NEC POWERMATE PROFESSIONAL - SERVICE 05-1997 User manual

First Printing — May 1997
Copyright 1997 Copyright 1997
NEC Computer Systems Division NEC Corporation
Packard Bell NEC, Inc. 7-1 Shiba 5-Chome, Minato-Ku
1414 Massachusetts Avenue Tokyo 108-01, Japan
Boxborough, MA 01719-2298 All Rights Reserved
All Rights Reserved
PROPRIETARY NOTICE AND LIABILITY DISCLAIMER
The information disclosed in this document, including all designs and related
materials, is the valuable property of NEC Computer Systems Division, Packard Bell NEC,
Inc. (hereinafter “NECCSD”) and/or its licensors. NECCSD and/or its licensors, as appro-
priate, reserve all patent, copyright and other proprietary rights to this document, including
all design, manufacturing, reproduction, use, and sales rights thereto, except to the extent
said rights are expressly granted to others.
The NECCSD product(s) discussed in this document are warranted in accordance with the
terms of the Warranty Statement accompanying each product. However, actual
performance of each such product is dependent upon factors such as system configuration,
customer data, and operator control. Since implementation by customers of each product
may vary, the suitability of specific product configurations and applications must be
determined by the customer and is not warranted by NECCSD.
To allow for design and specification improvements, the information in this document is
subject to change at any time, without notice. Reproduction of this document or portions
thereof without prior written approval of NECCSD is prohibited.
NEC is a registered trademark of NEC Corporation, and FastFacts, MagicEye, MultiSync, and PowerMate
are either trademarks or registered trademarks of NEC Technologies, Inc.; these trademarks are used
under license by Packard Bell, NEC.
All other product, brand, or trade names used in this publication are the trademarks or registered
trademarks of their respective trademark owners.

iii
Contents
Preface.........................................................................................................................xv
Abbreviations...............................................................................................................xvii
Section 1 Technical Information
System Chassis ............................................................................................................1-3
System Board ..............................................................................................................1-4
Processor and Secondary Cache............................................................................1-7
System BIOS........................................................................................................1-7
I/O Addressing......................................................................................................1-9
System Memory....................................................................................................1-10
Interrupt Controller...............................................................................................1-11
Plug and Play........................................................................................................1-12
ISA Bus................................................................................................................1-12
PCI Local Bus ......................................................................................................1-12
PCI/IDE Ports ......................................................................................................1-13
Parallel Interface...................................................................................................1-13
Serial Interface......................................................................................................1-14
Infrared Interface..................................................................................................1-15
Video Board................................................................................................................1-15
Video Support ......................................................................................................1-15
Video Playback.....................................................................................................1-16
Audio ..........................................................................................................................1-17
SCSI Board .................................................................................................................1-18
Diskette Drive..............................................................................................................1-19
Hard Disk Drive...........................................................................................................1-19
IDE Hard Drives...................................................................................................1-19
SCSI Hard Disk....................................................................................................1-20
Sixteen-Speed CD-ROM..............................................................................................1-20
CD-ROM Reader Operation..................................................................................1-20
CD-ROM Reader Settings.....................................................................................1-21
Power Supply..............................................................................................................1-22
Keyboard.....................................................................................................................1-22
Mouse .........................................................................................................................1-22
Speakers......................................................................................................................1-22
Specifications...............................................................................................................1-23

