NavInc REP-NP6-A3 User manual

Size UP + NAVplay Android 6.1 integration Audi A3 8V (7.0")
Art. Nr: REP-NP6-A3
DESCRIPTION
General
UPgrade your Audi A3 (8V) with a 7.0 inch High resolution capacitive touch
screen + NAVplay without replacing the original MMI system. The Size UP has
the same design as the
OEM 7.0" MMI display, to maintain the factory look.
Upgrade with a complete Android system for multimedia and navigation
without replacing your original radio. Receive the benefits
of your favorite apps, online Navigation, Bluetooth connectivity, video playback
and host of connection types including USB & SD.
Example video
Features
- RGB input with touch screen support (NAVplay or APPplay)
- RGB-HDMI input (for HDMI devices)
- Rear camera input
- Dynamic Parking Lines (IPAS)
- Picture in Picture from Parking sensors (PiP)
- Front camera input
- 2* Audio/Video input
- 800x480 Resolution
- Use OEM MMI button to enter screen inputs
- 2 Year warranty & Support
EXCLUSIVE INTERFACE FEATURES

Features:
- 2* AV input
- Audio output select
- Image retention while driving
- Adjustable parking lines via OSD menu
- Activation interface via original MMI buttons
- OSD menu
EXCLUSIVE NAVplay FEATURES
Extend your Size UP with a complete Android system for multimedia and
navigation and enjoy all your favourite apps in the car. All the original features
are retained.
The interface is equipped with various options such as; navigation, USB
connection for film and music, Carplay/Android Auto, WiFi, Audio/video input,
camera input, audio/video output, etc. You will have all the features of an
Android tablet integrated on your original screen of your vehicle!
Features:
- Supports Android Play-Store (Various applications supported)
- Customize your navigation with your own Apps from the App store
- Customize your Home screen with fast buttons to access your Apps
- Side navigation bar to control your Android system
- 1x Microphone connection for voice recognition (microphone optinal)
- 1x Speaker connection (speaker included)
- GPS connection to navigate without internet access (GPS antenna
included)
- Multiple ways to store data and communication ports (2x USB 2.0 & 1x
microSD Slot)
- Support 3G & 4G via uSIM slot (antenna included)
- Wifi hot spot (antenna included)
- Setting menu to change your display, Apps and other settings

NOTES
- It is essential to have an Aux-in
- We recommend that the installation will be performed by a qualified specialist
- Check the other tabs for "Compatibility" - "Package contents" - "Product
specifications"
COMPATIBILITY
CAR
This kit is compatible with the following models:
AUDI
A3 (8V) 2012-20.. Standard MMI Radio with 5.8" display
REQUIREMENT
AUDIO OUTPUT The interface inserts ONLY video signals into the infotainment. It is essential to
have an Aux-in, when using audio from an external AV source.
CVBS Only compatible with NTSC sources.
RGB RGB input is compatible with NAVplay & CARplay module
SCREEN Interface is compatible for cars with 5.8” radio screen.
FRONT CAMERA
The front camera input will automatically switch after leaving the reverse gear.
You can set the display time in seconds via the OSD menu (1-15 sec).
It is also possible to select the FRONT camera input manually

OEM REAR
CAMERA
The interface does switch back automatically to the OEM rear camera input
when the reverse gear is engaged.
GUIDELINES iPAS & Static lines are available via the interface OSD menu
PIP Parking sensor overlay option is only available (Picture in Picture)
REAR SELECT
CAMERA INPUT
Interface will respond on CAN for cars with auto gearbox. When manual gear
box please use the rear detection wire.
INSTALLATION We recommend that the installation will be performed by a qualified specialist
EXTRA NOTE Kit only replace the 5.8” LCD to 7” LCD High res touch
