Nauticam EEF60-F User manual

1.
Insert the plastic c
-
ring as shown and place
it
over the lens rubber focus ring.
2.
Insert the gear of
E
EF60
-
F
on the plastic c
-
ring
until it reaches the flange of the plastic c-ring.
1
Please follow the instructions below to mount the dedicated focus gear on the lens.
.
Mount the alignment ring onto the lens by
screwing it into the thread on the front of the
lens.
4. To remove the EEF60-F gear, reverse the above
steps.
5. The tightness between the EEF60-F gear and the
lens can be adjusted by removing or adding
rubber grips on either sides of the plastic c-ring,
spare rubber grips are included in the package.

2
Please
follow the instruc
tions below to mount the dedicated Macro port on the housing.
1.
Detach A from the port by turning it anti
-
clockwise while holding B firmly.
2.
Install the camera body only into the
housing.
*Please refer to the housing manual for
installing camera into the housing.
.
Align the port mounting indices of B and the
housing. Gently push B into the port opening
of the housing, until it cannot go in any
further.
*Please refer to housing manual for locking
and un-locking the port.
B
A

3
4.
M
ake sure the
two
k
nobs are at its most
outwards position before mounting/ un-
mounting the lens. The knobs should be left
at this position until it is made sure that the
lens and gear is properly installed.
5.
Remove the O
-
ring from A, inspect for any
damage and lightly coat it with the provided
lubricant. Clean the O-ring groove before
placing it back.
6. Verify that the threaded section of B and
sealing surface are clean and free from
foreign material.
7. Align the external threaded section of A and
the internal threaded section of B.
8.
Attach A on B
by holding the housing firmly
and turning A clockwise until it cannot go in
any further.
9. Engage the lens AF/MF switch by pushing in
the upper knob, then turn the knob both
ways to check if the lens is switching
between auto and manual focus.
10. Engage the gear by pushing in the lower
knob, then turn the knob both ways to check
if the lens manual focusing is functioning.
11. To un-mount the port, reverse the above
steps.
A
Upper Knob
Lower Knob