iv Contents
Section 2 Setup and Operation
Unpacking and Repacking............................................................................................2-1
System Setup...............................................................................................................2-1
Keyboard, Mouse, and Power Cable Connection...................................................2-1
Monitor Connection..............................................................................................2-3
Speaker and Microphone Connections...................................................................2-3
Starting Up..................................................................................................................2-7
The Setup Utility..........................................................................................................2-7
When to Use Setup...............................................................................................2-8
How to Start Setup...............................................................................................2-9
How to Use Setup.................................................................................................2-10
Main Menu ...........................................................................................................2-10
System Date/Time..........................................................................................2-11
Diskette Drive................................................................................................2-11
IDE Devices...................................................................................................2-11
Language.......................................................................................................2-13
Boot Options.................................................................................................2-13
Power-On COM1 Ring ..................................................................................2-16
Video Mode...................................................................................................2-16
Mouse............................................................................................................2-16
Base Memory.................................................................................................2-17
Extended Memory..........................................................................................2-17
BIOS Version................................................................................................2-17
Advanced Menu....................................................................................................2-17
Processor Type..............................................................................................2-18
Processor Speed.............................................................................................2-18
Cache Size.....................................................................................................2-18
Peripheral Configuration ................................................................................2-18
Advanced Chipset Configuration....................................................................2-20
Power Management Configuration.................................................................2-22
Plug and Play Configuration...........................................................................2-24
Event Logging Configuration.........................................................................2-26
Security Menu.......................................................................................................2-27
Enter Password and Set Administrative Password..........................................2-29
Unattended Start............................................................................................2-29
Security Hot Key (CTRL-ALT-)....................................................................2-30
Exit Menu.............................................................................................................2-30

Contents v
Exit Saving Changes ......................................................................................2-30
Exit Discarding Changes................................................................................2-31
Load Setup Defaults.......................................................................................2-31
Discard Changes............................................................................................2-31
Flash Utility .................................................................................................................2-31
NECCSD Bulletin Board Service..........................................................................2-32
Flash Utility ..........................................................................................................2-34
SCSISelect Utility........................................................................................................2-35
LANDesk Client Manager............................................................................................2-35
LANDesk Client Manager Setup...........................................................................2-35
Features................................................................................................................2-35
PC Health Indicator ..............................................................................................2-35
Managing Workstations .................................................................................2-35
PC Health Meter............................................................................................2-36
PC Health Description....................................................................................2-36
Inventory..............................................................................................................2-37
Using DMI............................................................................................................2-37
NEC MagicEye Technology..................................................................................2-38
Video Drivers..............................................................................................................2-38
Changing Display Properties .................................................................................2-39
Windows 95...................................................................................................2-39
Windows NT 4.0............................................................................................2-40
CD Restore..................................................................................................................2-41
Selecting CD Restore Options...............................................................................2-41
Restore Individual Files..................................................................................2-41
System Recovery ...........................................................................................2-41
Restoring Individual Files......................................................................................2-42
Selecting Files................................................................................................2-43
Checking Selected Files..................................................................................2-43
Restoring the Files .........................................................................................2-44
Recovering the System..........................................................................................2-44
Windows NT 4.0 Application CD Installation Instructions............................................2-45
McAfee VirusScan Installation..............................................................................2-45
LANDesk Client Manager Installation...................................................................2-46
Local Mode ...................................................................................................2-46
Administrator Mode.......................................................................................2-47
Driver CD Installation Instructions...............................................................................2-48

vi Contents
Driver Installation Guidelines................................................................................2-48
Guidelines for Windows 95 Installations.........................................................2-48
Guidelines for Windows NT Installations........................................................2-49
Driver Installation For the Windows 95 Operating System.....................................2-49
Preparation ....................................................................................................2-49
NEC 16X CD-ROM Drivers..........................................................................2-50
PIIX3 IDE Drivers.........................................................................................2-50
Matrox Mystique Video Drivers.....................................................................2-51
Yamaha Audio Drivers...................................................................................2-52
Driver Installation for the Windows NT Operating System....................................2-53
Preparation ....................................................................................................2-53
PIIX3 IDE Drivers.........................................................................................2-53
Matrox Mystique Video Drivers.....................................................................2-54
Yamaha Audio Drivers...................................................................................2-55
Number Nine Imagine 128 Series 2 Video Drivers..........................................2-56
Section 3 Option Installation
General Rules For Installing Options............................................................................3-1
Precautions...........................................................................................................3-1
Optional Hardware................................................................................................3-2
Removing the System Unit Cover ................................................................................3-3
Removing the Cover .............................................................................................3-3
Replacing the System Unit Cover..........................................................................3-5
Adding Internal Options...............................................................................................3-6
Expansion Boards.................................................................................................3-7
Slot Locations................................................................................................3-8
Expansion Board Installation..........................................................................3-8
Expansion Board Removal.............................................................................3-10
SIMM Upgrade.....................................................................................................3-11
Checking the Memory in the System ..............................................................3-11
SIMM Removal.............................................................................................3-13
SIMM Installation..........................................................................................3-13
Video Upgrade .....................................................................................................3-14
Data Storage Devices............................................................................................3-16
Device Support..............................................................................................3-16
Device Slots...................................................................................................3-16
Device Preparation.........................................................................................3-18

