Nebula Solar User manual
User Manual
Nebula Solar / Nebula Solar Portable
01 English
23 Deutsch
42 Español
61 Français
80 Italiano
99 Nederlands
118 Português
137 日本語
157 한국어
176 لعَرَبِية
EN
02
Safety Instructions
Read all instructions before you use this device. Do not make any changes or create
settings that are not described in this manual. If physical injury, loss of data or damage
is caused by failure to follow instructions, the warranty does not apply.
Setup
• To reduce the risk of fire and / or electric shock, do not expose the device to rain
or moisture. Objects filled with liquids, such as vases, should not be placed on this
device.
• Do not place this device on soft surfaces such as tablecloths or carpets, otherwise
the device could be a fire hazard.
• Do not place this device in areas susceptible to excessive dust and dirt or near any
appliance generating a strong magnetic field.
• To prevent overheating, do not block or clog the ventilation openings.
• Never place this device in a confined space. Always leave enough space around this
device for ventilation.
• Protect this device from overexposure to direct sunlight, heat, large temperature
fluctuations and moisture. Avoid extreme temperatures. The suitable operations and
storage temperature for this device and its accessories is 41°F to 95°F/ 5°C to 35°C.
• When this device is running for a long period of time, the surface may become hot.
Shut it down immediately and unplug the charger. Resume operation after this
device has cooled down.
• Always handle this device with care. Avoid touching the lens. Do not allow children
to handle the device without supervision.
• Never place heavy or sharp objects on this device.
• To avoid electric shock, do not disassemble.
• Use attachments or accessories specified by the manufacturer only.
• Avoid extreme vibrations as they may damage the internal components.
Power Supply
• Use only the provided power adapter.
• Power off the device before removing the power supply from the socket.
• Protect the power cord from being walked on or pinched, particularly at plugs,
convenience receptacles, and the point where they exit from this device.
• Unplug this device if there are lightning storms or when unused for a long period of
time.
• Where the power plug or an appliance coupler is used as the disconnect device, the
disconnect device shall remain readily operable.
• Before you make or change any connections, ensure that all devices are
EN
03
disconnected from the power outlet.
• Never touch the power cable or the power connector with wet hands.
Hearing Safety
• To prevent hearing damage, do not listen for extended periods at high volume. Set
the volume to a safe level.
Charging
• The charger type for D2130 is NSA60ED-190300 with output voltage / current of DC
19V, 3A Max.
• The charger type for D2131 is PN653I with output voltage / current of 5V DC, 3A /
9V DC, 3A / 12V DC, 3A / 15V DC, 3A / 20V DC, 3.25A.
• The charger type for D2131 is A2713 with output voltage / current of 5V DC, 3A / 9V
DC, 3A/ 15V DC, 3A / 20V DC, 3.25A.
• The adapter should be installed near this product and should be easily accessible.
• This adapter is for indoor use only.
• When charging, place this device in an environment that has a normal room temperature
(ranges from 5°C to 25°C/ 41°F to 77°F recommended) and good ventilation.
• Due to the enclosure material used, this device shall only be connected to a USB
interface of version 2.0 or higher.
Cleaning
• Use a soft, lint-free cloth. Never use liquid, gaseous or easily flammable cleansers
to clean.
• Do not use any liquid cleaning agents to clean the lens to avoid damaging the
coating film on the lens.
• Use lens cleaning paper to clean the lens.
Repairs
• Do not make any repairs to this device yourself. Only have your device repaired by
an authorized service center.
• Improper maintenance can result in injuries or damage to this device.
• Refer all servicing to qualified service personnel.
Caution
• Possible hazardous optical radiation emitted from this device.
• Do not stare at the operating beam. The bright light may damage your eyes.
