Napoleon GDIZC - N User manual

1
W415-0223/D/01.12.04
INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
Wolf Steel Ltd., 24 Na oleon Rd., Barrie, ON L4M 4Y8 Canada • [phone] • fax[phone]
www.na oleonfire laces.com • ask@na oleon.on.ca
GAS-FIRED DIRECT VENT INSERT
INSTALLATION AND OPERATION INSTRUCTIONS FOR:
VENTED GAS FIREPLACE HEATER
NATURAL GAS MODELS GDIZC - N
PROPANE GAS MODELS GDIZC - P
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS, CSA 2.33, ANSI Z21.88 FOR VENTED GAS FIREPLACE HEATERS
R-2000
• Immediately call your gas supplier
from a neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
WARNING: If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapours and li uids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
Installation and service must be performed by a ualified installer, service
agency or the gas supplier.
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI / CSA METHODS

2
W415-0223/D/01.12.04
Pg 2-4 INTRODUCTION
Warranty
General Instructions
General Information
Care of Glass & Plated Parts
5-7 INSTALLATION
Insert Vent Connection
Chimney Connection
Wall Switch / Thermostat
Gas Pipe Installation
7-8 FINISHING
Trim Extrusion Installation
Log Placement
Door Installation
Mantle Clearances
Logo Placement
Pg 9 OPERATION / MAINTENANCE
Operating Instructions
Maintenance
10 REPLACEMENT BLOWER
11 AD USTMENTS
Pilot Burner Adjustment
Vent Restrictions
Venturi Adjustments
12-13 REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
Terminal Kits
Accessories
14-15 TROUBLE SHOOTING GUIDE
16 SERVICE HISTORY
NOTE: changes, other than editorial, are denoted by a vertical line in the margin.
WARNING
• Thefireplaceinsertisaventedgas-firedheater.Donot burn wood or other materials in this fireplace insert.
• Adultsandespeciallychildrenshouldbe alerted to the hazards of high surface temperatures and should stay
awaytoavoid burns or clothing ignition. Supervise young childrenwhenthey are in the same room asthe
fireplaceinsert.
• Duetohightemperatures,thefireplaceinsertshouldbelocatedout of traffic and away from furniture and
draperies.
• Clothingorotherflammablematerialshouldnotbeplacedonornearthe fireplace insert.
• Anysafetyscreenorguardremovedfor servicing must be replaced prior tooperatingthefireplaceinsert.
• Itis imperative that thecontrol compartments, burners and circulating blower and its passageway in the
fireplaceinsert and venting system are kept clean. The fireplaceinsert and its ventingsystem should be
inspectedbeforeuseandatleastannuallybyaqualifiedservice person. More frequent cleaning may be
requiredduetoexcessivelintfromcarpeting,beddingmaterial,etc.Thefireplaceinsertareamustbekept
clearandfreefromcombustible materials, gasoline andotherflammablevapoursandliquids.
• Undernocircumstancesshouldthisfireplaceinsertbemodified.
• Thisfireplaceinsertmustnotbe connected to a chimney flue pipe serving a separate solidfuelburning
appliance.
• Donotusethis fireplace insertifanyparthas beenunderwater.Immediatelycalla qualified service technician
to inspect the fireplace insert and to replace any part of the control system and any gas control which has
beenunder water.
• Donotoperatethefireplaceinsertwith the glass door opened, crackedor broken. Replacement of the glass
shouldbe done by a licensed or qualified service person.
• Do not strike or slam shut the fireplace insert glass door.
• This fireplace uses and requires a fast acting thermocouple. Replace only with a fast acting thermocouple
supplied by Wolf Steel Ltd.
TABLE of CONTENTS
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE

