Nauticam 70 User manual

Current as of 2020-05-25
Instruction Manual for
Extension Ring 70 with Focus knob for
Canon EF 11-24 f/4L USM
PN# 21271
F
OREWORD
Thank you for your purchase of a NAUTICAM product.
At NAUTICAM, we pr de ourselves n the ab l ty to recogn ze the
requ rements of profess onal as well as amateur underwater
photographers and fulf ll them through the nnovat ve des gns of
our products. We str ve to ach eve a h gh level of user-
fr endl ness by allow ng stress-free nstallat on and easy operat on
of all mportant funct ons of the camera.
Please read th s manual carefully before us ng the product, th s
w ll max m ze ts performance as well as ts l fet me.
W
ARRANTY
All NAUTICAM Products are warranted aga nst any mater al and
manufactur ng defects for two years from the date of purchase for
consumer use. Th s warranty only appl es to products purchased
from author zed NAUTICAM dealers and does not extend beyond
the or g nal reta l purchaser.
To return your product for serv ce, please contact your reg onal
author zed serv ce center(s). Please note that th s warranty only
appl es when the product s purchased n the terr tory where the
serv ce center s located.
NAUTICAM does not hold respons b l ty for damage, of any nature,
to any equ pment used w th and/or placed w th n our products.
NAUTICAM accepts no l ab l ty for any loss of captured mages or
the nab l ty to capture mages even f t s due to the
malfunct on ng of our products.
Unauthor zed mod f cat ons and/or repa rs of our products w ll
automat cally nval date the warranty.
Please follow the nstruct ons below to mount the Extens on R ng
on a port.
M
OUNT ON THE
P
ORT
1.
Conf rm that the Extens on R ng
s
unlocked, w th the lock ng lever po nt ng
upwards as shown.
2.
Al gn the "I" mark on t
he extens on r ng
w th the WHITE dot on the port.
Gently push the extens on r ng towards the
port unt l t cannot go any further.
2
3.
Turn the extens on r ng clockw se unt l the
wh te dot on the extens on r ng al gns w th
the wh te dot on the port.
4.
Push t
he lock ng dev ce nwards. Ensure
that the extens on r ng s securely locked
w th the port
To unlock, release the lock ng dev ce and
reverse the above procedures.

Current as of 2020-05-25
2.
Engage the gear by push ng n the knob,
then turn the knob both ways to check f
the lens focuses.
3.
Replace w th the correct cog and nstall t
back to the shaft of the control knob by
t ghten ng the screw.
The control knob of th s extens on r ng can be used
w th some focus gears. Please refer to the below table
for deta ls. The control knob s set w th A type cog by
default. To use 19542 and 19155 gears, B type
(suppl ed) has to be nstalled. Please follow the
nstruct on below for chang ng the cog of the control
knob.
Ava lable G
ears
A type
(Pre-
nstalled)
19551 C1124-F Focus Gear
19555 C1635III-F Focus Gear
19560 C1635f4-F Focus Gear
B type
19542 C1635II-F focus gear
19155 N120 DSLR Gear Set for
Laowa 24mm f/14 2x Macro Probe
Remark: Naut cam supports only e-manuals. Please download
correspond ng product manuals on Naut cam.com webs te, or contact us
for e-manuals.
M
OUNT THE PORT TO THE HOUSING
C
HANGE OF
C
OGS
P
RE
-
CAUTIONS
1.
Make sure the control knob s at ts most
outwards pos t on before mound ng/un-
mount ng the port. The knob should be
left at th s pos t on unt l t s made sure
that the lens and focus gear s properly
nstalled.
1.
Ide
nt f cat on
of
cogs.
2.
Remove the cog by unscrew ng the screw.
26.5mm 32.3mm
· After nstallat on of the port combo, please make sure the
o-r ng (s) are free from debr s and uneven surface ssues.
· A water-t ght test w thout the camera ns de the hous ng
s h ghly recommended after the chang ng of port and O-
r ng(s).
· Do not use lubr cants from other brands w th the s l cone
rubber O-r ng on th s hous ng, only use the lubr cant
prov ded by NAUTICAM.
· D scont nue use mmed ately should you not ce any
leakage.
· Do not open the product n a wet or sandy env ronment.
Protect the nter or from mo sture and debr s n order to
prevent malfunct on or leakage.
· Defect ve products should be sh pped to our d str butors
for serv ce, unauthor zed d sassembl ng and/or
mod f cat ons could result n malfunct on or leakage.
3
