National Instruments AT-GPIB/TNT User manual

© Copyright 1994 National Instruments Corporation.
All Rights Reserved.
Getting Started with Your AT-GPIB/TNT and
the NI-488.2™Software for Windows
Graphics Applications
September 1994 Edition
Part Number 370880A-01

National Instruments Corporate Headquarters
6504 Bridge Point Parkway
Austin, TX 78730-5039
[phone]
Technical support fax: [phone]
[phone]
Branch Offices:
Australia [phone], Austria [phone], Belgium 02/757.00.20,
Canada (Ontario) [phone], Canada (Québec) [phone],
Denmark 45 76 26 00, Finland (90) 527 2321, France (1) 48 14 24 24,
Germany 089/741 31 30, Italy 02/48301892, Japan [phone],
Mexico 95 800 010 0793, Netherlands 03480-33466, Norway 32-84 84 00,
Singapore 2265886, Spain (91) 640 0085, Sweden 08-730 49 70,
Switzerland 056/20 51 51, Taiwan 02 377 1200, U.K. 0635 523545

Limited Warranty
The AT-GPIB/TNT and AT-GPIB hardware are warranted against defects in materials
and workmanship for a period of two years from the date of shipment, as evidenced by
receipts or other documentation. National Instruments will, at its option, repair or replace
equipment that proves to be defective during the warranty period. This warranty includes
parts and labor.
The media on which you receive National Instruments software are warranted not to fail
to execute programming instructions, due to defects in materials and workmanship, for a
period of 90 days from date of shipment, as evidenced by receipts or other
documentation. National Instruments will, at its option, repair or replace software media
that do not execute programming instructions if National Instruments receives notice of
such defects during the warranty period. National Instruments does not warrant that the
operation of the software shall be uninterrupted or error free.
A Return Material Authorization (RMA) number must be obtained from the factory and
clearly marked on the outside of the package before any equipment will be accepted for
warranty work. National Instruments will pay the shipping costs of returning to the
owner parts which are covered by warranty.
National Instruments believes that the information in this manual is accurate. The
document has been carefully reviewed for technical accuracy. In the event that technical
or typographical errors exist, National Instruments reserves the right to make changes to
subsequent editions of this document without prior notice to holders of this edition. The
reader should consult National Instruments if errors are suspected. In no event shall
National Instruments be liable for any damages arising out of or related to this document
or the information contained in it.
EXCEPT AS SPECIFIED HEREIN, NATIONAL INSTRUMENTS MAKES NO
WARRANTIES, EXPRESS OR IMPLIED, AND SPECIFICALLY DISCLAIMS ANY
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
CUSTOMER'S RIGHT TO RECOVER DAMAGES CAUSED BY FAULT OR NEGLIGENCE
ON THE PART OF NATIONAL INSTRUMENTS SHALL BE LIMITED TO THE AMOUNT
THERETOFORE PAID BY THE CUSTOMER. NATIONAL INSTRUMENTS WILL NOT BE
LIABLE FOR DAMAGES RESULTING FROM LOSS OF DATA, PROFITS, USE OF
PRODUCTS, OR INCIDENTAL OR CONSEQUENTIAL DAMAGES, EVEN IF ADVISED OF
THE POSSIBILITY THEREOF. This limitation of the liability of National Instruments will
apply regardless of the form of action, whether in contract or tort, including negligence.
Any action against National Instruments must be brought within one year after the cause
of action accrues. National Instruments shall not be liable for any delay in performance
due to causes beyond its reasonable control. The warranty provided herein does not
cover damages, defects, malfunctions, or service failures caused by owner's failure to
follow the National Instruments installation, operation, or maintenance instructions;
owner's modification of the product; owner's abuse, misuse, or negligent acts; and power
failure or surges, fire, flood, accident, actions of third parties, or other events outside
reasonable control.

