NEAR 5050 User manual

Near® Wi-Fi Smart Door Lock
User Manual
Take Note:
Please read this user manual before use.
Carry a spare key with you and store the other at a safe place.

1.Installationa. Professional installation recommended
b. Pay attention to the connecting line during installation
c. Adjust the handle's direction according to the instructions
d. Please keep the door half opened during installation.
e. After installation, please try accessing the door with fingerprint,
passwords, NFC Cardkey, Mechanical keys, internal and external door handles.
f. Refer to the manual to rectify any issues before using the lock.
2. Installation diagram5050 Lock body6052 Lock body1. Outer panel
2. Connecting column
3. Lock body
4. Square steel
5. Battery case cover
6. Connecting screw
7. Rear handle
8. Lock body fixing screw
9. Emergency power supply port
10. Lock core
11. Front handle.
12. Knob
13. Anti lock pick up
15. Setting key
14. Lock body(5050)

3. Determine the direction of the handle
Left door opening
Right door opening
Change direction of the handle
1.Remove the cross screw in the figure,
Turn the handle 180 degrees in the
direction of the arrow.
2.After adjusting the handle
direction, install the screw
and complete the reversing.
Cross screw
4. Open the installation hole:
According to the hole drawing and the lock body model.
5. Install the lock body:
a. Support Lock Body: 5050 only
b. Adjust direction of the diagonal tongue according to the direction of the door.
Left: Inside o pen
Right: Outside o pen
Right: Inside open
Left: Outside open

c. Lock Body Reversing
5050 lock body 6052 lock body
Reversing paddle h ole
latch bolt reversing
paddle
Square bar socket latch bolt reversing
paddle
Heaven and earth hook
Square bar Socket
Heaven and earth hook
Anti lock paddle
socket
a. Pull t he r eversing p addle of l ocking tab to the other end.
b. Push the Oblique tongue into the lock body and rotate 180°
c. Release reversing paddle.
d. Install the lock into the door frame and (hang the heaven &
earth hook, tighten the fixing screw in the lock body - 6052
Lock Configuration)
6. Door lock installation
a. 1 Connect the two corresponding studs on the outer plate
b. Fixed outer panel
i.Insert the square bar into the square bar hole
ii. Pull the main board connecting cable into the door
iii. Align the outer panel with the opening position and install the square bar
c. Fixed inner panel
i.Connect the main board connecting line, and put the redundant line into the slot.
ii.Insert the anti lock paddle. The length of the paddle can be cut according to the
thickness of the door (6052 lock body only)
iii. Align the square bar of the inner panel and compress the inner panel.
iv. Lock the screws and fix the panel.
7. Install the door buckle plate and buckle box
Door frame
Door buckle box
Door buckle
plate
Wood screw
Latch
Bolt
Latch
Bolt

After operation successfully,
voice broadcast: press 1 for
administrator settings, press 2 for
user settings, pres s 3 for system
settings, press 4 for restore
factory settings.
Initialization Stage
press “*”
then press “#”
Voice broadcast:
please enter
administrator
information
(enter 123456#)
5 in 1 Near Smart Door Lock Operation Manual
1. Function and Operation
1.1 Description of terms and functional keys
1) Administrator information: refers to the administrator's fingerprint, password or NFC Card
2) Unlock information: refers to the input fingerprint, password or NFC Card information (including
administrators and ordinary users).
3) Key “*”： clear key / back key. Enter the password and point by clearing the previous input.
Click the clear key three times in succession to empty all input.
4) Key "#”： confirmation key or menu function key.
2. Original State
1) Before setup, the smart lock can be unlocked with any fingerprint, NFC
card, password. The factory password is: 123456.
2) Any fingerprint, NFC card or password which are unregistered after the
setup will not have access to the smart lock.
3.Access door lock function management (step one)

4. Administrator settings
1）Add administrator (step 2)
lock function management
(step one)
2） Delete administrator information
5. Common user setting
a. Add administrator information
Voice Broadcast:
Press 1 for admin setting,
Press 2 for user setting.
After entering input
information. Press * to
return to the previous step
to continue adding and/or
delete administrators
Press 1 to add users, fingerprints or
password. We recommend that you
test by unlocking using your
fingerprints 4 times, passwords at
least twice and once with the NFC
Card
Enter Administrator Settings
(Step Two)
Voice Broadcast:
Press 1 for administrator settings
Press 2 for user settings
Press 2: Voice Broadcast
Please enter number, press # to
confirm
e.g. 002#
Once confirmed, press * to
return to the previous level
to continue adding or
deleting an administrator
Enter administrator Settings
(Step One)
Voice Broadcast:
Press 1 for administrator setting,
press 2 for user setting.
Press 2 voice broadcast:
a. Press 1 to add user
b. Press 2 to delete user
Press 1 to add administrator,
and input security details.
- Fingerprint (add at least 4 sets
of fingerprints)
- Passwords (4 to 8 digits and
press #)