Contents vii
Device Cables ................................................................................................3-18
Diskette Drive Signal Cable............................................................................3-19
IDE Signal Cables..........................................................................................3-20
SCSI Cable ....................................................................................................3-20
System Power Cables.....................................................................................3-21
Cabling an IDE or SCSI Device .....................................................................3-21
Cabling a Diskette Drive ................................................................................3-22
Storage Device Installation....................................................................................3-23
3 1/2-Inch Drive Installation...........................................................................3-23
Removing the Side Panel................................................................................3-26
Removing the Front Panel..............................................................................3-27
Installing the 5 1/4-Inch Device......................................................................3-29
Replacing the Front and Side Panels...............................................................3-31
Adding External Options..............................................................................................3-31
Parallel Printer ......................................................................................................3-32
Serial Devices.......................................................................................................3-32
SCSI Devices........................................................................................................3-33
Section 4 Maintenance and Troubleshooting
Online Services............................................................................................................4-2
NEC’s FastFacts Service.......................................................................................4-2
NECCSD Bulletin Board Service..........................................................................4-3
E-mail/Fax Technical Support Service...................................................................4-5
Internet.................................................................................................................4-5
NECCSD Technical Support Services...................................................................4-6
Maintenance ................................................................................................................4-6
System Cleaning....................................................................................................4-6
Keyboard Cleaning................................................................................................4-7
Mouse Cleaning....................................................................................................4-7
Troubleshooting...........................................................................................................4-8
Error Messages.....................................................................................................4-8
Diagnosing and Solving Problems .........................................................................4-11
Beep Codes...........................................................................................................4-17
CMOS Battery Replacement.................................................................................4-17

viii Contents
Section 5 Repair
Disassembly and Reassembly........................................................................................5-1
System Unit Cover Removal.................................................................................5-2
Side Panel Removal ..............................................................................................5-4
Expansion Board Removal....................................................................................5-4
SIMM Removal....................................................................................................5-5
Front Panel Assembly Removal.............................................................................5-7
Blank Panel and Metal Cover Plate Removal.........................................................5-7
3 1/2-Inch Diskette Drive Removal.......................................................................5-8
3 1/2-Inch Hard Disk Drive Removal....................................................................5-10
5 1/4-Inch Device Removal...................................................................................5-11
Power Supply Removal.........................................................................................5-13
System Board Removal.........................................................................................5-15
Processor Subsystem Removal..............................................................................5-16
Illustrated Parts Breakdown.........................................................................................5-17
Appendix A Connector Pin Assignments
I/O, Power Supply, and Chassis Intrusion Connectors..................................................A-1
Parallel Interface Connector..................................................................................A-2
Serial Interface Connectors ...................................................................................A-3
Keyboard and Mouse Connectors..........................................................................A-4
USB Connectors...................................................................................................A-5
Audio/MIDI Connectors.......................................................................................A-5
Power Supply Connector ......................................................................................A-6
Chassis Intrusion Connector..................................................................................A-7
Storage Device Connectors..........................................................................................A-7
Diskette Drive Connector......................................................................................A-8
IDE Connectors....................................................................................................A-9
LED Connectors..........................................................................................................A-10
Hard Drive LED Connector..................................................................................A-10
Power LED Connector..........................................................................................A-11
Reset Button Connector........................................................................................A-11
Infrared Connector................................................................................................A-12
Sleep Connector....................................................................................................A-12
Power On Connector ............................................................................................A-13
ISA, PCI, and SIMM Connectors.................................................................................A-13

