Navitar 1-62318 Guide

REV CHANGERECORD AND DATECH
ROCHESTER,NEWYORK
REV
SIZE
B
P/NSUFFIXDEFINITION
-1CONVERSIONCOATING
-2PAINTING
-3MARKING
-RREWORK
UNLESS OTHERWISE
SPECIFIED
DIMENSIONSAREININCHES
AND INCLUDECHEMICALLY
APPLIEDORPLATEDFINISHES
DEC..XXX `.005
DEC..XX `.010
FRACT.`1/64
ANGLES `30'
CONCENTRICITY.003 TIR
BREAK ALL SHARPEDGES
.005 MIN..010 MAX
MAX.SURF.ROUGHNESS 32
TOLERANCES:
MATERIAL:
FINISH:
CHAMFERALL THREADS
30~TOROOTDIAM.
USEDON:
SCALE:
DR.:
CH.:
APP.:
DATEDR.:
DONOTSCALEDRAWING
0.0mm 25.0
0.0inch1.0
SHEETOF
THECONTENTSOFTHIS
DOCUMENTAREPROPRIETARY
TONAVITAR,ITSUSE IS
AUTHORIZEDONLYFOR
RESPONDINGTOREQUEST
FORQUOTATIONOR
PERFORMANCEOFWORKFOR
NAVITAR
1-62318 A
11
R.PODLENA
P.BONAFEDE
8/9/2002
MOTORIZED(STEPPER)6xZOOM&
12mm FF,DUAL2POSITIONLS(HE)
1:1
ANODIZE,DYE BLACK
OUTLINE
ARELEASE 06/13/03
M25x.75T
1.093 -32T
n1.24 [31.5]
.50 [12.7]
n1.60 [40.6]
n1.60 [40.6]
1.05 [26.7]
.14 [3.4]
4.57 [116.1]
1.312n-.001
.000+2.22 [56.3]
2.36 [59.8]
1.33 [33.8]
1.47 [37.3]
MOTORWIRECONFIGURATION
PIN
1MOTORA+
3+5Vdc
6MOTORB+
7MOTORA-
8FARLIMIT
11 MOTORB-
12 NEARLIMIT
13 COMMON
