Navitar 1-62309 Guide

REV CHANGERECORD AND DATECH
ROCHESTER,NEWYORK
REV
SIZE
B
P/NSUFFIXDEFINITION
-1CONVERSIONCOATING
-2PAINTING
-3MARKING
-RREWORK
UNLESS OTHERWISE
SPECIFIED
DIMENSIONSAREININCHES
AND INCLUDECHEMICALLY
APPLIEDORPLATEDFINISHES
DEC..XXX `.005
DEC..XX `.010
FRACT.`1/64
ANGLES `30'
CONCENTRICITY.003 TIR
BREAK ALL SHARPEDGES
.005 MIN..010 MAX
MAX.SURF.ROUGHNESS 32
TOLERANCES:
MATERIAL:
FINISH:
CHAMFERALL THREADS
30~TOROOTDIAM.
USEDON:
SCALE:
DR.:
CH.:
APP.:
DATEDR.:
DONOTSCALEDRAWING
0.0mm 25.0
0.0inch1.0
SHEETOF
THECONTENTSOFTHIS
DOCUMENTAREPROPRIETARY
TONAVITAR,ITSUSE IS
AUTHORIZEDONLYFOR
RESPONDINGTOREQUEST
FORQUOTATIONOR
PERFORMANCEOFWORKFOR
NAVITAR
1-62309 A
11
R.PODLENA
P.BONAFEDE
4/30/2003
MOTORIZED(ENCODED)6X
ULTRAZOOMw/3mm FINEFOCUS&
COAX,DUAL2POSITIONLS(HE)
1:1
ARELEASE 06/12/03
OUTLINE
n1.44 [36.5]
M25x.75T
n1.25 [31.8]
n1.56 [39.6]
n1.78 [45.2]
n1.60 [40.6]
1.312n-.001
.000+
11/16-32 UN -2B
.43 [10.9]
.76 [19.2]
5.78 [146.8]
2.22 [56.4]
2.36 [59.9]
1.47 [37.3]
1.33 [33.8]
4.08 [103.5]
