Navitar 1-51319 Guide

ROCHESTER,NEWYORK
UNLESS OTHERWISE SPECIFIED
DIMENSIONSAREININCHES AND
INCLUDECHEMICALLYAPPLIED
ORPLATEDFINISHES
0.0inch1.0
0.0mm 25.0
P/NSUFFIXDEFINITION
-1CONVERSIONCOATING
-2PAINTING
-3MARKING
-RREWORK
SIZE REV
TOLERANCES AS FOLLOWS
DEC..XXX
DEC..XX
FRACT.
ANGLES
CONCENTRICITY
BREAK ALL SHARPEDGES
.005 MIN..010 MAX.
MAX.SURF.ROUGHNESS:32
`.005
`.010
`1/64
`30'
.003 TIR
USEDON:
MATERIAL:
FINISH:
CHAMFERALL THREADS30~
TOROOTDIAMETER
SCALE:
DR:
CH:
APP:
DATEDR:
DONOTSCALEDRAWINGSHEETOF
THECONTENTSOFTHIS
DOCUMENTAREPROPRIETARY
TONAVITAR,ITSUSE IS
AUTHORIZEDONLYFOR
RESPONDINGTOREQUESTFOR
QUOTATIONORPERFORMANCE
OFWORKFORNAVITAR
11A
1-51319
R.PODLENA
P.BONAFEDE
9/18/2003
MOTORIZED(STEP)12Xw/12mm FF &2
POSLS(HE)
1:1
B
OUTLINE
4-40 UNC -2B
(4PLS.)
n1.31 [33.3]
.75 [19.1]
.80 [20.3]4.70 [119.5].32 [8.1]
.38 [9.5]
.34 [8.7]
5.82 [147.9]
.76 [19.4]
2.77 [70.5]
n1.50 [38.1]
n1.81 [46.0]
1.88 [47.6]nn1.91 [48.4]
1.46 [37.0]
2.41 [61.3]
1.18 [29.8]
2.13 [54.1]
PIN
(2-62565)
2PHASE ZOOMMOTORASSY
PINS4,5,10,14,15
(NOCONNECTIONS)
1BROWNMOTORA+
3GREEN+5Vdc
7REDMOTORA-
8VIOLETFARLIMIT
11 YELLOWMOTORB-
12 GRAY NEARLIMIT
13 BLUECOMMON
6ORANGEMOTORB+
_OL