Contents ix
ISA Pin Assignments.............................................................................................A-13
PCI Pin Assignments.............................................................................................A-15
SIMM Sockets......................................................................................................A-16
Appendix B System Board Settings
Changing Jumper Settings............................................................................................B-2
System Board Jumper Locations...........................................................................B-3
Changing System Board Jumper Settings ..............................................................B-4
Processor/Bus Speed Jumpers........................................................................B-4
BIOS Recovery..............................................................................................B-6
Clearing CMOS .............................................................................................B-7
Denying Access to CMOS Setup....................................................................B-8
Clearing the Password....................................................................................B-10
Appendix C Hard Disk Drive Specifications
Hard Disk Drive Specifications ....................................................................................C-1
Appendix D CD-ROM Reader Specifications and Jumper Settings
CD-ROM Reader Specifications...................................................................................D-1
CD-ROM Reader Connectors and Jumper Settings......................................................D-2
List of Figures
1-1 System Controls and Storage Device Slots.....................................................1-3
1-2 Rear Panel Features........................................................................................1-4
1-3 IDE Hard Disk Drive Jumper Settings............................................................1-20
1-4 CD-ROM Reader Controls and Indicators......................................................1-21
1-5 CD-ROM Jumper Settings.............................................................................1-22
2-1 Voltage Selector Switch.................................................................................2-2
2-2 Keyboard/Mouse Connections........................................................................2-2
2-3 Monitor Signal Cable Connection...................................................................2-3
2-4 Right Speaker ................................................................................................2-4
2-5 Speaker Cables...............................................................................................2-4
2-6 Connecting the Two Speakers........................................................................2-5
2-7 Attaching the Microphone and Y-Cable..........................................................2-6
2-8 Connecting the AC Adapter ...........................................................................2-6

x Contents
2-9 Power Button.................................................................................................2-7
2-10 Main Menu ....................................................................................................2-9
2-11 Display Properties Window – Windows 95.....................................................2-39
2-12 Display Properties Window – Windows NT 4.0..............................................2-40
3-1 Cover Screws.................................................................................................3-4
3-2 Releasing the System Unit Cover....................................................................3-5
3-3 System Unit Cover Replacement ....................................................................3-6
3-4 System Board Upgrade Sockets and Connectors............................................3-7
3-5 Expansion Slot Locations...............................................................................3-8
3-6 Removing a Slot Cover..................................................................................3-9
3-7 Inserting the Expansion Board........................................................................3-10
3-8 Removing a SIMM.........................................................................................3-13
3-9 Inserting the SIMM........................................................................................3-14
3-10 Aligning the Video Module with the Socket...................................................3-15
3-11 Storage Device Slots......................................................................................3-17
3-12 System Board Cable Connectors....................................................................3-19
3-13 Diskette Drive Signal Cable............................................................................3-19
3-14 IDE Cable Connectors ...................................................................................3-20
3-15 SCSI Connectors ...........................................................................................3-20
3-16 Power Cable Connectors................................................................................3-21
3-17 Connecting IDE Device Cables ......................................................................3-22
3-18 Connecting 1.2-MB Diskette Drive Cables.....................................................3-22
3-19 Locating the Power Supply............................................................................3-24
3-20 Removing the Power Supply Screws..............................................................3-25
3-21 Securing a 3 1/2-Inch Drive............................................................................3-26
3-22 Removing Side Panel Screws .........................................................................3-27
3-23 Removing the Front Panel..............................................................................3-28
3-24 Removing the Slot Cover...............................................................................3-28
3-25 Attaching the Device Rails .............................................................................3-29
3-26 Inserting the Device .......................................................................................3-30
3-27 Aligning the Front Panel.................................................................................3-31
3-28 Connecting a Printer Cable.............................................................................3-32
3-29 Connecting an RS-232C Cable.......................................................................3-33
3-30 Connecting a SCSI Cable...............................................................................3-34