3
W415-0223/D/01.12.04
NAPOLEON gas fireplaces are manufactured under the strict Standard of the world recognized
ISO 9001:2000 Quality Assurance Certificate.
NAPOLEON products are designed with superior components and materials, assembled by trained craftsmen
who take great pride in their work. The burner and valve assembly are leak and test-fired at a quality test
station. The complete fireplace is thoroughly inspected by a qualified technician before packaging to ensure that
you, the customer, receives the quality product that you expect from NAPOLEON.
NAPOLEON GAS FIREPLACE PRESIDENT'S LIFETIME LIMITED WARRANTY
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your new NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON gas fireplace aregas fireplace are
gas fireplace aregas fireplace are
gas fireplace are
warranted against defects for as long as you own the fireplace. This covers: combustionwarranted against defects for as long as you own the fireplace. This covers: combustion
warranted against defects for as long as you own the fireplace. This covers: combustionwarranted against defects for as long as you own the fireplace. This covers: combustion
warranted against defects for as long as you own the fireplace. This covers: combustion
chamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glasschamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass
chamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glasschamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass
chamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass
(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-
(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-
(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-
ponents and aluminum extrusion trims.ponents and aluminum extrusion trims.
ponents and aluminum extrusion trims.ponents and aluminum extrusion trims.
ponents and aluminum extrusion trims.
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly arethermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly arethermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
covered andcovered and
covered andcovered and
covered and NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON will provide replacement parts free of charge during the first yearwill provide replacement parts free of charge during the first year
will provide replacement parts free of charge during the first yearwill provide replacement parts free of charge during the first year
will provide replacement parts free of charge during the first year
of the limited warranty.of the limited warranty.
of the limited warranty.of the limited warranty.
of the limited warranty.
Labour related to warranty repair is covered free of charge during the first year. RepairLabour related to warranty repair is covered free of charge during the first year. Repair
Labour related to warranty repair is covered free of charge during the first year. RepairLabour related to warranty repair is covered free of charge during the first year. Repair
Labour related to warranty repair is covered free of charge during the first year. Repair
work, however, requires the prior approval of an authorized company official. Labour costswork, however, requires the prior approval of an authorized company official. Labour costs
work, however, requires the prior approval of an authorized company official. Labour costswork, however, requires the prior approval of an authorized company official. Labour costs
work, however, requires the prior approval of an authorized company official. Labour costs
to the account ofto the account of
to the account ofto the account of
to the account of NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON are based on a predetermined rate schedule and any repairare based on a predetermined rate schedule and any repair
are based on a predetermined rate schedule and any repairare based on a predetermined rate schedule and any repair
are based on a predetermined rate schedule and any repair
work must be done through an authorizedwork must be done through an authorized
work must be done through an authorizedwork must be done through an authorized
work must be done through an authorized NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON dealer.dealer.
dealer.dealer.
dealer.
CONDITIONS AND LIMITATIONS
NAPOLEONwarrants itsproductsagainst manufacturingdefects to the original purchaser only -- i.e.,the individual or legal entity (registered customer) whosename appears on the
warrantyregistrationcard filedwith NAPOLEON--provided that thepurchase was madethrough an authorized NAPOLEON dealerand issubjectto the followingconditions and limitations:
Thisfactory warranty is nontransferable andmay not be extended whatsoever by any ofour representatives.
Thegas fireplacemust beinstalled bya licenced, authorized service technician or contractor. Installation must be done in accordancewith theinstallation instructionsincluded withthe
productand all local and national building andfire codes.
Thislimited warranty does not coverdamages causedby misuse, lack of maintenance,accident, alterations, abuse or neglectand parts installed from other manufacturers willnullify
this warranty.
Thislimited warranty furtherdoes notcover any scratches,dents, corrosionor discolouringcaused by excessiveheat, abrasiveand chemical cleaners nor chippingon porcelainenamel
parts,mechanical breakage of PHAZER™ logsand embers, norany venting components used inthe installation of the fireplace.
NAPOLEONwarrants itsstainless steel burnersagainst defects inworkmanship andmaterialfor life,subject to thefollowing conditions: Duringthe first10years NAPOLEONwill replace
or repair the defective parts at our option free of charge. From 10 years to life, NAPOLEON will provide replacement burners at 50% of the current retail price.
Inthe firstyear only, this warranty extends to the repairor replacement of warranted partswhich are defective in material or workmanship providedthat theproduct has been operated
inaccordance with the operation instructionsand under normal conditions.
Afterthe first year,withrespect to this President's Limited LifetimeWarranty,NAPOLEON may, atitsdiscretion, fully discharge allobligations withrespect tothis warrantyby refunding
tothe original warrantedpurchaser the wholesale price of any warranted butdefective part(s).
Afterthe firstyear, NAPOLEON will not be responsible for installation, labour or any othercosts orexpenses relatedto thereinstallation ofa warrantedpart, andsuch expensesare not
coveredby this warranty.
Notwithstandinganyprovisions containedinthis President's Limited Lifetime Warranty, NAPOLEON’S responsibilityunder thiswarranty isdefined as aboveand itshall notin any event
extendto anyincidental, consequentialor indirectdamages.
Thiswarranty defines theobligations andliabilityof NAPOLEON withrespect to theNAPOLEON gasfireplace and anyother warrantiesexpressedor impliedwith respect tothis product,
itscomponents or accessoriesare excluded.
NAPOLEON neither assumes, norauthorizes anythird party toassume, onits behalf, anyother liabilitieswith respect tothe saleofthis product. NAPOLEONwill not be responsible
for:over-firing, downdrafts, spillage caused by environmental conditions such as rooftops, buildings, nearby trees, hills, mountains, inadequate vents or ventilation, excessive venting
configurations,insufficient makeup air, or negative air pressures which may ormay not be caused by mechanical systems such as exhaust fans, furnaces, clothesdryers, etc.
Anydamages tofireplace, combustion chamber, heat exchanger,brass trimor other component due to water, weather damage,long periodsof dampness, condensation, damaging
chemicals or cleaners will not be the responsibility of NAPOLEON.
The bill of sale or copy will be required together with a serial number and a model number when making any warranty claims from your authorized dealer. The warranty registration
cardmust be returnedwithin fourteen daysto register thewarranty.
NAPOLEONreserves the rightto have itsrepresentative inspect anyproduct or partthereof prior tohonouring any warrantyclaim.
ALL SPECIFICATIONSAND DESIGNS ARE SUBJECTTO CHANGE WITHOUT PRIOR NOTICE DUETO ON-GOING PRODUCT IMPROVEMENTS. NAPOLEON® ISAREGISTERED
TRADEMARKOFWOLFSTEELLTD. PATENTS U.S. 5.303.693.801-CAN. 2.073.411,2.082.915&DES417,497(12.07.1999).© WOLF STEELLTD.

