lazy,
transparent flame.
Blockage in vent. - remove blockage. In really cold conditions, ice buildup may occur
on the terminal and should be removed as required.
- refer to Figure 15 to ensure correct location of storm collars.
Incorrect installation.
Carbon is being
deposited on
glass, logs or com-
bustion chamber
surfaces. Flame is impinging on the
logs or combustion cham-
ber.
- check that the logs are correctly positioned.
- open air shutter to increase the primary air.
- check the input rate: check the manifold pressure and orifice size
as specified by the rating plate values.
- check that the door gasketing is not broken or missing and that the
seal is tight.
- check that both 4" and 7" vent liners are free of holes and well
sealed at all joints.
- check that minimum rise per foor has been adhered to for any
horizontal venting.
Air shutter has become
blocked - ensure air shutter opening is free of lint or other obstructions.
Exhaust fumes
smelled in room,
headaches.
Fireplace is spilling. - check door seal and relief flap seal.
- check for chimney blockage
- check that chimney is installed to building code.
- room is in negative pressure; increase fresh air supply.
Flames are very
aggressive. - tighten screws holding door in place
Door is ajar
fire-parts.com