Contents xi
4-1 Removing the Mouse Ball Cover....................................................................4-8
4-2 Battery Socket Location.................................................................................4-18
4-3 Battery Removal............................................................................................4-18
5-1 Cover Screws.................................................................................................5-3
5-2 Releasing the System Unit Cover....................................................................5-3
5-3 Removing Side Panel Screws .........................................................................5-4
5-4 Expansion Board Removal.............................................................................5-5
5-5 System Board SIMM Sockets........................................................................5-6
5-6 Removing a SIMM.........................................................................................5-6
5-7 Removing the Front Panel..............................................................................5-7
5-8 Removing the Slot Cover...............................................................................5-8
5-9 3 1/2-Inch Diskette Drive Cables....................................................................5-8
5-10 Diskette Drive Screws....................................................................................5-9
5-11 Diskette Drive Removal.................................................................................5-9
5-12 3 1/2-Inch Hard Disk Drive Cables.................................................................5-10
5-13 Removing the 3 1/2-Inch Drive ......................................................................5-11
5-14 Removing the Device.....................................................................................5-12
5-15 Removing the Device Rails.............................................................................5-12
5-16 Power Supply Screws ....................................................................................5-13
5-17 Power Supply Ducting (266-MHz Models) ....................................................5-14
5-18 System Board Removal..................................................................................5-15
5-19 Processor Subsystem Removal.......................................................................5-16
5-20 PowerMate Professional Series Illustrated Parts Breakdown ..........................5-20
A-1 System Board Chassis Intrusion, Power, and I/O Connector Locations...........A-2
A-2 Parallel Interface Connector ...........................................................................A-2
A-3 Serial Interface Connector..............................................................................A-3
A-4 PS/2-Style Keyboard and Mouse Interface Connectors...................................A-4
A-5 Storage Device Connector Locations.............................................................A-7
A-6 LED Connectors............................................................................................A-10
A-7 Hard Disk LED Connector.............................................................................A-10
A-8 Power LED Connector...................................................................................A-11
A-9 Reset Button Connector.................................................................................A-11
A-10 Infrared Connector.........................................................................................A-12

xii Contents
A-11 Sleep Connector.............................................................................................A-12
A-12 Power On Connector .....................................................................................A-13
A-13 PCI, ISA, and SIMM Connector Locations....................................................A-13
B-1 Locating System Configuration Jumpers.........................................................B-3
List of Tables
1-1 PowerMate Professional Series System Configurations...................................1-1
1-2 System Board Feature Components................................................................1-6
1-3 System Memory Map.....................................................................................1-8
1-4 I/O Address Map ...........................................................................................1-9
1-5 Interrupt Level Assignments...........................................................................1-11
1-6 Parallel Port Addressing and Interrupts ..........................................................1-13
1-7 Serial Port Addressing and Interrupts.............................................................1-14
1-8 Matrox Mystique Video Board Support .........................................................1-16
1-9 Number Nine Imagine Video Board Support..................................................1-16
1-10 Audio Subsystem Resources..........................................................................1-18
1-11 Specifications.................................................................................................1-23
2-1 Navigation Keys.............................................................................................2-10
2-2 Hot Key Parameters.......................................................................................2-24
2-3 Security Passwords........................................................................................2-28
3-1 Recommended Memory Upgrade Path...........................................................3-12
4-1 NECCSD Service and Information Telephone Numbers.................................4-1
4-2 System Error Messages..................................................................................4-9
4-3 PCI Error Messages.......................................................................................4-10
4-4 Problems and Solutions..................................................................................4-12
4-5 Diagnostic Beep Codes..................................................................................4-17
5-1 PowerMate Professional Series System Unit Disassembly Sequence...............5-1
5-2 PowerMate Professional Series Field-Replaceable Parts List...........................5-15
5-3 PowerMate Professional Series Options.........................................................5-19
5-4 PowerMate Professional Series Documentation and Packaging.......................5-19