4
W415-0223/D/01.12.04
FOR YOUR SATISFACTION, THIS FIREPLACE INSERT
HAS BEEN TEST-FIRED TO ASSURE ITS OPERATION
AND QUALITY!
Minimum inlet gas supply pressure is 4.5 inches water
column for natural gas and 11 inches water column for
propane. Maximum inlet gas pressure is 7 inches water
column for natural gas and 13 inches water column for
propane. Manifold pressure under flow conditions is 3.5
inches water column for natural gas and 10 inches water
column for propane. When the fireplace is installed at el-
evations above 4,500ft, and in the absence of specific rec-
ommendations from the local authority having jurisdiction,
the certified high altitude input rating shall be reduced at
the rate of 4% for each additional 1,000ft.
Expansion / contraction noises during heating up and cool-
ing down cycles are normal and to be expected.
Maximum input is 24,000 BTU/hr for natural gas and pro-
pane. Maximum output for natural gas and propane is
20,400 BTU/hr at an efficiency of 85% with the fan on. Maxi-
mum A.F.U.E. (annual fuel utilization efficiency) rating is
79 % for natural gas and propane. This fireplace insert is
not approved for closet or recessed installations. It is ap-
proved for bathroom, bedroom and bed-sitting room in-
stallations and is suitable for mobile homes. The natural
gas model is suitable for installation in a mobile home that
is permanently positioned on its site and fuelled with natu-
ral gas.
This insert must be recessed into a vented noncombus-
tible wood-burning fireplace (prefabricated or masonry)
only. The minimum fireplace opening size in which the
heater is to be installed is:
HEIGHT 14½ inches
WIDTH 25 inches
DEPTH 11 inches
The minimum allowable chimney flue size is 6" round.
The minimum distance, from the bottom of a combustible
mantle projecting 3" maximum from the wall to the top of
the aluminium trim, is 3".
Do not use abrasive cleaners to clean these parts. Buff
lightly with a clean dry cloth.
The glass is 3/16" ceramic glass available from your Na-
poleon / Wolf Steel Ltd. dealer. DO NOT SUBSTITUTE MA-
TERIALS. Clean the glass after the first 10 hours of opera-
tion with a recommended gas fireplace glass cleaner.
Thereafter clean as required. DO NOT CLEAN GLASS
WHEN HOT! If the glass is not kept clean permanent
discolouration and / or blemishes may result.
THIS GAS FIREPLACE INSERT SHOULD BE INSTALLED
AND SERVICED BY A QUALIFIED INSTALLER to con-
form with local codes. Installation practices vary from re-
gion to region and it is important to know the specifics that
apply to your area,
for example: in Massachusetts State:
• The fireplace damper must be removed or welded in the open
position prior to installation of a fireplace insert or gas log.
• The appliance off valve must be a “T” handle gas cock.
• The flexible connector must not be longer than 36 inches.
• The appliance is not approved for installation in a bedroom or
bathroom unless the unit is a direct vent sealed combustion
product.
• WARNING: This product must be installed by a licensed plumber
or gas fitter when installed within the commonwealth of
Massachusetts.
In absence of local codes, install to the current CAN1-
B149 Installation Code in Canada or to the National Fuel
Gas Code, ANSI Z223.1, and NFPA 54 in the United
States. Mobile home installation must conform with local
codes. In the absence of local codes, install to the current
standard for gas equipped mobile housing CAN/CSA
Z240 MH Series in Canada or the manufactured home
construction and safety standard, Title 24 CFR, part 3280,
or the Fire Safety Criteria for manufactured home installa-
tions, Sites and Community Standard ANSI/NFPA 501A in
the United States.
Purge all gas lines with the glass door of the fireplace
insert opened. Assure that a continuous gas flow is at
the burner before closing the door.
Under extreme vent configurations, allow several min-
utes (5-15 for the flame to stabilize after ignition.
The fireplace insert and its individual shutoff valve must be
disconnected from the gas supply piping system during
any pressure testing of that system at test pressures in
excess of 1/2 psig (3.5 kPa). The fireplace insert must be
isolated from the gas supply piping system by closing its
individual manual shutoff valve during any pressure test-
ing of the gas supply piping system at test pressures
equal to or less than 1/2 psig (3.5 kPa).
A 1/8 inch NPT plug, accessible for test gauge connection,
must be installed immediately upstream of the gas supply
connection to the fireplace insert.
The fireplace insert must be electrically connected and
grounded in accordance with local codes. In the absence
of local codes, use the current CSA C22.1 CANADIAN
ELECTRICALCODE in Canada or theANSI/NFPA70-1990
NATIONAL ELECTRICAL CODE in the United States. The
blower power cord must be connected into a properly
grounded receptacle. The grounding prong must not be
removed from the cord plug.
GENERAL INSTRUCTIONS GENERAL INFORMATION
CARE OF GLASS, AND PLATED PARTS

5
W415-0223/D/01.12.04
Provide adequate ventilation air.
Provide adequate accessibility clearance for
servicing and operating the fireplace insert.
Never obstruct the front opening of the fire-
place insert.
Objects placed in front of the fireplace must
be kept a minimum of 48 away from the
front face of the unit.
FIGURES1a-c
Clean out ashes from the inside of the wood-burning fire-
place. Make sure that the chimney and wood-burning fire-
place are in a clean and sound condition and constructed
of non-combustible materials. If necessary have any re-
pair work done by a qualified person before installing the
insert. Remove the existing fireplace damper or lock into
an open position.
Using screws, attach the fireplace warning tag
(W385-0199) to the inside of the firebox of the fireplace into
which the insert is being installed.
The sheet-metal parts of the fireplace, in which the gas
fireplace insert is to be installed, must not be cut.
If the wood-burning factory-built fireplace has no gas
access hole(s provided, an access hole of 1½ inch or
less may be drilled through the lower sides or bottom
of the fireplace in a proper workman like manner. This
access hole must be plugged with non-combustible in-
sulation after the gas supply line has been installed.
Ensure that existing chimney cleanouts fit properly.
The refractory, glass doors, screen rails, screen mesh
and log grates may be removed from the fireplace be-
fore installing the gas fireplace insert.
Smoke shelves, shields and baffles may be removed if
attached by mechanical fasteners.
The ventilation openings in the fireplace may be ob-
structed by the backer plates, aluminium trim etc. but
these parts are not to be applied so as to have an air-
tight seal.
WARNING: THIS FIREPLACE HAS BEEN CONVERTED FOR USE WITH A GAS
FIREPLACE INSERT ONLY AND CANNOT BE USED FOR BURNING WOOD OR SOLID
FUELS UNLESS ALL ORIGINAL PARTS HAVE BEEN REPLACED AND THE FIREPLACE
IS RE-APPROVED BY THE AUTHORITY HAVING JURISDICTION.
ATTENTION: CE FOYER A ETE CONVERTI AFIN D'ETRE UTILISE SEULEMENT COMME
FOYER ENCASTRE AU GAZ ET NE PEUT ETRE UTILSE POUR BRULER DU BOIS OU
TOUT AUTRE COMBUSTIBLE SOLIDE, SANS QUE TOUTES LES PIECES ORIGINALES
AIENT ETE REMPLACEES ET QUE LE FOYER SOIT APPROUVE DE NOUVEAU PAR
LES AUTORITES AYANT JURIDICTION. W385-0199
3SIDEDBACKERPLATE-FRONTVIEW
4SIDEDBACKERPLATE-FRONTVIEW
TOP VIEW
3& 4 SIDED BACKERPLATES-SIDE VIEWS
INSTALLATION

