NavInc NAVplay NP6-RR-GV4 User manual

NAVplay Android 6.0.1 integration LR & Jaguar 3rd gen. incl.
OEM touch support
Art. Nr: NP6-RR-GV4
DESCRIPTION
General
Extend your existing Jaguar InControl system with a complete Android system
for multimedia and navigation and enjoy all your favourite apps in the car. All
the original features are retained.
The interface is equipped with various options such as; navigation, USB
connection for film and music, Carplay/Android Auto, WiFi, Audio/video input,
camera input, audio/video output, etc. You will have all the features of
an Android tablet integrated on your original screen of your vehicle!
Example installation:
Features
- Android Operating system 6.0.1 (Marshmallow)
- Powerful CPU (1.1GHz Cortex A7 Quad-Core CPU )
- High quality video Display (800x480 & 480x234)
- Supports Android Play-Store (Various applications supported)
- Customize your navigation with your own Apps from the App store
- Customize your Home screen with fast buttons to access your Apps
- Side navigation bar to control your Android system
- 3x Audio/Video RCA input to connect external A/V sources
- 1x Audio RCA output to connect Android audio with your car
- 1x Microphone connection for voice recognition (microphone optinal)
- 1x Speaker connection (speaker included)
- GPS connection to navigate without internet access (GPS antenna
included)
- 1x camera input with adjustable parking lines
- Multiple ways to store data and communication ports (2x USB 2.0 & 1x
microSD Slot)
- Support 3G & 4G via uSIM slot (antenna included)
- Wifi hot spot (antenna included)
- Setting menu to change your display, Apps and other settings
EXCLUSIVE CAR FEATURES

Features:
- xxxxxxxxxxxx
- xxxxxxxxxxxx
- xxxxxxxxx
CAMERA FEATURES
Picture in Picture (PiP)
Via the camera input of the interface an aftermarket camera system can be
connected to the navigation system. The camera image will be displayed
automatically on the screen when the car is put in the reverse gear. The
camera input knows 2 views:
1: Camera with Picture in Picture of the Parking assist
2: Full camera view
Parking guidelines
In the camera image on screen parking guidelines can be displayed. This
makes it much easier to determine the distance to the object you are driving
towards. The guidelines are adjustable horizontal as well as vertical so the lines
can be adjusted to the car.
Intelligent Park Assist System (IPAS)
The interface have also the Intelligent Park Assist System (iPAS). With this
function the guidelines will respond on the steering wheel position. The guide
lines are adjustable horizontal and vertical via the interface OSD menu.

Front camera input
The front camera input will be activated after leaving the reverse gear.
The camera will switch OFF automatically after 10 km/h or when you press the
NAVI button.
NAVPLAY
Customize
Download your favourite Apps via the Play Store or APK uploader to customize
your NAVplay, like;
Video: Youtube / Netflix / Ziggo / Proximus / Videoland
Music: Spotify / Sound Cloud / PODcast
Navigation: iGo / Waze / Goolge maps
Radio: Radium for Internet Radio / Nederland FM / Radio.net
Communication: Skype / Carplay / Android Auto
Customize your own home screen via the Quick Launch menu
Navigation
Dowload your favourite navigation system like;
iGO
Goolge maps
WAZE

Media
The NAVplay is equipped with several media inputs such as;
Bluetooth streaming
Dual USB 2.0 input (media)
Micro SD slot (up to 64GB)
Audio output via RCA
Audio output via Bluetooth
USB OTG input
Internet
The NAVplay is equipped with a WiFi connection that can be connected to the
Internet. In addition, it is also possible to create an 3G/4G Internet connection
(via the uSIM slot).
Carplay
Upgrade your NAVplay with CARPLAY to your existing system. You can run apps
from your iPhone Via CarPlay without touching your iPhone. You can control
this Carplay kit via the NAVplay and via voice control (Siri).

PACKAGE CONTENTS
The following is provided in the set:
- Specific video interface (IF-PO-PCM41PHV): 1x
- NAVplay module: 1x
Dual USB cable (HARETC0111): 1x
Dipol antenna (ETCETC0332): 2x
Dipol extension cable (HAGPS0006): 2x
RGB output cable (HRGBCA00025): 1x
Resistive touch (HTOUCH0022): 1x
Power supply cable (HPOWER0137): 1x
GPS antenna fakra (GPSANT003): 1x
Speaker (SPEAKER007): 1x
Button (HARETC0001): 1x
MULTI kabel (HARETC0208): 1x
- Installation- & user instructions
- Warranty
NOTES
- It is essential to have an Aux-in
- We recommend that the installation will be performed by a qualified specialist
PRODUCT SPECIFICATIONS
OS Android 6.0.1 (Marshmallow)
CPU MSM8909
(Qualcomm Cortex-A7 Quad 1.1GHz)
Memory 1GByte DDR3
Internal Storage 8GByte eMMC
Display Analog RGB + Composite HYsync
Resolution 800 x 480 (WVGA)
SD CARD Single microSD slot

GNSS
GPS/GLONASS/BeiDou
FAKRA Connector
(with GPS Antenna, 5m)
USB Dual USB(A) Host
(with Dual USB Host Cable)
LTE/3G Network
Frequency Bands
FDD LTE: B1/B3/B5/B7/B8/B20
TDD LTE: B38/B40/B41
WCDMA: B1/B5/B8
GSM: 850/900/1800/1900Mhz
FAKRA Connector
(with Dipole Antenna)
USIM Single USIM slot (support 3G & 4G)
WLAN
Bluetooth
2.4G/5.8G, 802.11b/g/n
BT2.1+EDR/3.0/4.1LE
FAKRA Connector
(with Dipole Antenna)
Touch C-Touch, R-Touch, UART-Touch
(within Multi cable)
Video Input none
Map voice exclusive Speaker Φ 57 mm 4Ω /2 W Speaker
(within Multi cable)
Audio Output
Stereo AUX
(within Multi cable: dual RCA)
Bluetooth(Source)
Language
Worldwide language
(Support Google android’s world language)
Virtual Keyboard: English
Power DC +12V/2A
Operating Temperature -10°C ~ +70°C
Storage Temperature -20°C ~ +80°C
Dimension 150mm(W) x 100mm(H) x 25mm(D)
COMPATIBILITY
Compatible with the following models
Jaguar:
XF 2011-2014
XF Sportbrake 2012-2014
XJ 2009-2014
Landrover:
Evoque 2011-2014
Sports 2012-2012
Discovery 4 2012-2014
Freelander 2013 - 2014
Remarks:
- Only in combination with InControl navigation system.
- Installation also possible in combination with original TV Tuner.
- AUX-output of the interface needs to be connected with AUX input of the car.
- Also possible to use the interface stand alone for reversing and/or forward driving
camera function.
- Automatic switching to camera on navigation level.
- Control of the connected Audio/Video source possible via the optional touch

screen.