Contents xiii
A-1 System Board Connectors..............................................................................A-1
A-2 Parallel Interface Pin Assignments..................................................................A-3
A-3 Serial Interface Pin Assignments.....................................................................A-4
A-4 Keyboard and Mouse Pin Assignments...........................................................A-4
A-5 USB Port Pin Assignments.............................................................................A-5
A-6 Microphone In Pin Assignments.....................................................................A-5
A-7 Line In Pin Assignments.................................................................................A-5
A-8 Line Out Pin Assignments..............................................................................A-5
A-9 MIDI Pin Assignments...................................................................................A-6
A-10 Power Connector Pin Assignments.................................................................A-6
A-11 Chassis Intrusion Pin Assignments..................................................................A-7
A-12 Diskette Drive Pin Assignments......................................................................A-8
A-13 IDE Interface Pin Assignments.......................................................................A-9
A-14 Hard Disk LED Pin Assignments....................................................................A-10
A-15 Power LED Pin Assignments .........................................................................A-11
A-16 Reset Pin Assignments...................................................................................A-11
A-17 Infrared Pin Assignments................................................................................A-12
A-18 Sleep Pin Assignments ...................................................................................A-12
A-19 Power On Pin Assignments ............................................................................A-13
A-20 ISA Bus Pin Assignments...............................................................................A-14
A-21 PCI Connector Pin Assignments.....................................................................A-15
A-22 SIMM Socket Pin Assignments......................................................................A-16
B-1 System Board Jumper Settings.......................................................................B-4
C-1 Quantum 3.2-GB Hard Disk Specifications ....................................................C-1
C-2 4-GB Seagate Hard Disk Specifications..........................................................C-3
D-1 Specifications for Sixteen-Speed NEC CD-ROM Reader................................D-1
D-2 Jumper A Settings..........................................................................................D-3
D-3 Jumper B Settings..........................................................................................D-4

xiv Contents

xv
Preface
This service and reference manual for NEC PowerMate®Professional Series computer
systems contains hardware and interface information for users who need an overview of
system design. The manual also includes system setup information, procedures for installing
options, and illustrated parts lists. The manual is written for NEC-trained customer
engineers, system analysts, service center personnel, and dealers.
The manual is organized as follows:
Section 1 — Technical Information, provides an overview of the system features,
hardware design, interface ports, and internal devices. System specifications are listed,
including dimensions, weight, environment, safety compliance, power consumption, and
memory.
Section 2 — Setup and Operation, includes unpacking, setup, and operation information.
It contains procedures for configuring the system through the Setup utility program and
reinstalling the system software. This section includes procedures for restoring the
operating system, various drivers, and application programs. Information on using the BIOS
Update utility is also included.
Section 3 — Option Installation, provides installation procedures for adding optional
expansion boards, diskette and hard disk storage devices, and system and video memory.
Section 4 — Maintenance and Troubleshooting, provides information on cleaning the
system and identifying system malfunctions.
Section 5 — Repair, includes disassembly procedures along with an exploded view
diagram of the system. Also included are parts lists for field-replaceable parts.
Appendix A — Connector Pin Assignments, provides a list of the system board’s internal
and external connector pin assignments.
Appendix B — System Board Settings, includes information on setting jumpers for
clearing passwords, resetting CMOS, disabling Setup access, and recovering from a
corrupted BIOS.
Appendix C — Hard Disk Specifications, includes specifications for the IDE and SCSI
hard disk drives provided with the computer.
Appendix D — CD-ROM Reader Specifications and Jumper Settings, provides
specification and jumper setting information for the CD-ROM reader provided with the
computer.
An Index is provided at the end of this guide.