Copyright
Under the copyright laws, this publication may not be reproduced or transmitted in any
form, electronic or mechanical, including photocopying, recording, storing in an
information retrieval system, or translating, in whole or in part, without the prior written
consent of National Instruments Corporation.
Trademarks
NAT4882®, NI-488®,Turbo488®, NI-488.2™, and TNT4882C™are trademarks of
National Instruments Corporation.
Product and company names listed are trademarks or trade names of their respective
companies.
WARNING REGARDING MEDICAL AND CLINICAL
USE OF NATIONAL INSTRUMENTS PRODUCTS
National Instruments products are not designed with components and testing intended to
ensure a level of reliability suitable for use in treatment and diagnosis of humans.
Applications of National Instruments products involving medical or clinical treatment can
create a potential for accidental injury caused by product failure, or by errors on the part
of the user or application designer. Any use or application of National Instruments
products for or involving medical or clinical treatment must be performed by properly
trained and qualified medical personnel, and all traditional medical safeguards,
equipment, and procedures that are appropriate in the particular situation to prevent
serious injury or death should always continue to be used when National Instruments
products are being used. National Instruments products are NOT intended to be a
substitute for any form of established process, procedure, or equipment used to monitor
or safeguard human health and safety in medical or clinical treatment.

FCC/DOC Radio Frequency Interference Compliance
This equipment generates and uses radio frequency energy and, if not installed and used
in strict accordance with the instructions in this manual, may cause interference to radio
and television reception. This equipment has been tested and found to comply with the
following two regulatory agencies:
Federal Communications Commission
This device complies with Part 15 of the Federal Communications Commission (FCC)
Rules for a Class B digital device. A Class B device is distinguishable from a Class A
device by the appearance of an FCC ID number located on the Class B device.
Canadian Department of Communications
This device complies with the limits for radio noise emissions from digital apparatus set
out in the Radio Interference Regulations of the Canadian Department of
Communications (DOC).
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de classe B prescrites dans le règlement sur le
brouillage radioélectrique édicté par le ministère des communications du Canada.
Instructions to Users
These regulations are designed to provide reasonable protection against harmful
interference from the equipment to radio reception in residential areas.
There is no guarantee that interference will not occur in a particular installation.
However, the chances of interference are much less if the equipment is installed and used
according to this instruction manual.
If the equipment does cause interference to radio or television reception, which can be
determined by turning the equipment on and off, one or more of the following
suggestions may reduce or eliminate the problem.
• Operate the equipment and the receiver on different branches of your AC electrical
system.
• Move the equipment away from the receiver with which it is interfering.
• Reorient or relocate the receiver’s antenna.
• Be sure that the equipment is plugged into a grounded outlet and that the grounding
has not been defeated with a cheater plug.

Notice to user: Changes or modifications not expressly approved by National
Instruments could void the user’s authority to operate the equipment
under the FCC Rules.
If necessary, consult National Instruments or an experienced radio/television technician
for additional suggestions. The following booklet prepared by the FCC may also be
helpful: How to Identify and Resolve Radio-TV Interference Problems. This booklet is
available from the U.S. Government Printing Office, Washington, DC 20402, Stock
Number 004-000-00345-4.
Bescheinigung des Herstellers/Importeurs
Hiermit wird bescheinigt, daß die AT-GPIB in Übereinstimmung mit den Bestimmungen
der Vfg. 1046/1984 funk entstört ist.
Der Detuschen Bundespost wurde das Inverkehrbringen dieses Gerätes angezeigt und die
Berechtigung zur Überprüfung der Serie auf Bestimmungen eingeräumt.