EN
04
What’s Included
Overview
1. Front View
2. Rear View
Power Button
• Press to power on
• Press and hold to power off
USB-A Port
• Connect to a USB flash drive
DC Input (Nebula Solar)
USB-C Charging Port (Nebula Solar
Portable)
HDMI Input Port
• Connect to a playback device
Camera for Autofocus
Lens
Nebula Solar /
Nebula Solar
Portable
Nebula Solar
Nebula Solar Portable
Adapter Remote Control 2 x AAA Batteries Quick Start Guide
EN
05
3. Bottom View
3
4. Bottom View
1
2
4
5
6
7
8
9
3
Adjust Focus
Navigation
Back
Power On / Off
Press to activate Google Assistant
Confirm the selected content
Home
System Settings
Volume up / down
Remote Control: Nebula RC
Model: D0413
Solar / Solar Portable nameplate
• Open to use it as a stand
Tripod socket
Speaker
EN
06
5. LED Indicator Guide
Nebula Solar:
Button LED Status Description
Solid blue Power on / operating in projector mode
Solid yellow Standby in projector mode
Off Power off
Flashing blue
Ready to pair / Bluetooth is pairing /
Bluetooth disconnected (Bluetooth
speaker mode)
Solid blue Bluetooth connected (Bluetooth
speaker mode)
Nebula Solar Portable:
Button LED Status Description
Solid blue Power on / operating in projector mode
Solid yellow Standby in projector mode
Solid red Charging
Solid green Fully charged
Flashing red Low battery
Flashing blue
Ready to pair / Bluetooth is pairing /
Bluetooth disconnected (Bluetooth
speaker mode)
Solid blue Bluetooth connected (Bluetooth
speaker mode)
EN
07
Getting Started
1. Placement
Place this device on a stable, flat surface, and squarely point it to face the projection
surface. For best results, the projection surface should be white and flat. The distance
between this device and the projection surface must be a minimum of 30 inches (0.8
meters) and a maximum of 120 inches (3.18 meters) to get a projection image from 30
to 120 inches.
0.8 m - 3.18 m
T
• It is unnecessary to tilt it towards the projection surface. You can
correct the projection image with the built-in keystone correction.
• The distance between the device and the projection surface
determines the projection image size. For the best result, set the
projector between 63 and 104 inches away.
• You can also mount your projector on the ceiling.
There is a nameplate on the back panel of Nebula Solar / Nebula Solar Portable. Open
the nameplate to use it as a stand. After use, close the nameplate.
EN
08
2. Prepare the Remote Control
The remote control comes with two AAA batteries.
①For first-time use, slide to open the battery compartment and install two AAA
batteries.
EN
09
②To replace the battery, unlock and open the battery compartment, insert a new
battery matching the polarity (+/-) as indicated, and then close and lock the battery
compartment.
3. Get Started
①Connect Nebula Nebula Solar / Nebula Solar Portable to the power outlet by using
the provided power adapter.
EN
10
② Nebula Solar: Press to turn it on.
Nebula Solar Portable: Press and hold for 2s to turn it on.
③Angle the projector towards a suitable projection surface or wall. The built-in
autofocus automatically adjusts the protector's image focus. Or you can press
on the remote control to manually adjust the focus.
④When using for the first time, follow the on-screen instructions to complete the basic
set-up.
EN
11
Nebula Connect App
To easily control this device, we recommend downloading the Nebula Connect app.
With this app, you can operate your mouse using your phone screen.
①Download the Nebula Connect app from the App Store (iOS devices) or Google Play
(Android devices).
②Enable Bluetooth on your smartphone and select [Nebula-XXXXXX-Solar] or
[Nebula-XXXXXX- Solar P] as the device to be connected.
③Open the Nebula Connect app and follow the on-screen instructions to complete the
connection setup.
EN
12
Powering the Nebula Solar / Nebula Solar Portable
with Android TV™
Follow the on-screen instructions to complete the setup process.
Option 1. Quick setup
Android phone users can follow the instructions to quickly set up Android TV with your
Android phone.
Option 2. Set up Nebula Solar / Nebula Solar Portable
For iOS users, follow the instructions to complete the process.
①Skip the quick setup process.
②Connect Nebula Solar / Nebula Solar Portable to the network.
③Sign in with your Google account.
Your Nebula Solar / Nebula Solar Portable will be powered by Android TV after finishing
the setup process.
Settings
Go through the setup process when you turn on Nebula Solar / Nebula Solar
Portable for the first time.
1. Network
This device can be connected to the Internet via a wireless (Wi-Fi) connection.
①On the home page, select > [Network & Internet] and press .
②Follow the on-screen instructions to complete the network connection.
2. Projector
①On the home page, select > [Projector Settings] and press .
