Nasco Healthcare Simulaids Life/form Auscultation Trainer... Reference guide

Copyright © Nasco 2013 HC18000028INM18
ONLINE: NascoHealthcare.com
E-MAIL: [email protected]
PHONE: [phone]
ADDRESS: 901 Janesville Ave.
Fort Atkinson, WI 53538
HEALTHCARE
HEALTHCARE
Auscultation Trainer
USER HELP GUIDE
• Incorrect SmartScope™ placement. Move the SmartScope™ slowly
over the torso to locate sensors. See diagrams in your instruction man-
ual for placement of sensors. You may apply color-coded dots on the
heart and lung sites to assist with training.
• Ear tips facing the wrong way. Verify that the ear tips of the Smart-
Scope™ are facing forward in your ear canal.
(lower left)
sternum
space (aortic)
intercostal
Second right
intercostal space
First right
Tracheal Site
Apex
intercostal space
Fourth left
(Erb’s point)
intercostal space
Third left
(pulmonic)
intercostal
Second left
intercostal space
First left
Lung Sounds
Heart Sounds
Anterior Heart and Lung Sites
Midaxillary
Posterior Lung Sites
COMMON CAUSES OF NO SOUNDS
HC18000028INM18.indd 1-2 9/6/18 8:03 AM

COMMON CAUSES OF NO SOUNDS
COMMON CAUSES OF NO SOUNDS
• Batteries need to be replaced. After installing new batteries, make
sure to turn the remote off and back on. This allows the device to
reset.
NOTE: SmartScope™ does not turn off.
• Battery saver mode. The remote will go into battery saver mode if
left on the same setting for 8 minutes.
• Using multiple remotes. One remote will operate all Smart-
Scopes™ within 100 ft. simultaneously as long as the serial numbers
are compatible. Using multiple remotes can cause interference.
• Interference. Wireless communication from another transmitter
using 433 MHz may cause sound selection issues or existing sounds
to stop or restart. Reset the remote by turning it off briefly, then on
again and select a different Heart or Lung sound.
• Using an external speaker. When using an amplifier/speaker, no
sounds will be heard through the SmartScope™.
• Check volume. Make sure the volume on the amplifier/speaker is
turned up.
• When preparing to use your SmartScope™
and remote, use batteries that are fully
charged and positioned correctly. The
SmartScope™ is not equipped with a
power button, this may drain the useful life
of your batteries.
• We recommend that batteries be removed
when not in use.
• Due to frequency changes, Adult Auscul-
tation Trainer SmartScopes™ with serial
numbers 0 to 4999 are only compatible
with remotes with serial numbers
0 to 4999. SmartScopes™ with serial
numbers 5000 and up will only work with
remotes with serial numbers 5000 and up.
The serial numbers are located on the back
of the device and are handwritten in ink.
• Avoid getting ink on torso simulator or practice boards. Ink will transfer
indelible stains.
• Colored dots are included with the torso to aid with teaching.
• Use Nasco Cleaner (LF09919U) to clean torso of any remaining
adhesive or general soil.
GENERAL INFORMATION
HC18000028INM18.indd 3-4 9/6/18 8:03 AM

COMMON CAUSES OF NO SOUNDS
COMMON CAUSES OF NO SOUNDS
• Batteries need to be replaced. After installing new batteries, make
sure to turn the remote off and back on. This allows the device to
reset.
NOTE: SmartScope™ does not turn off.
• Battery saver mode. The remote will go into battery saver mode if
left on the same setting for 8 minutes.
• Using multiple remotes. One remote will operate all Smart-
Scopes™ within 100 ft. simultaneously as long as the serial numbers
are compatible. Using multiple remotes can cause interference.
• Interference. Wireless communication from another transmitter
using 433 MHz may cause sound selection issues or existing sounds
to stop or restart. Reset the remote by turning it off briefly, then on
again and select a different Heart or Lung sound.
• Using an external speaker. When using an amplifier/speaker, no
sounds will be heard through the SmartScope™.
• Check volume. Make sure the volume on the amplifier/speaker is
turned up.
• When preparing to use your SmartScope™
and remote, use batteries that are fully
charged and positioned correctly. The
SmartScope™ is not equipped with a
power button, this may drain the useful life
of your batteries.
• We recommend that batteries be removed
when not in use.
• Due to frequency changes, Adult Auscul-
tation Trainer SmartScopes™ with serial
numbers 0 to 4999 are only compatible
with remotes with serial numbers
0 to 4999. SmartScopes™ with serial
numbers 5000 and up will only work with
remotes with serial numbers 5000 and up.
The serial numbers are located on the back
of the device and are handwritten in ink.
• Avoid getting ink on torso simulator or practice boards. Ink will transfer
indelible stains.
• Colored dots are included with the torso to aid with teaching.
• Use Nasco Cleaner (LF09919U) to clean torso of any remaining
adhesive or general soil.
GENERAL INFORMATION
HC18000028INM18.indd 3-4 9/6/18 8:03 AM