© National Instruments Corp. vii AT-GPIB/TNT for Windows Graphics
Contents
About This Manual..............................................................................................xi
Organization of This Manual.........................................................................xi
Conventions Used in This Manual.................................................................xii
Related Documentation..................................................................................xiii
Customer Communication .............................................................................xiii
Chapter 1
Introduction............................................................................................................1-1
How to Use This Manual ...............................................................................1-1
What You Need to Get Started.......................................................................1-2
Optional Equipment.......................................................................................1-2
Hardware Description ....................................................................................1-2
Software Description......................................................................................1-3
Chapter 2
Hardware Installation.........................................................................................2-1
Default Hardware Configuration....................................................................2-1
Install the Hardware.......................................................................................2-1
Note to EISA Users........................................................................................2-3
Chapter 3
Software Installation...........................................................................................3-1
NI-488.2 Software Components.....................................................................3-1
Install the Software.........................................................................................3-2
Chapter 4
Installation Verification and Troubleshooting.........................................4-1
Run the Hardware Diagnostic Test ................................................................4-1
Troubleshooting Hardware Diagnostic Test Error Messages..........4-1
Using Single-Cycle DMA.................................................4-1
Correcting Hardware Settings...........................................4-2
Run the Software Diagnostic Test .................................................................4-3
Troubleshooting Software Diagnostic Test Error Messages...........4-3
Common Questions........................................................................................4-5
Appendix A
Changing Hardware Configuration Settings............................................A-1
Selecting the Base I/O Address......................................................................A-3
Selecting the Interrupt Request Line..............................................................A-7
Note to EISA Users .........................................................................A-9
Selecting the DMA Channel ..........................................................................A-9
Note to EISA Users .........................................................................A-10

Contents
AT-GPIB/TNT for Windows Graphics viii © National Instruments Corp.
Using Programmed I/O for GPIB Transfers ..................................................A-11
Setting the Shield Ground Configuration.......................................................A-11
Appendix B
Changing Software Configuration Settings...............................................B-1
Default Software Configuration.....................................................................B-1
Note to EISA Users........................................................................................B-2
Starting and Exiting the GPIB Software Configuration Utility.....................B-2
Board Configuration.......................................................................................B-3
Expanded Board Configuration .....................................................................B-5
Device Template Configuration.....................................................................B-7
Appendix C
Hardware Specifications....................................................................................C-1
Appendix D
Customer Communication................................................................................D-1
Glossary....................................................................................................................G-1
Figures
Figure 2-1. Installing the GPIB Board...................................................................2-2
Figure 3-1. Software Installation Screen................................................................3-3
Figure A-1. AT-GPIB/TNT Parts Locator Diagram...............................................A-2
Figure A-2. AT-GPIB Parts Locator Diagram........................................................A-3
Figure A-3. Base I/O Address Switch Settings.......................................................A-6
Figure A-4. Interrupt Jumper Setting for IRQ11 (Default Setting) ........................A-8
Figure A-5. Interrupt Jumper Setting for IRQ5 ......................................................A-8
Figure A-6. Jumper Setting for Disabling Interrupts..............................................A-8
Figure A-7. DMA Channel Jumper Setting for DMA Channel 7...........................A-10
Figure A-8. DMA Jumper Setting for No DMA Channel ......................................A-11
Figure A-9. Ground Configuration Jumper Settings...............................................A-12
Figure B-1. Main Dialog Box in the GPIB Software Configuration......................B-2
Figure B-2. Board Configuration Dialog................................................................B-3
Figure B-3. Expanded Board Configuration...........................................................B-3
Figure B-4. Device Template Configuration..........................................................B-3

Contents
© National Instruments Corp. ix AT-GPIB/TNT for Windows Graphics
Tables
Table 2-1. Hardware Default Settings ..................................................................2-1
Table A-1. Possible Base I/O Address Switch Settings.........................................A-4
Table A-2. DMA Channels....................................................................................A-10
Table C-1. Electrical Characteristics of the AT-GPIB/TNT.................................C-1
Table C-2. Electrical Characteristics of the AT-GPIB..........................................C-1
Table C-3. Physical Characteristics.......................................................................C-1
Table C-4. Environmental Characteristics.............................................................C-2