[Brightness] / [Image Mode]
[Brightness]:
Adjust the brightness from 0 to 100% (for
Nebula Solar)
[Image Mode]: Auto / Standard / Battery Mode
(for Nebula
Solar Portable)
[Color Temperature] [Normal] / [Cool] / [Warm]
[Wall Color]
[White] / [Red] / [Orange] / [Blue] / [Green] / [Cyan] / [Yellow]
/ [Purple]
[3D] Press
Enter
to select 3D effect.
Option:
[2D] / [3D (Side by Side)] / [3D (Over-Under)]
EN
13
[Keystone Correction]
Enable / disable auto keystone correction.
[Zoom]
[70-100%]
[Auto Focus Correction]
Press
Enter
to run auto focus correction.
Set to On by default.
[HDR]
Enable / disable HDR effect.
[Projector Mode]
[Auto]:
Automatically detects whether the projector is inverted.
Automatically switch between these options.
[Front Projection]: The projector is located in front of the
projection surface.
[Rear Projection]: The projector is located behind the
projection surface.
[Inverted Front Projection]: The projector is hanging
from the ceiling in an upside down position. The image is
rotated by 180 degrees.
[Inverted Rear Projection]: The projector is hanging
from the ceiling in an upside down position behind the
projection surface. The image is rotated by 180 degrees
and horizontally mirrored.
3. Audio
Audio format can be changed via the Audio Settings.
①On the home page, select > [Audio Settings] and and press .
Auto change digital audio format Enable or disable automatic digital audio format
change between PCM and RAW.
4. HDMI
Choose HDMI as the input source. You can also change CEC settings.
①On the home page, select > [HDMI] and and press .
CEC Settings
Press Enter to change CEC settings.
HDMI
When an HDMI device is connected, the projector
will start playing content on the HDMI devices.
HDMI 2.0
On / Off
EN
14
5. Bluetooth Speaker
You can use Nebula Solar / Nebula Solar Portable as a standalone Bluetooth speaker.
To switch to Bluetooth speaker mode, you have two options:
①A. Press to switch to Bluetooth speaker mode.
B. On the home page, select > [Bluetooth Speaker Mode] and press .
②Enable Bluetooth on your smartphone and select [Nebula Solar] or [Nebula Solar P]
as the device to be connected.
③Follow the on-screen instructions to complete Bluetooth connection or quit the
Bluetooth speaker mode.
6. Apps
①On the home page, select > [Apps], and press .
②Select an app and check the current version, open or force stop, check the storage
used, clear data or cache, or enable or disable notifications and permissions.
7. Others
On the home page, select to find more setting options.
[Device Preferences]
[About] Check the device information and firmware version.
[Date & time] Manually set the date and time.
[Language] Select the on-screen language.
[Keyboard] Select the keyboard language type.
[Sound] Select the audio output source and sound format.
[Storage] Check the device storage and removable storage.
[Reset] All data from your device’s internal storage will be
erased.
[Date & Time]
[Automatic date & time] Enable or disable automatic date and time.
[Set date] Manually set date.
[Set time] Manually set time.
[Set time zone] Set a time zone.
[Use 24-hour format] Enable or disable 24-hour format.
EN
15
Using Nebula Solar / Nebula Solar Portable
1. Play from HDMI Playback Devices
Nebula Solar / Nebula Solar Portable can be connected to various HDMI playback
devices such as a TV box, TV stick, DVD player, set-top box (STB), gaming consoles or
other devices.
To play from HDMI playback devices:
①Connect Nebula Solar / Nebula Solar Portable to an HDMI playback device with an
HDMI cable (not included).
• It will automatically start HDMI playback once connected to an HDMI playback
device.
2. Play from a USB Drive
With Nebula Solar / Nebula Solar Portable, you can enjoy music, video, and pictures
that are stored on a USB drive.
EN
16
To play from a USB drive:
①Download the ES File Explorer from Google Play.
②Insert a USB drive into the USB port.
• The USB folder will appear on the ES File Explorer.
③Select videos or photos from the USB drive that you want to play, and press
④Press to stop playback.
3. Connect Bluetooth Accessories
You can connect Bluetooth devices to Nebula Solar / Nebula Solar Portable.
①On the home page, select > [Remotes & Accessories] and press .
②Select Add accessories.
• This projector will begin searching for accessories.
③Pair your projector with the device to be connected.
④Follow the on-screen instructions to complete the Bluetooth connection.
