Navitar 1-51336 Guide

ROCHESTER,NEWYORK
UNLESS OTHERWISE SPECIFIED
DIMENSIONSAREININCHES AND
INCLUDECHEMICALLYAPPLIED
ORPLATEDFINISHES
0.0inch1.0
0.0mm 25.0
P/NSUFFIXDEFINITION
-1CONVERSIONCOATING
-2PAINTING
-3MARKING
-RREWORK
SIZE
REV
TOLERANCES AS FOLLOWS
DEC..XXX
DEC..XX
FRACT.
ANGLES
CONCENTRICITY
BREAK ALL SHARPEDGES
.005 MIN..010 MAX.
MAX.SURF.ROUGHNESS:32
`.005
`.010
`1/64
`30'
.003 TIR
USEDON:
MATERIAL:
FINISH:
CHAMFERALL THREADS30~
TOROOTDIAMETER
SCALE:
DR:
CH:
APP:
DATEDR:
DONOTSCALEDRAWINGSHEETOF
THECONTENTSOFTHIS
DOCUMENTAREPROPRIETARY
TONAVITAR,ITSUSE IS
AUTHORIZEDONLYFOR
RESPONDINGTOREQUESTFOR
QUOTATIONORPERFORMANCE
OFWORKFORNAVITAR
11A
1-51336
R.PODLENA
P.BONAFEDE
9/16/2003
MOTORIZED(ENC)12Xw/2POSLS(HE)&
COAX PORT
1:1
B
OUTLINE
DC ENCODEDPINOUT
PIN1=MOTORCH A
PIN2=FARLIMIT
PIN3=N/C
PIN4=+5Vdc
PIN5=MOTOR+
PIN6=MOTORCH B
PIN7=NEARLIMIT
PIN8=COMMON
PIN9=MOTOR-9PINMALED-SUB
2.41 [61.3]
2.09 [53.1]
1.88 [47.6]n
1.312n-.001
.000+
n1.91 [48.4]
.14 [3.6]
6.71 [170.5]
3.66 [93.0]
.75 [19.1]
.38 [9.5]
5.59 [142.1] .80 [20.3]
.32 [8.1]
1.46 [37.0]
1.14 [28.9]1.20 [30.6]13/16-32 UN -2B
n1.73 [43.9]
n1.50 [38.1]
n1.27 [32.3]