xvii
Abbreviations
Aampere
AC alternating current
ASIC application-specific integrated
circuit
AT advanced technology (IBM PC)
ATA AT attachment
ATAPI AT attachment packet interface
BBS Bulletin Board System
BCD binary-coded decimal
BCU BIOS Customized Utility
BIOS basic input/output system
bit binary digit
BUU BIOS Upgrade Utility
bpi bits per inch
bps bits per second
C capacitance
Ccentigrade
cache high-speed buffer storage
CAM constantly addressable memory
CAS column address strobe
CD-ROM compact disk-ROM
CGA Color Graphics Adapter
CGB Color Graphics Board
CH channel
clk clock
cm centimeter
CMOS complementary metal oxide
semiconductor
COM communication
CONT contrast
CPGA ceramic pin grid array
CPU central processing unit
DAC digital-to-analog converter
DACK DMA acknowledge
db decibels
DC direct current
DIP dual in-line package
DMA direct memory access
DMAC DMA controller
DOS disk operating system
DRAM dynamic RAM
ECC error checking and correction
ECP enhanced capabilities port (ECP)
EGA Enhanced Graphics Adapter
EPP Enhanced Parallel Port
EPROM erasable and programmable ROM
EVGA Enhanced Video Graphics Array
F Fahrenheit
FAX facsimile transmission
FCC Federal Communications
Commission
FG frame ground
FIFO first-in/first-out
FM frequency modulation
FRU field-replaceable unit
ftp file transfer protocol
GB gigabyte
GND ground
HEX hexadecimal
HGA Hercules Graphics Adapter
Hz hertz
IC integrated circuit
ID identification
IDE intelligent device electronics
in. inch
IPB illustrated parts breakdown
ISA Industry Standard Architecture
I/O input/output
IPC integrated peripheral controller
ips inches per second
IR infrared
IRQ interrupt request
K kilo (1024)
k kilo (1000)

xviii Abbreviations
KB kilobyte
kg kilogram
kHz kilohertz
lb pound
LED light-emitting diode
Mmega
mA milliamps
max maximum
MB megabyte
MDA Monochrome Display Adapter
MFM modified frequency modulation
MHz megahertz
MIC microphone
MIDI musical instrument device
interface
MPC multimedia PC
mm millimeter
MPEG Motion Picture Experts Group
ms millisecond
NC not connected
NMI Non-maskable Interrupt
ns nanosecond
PAL programmable array logic
PC personal computer
PCI Peripheral Component
Interconnect
PDA personal digital assistant
PFP plastic flat package
PIO parallel input/output
pixel picture element
PROM programmable ROM
RAM random-access memory
RAMDAC RAM digital-to-analog converter
RGB red green blue
RGBI red green blue intensity
RM retention mechanism
ROM read-only memory
rpm revolutions per minute
Rread
RTC real-time clock
R/W read/write
Sslave
SCSI Small Computer System Interface
SG signal ground
SIMM single inline memory module
SVGA Super Video Graphics Array
SW switch
TSC Technical Support Center
TTL transistor/transistor logic
tpi tracks per inch
V volt
Vac volts, alternating current
Vdc volts, direct current
VESA video electronics standards
association
VGA Video Graphics Array
VRAM video RAM
Wwatt
Wwrite
WWW world-wide web