6
W415-0223/D/01.12.04
Move the insert close to its final position inside the wood-
burning fireplace. This unit is equipped with 6 levelling
screws located as follows: two are on either side of the
circulation blower on the rear panel; four are located front
and back on either side beneath the log support. Level
using four of the levelling screws. See Figure 1a. Levelling
the unit will eliminate rocking or excessive noise when the
fan is in operation. Once the unit is level, move it partially
into place within the fireplace to allow for all connections to
be made. It is not practical to level the insert once the it has
been installed. Determine the required depth prior to in-
stalling the unit and adjust the four levelling screws accord-
ingly.
Chimney installation must conform to both national and
local code requirements. The chimney must be lined with
one 2" or 3" diameter liner for intake and one 3" diameter
liner for exhaust. The minimum and maximum vent lengths
are 10 and 35 feet respectively. Recommended Napoleon
kits come in 3 lengths: While the liners must be continuous
from the fireplace to the terminal, to achieve the needed
length, they may be coupled, using an aluminium coupler,
provided installation is sealed & secured.
We recommend that exhaust vents that pass through
unheated spaces, such as a garage or attic, be
wrapped in a protective sleeve to minimize condensa-
tion and reverse flow symptoms. See Trouble Shooting
for details.
This unit is approved for use with a 2" liner for air intake
and a 3" liner for exhaust. For best performance,
however, it is recommended to use two 3" liners.
If a 2" liner is used for the intake, it is necessary to
adjust the primary air shutter. See "Air Shutter Settings"
on page 11.
1. OUTSIDE: Slip one
end of a liner a minimum
of 2" over one of the
collars of the terminal. Se-
cureusing 3 screws.Then
seal the joint and screw
heads with high tempera-
ture sealant. Repeat with
the other liner.
NOTE: We recommend that the other end of the exhaust
liner be marked to eliminate the exhaust liner being con-
nected to the intake collar at the unit.
FIGURE3
4. Detach the two screws from the back of the firebox and
remove the panel, as illustrated.
5. Reaching in through the insert, manoeuvre the vent con-
nection assembly through the openings in the firebox top,
taking care not to damage the gasket. In case of a low
ceiling fireplace, the extension should be removed and
reinstalled after the vent connection is secured to the fire-
box. Attach the restrictor plate to the centre stud and se-
cure the assembly using the three studs and ¼-20 hex
nuts.
INSERT VENT CONNECTION
CHIMNEY CONNECTION
FIGURE4
VENTCONNECTOR
EXTENSION RESTRICTOR
PLATE
STUDS
FIGURE5a-b
1-2" & 1-3" DOUBLE PLYALUMINUM LINER-INLET AND EXHAUST &
2-3" TO 2" REDUCER:
GDI-2320KT VENT KIT 20FT
GDI-2325KT VENT KIT 25FT
GDI-2335KT VENT KIT 35FT
2-3" DOUBLE PLYALUMINUM LINER-INLET AND EXHAUST:
GDI-320KT VENT KIT 20FT
GDI-325KT VENT KIT 25 FT
GDI-335KT VENT KIT 35 FT
2. Gently stretch the liners to the required lengths and in-
sert into the chimney. Place the terminal onto the top of the
chimney cap and fit the flashing plate to suit. Make weather
tight by sealing with caulking (not supplied) and fasten to
the chimney with screws and plugs (not supplied)
3. INSIDE: Attach and secure the flex liners to the vent
connection assembly using the same procedure as be-
fore, ensuring that the marked exhaust liner is attached
to the exhaust collar.
FIGURE2

7
W415-0223/D/01.12.04
To adjust the trim: If the mitre is out of alignment, open
each side and loosen the two screws at either side trim
hinge. Slide the trim up or down to adjust and re-tighten
screws. There is also a very slight in/out adjustment that
can be made.
Note: Since the side panels open and close, to access
the controls, a gap is necessary at the mitre joint.
The top trim piece has an adjustable securing bracket
which enables the trim to be secured to the firebox shell.
In order to close off the fireplace opening or if the opening
is larger than the 3- or 4-sided aluminium extrusion trim
kits, it is recommended to reduce the opening using a non-
combustible material such as ceramic tile, marble, etc or
the GIZBP6-3 or GIZBP6-4 backer plate kits. The outside
edge of the backer plate is finished off with gold trim in-
cluded in each kit. A deluxe flashing kit complete with mar-
quis trim may also be used to complete the installation.
These flashing and trim combinations are available in 6
and 9 inch widths as well as many finishes to accent any
room decor. Mounting brackets, GIZBRKT, are required to
install the deluxe flashing. Detailed installation instructions
are included with each kit.
If this unit is being installed into an existing wood burning,
zero clearance fireplace, then be aware of this precaution:
Any circulation air opening may be covered (with non-
combustible material) but not sealed!
The insert can be equipped
with either a 3- or 4-sided
trim kit to finish off the fire-
place opening. Slide the trim
assembly over the keyholes
(2 per side) and drop into
place. If installing the op-
tional 3- or 4-sided backer
plate (GIZBP6-3 orGIZBP6-
4), it must be hung prior to
the trim kit installation us-
ing the same keyholes.
FIGURE8
FIREVIEWINGDOOR
FIGURE11
FIGURE6
Foreaseofaccessibility,an optional remote wallswitch
or millivolt thermostat may be installed in a convenient
location. Route 2-strand solid core millivolt wire from
thegas fireplace insert to the wall switch / millivolt ther-
mostat. The recommended maximum lead length de-
pends on the wire size:
WIRESIZE MAX.LENGTH
14gauge 100 feet
16gauge 60 feet
18gauge 40 feet
Do not connect either the wall switch, thermo-
stat or gas valve to electricity (110 VOLTS).
The insert may now be
pushed into its final posi-
tion inside the wood-burn-
ing fireplace. Secure the in-
sert to the fireplace using
perforated strapping at-
tached to the two securing
holes on either side of the
unit as shown. We recom-
mend that the trim be in-
stalled before the unit is
placed into its final position.
SECURING
HOLES
FIGURE 7
FIGURE9
VALVE
CONTROL
DOOR
Install suitable supply piping connection to the 3/8" flex
connector supplied (as per local gas codes).
FIGURE10
LOOSEN
SCREWS
SLIDE TO
ADJUST
WALL SWITCH / THERMOSTAT GAS INSTALLATION
FINISHING
ALUMINIUM EXTRUSION TRIM KIT
INSTALLATION