© National Instruments Corp. xi AT-GPIB/TNT for Windows Graphics
About This Manual
This manual contains instructions to help you install and configure the National
Instruments AT-GPIB/TNT or AT-GPIB interface board and the NI-488.2 software for
Windows graphics applications. The NI-488.2 software is intended for use with
Windows version 3.1 or higher.
This manual uses the term AT-GPIB/TNT to refer to a National Instruments GPIB board
for the ISA (PC AT) bus equipped with the TNT4882C ASIC. The term AT-GPIB refers
to a National Instruments GPIB board for the ISA bus equipped with the NAT4882 and
Turbo488 ASICs. This manual also uses the term GPIB board in cases where the
material can apply to either board.
This manual assumes that you are already familiar with the Windows operating system.
Organization of This Manual
This manual is organized as follows:
• Chapter 1, Introduction, explains how to use this manual, lists what you need to get
started and optional equipment you can order, and briefly describes the GPIB
hardware and the NI-488.2 software.
• Chapter 2, Hardware Installation, contains instructions for installing your GPIB
board.
• Chapter 3, Software Installation, contains a description of the files on the NI-488.2
distribution disks and instructions for installing your NI-488.2 software.
• Chapter 4, Installation Verification and Troubleshooting, describes how to verify the
hardware and software installation and how to troubleshoot problems.
• Appendix A, Changing Hardware Configuration Settings, contains instructions for
changing the configuration settings of your GPIB board.
• Appendix B, Changing Software Configuration Settings, contains a description of
the GPIB software configuration utility you can use to configure the NI-488.2
software for Windows.
• Appendix C, Hardware Specifications, describes the electrical, physical, and
environmental characteristics of the GPIB board and the recommended operating
conditions.
• Appendix D, Customer Communication, contains forms you can use to request help
from National Instruments or to comment on our products and manuals.

About This Manual
AT-GPIB/TNT for Windows Graphics xii © National Instruments Corp.
• The Glossary contains an alphabetical list and a description of terms used in this
manual, including abbreviations, acronyms, metric prefixes, mnemonics, and
symbols.
Conventions Used in This Manual
The following conventions are used in this manual.
bold Bold text denotes menus, menu items, dialog buttons, LEDs,
options, or checkboxes.
italic Italic text denotes emphasis, a cross reference, or an
introduction to a key concept.
bold italic Bold italic text denotes a note, caution, or warning.
monospace Text in this font denotes text or characters that are to be
literally input from the keyboard, sections of code,
programming examples, and syntax examples. This font is
also used for the proper names of disk drives, directories,
programs, subprograms, subroutines, device names, functions,
variables, field names and filenames.
bold monospace Bold text in this font denotes the messages and responses that
the computer automatically prints to the screen.
italic monospace Italic text in this font denotes that you must supply the
appropriate words or values in place of these items.
<> Angle brackets enclose the name of a key on the keyboard—
for example, <PageDown>.
- A hyphen between two or more key names enclosed in angle
brackets denotes that you should simultaneously press the
named keys—for example, <Control-Alt-Delete>.
<Enter> Key names are capitalized.
AT-GPIB/TNT AT-GPIB/TNT refers to a National Instruments GPIB board
for the ISA (PC AT) bus equipped with the TNT4882C ASIC.
AT-GPIB AT-GPIB refers to a National Instruments GPIB board for the
ISA bus equipped with the NAT4882 and Turbo488 ASICs.
GPIB board GPIB board refers to either the AT-GPIB/TNT or the
AT-GPIB board in cases where the material can apply to
either board.