Note: Before pairing your Bluetooth devices, make sure the remote control and your
projector are in pairing mode.
4. Use ChromecastTM Built-in
You can wirelessly cast photos, videos, and music from your phone or computer right
to your Nebula Solar / Nebula Solar Portable.
EN
17
①Play a YouTube video clip on your phone and then tap the cast icon on the
video screen.
②Select the device “D2130” or “D2131” you want to cast to.
• This projector will mirror the screen of the connected phone or computer.
T
• Make sure Nebula Solar / Nebula Solar Portable and your phone are
connected to the same wireless network.
• Certain content may be unavailable to be casted due to copyright
restrictions. In this case, you can stream the content via the same app
installed in your Nebula Solar / Nebula Solar Portable.
5. Enjoy Google Features
Nebula Solar / Nebula Solar Portable also supports Google features. Once connected
to a wireless network, you can access online services, enjoy movies, music and
pictures, and browse online. Aside from the pre-installed apps, you can also install any
other apps from Google Play, and talk to the Google Assistant to do certain tasks.
To talk to the Google Assistant:
①Make sure you’ve followed the steps in the section “Connect Bluetooth Accessories”
to connect your remote control to Nebula Solar / Nebula Solar Portable. Once
connected, the LED indicator on the remote control turns solid red.
②Press on the remote control to talk to the Google Assistant.
EN
18
Specifications
Specifications and design are subject to change without notice.
Nebula Solar: Nebula Solar Portable:
Power supply: 19V 3A
Power consumption: < 57W
Standby power consumption: < 0.5W
Display technology: FHD 1920 × 1080p
DLP
Light source: RGB LED
Projection image size: 30-120 inch
Resolution: 1920 × 1080p
Brightness: 400 ANSI Lumens
Contrast ratio: 1000:1
Throw ratio: 1.2
Throw distance: 0.8m to 3.18m
CPU: Quad-core ARM Cortex-A55
OS: Android TV 9.0
RAM: 2GB DDR
ROM: 8GB eMMC
Speaker drivers: 3W × 2
Wi-Fi: IEEE802.11a/b/g/n/ac Dual
Frequency 2.4G/5G
Bluetooth version: V4.2
USB file system: FAT32 / NTFS / exFAT
Recommended ambient: 41°F to 95°F /
5°C to 35°C
Relative humidity: 15% ~ 85% (non-
condensing)
Storage temperature and humidity: <
149°F / 65°C, < 90% humidity
Dimensions (H*D): 192.25 × 192 × 58.65
mm / 7.6 × 7.6 × 2.3 inch
Weight: 1 kg / 35.2 oz
Power supply: 20V 3.25A
Power consumption: < 65W
Standby power consumption: < 0.5W
Display technology: FHD 1920 × 1080p
DLP
Light source: RGB LED
Projection image size: 30-120 inch
Resolution: 1920 × 1080p
Brightness: 400 ANSI Lumens
Contrast ratio: 1000:1
Throw ratio: 1.2
Throw distance: 0.8m to 3.18m
CPU: Quad-core ARM Cortex-A55
OS: Android TV 9.0
RAM: 2GB DDR
ROM: 8GB eMMC
Speaker drivers: 3W × 2
Wi-Fi: IEEE802.11a/b/g/n/ac Dual
Frequency 2.4G/5G
Bluetooth version: V4.2
USB file system: FAT32 / NTFS / exFAT
Recommended ambient: 41°F to 95°F /
5°C to 35°C
Relative humidity: 15% ~ 85% (non-
condensing)
Storage temperature and humidity: <
149°F / 65°C, < 90% humidity
Dimensions (H*D): 192.25 × 192 × 58.65
mm / 7.6 × 7.6 × 2.3 inch
Weight: 1.4 kg / 49.4 oz
Table of contents
Other Nebula Projector manuals
Nebula
Nebula P1 Lite D2321 User manual
Nebula
Nebula Capsule II User manual
Nebula
Nebula Prizm User manual
Nebula
Nebula Capsule II User manual
Nebula
Nebula Mars II User manual
Nebula
Nebula Capsule User manual
Nebula
Nebula Capsule II User manual
Nebula
Nebula Mars II User manual
Nebula
Nebula Mars II Pro User manual
Nebula
Nebula Capsule D4111 User manual