8
W415-0223/D/01.12.04
Positioning the logs improperly will cause flame im-
pingement and carboning.
PHAZERTM logs and glowing embers, exclusive to Napoleon
Fireplaces, glow when exposed to direct flame and provide
a unique and realistic glowing effect that is different in every
installation. Take the time to carefully position the glowing
embers for a maximum glowing effect. Use only certified
PHAZERTM logs available from your Napoleon / Wolf Steel
Ltd. dealer.
1. Place the rear log (#1) onto the two log supports and
against the air intake pipe.
2. Position logs #2 and #3 against the grate posts and line up
the studs located on the burner with the holes on the bottom
of the logs. Keep slightly back of the front row of ports.
3. Fit the centre log (#4) into place behind log #3 and into
the pocket provided on the back log.
This can vary according to the mantle depth. Use the graph
to help evaluate the clearance needed.
4. Tear the glowing embers into pieces and place along
the front row of ports covering all of the burner area in front
of the logs. Care should be taken to shred the embers into
thin, small irregular pieces as only the exposed edges of
the fibre hairs will glow. The ember material will only glow
when exposed to direct flame; however, care should be
taken to not block the burner ports. Blocked burner ports
can cause an incorrect flame pattern, carbon deposits and
delayed ignition.
Log colours may vary. During the initial use of the fireplace,
the colours will become more uniform as colour pigments
burn in during the heat activated curing process.
FIGURE17
M
ANTLE WIDTH
H
E
I
G
H
T
M
A
N
T
L
E
FIGURE16
LOWERDOORBRACKET
#3
#2
#1
FIGURE12
FIGURE13
FIGURE14
#4
Place the door into the two lower door brackets, and se-
cure at the top of the unit with two #10-24 machine screws.
FIGURE15
GLOWINGEMBERS
Remove the backing of the logo supplied and place on the
glass viewing door, as indicated.
½”
½”
LOGO
LOG PLACEMENT DOOR INSTALLATION
MANTLE CLEARANCE
LOGO PLACEMENT
FIGURE18

9
W415-0223/D/01.12.04
The on-off switch is located behind the left side control
door.
Purge all gas lines with the glass door open. Assure
that a continuous gas flow is at the burner before clos-
ing the door. Allow several minutes (5-15) for the flame
to stabilize after ignition.
Do not operate the main burner of the in-
sert with the door removed.
hen lit for the first time, the fireplace will emit a slight
odour for a few hours. This is a normal temporary con-
dition caused by the "burn-in" of paints and lubricants
used in the manufacturing process and will not occur
again. Simply open a window to sufficiently ventilate
the room. After extended periods of non-operation such
as following a vacation or a warm weather season, the
fireplace may emit a slight odour for a few hours. This is
caused by dust particles in the heat exchanger burning
off. Open a window to sufficiently ventilate the room.
PURGETHEGASLINEWITHTHEGLASS DOOR OPEN.
7. Turn gas knob counter-clockwise to pilot.
8. Depress slightly and hold gas knob while lighting the pilot
with the push button ignitor. Keep knob depressed for one
minute, then release. If pilot does not continue to burn, re-
peat steps 3 through 7.
9. With pilot lit, depress and turn gas knob counter-clock-
wise to on.
10. If equipped with flame adjustment valve, push and turn
knob to high.
11. If equipped with remote on-off switch/thermostat, main
burner may not come on when you turn valve to on. Remote
switch must be in the on position to ignite burner.
12. Turn on all electric power to the fireplace.
FLAME ADJUSTMENT
KNOB ON/OFF KNOB
A. This fireplace is equipped with a pilot which must be lit
by hand. While following these instructions exactly.
B. Before operating smell all around the fireplace area for
gas and next to the floor because some gas is heavier
than air and will settle on the floor.
C. Use only your hand to turn the gas control knob. Never
use tools. If the knob will not turn by hand, do not try to
repair it. Call a qualified service technician. Force or at-
tempted repair may result in a fire or explosion.
D. Do not use this fireplace if any part has been under water.
Immediately call a qualified service technician to inspect
the fireplace and replace any part of the control system
and any gas control which has been under water.
• Turn off all gas to the fireplace.
• Open windows.
• Do not try to light any appliance.
• Do not touch any electric switch; do not use any phone in
your building.
• Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire depart-
ment.
When lighting and re-lighting, the gas knob cannot be turned
from pilot to off unless the knob is depressed slightly.
1. Stop! Read the above safety information on this label.
2. Turn off all electric power to the fireplace.
3. Turn the gas knob clockwise to off.
4. Wait five (5) minutes to clear out any gas. If you smell gas
including near the floor. Stop! Follow "B" in the above safety
information on this label. If you don't smell gas go the next step.
5. If fireplace is equipped with flame adjustment valve turn
clockwise to off.
6. Find pilot located in front of back log.
2. Push in gas control knob slightly and turn clockwise
to off. Do not force.
1. Turn off all electrical power to the unit if service is to be
performed.
TURN OFF THE GTURN OFF THE G
TURN OFF THE GTURN OFF THE G
TURN OFF THE GAS AND UNPLAS AND UNPL
AS AND UNPLAS AND UNPL
AS AND UNPLUG ELECTRICAL POUG ELECTRICAL PO
UG ELECTRICAL POUG ELECTRICAL PO
UG ELECTRICAL POWERWER
WERWER
WER
BEFORE SERBEFORE SER
BEFORE SERBEFORE SER
BEFORE SERVICING THE FIREPLVICING THE FIREPL
VICING THE FIREPLVICING THE FIREPL
VICING THE FIREPLAA
AA
ACE INSERCE INSER
CE INSERCE INSER
CE INSERT!T!
T!T!
T!
CAUTION: Label all wires prior to disconnection when serv-
icing controls. Wiring errors can cause improper and dan-
gerous operation. Verify proper operation after servicing.
This insert and its venting system should be inspected
before use and at least annually by a qualified service per-
son. The fireplace area must be kept clear and free of
combustible materials, gasoline or other flammable va-
pours and liquids. The flow of combustion and ventilation
air must not be obstructed.
1. In order to properly clean the burner and pilot assembly,
remove the logs exposing both assemblies.
2.Keep thecontrolcompartment,logs,burner,airshutteropen-
ing and the area surrounding the logs clean by vacuuming
or brushing, at least once a year.
3. Check to see that all burner ports are burning. Clean out
any of the ports which may not be burning or are not burning
properly.
4. Check to see that the pilot flame is large enough to engulf
the thermocouple on one leg and reaches toward the burner
on the other leg.
5. Replace the cleaned logs.
6. Check to see that the main burner ignites completely on all
openings when the gas knob for the burner is turned on. A
5-10 second total light-up period is satisfactory. If ignition
takes longer, consult your Napoleon dealer/distributor.
7. Check that the door gasketing is not broken or missing.
Replace if necessary.
OPERATION / MAINTENANCE
WHAT TO DO IF YOU SMELL GAS:
OPERATING INSTRUCTIONS
FOR YOUR SAFETY READ BEFORE LIGHTING:
LIGHTING INSTRUCTIONS
TO TURN OFF GAS
MAINTENANCE
FIGURE19
FIGURE20

