Navitar 1-51311 Guide

REV CHANGERECORD AND DATECH
ROCHESTER,NEWYORK
REV
SIZE
B
P/NSUFFIXDEFINITION
-1CONVERSIONCOATING
-2PAINTING
-3MARKING
-RREWORK
UNLESS OTHERWISE
SPECIFIED
DIMENSIONSAREININCHES
AND INCLUDECHEMICALLY
APPLIEDORPLATEDFINISHES
DEC..XXX `.005
DEC..XX `.010
FRACT.`1/64
ANGLES `30'
CONCENTRICITY.003 TIR
BREAK ALL SHARPEDGES
.005 MIN..010 MAX
MAX.SURF.ROUGHNESS 32
TOLERANCES:
MATERIAL:
FINISH:
CHAMFERALL THREADS
30~TOROOTDIAM.
USEDON:
SCALE:
DR.:
CH.:
APP.:
DATEDR.:
DONOTSCALEDRAWING
0.0mm 25.0
0.0inch1.0
SHEETOF
THECONTENTSOFTHIS
DOCUMENTAREPROPRIETARY
TONAVITAR,ITSUSE IS
AUTHORIZEDONLYFOR
RESPONDINGTOREQUEST
FORQUOTATIONOR
PERFORMANCEOFWORKFOR
NAVITAR
1-51311 A
11
R.PODLENA
P.BONAFEDE
9/16/2003
MOTORIZED(STEP)12Xw/2POS.LS
(HE),3mm FF &COAX PORT
1:1
ARELEASE 09/04/03
OUTLINE
6.55 [166.4]
5.26 [133.5]
.76 [19.4]
1.312n-.001
.000
+
n1.50 [38.1]
n1.73 [43.9]
n1.91 [48.4]
n1.88 [47.6]2.31 [58.8]
2.41 [61.3]
1.46 [37.0]
13/16-32 UN -2B
MOTORWIRECONFIGURATION
PIN
1MOTORA+
3+5Vdc
6MOTORB+
7MOTORA-
8FARLIMIT
11 MOTORB-
12 NEARLIMIT
13 COMMON