About This Manual
© National Instruments Corp. xiii AT-GPIB/TNT for Windows Graphics
IEEE 488 and IEEE 488 and IEEE 488.2 refer to the ANSI/IEEE Standard
IEEE 488.2 488.1-1987 and the ANSI/IEEE Standard 488.2-1987,
respectively, which define the GPIB.
Abbreviations, acronyms, metric prefixes, mnemonics, symbols, and terms are listed in
the Glossary.
Related Documentation
The following documents contain information that you may find helpful as you read this
manual.
• ANSI/IEEE Standard 488.1-1987, IEEE Standard Digital Interface for
Programmable Instrumentation
• ANSI/IEEE Standard 488.2-1987, IEEE Standard Codes, Formats,
Protocols, and Common Commands
•Microsoft Windows User's Guide, Microsoft Corporation
• Documentation included with your graphics software
Customer Communication
National Instruments wants to receive your comments on our products and manuals. We
are interested in the applications you develop with our products, and we want to help if
you have problems with them. To make it easy for you to contact us, this manual
contains comment and configuration forms for you to complete. These forms are in
Appendix D, Customer Communication, at the end of this manual.

© National Instruments Corp. 1-1 AT-GPIB/TNT for Windows Graphics
Chapter 1
Introduction
This chapter explains how to use this manual, lists what you need to get started and
optional equipment you can order, and briefly describes the GPIB hardware and the
NI-488.2 software.
How to Use This Manual
No
Chapter 1
Chapter 2
Chapter 4
Troubleshooting
Yes
No
Need to
Change Software
Settings?
Passes?
Install the Hardware
Install the Software
Verify the Installation
Gather What You Need
to Get Started
Chapter 3
Yes
Yes
No
Need to
Change Hardware
Settings? Appendix A
Appendix B
Run Your Application

Introduction Chapter 1
AT-GPIB/TNT for Windows Graphics 1-2 © National Instruments Corp.
What You Need to Get Started
One of the following boards:
AT-GPIB/TNT board
AT-GPIB/TNT board with keys
AT-GPIB board
AT-GPIB board with keys
NI-488.2 Software for Windows Graphics Applications. Distribution Disk for
the EISA-GPIB, AT-GPIB/TNT and the AT-GPIB
3.5 in. high density (1.44 MB)
or
5.25 in. high density (1.2 MB)
Microsoft Windows version 3.1 or higher installed on your computer
Optional Equipment
• Shielded GPIB Cables*
Type X1 single-shielded cables (1 m, 2 m, or 4 m)
Type X2 double-shielded cables (1 m, 2 m, or 4 m)
• GPIB Connector Extender
• GPIB-SWITCH Box
• GPIB Bus Extenders
Parallel – 100 to 120 VAC
Parallel – 220 to 240 VAC
Fiber-optic – 100 to 120 VAC
Fiber-optic – 220 to 240 VAC
Coaxial – 100 to 120 VAC
Coaxial – 220 to 240 VAC
* To meet FCC emission limits for a Class B device, you must use a shielded
(Type X1 or X2) GPIB cable. Operating this equipment with a non-shielded
cable may cause interference to radio and television reception in commercial
areas.

Chapter 1 Introduction
© National Instruments Corp. 1-3 AT-GPIB/TNT for Windows Graphics
Hardware Description
The AT-GPIB/TNT is an IEEE 488 interface board for PC AT compatible computers.
The TNT4882C chip on the board performs the basic IEEE 488 Talker, Listener, and
Controller functions, including those required by the most recent GPIB standard,
IEEE 488.2. This board can sustain data transfer rates exceeding 1 Mbytes/s. It can also
implement a high-speed GPIB protocol (HS488), so that you can have data transfers up to
3.4 Mbytes/s when using the AT-GPIB/TNT in an EISA computer. The AT-GPIB/TNT
board is fully software compatible with all versions of AT-GPIB hardware.
The AT-GPIB, equipped with NAT4882 and Turbo488 ASICs, is also an IEEE 488
interface board for PC AT compatible computers. The NAT4882 controller chip
performs the basic IEEE 488 Talker, Listener, and Controller functions, including those
required by IEEE 488.2. The Turbo488 performance-enhancing chip boosts GPIB read
and write transfers to rates exceeding 1 Mbytes/s.
Note: Actual transfer rates depend on your host computer, system configuration,
and the types of devices attached to the bus.
You can use standard GPIB cables to connect the AT-GPIB/TNT with up to 14
instruments. You can connect the AT-GPIB board with up to 13 instruments. If you
want to use more than the maximum number of instruments, you can order a bus extender
or expander from National Instruments.
Refer to Appendix C, Hardware Specifications, for more information about the GPIB
hardware specifications and recommended operating conditions.
Software Description
Your kit includes NI-488.2 software, which National Instruments has developed for use
with the GPIB board. It is comprehensive software that transforms your PC AT
compatible computer into a GPIB Controller with complete communications and bus
management capability.
The kit includes DOS and Windows versions of the NI-488.2 software. This manual
describes the NI-488.2 software for Windows. If you want to use the NI-488.2 software
for DOS, refer to the manual Getting Started with Your AT-GPIB/TNT and the NI-488.2
Software for DOS Graphics Applications.