10
W415-0223/D/01.12.04
1. Turn off the electrical power and the gas supply to the
fireplace insert.
2. Remove the fire viewing door. Remove the logs.
3. Detach the two screws from the back of the firebox and
remove the panel, as illustrated.
4. Remove the blower access door held on with the re-
maining 8 screws. Replace the blower access door gas-
ket when changing the blower.
FIGURE 21
4. Disconnect the two blower wires. Remove the blower
bracket secured with one wing nut and lock washer.
For thermodisc replacement: Remove the "Z" shaped
mounting bracket secured to the firebox wall to the left of
the blower. Remove the thermodisc from the bracket and
replace.
5. Replace the blower using the existing bracket. Slide the
vibration reducing pad (A) into the clip (C) and up against
the threaded stud (B) at the other end. The blower must be
able to be positioned entirely onto the pad.
Slide the blower into the clip (C). Secure to the threaded
stud using the existing lock washer and wing nut. Ensure
that the blower does not touch the fireplace base or the
firebox.
6. Reconnect the two wires. Holding the replacement gas-
ket in place, reattach the blower access door and panel.
Replace the logs. Re-install the fire viewing door.
7. Turn the gas supply and electricity back on.
Becausethebloweristhermallyactivated,whenturned
on, it will automatically start approximately 5-15 min-
utes after lighting the fireplace insert and will run for
approximately 30-45 minutes after the fireplace insert
has been turned off. Use of the fan increases the out-
put of heat.
Drywalldustwillpenetrateintotheblowerbearingscaus-
ing irreparable damage and must be prevented from
comingintocontact with the blower or its compartment.
Any damage resulting from this condition is not cov-
eredbythe warranty policy.
red
white
black
BLOWER
WIRES
FIGURE24
THERMODISC
BRACKET
ASSEMBLY
FIGURE26
FIGURE25
A
BC
OPTIONAL BLOWER INSTALLATION
FIGURE 22
FIGURE 23
BLOWER ACCESS DOOR

11
W415-0223/D/01.12.04
Remove the pilot screw cap. Adjust the pilot screw to pro-
vide properly sized flame. Turn in a clockwise direction to
reduce the gas flow. Replace the pilot screw cap.
FIGURE27
Air shutter adjustment
must only be done by a
qualified gas installer!
FIGURE30
This unit is approved for use with a 2" liner for air intake
and a 3" liner for exhaust. For best performance, however,
it is recommended to use two 3" liners.
Air shutter settings will differ depending on the liner sys-
tem used. Use the charts below to determine the correct
air shutter setting:
Some vent configurations may display a very active flame. If
this appearance is not desirable, the vent exit may be re-
stricted using the restrictor plate shown in FIGURE 6b. Bend
the flap up as shown to reduce the velocity of the exhaust
gases, slowing down the flame pattern and creating a more
traditional appearance.
FIGURE29
Closing the air shutter will cause a more yellow flame, but
can lead to carboning. Opening the air shutter will cause a
more blue flame, but can cause flame lifting from the burner
ports. The flame may not appear yellow immediately; allow
15 to 30 minutes for the final flame colour to be estab-
lished.
FIGURE28
ADJUSTMENTS
PILOT BURNER ADJUSTMENT VENTURI ADJUSTMENT
VENT RESTRICTION
HELPFULHINT:
A mirror will let you see the opening of
the air shutter without removing the
burner. Scribe a line along the venturi
tube and air shutter cap. Open or close
according to the original opening by
using the scribed line as your datum.
3"/ 3" LINER SYSTEM
NG 1/16"
LP 3/16"
AIRSHUTTERSETTING
2"/ 3" LINER SYSTEM
NG 1/8"
LP 5/16"
AIRSHUTTERSETTING