Section 1
Technical Information
This section provides technical information about PowerMate®Professional Series
computers. PowerMate Professional Series computers are Intel®Pentium®II processor-
based systems with MMX™ and cache memory enhancements.
Depending on the model, the PowerMate Professional Series computer comes with a
Pentium II 233-MHz or 266-MHz microprocessor and the Windows®95 or Windows
NT®4.0 operating system. Multimedia and SCSI configurations are available in six models
as described in Table 1-1.
Table 1-1 PowerMate Professional Series System Configurations
Model Number Processor Operating System System Memory Video Memory Hard Disk
MT-2550-24874X 233-MHz
Pentium II Windows 95 32 MB 2 MB synchronous
graphics RAM
(SGRAM) on
Matrox Mystique®
video board
3.2-GB IDE
MT-2560-24874X 266-MHz
Pentium II Windows 95 32 MB 2 MB synchronous
graphics RAM
(SGRAM) on
Matrox Mystique
video board
3.2-GB IDE
MT-2560-24874C 266-MHz
Pentium II Windows NT 4.0 32 MB 2 MB synchronous
graphics RAM
(SGRAM) on
Matrox Mystique
video board
3.2-GB IDE
MT-2550-24874C 233-MHz
Pentium II Windows NT 4.0 32 MB 2 MB synchronous
graphics RAM
(SGRAM) on
Matrox Mystique
video board
3.2-GB IDE
MT-2560-2784S 266-MHz
Pentium II Windows NT 4.0 32 MB 4 MB video RAM (VRAM) on
Number Nine
Imagine™ 128
Series 2 video
board
4.35-GB SCSI

1-2 Technical Information
Table 1-1 PowerMate Professional Series System Configurations
Model Number Processor Operating System System Memory Video Memory Hard Disk
MT-2560-2785S 266-MHz
Pentium II Windows NT 4.0 64 MB 4 MB VRAM on Number Nine
Imagine 128
Series 2 video
board
4.35-GB IDE
All PowerMate Professional Series configurations come with the following common
hardware:

3 1/2-inch diskette drive

512-kilobyte (KB) burst-rate synchronous secondary cache (BSRAM)

sixteen-speed (maximum) CD-ROM reader

8-watt (W) external speakers.
The PowerMate Professional SCSI configuration comes with the above features and an
Adaptec SCSI controller board.
NOTE: All PowerMate Professional Series
systems contain audio connectors on the system
board that are accessible on the rear of the
system unit.
The following paragraphs give an overview of the PowerMate Professional Series systems.
Differences between the systems are noted as they occur.

Technical Information 1-3
SYSTEM CHASSIS
The chassis provides an enclosure for the system board, power supply, six PCI/ISA
expansion slots, and six storage device slots. The expansion slots include two 8-/16-bit ISA
slots, one shared PCI/ISA slot, and three 32-bit PCI slots. One PCI slot contains either a
Matrox Mystique or a Number Nine Imagine 128 Series 2 video board, depending on the
model.
The six storage device slots accommodate up to four accessible devices and two internal
hard disk drive devices. The accessible devices include the standard one-inch high 3 1/2-
inch 1.44-MB diskette drive and up to three 1.6-inch high 5 1/4-inch storage devices. The
internal device slots support up to two 1-inch high 3 1/2-inch hard disks.
Figure 1-1 shows the front panel features and the locations of the accessible storage device
slots in a system. Figure 1-2 shows the features on the rear panel of the system chassis.
Figure 1-1 System Controls and Storage Device Slots
NOTE: The Matrox Mystique video board
installed in some models contains a video module
feature connector, in addition to the standard
VGA connector. The Number Nine Imagine 128
Series 2 video board installed in some models
contains only the standard VGA connector.

1-4 Technical Information
Figure 1-2 Rear Panel Features
SYSTEM BOARD
The system board includes the following features:

Intel Pentium II microprocessor running at 233- or 266-MHz (model dependent)

Intel 82440FX PCI chipset used for PCI/ISA, memory, and peripheral control

PC87308 Super I/O controller (integrates standard PC I/O functions: two serial
ports, one EPP/ECP-capable parallel port, floppy disk interface, real time clock,
CMOS RAM, keyboard controller, and support for an IrDA-compatible infrared
interface)

PCI and ISA peripheral connectors on the system board

Support for up to 256 MB of 60 nanosecond (ns) single in-line memory modules
(SIMMs)

Intel BIOS in a 2-MB flash memory device supports system setup and PCI auto-
configuration

Sound Blaster Pro™-compatible Yamaha audio chip

Expansion slots for up to five add-in boards
Three dedicated PCI slots
Two dedicated ISA-bus slots
One combination slot for either a PCI or an ISA add-in board