© National Instruments Corp. 2-1 AT-GPIB/TNT for Windows Graphics
Chapter 2
Hardware Installation
This chapter contains instructions for installing your GPIB board.
Warning: Several components on your GPIB board can be damaged by electrostatic
discharge. To avoid such damage in handling the board, touch the
antistatic plastic package to a metal part of your computer chassis before
removing the board from the package.
Default Hardware Configuration
The GPIB board default settings are suitable for most PC AT compatible computer
systems. However, if the default settings conflict with another device in your system,
you must reconfigure the hardware.
Table 2-1 shows the default settings for the switches and jumpers on the GPIB board.
Table 2-1. Hardware Default Settings
GPIB Board Setting Default
Base I/O Address (hex) 2C0
DMA Channel 5
Interrupt Line (IRQ) 11
If you need to modify the default settings of the GPIB board, refer to Appendix A,
Changing Hardware Configuration Settings. Otherwise, proceed to the next section for
installation instructions.
Install the Hardware
Keep in mind the following naming conventions as you read through the rest of this
manual.
•AT-GPIB/TNT refers to a National Instruments GPIB board for the ISA (PC AT) bus
equipped with the TNT4882C ASIC.

Hardware Installation Chapter 2
AT-GPIB/TNT for Windows Graphics 2-2 © National Instruments Corp.
•AT-GPIB refers to a National Instruments GPIB board for the ISA bus equipped with
the NAT4882 and Turbo488 ASICs.
•GPIB board refers generically to either the AT-GPIB/TNT or AT-GPIB board in
cases where the material can apply to either board.
Perform the following steps to install the GPIB board:
1. Turn off your computer. Keep the computer plugged in so that it remains grounded
while you install the GPIB board.
2. Remove the top cover or access port of the I/O channel.
3. Remove the expansion slot cover on the back panel of the computer.
4. Insert the GPIB board into any unused 16-bit ISA or EISA slot with the GPIB
connector sticking out of the opening on the back panel, as shown in Figure 2-1. It
might be a tight fit, but do not force the board into place. You can install the
AT-GPIB/TNT in an 8-bit slot, if necessary. When you use an 8-bit slot, you must
disable DMA and use only interrupt request lines 3, 4, 5, 6, 7, or None.
1
3
2
1 GPIB board
2 Back panel
3 PC AT plug-in board
Figure 2-1. Installing the GPIB Board

Chapter 2 Hardware Installation
© National Instruments Corp. 2-3 AT-GPIB/TNT for Windows Graphics
5. Screw the mounting bracket of the GPIB board to the back panel rail of the
computer.
6. Check the installation.
7. Replace the top cover or access port to the I/O channel.
8. Turn on your computer.
Note to EISA Users
If you have an EISA bus-based computer, you can use the EISA configuration files
included on your NI-488.2 distribution disk to give the EISA configuration utility
information about your GPIB board. Follow the instructions that came with your
computer to copy the appropriate EISA configuration file to your EISA configuration
disk. Then, run your EISA configuration program, which uses the information in the
configuration file to help you select appropriate settings for the GPIB hardware. After
the EISA configuration program determines the settings, you must manually set the DIP
switches and jumpers on the GPIB hardware to match the selections.