12
W415-0223/D/01.12.04
31* W690-0001 MILLIVOLTTHERMOSTAT
32* W660-0010 REMOTE CONTROL - ADVANTAGE
32* W660-0011 REMOTE CONTROL - ADVANTAGE PLUS
33* GD660 REMOTE WALL SWITCH C/W20FT WIRE
34 GI-790KT DECORATIVE BRICK PANELS
35* W175-0162 CONVERSION KIT - NG-LP
35* W175-0192 CONVERSION KIT - LP-NG
36* GIZBP6-3 3 SIDED BACKER PLATE C/WACCENT TRIM
37* GIZBP6-4 4 SIDED BACKER PLATE C/WACCENT TRIM
38* GIZTRM3 ALUMINIUM EXTRUSION - MATTE BLACK
38* GIZTRM3-K ALUMINIUM EXTRUSION - POLISHED BLACK
38* GIZTRM3-B ALUMINIUM EXTRUSION - POLISHED BRASS
39 GIZTRM4 ALUMINIUM EXTRUSION - MATTE BLACK
39 GIZTRM4-K ALUMINIUM EXTRUSION - POLISHED BLACK
39 GIZTRM4-B ALUMINIUM EXTRUSION - POLISHED BRASS
40 GIZUT-B UPPER DOOR TRIM - BRASS
40 GIZUT-G UPPER DOOR TRIM - GOLD
41 GI-900K6 6" DELUXE FLASHING WMARQUIS TRIM - BLACK
41 GI-900B6 6" DELUXE FLASHING WMARQUIS TRIM - POLISHED BRASS
41 GI-900AB6 6" DELUXE FLASHING WMARQUIS TRIM - ANTIQUE BRASS
41 GI-900SS6 6" DELUXE FLASHING WMARQUIS TRIM - BRUSHED STAINLESS STEEL
41 GI-909S6 6" DELUXE FLASHING WMARQUIS TRIM - PORCELAIN ALMOND
41 GI-909K6 6" DELUXE FLASHING WMARQUIS TRIM - PORCELAIN BLACK
41 GI-909F6 6" DELUXE FLASHING WMARQUIS TRIM - PORCELAIN GREEN
41 GI-900K9 9" DELUXE FLASHING WMARQUIS TRIM - BLACK
41 GI-900B9 9" DELUXE FLASHING WMARQUIS TRIM - POLISHED BRASS
41 GI-900AB9 9" DELUXE FLASHING WMARQUIS TRIM - ANTIQUE BRASS
41 GI-900SS9 9" DELUXE FLASHING WMARQUIS TRIM - BRUSHED STAINLESS STEEL
41 GI-909S9 9" DELUXE FLASHING WMARQUIS TRIM - PORCELAIN ALMOND
41 GI-909K9 9" DELUXE FLASHING WMARQUIS TRIM - PORCELAIN BLACK
41 GI-909F9 9" DELUXE FLASHING WMARQUIS TRIM - PORCELAIN GREEN
42* GIZBRKT MOUNTING BRACKETS (REQUIRED FOR THE 900 SERIES FLASHING KITS)
43 CISK-A CAST IRON SURROUND KIT - PAINTED BLACK
43 CISKK-A CAST IRON SURROUND KIT - PORCELAIN ENAMEL BLACK
43 CISKN-A CAST IRON SURROUND KIT - PORCELAIN ENAMEL MAJOLICA BROWN
43 CISKF-A CAST IRON SURROUND KIT - PORCELAIN ENAMEL MAJOLICA GREEN
44* AK-4 ADAPTOR KIT FOR CAST IRON SURROUND
45 ANI-K ANDIRON - PAINTED BLACK
45 ANI-G ANDIRON - GOLD PLATED
When ordering replacement parts always give the follow-
ing information:
1. MODEL &SERIAL NUMBER OF FIREPLACE
2. INSTALLATION DATE OF FIREPLACE
3. PART NUMBER
4. DESCRIPTION OF PART
5. FINISH
Contact your dealer for questions concerning prices and
availability of replacement parts. Normally all parts can be
ordered through your Napoleon dealer or distributor.
1 W725-0039 RBT SHAW VALVE - NG
1 W725-0040 RBT SHAW VALVE - LP
2 W100-0068 BURNER
3 W455-0017 #42 BURNER ORIFICE - NG
3 W455-0059 #53 BURNER ORIFICE - LP
4 W010-0800 PILOTASSEMBLY - LP
4 W010-0801 PILOT ASSEMBLY - NG
5 W455-0069 PILOT INJECTOR - NG
5 W455-0067 PILOT INJECTOR - LP
6 W680-0005 THERMOCOUPLE
7 W680-0004 THERMOPILE
8* W573-0008 HIGH TEMPERATURE SEALANT
9* W357-0001 PIEZO IGNITOR
10 GL-631 LOGSET
11 W135-0136 REAR LOG
12 W135-0138 RIGHT LOG
13 W135-0137 LEFT LOG
14 W135-0139 CENTER LOG
15* W361-0016 GLOWING EMBERS
16 GZ552 BLOWER
17* W385-0245 NAPOLEONLOGO
18* W010-0804 DOOR GLASS C/WGASKET
19* W225-0095 DOOR FRAME
20 W010-0802 DOOR C/WGLASS
21* W290-0063 BLOWER ACCESS GASKET
22* W430-0013 MAGNETIC CLOSURE
23* W660-0009 ON/OFF SWITCH
24* W690-0002 THERMODISC
25* W380-0002 VARIABLE SPEED SWITCH KNOB
26* KB35 VARIABLE SPEED SWITCH
27 W080-0451 RESTRICTOR BRACKET
28 GDI-223 TERMINALKIT
REPLACEMENTS
FORFOR
FORFOR
FOR WARRANTYWARRANTY
WARRANTYWARRANTY
WARRANTY REPLREPL
REPLREPL
REPLAA
AA
ACEMENTCEMENT
CEMENTCEMENT
CEMENT PP
PP
P
ARAR
ARAR
ARTSTS
TSTS
TS, ,
, ,
, AA
AA
A PHOPHO
PHOPHO
PHOTT
TT
TOCOPYOCOPY
OCOPYOCOPY
OCOPY OFOF
OFOF
OF THETHE
THETHE
THE ORIGINORIGIN
ORIGINORIGIN
ORIGINALAL
ALAL
AL INVINV
INVINV
INVOICEOICE
OICEOICE
OICE WILLWILL
WILLWILL
WILL BEBE
BEBE
BE REQUIREDREQUIRED
REQUIREDREQUIRED
REQUIRED TT
TT
TOO
OO
O HONOURHONOUR
HONOURHONOUR
HONOUR THETHE
THETHE
THE CLCL
CLCL
CLAIMAIM
AIMAIM
AIM..
..
.
REPLACEMENT PARTS
TERMINAL KITS
ACCESSORIES:
1-2" & 1-3" DOUBLE PLYALUMINUM LINER-INLET AND
EXHAUST & 2-3" TO 2" REDUCER:
29* GDI-2320KT VENT KIT 20FT
29* GDI-2325KT VENT KIT 25FT
29* GDI-2335KT VENT KIT 35FT
2-3" DOUBLE PLY ALUMINUM LINER-INLET AND
EXHAUST:
30* GDI-320KT VENT KIT 20FT
30* GDI-325KT VENT KIT 25 FT
30* GDI-335KT VENT KIT 35 FT
VENT KITS
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR
FURTHER INFORMATION, CONTACT YOUR NAPOLEON
DEALER.

