Navitar 1-51334 Guide

REV CHANGERECORD AND DATECH
ROCHESTER,NEWYORK
REV
SIZE
B
P/NSUFFIXDEFINITION
-1CONVERSIONCOATING
-2PAINTING
-3MARKING
-RREWORK
UNLESS OTHERWISE
SPECIFIED
DIMENSIONSAREININCHES
AND INCLUDECHEMICALLY
APPLIEDORPLATEDFINISHES
DEC..XXX `.005
DEC..XX `.010
FRACT.`1/64
ANGLES `30'
CONCENTRICITY.003 TIR
BREAK ALL SHARPEDGES
.005 MIN..010 MAX
MAX.SURF.ROUGHNESS 32
TOLERANCES:
MATERIAL:
FINISH:
CHAMFERALL THREADS
30~TOROOTDIAM.
USEDON:
SCALE:
DR.:
CH.:
APP.:
DATEDR.:
DONOTSCALEDRAWING
0.0mm 25.0
0.0inch1.0
SHEETOF
THECONTENTSOFTHIS
DOCUMENTAREPROPRIETARY
TONAVITAR,ITSUSE IS
AUTHORIZEDONLYFOR
RESPONDINGTOREQUEST
FORQUOTATIONOR
PERFORMANCEOFWORKFOR
NAVITAR
1-51334 A
11
R.PODLENA
P.BONAFEDE
9/16/2003
MOTORIZED(ENC)12XULTRAw/2
POSLS(HE),3mm FF &COAX PORT
1:1
OUTLINE
DC ENCODEDPINOUT
PIN1=MOTORCH A
PIN2=FARLIMIT
PIN3=N/C
PIN4=+5Vdc
PIN5=MOTOR+
PIN6=MOTORCH B
PIN7=NEARLIMIT
PIN8=COMMON
PIN9=MOTOR-9PINMALED-SUB
6.56 [166.5]
5.26 [133.5]
.14 [3.6]
1.312n-.001
.000+
11/2-32 UN -2A
n1.73 [43.9]
n1.91 [48.4]
n1.88 [47.6]2.31 [58.8]
2.41 [61.3]
1.46 [37.0]
4-40 UNC -2B(4)x
5.43 [138.0] .80 [20.3]
.32 [8.1]
.75 [19.1]
.38 [9.5]
1
2-50026 1
2-50025
26.0-36RMS
.800-36RMS
13/16-32 UN -2B