© National Instruments Corp. 3-1 AT-GPIB/TNT for Windows Graphics
Chapter 3
Software Installation
This chapter contains a description of the files on the NI-488.2 distribution disks and
instructions for installing your NI-488.2 software.
NI-488.2 Software Components
The NI-488.2 software for Windows includes the following components.
•setup.exe is a menu-driven program that installs the NI-488.2 software and
updates system.ini, the Windows system configuration file.
•gpib.dll is a 16-bit dynamic link library that implements the NI-488 and
NI-488.2 functions.
•gpib.ini is the GPIB configuration information file that describes the default
configuration of the NI-488.2 software. It is accessed and modified by the GPIB
software configuration utility.
• The Hardware Diagnostic Test, ibdiag.exe, is a program that you can use to test
the GPIB hardware and ensure that it is functioning properly.
• The Software Diagnostic Test, ibtest.exe, is the Windows NI-488.2 software
installation test.
• GPIB Information, gpibinfo.exe, is a utility you can use to obtain information
about your GPIB hardware and software, such as the version of the NI-488.2
software and the type of interface board you are using.
• The GPIB software configuration utility, ibconf.cpl, is a control panel applet
that is installed in the Windows System directory. It is used to configure the
NI-488.2 software for Windows. Like other control panel applets, it is located in
the Control Panel, which is in the Main group of the Program Manager.
• The GPIB software configuration utility help file, ibconf.hlp, is a Windows help
file that gives information about the GPIB software configuration utility. This file is
also installed in the Windows System directory.
• Win16 Interactive Control, wibic.exe, is an interactive communication utility that
you can use to communicate with GPIB devices from the keyboard. You can also
use the Win16 Interactive Control utility to troubleshoot problems.
• The interactive control help file, wibic.hlp, is a Windows help file that gives
information about the Interactive Control utilities.

Software Installation Chapter 3
AT-GPIB/TNT for Windows Graphics 3-2 © National Instruments Corp.
• GPIB Spy, gpibspy.exe, is the GPIB application monitor program. It is a
debugging tool that you can use to monitor the NI-488.2 calls made by your
Windows applications.
• The GPIB Spy help file, gpibspy.hlp, is a Windows help file that gives
information about the GPIB Spy application monitor program.
•nivgpibd.386, the National Instruments virtual GPIB device, allows the driver to
perform DMA transfers.
•gpib-32.dll is a 32-bit translation dynamic link library that handles the 32-bit to
16-bit translation to allow Win32s GPIB applications to communicate with the 16-bit
gpib.dll.
•gpib-16.dll is a 16-bit translation dynamic link library.
• Win32s Interactive Control, wibic32.exe, is a Win32s version of the Win16
Interactive Control program described earlier. Microsoft Win32s is an operating
system extension that allows Win32 applications to run under Microsoft Windows
version 3.1 and higher.
• Read Me (readme.txt) is a documentation file that contains the latest updates
and corrections to the manual when appropriate.
• The EISA configuration files for the AT-GPIB, the AT-GPIB/TNT, and the
EISA-GPIB are in the root directory of the installation disk. They are not copied by
the installation program. These files should be used only if you have an EISA
computer.
Install the Software
After you have installed and configured the hardware, you are ready to install the
NI-488.2 software. Complete the following steps to run the software installation
program.
1. Insert the NI-488.2 software for Windows distribution disk into an unused drive.
2. Choose Run... from the File menu in the Program Manager window and type the
following command into the dialog box:
x :\setup
where x is the letter of the drive containing the distribution disk (usually aor b).