13
W415-0223/D/01.12.04
*WARNING: This is a fast acting thermocouple. It is an integral safety component. Replace only
with a fast acting thermocouple supplied by Wolf Steel Ltd.

14
W415-0223/D/01.12.04
Main burner goes out;
pilot stays on. Pilot flame is not large enough
or not engulfing the thermopile.
Thermopile shorting
Remote wall switch wire is too
long, too much resistance in
the system
Faulty thermostat or switch
- turn up pilot flame.
- replace pilot assembly.
- clean thermopile and thermopile connection to valve.
- shorten wire to correct length or wire gauge.
- replace
Gas piping is undersized.
Pilot goes out while
standing; Main burner
is in 'OFF' position.
- turn on all gas appliances and see if pilot flame flutters,
diminishes or extinguishes, especially when main burner ig-
nites. Monitor supply pressure.
- check if supply piping size is to code. Correct all undersized
piping.
Pilot burning; no gas
to main burner; gas
knob is on 'HI'; wall
switch / thermostat is
on.
Main burner orifice is plugged.
Faulty thermopile.
Faulty themostat or switch.
- remove stoppage in orifice.
- replace.
- connect a jumper wire across the wall switch terminals; if
main burner lights, replace thermostat.
- disconnect the switch wires & connect a jumper wire across
terminals 1 & 3; if the main burner lights, check the wires for
defects and / or replace wires.
Faultyvalve. - replace.
- check that the manual valve is turned on.
- check the pilot orifice for blockage.
- replace the valve.
- call the gas distributor.
No gas at the pilot burner
- fill the tank.
Out of propane gas.
Pilot will not light. - check if pilot can be lit by a match
- check that the wire is connected to the push button ignitor.
- check if the push button ignitor needs tightening.
- replace the push button ignitor.
No spark at pilot burner
Spark gap is incorrect - spark gap should be 0.150" to 0.175" (5/32" to 11/64" approx.)
from the electrode tip and the pilot burner.
Pilot flame is not large enough
- turn up the pilot flame.
Pilot flame is not engulfing the
thermocouple. - turn up pilot flame. - replace pilot assembly.
Thermocouple shorting.
Faultly thermocouple.
Faultyvalve.
System is not correctly purged. - purge the gas line with the glass door open.
- fill the tank.
Out of propane gas
Pilot goes out when
the gas knob is re-
leased.
- loosen and tighten thermocouple.
- clean thermocouple and valve connection.
- replace thermocouple.
- replace valve.
- replace.
- replace.
TROUBLE SHOOTING GUIDE
B EFORE ATTEMPTING TO TROUBLESHOOT , PURGE YOUR UNIT AND INITIALLY LIGHT THE PILOT AND THE MAIN BURNER WITH THE GLASS DOOR REMOVED .
SYMPTOM PROBLEM TEST SOLUTION

15
W415-0223/D/01.12.04
Exhaust fumes
smelled in room,
headaches.
- check all seals.
Fireplace is spilling.
Carbon is being de-
posited on glass,
logs or combustion
chamber surfaces. Flame is impinging on the
logs or combustion chamber. - check that the logs are correctly positioned. - open air shutter to increase the primary air.
- check the input rate: check the manifold pressure and orifice
size as specified by the rating plate values.
- check that the door gasketing is not broken or missing and
that the seal is tight.
- check that both vent liners are free of holes and well sealed at
all joints.
Air shutter has become
blocked - ensure air shutter opening is free of lint or other obstruc-
tions.
White / grey film
forms. Sulphur from fuel is being de-
posited on glass, logs or com-
bustion chamber surfaces.
- clean the glass with a recommended gas fireplace glass
cleaner. DO NOT CLEAN GLASS WHEN HOT.
If deposits are not cleaned off regularly, the glass may be-
come permanently marked.
Main burner goes out;
pilot goes out. REFER TO "MAIN BURNER GOES OUT; PILOT STAYS ON"
Thermocouple shorting or
faulty.
Vent re-circulating - check joint seals and installation.
- loosen and tighten thermocouple
- clean thermocouple and valve connection.
- replace thermocouple.
- replace valve.
Vent is reversing - check all venting and insert seals.
- check that door is properly sealed. If the insert is allowed to
burn with the door off when purging the unit, exhaust products
may escape through the air intake pipe and reverse the venting
action. Let the unit cool down to correct the reversed venting
action.
Main burner flame is
a blue, lazy, transpar-
ent flame.
Blockage in vent. - remove blockage. In really cold conditions, ice buildup may
occur on the terminal and should be removed as required.
- vent liners are reversed. Refer to Figure 2.
- check all venting and insert seals.
Incorrect installation.
SYMPTOM PROBLEM TEST SOLUTION

16
W415-0223/ D/01.12.04
Wolf Steel Fireplace Service History
This fireplace must be serviced annually depending on usage.
Date Service Technician
Name Service Performed Special ConcernsDealer Name