b. Deleting user information
6. System setting
1. Voice setting
2. Unlock mode setting
Enter Administrator Settings
(Step one)
Voice broadcast:
Press 1 for administrator settings.
Press 2 for user settings
Press 2 Voice Broadcast:
Press 1 to add user
Press 2 to delete user
Press 2 Voice Broadcast:
Press 1 for number delete,
Press 2 to delete all.
E.g. Press 1, then input
number (010#) and user
010 will be deleted
Enter Administrator Settings
(Step one)
Voice broadcast:
Press 1 for administrator settings.
Press 2 for user settings
Press 3 Voice Broadcast:
Press 1 for voice setting
Press 2 for unlock mode
Press 3 for language setting
Press 4 for time setting
Press 1 Voice Broadcast:
Press 1 to enter settings
Press 2 to close the setting.
Upon selection, you will hear
the confirmation.
Enter Administrator Settings
(Step one)
Voice broadcast:
Press 1 for administrator settings.
Press 2 for user settings
Press 3 Voice Broadcast:
Press 1 for voice setting
Press 2 for unlock mode
Press 3 for language setting
Press 4 for time setting
Press 2 Voice Broadcast:
Press 1 to enable passage mode,
Press 2 to cancel passage mode
Press 3 for Single mode.
Press 4 for combination mode.
You can only select an option at
a time.

3) Language settings
4) Time setting
7. Restore factory settings
Enter Administrator Settings
(Step one)
Voice broadcast:
Press 1 for administrator settings.
Press 2 for user settings
Press 3 Voice Broadcast:
Press 1 for voice setting
Press 2 for unlock mode
Press 3 for language setting
Press 4 for time setting
Press 3 Voice Broadcast:
Press 1 for Chinese
Press 2 for English
Enter Administrator Settings
(Step one)
Voice broadcast:
Press 1 for administrator settings.
Press 2 for user settings
Press 3 Voice Broadcast:
Press 1 for voice setting
Press 2 for unlock mode
Press 3 for language setting
Press 4 for time setting
Press 4 voice broadcast: Current time
Enter Time & Date
Enter Administrator Settings
(Step one)
Voice broadcast:
Press 1 for administrator settings.
Press 2 for user settings
Press 4 Voice Broadcast:
Please input administrator
information (123456), press # to
confirm
Sucessfully Restored to
Factory Settings

8. APP Configuraon (Near® App) oponal
1) Search “Near Smart” in App Store or an App market, download and install it.
2) Register using your email and log in.
3) Select “Lock (Wi-Fi)”, click and add a device following instrucons before use.
4) Remote unlocking: wake up the screen and press “9”+”#”.
There will be a voice prompt: requesng remote unlocking.
Add a network
a) Hotspot connecon mode:1) Press“ *” +“ # ” to authencate administrator identy and then press “1” to access administrator
sengs. Then there will be a voice prompt of pressing “3” for network configuraon.
2) Voice prompt in network configuraon mode: press “1” for hotspot connecon and “2” for intelligent
connecon.
b) Intelligent connecon mode:3) When the network is successfully added, the 1st, 2nd, 3rdand 4thlights on the keyboard will be on in order with a voice prompt of “operaon completed”.4)In the event of network addion failure, the 1st, 2nd, 3rdand 4thlights on the keyboard will not be on and there will be a voice prompt of “operaon failed” upon meout.
9. Other notes
a. Input the wrong password more than 5 times in a row, the keyboard locks for 30 seconds,
it does not respond to any operating system in 30 seconds.
b. Password peeping prevention function: input password as follows when opening the door with
password: XXX password XXX; you can add false codes before and after the password, and then press
# to confirm. The password must be included in the input contents.
c. If there is no activity for more than 10 seconds, the system will exit setting status.
d. If the voltage is lower than 4.8V, the lock will automatically alarm every time it is unlocked.
(Note: Smart lock open/close for about 200 times before replacement is required. As an indicator,
if your smart lock takes more than 5 seconds, the battery needs to be replaced.)
e. When normal open mode is switched off, press 5# repetitively and when the voice broadcast
says "Please enter unlock information". Enter unlocking the smart lock, you will hear "Normal mode
opened, please pay attention when you lock"
f. When normal open mode is active, press 5# repetitively, and you will hear "normal open mode closed".

Technical ParametersItemsParametersMemo 1Quiescent current≦50uA2Dynamic current10.
Technical Parameters ≦180mA3Administrators’number94Fingerprint number 100 5Fingerprint + password + card capacity200 6Fingerprint scanner semiconductor 7Fingerprint contrast time ≦0.6Second8Fingerprint identification Angle360°9False Rejection Rate ≦0.1% 10False Recognition Rate ≦0.0001% 11Reaction time≦0.1 Second12Power type6V13Emergency powering 5VDC 14Working temperature -25℃~60℃ 15Working Relative Humidity 20%~90%RH 16Human voice Yes 17KBD Touch standard 12-bit keyboard18Password Length 4-8bit 19Phantom password 32bit 20Low voltage alarm 4.8±0.2V 21Unlock time≦1Second
