NEC POWERMATE User manual

First Printing — March 1996
Copyright 1996 Copyright 1996
NEC Technologies, Inc. NEC Corporation
1414 Massachusetts Avenue 7-1 Shiba 5-Chome, Minato-Ku
Boxborough, MA 01719 Tokyo 108-01, Japan
All Rights Reserved All Rights Reserved
PROPRIETARY NOTICE AND LIABILITY DISCLAIMER
The information disclosed in this document, including all designs and related materials, is
the valuable property of NEC Corporation (NEC) and/or its licensors. NEC and/or its licen-
sors, as appropriate, reserve all patent, copyright and other proprietary rights to this docu-
ment, including all design, manufacturing, reproduction, use, and sales rights thereto, except
to the extent said rights are expressly granted to others.
The NEC product(s) discussed in this document are warranted in accordance with the terms
of the Warranty Statement accompanying each product. However, actual performance of
each such product is dependent upon factors such as system configuration, customer data,
and operator control. Since implementation by customers of each product may vary, the
suitability of specific product configurations and applications must be determined by the
customer and is not warranted by NEC.
To allow for design and specification improvements, the information in this document is
subject to change at any time, without notice. Reproduction of this document or portions
thereof without prior written approval of NEC is prohibited.
MultiSync and PowerMate are U.S. registered trademarks of NEC Technologies, Inc.
FastFacts is a U.S. trademark of NEC Technologies, Inc.
All other product, brand, or trade names used in this publication are the trademarks or registered
trademarks of their respective trademark owners.

iii
Contents
Preface......................................................................................................................... xv
Abbreviations............................................................................................................... xvii
Section 1 Technical Information
Desktop System Chassis............................................................................................... 1-3
Minitower System Chassis ........................................................................................... 1-4
System Board .............................................................................................................. 1-5
Processor.............................................................................................................. 1-7
Secondary Cache .................................................................................................. 1-8
System and Video BIOS ....................................................................................... 1-8
System Memory.................................................................................................... 1-9
Integrated Graphics............................................................................................... 1-11
Motion Video Controller............................................................................... 1-11
Graphics Accelerator..................................................................................... 1-11
Video Memory.............................................................................................. 1-11
Interrupt Controller............................................................................................... 1-12
I/O Addressing...................................................................................................... 1-14
ISA Bus................................................................................................................ 1-15
PCI Local Bus ...................................................................................................... 1-15
PCI Auto Configuration........................................................................................ 1-15
PCI/IDE Ports ...................................................................................................... 1-15
Parallel Interface................................................................................................... 1-16
Serial Interface...................................................................................................... 1-16
Infrared Interface.................................................................................................. 1-17
Power Supply .............................................................................................................. 1-18
Diskette Drive.............................................................................................................. 1-18
Hard Disk Drive........................................................................................................... 1-18
Keyboard..................................................................................................................... 1-19
Mouse ......................................................................................................................... 1-19
Multimedia Components.............................................................................................. 1-19
Integrated Audio................................................................................................... 1-19
CD-ROM Reader.................................................................................................. 1-20
Speakers............................................................................................................... 1-20
Microphone .......................................................................................................... 1-20

iv Contents
Network Board............................................................................................................ 1-20
Plug and Play............................................................................................................... 1-20
Power Management..................................................................................................... 1-21
Desktop Management Interface.................................................................................... 1-21
DMI Components................................................................................................. 1-21
Manageable Components ...................................................................................... 1-22
CI Module ............................................................................................................ 1-22
DMI Browser ....................................................................................................... 1-22
Usage ................................................................................................................... 1-23
DMI Troubleshooting ........................................................................................... 1-24
Specifications............................................................................................................... 1-25
Section 2 Setup and Operation
Unpacking and Repacking............................................................................................ 2-1
Setup........................................................................................................................... 2-1
Desktop Setup...................................................................................................... 2-1
Minitower Setup................................................................................................... 2-6
CD-ROM Reader......................................................................................................... 2-11
System Configuration................................................................................................... 2-12
Setup Utility.......................................................................................................... 2-12
How to Start Setup............................................................................................... 2-13
How to Use Setup................................................................................................. 2-14
Menu Bar...................................................................................................... 2-14
Legend Bar................................................................................................... 2-15
Field Help Window ....................................................................................... 2-16
General Help Window................................................................................... 2-16
Main Menu Options ...................................................................................... 2-16
IDE Adapters................................................................................................ 2-17
Memory Cache.............................................................................................. 2-19
Memory Shadow........................................................................................... 2-19
Boot Options ................................................................................................ 2-20
Numlock....................................................................................................... 2-20
Advanced Menu.................................................................................................... 2-21
Integrated Peripherals Menu.......................................................................... 2-21
Security Menu....................................................................................................... 2-23
Power Menu......................................................................................................... 2-24
Boot Menu ........................................................................................................... 2-25

Contents v
Exit Menu............................................................................................................. 2-26
Save Changes & Exit .................................................................................... 2-26
Discard Changes & Exit................................................................................ 2-26
Get Default Values........................................................................................ 2-27
Load Previous Values ................................................................................... 2-27
Save Changes................................................................................................ 2-27
BIOS Update Utility .................................................................................................... 2-27
NEC Bulletin Board Service.................................................................................. 2-28
Using the BIOS Update Utility.............................................................................. 2-29
Section 3 Option Installation
General Rules for Installing Options............................................................................. 3-1
Precautions.................................................................................................................. 3-2
Removing the System Unit Cover ................................................................................ 3-3
Removing the Desktop Cover ............................................................................... 3-3
Removing the Minitower Cover ............................................................................ 3-5
Expansion Boards........................................................................................................ 3-6
Expansion Slot Locations...................................................................................... 3-7
Expansion Board Installation................................................................................. 3-8
Inside Slot Expansion Board Installation ....................................................... 3-11
System Board Options ................................................................................................. 3-12
SIMM Upgrade..................................................................................................... 3-13
Checking System Memory............................................................................. 3-13
SIMM Removal ............................................................................................ 3-15
SIMM Installation......................................................................................... 3-16
Video Upgrade ..................................................................................................... 3-17
Processor Upgrade................................................................................................ 3-18
Processor Removal ....................................................................................... 3-18
Processor Installation.................................................................................... 3-19
MIDI/Joystick Upgrade ............................................................................................... 3-19
Data Storage Devices................................................................................................... 3-21
Device Slots.......................................................................................................... 3-21
Device Preparation................................................................................................ 3-23
Device Cables....................................................................................................... 3-23
Diskette Drive Signal Cable........................................................................... 3-24
IDE Signal Cables......................................................................................... 3-24
System Power Cables.................................................................................... 3-25

vi Contents
Device Cabling...................................................................................................... 3-26
Cabling an IDE Device.................................................................................. 3-26
Cabling a Diskette Drive ............................................................................... 3-27
Desktop Storage Device Installation...................................................................... 3-27
Removing the Desktop 3 1/2-Inch Drive Bracket .......................................... 3-28
Installing the Desktop 3 1/2-Inch Drive......................................................... 3-28
Removing the Desktop Front Panel............................................................... 3-29
Installing the Desktop 5 1/4-Inch Device....................................................... 3-31
Replacing the Desktop Front Panel................................................................ 3-32
Replacing the Desktop 3 1/2-Inch Drive Bracket........................................... 3-32
Minitower Storage Device Installation................................................................... 3-33
Installing the 3 1/2-Inch Drive into the Minitower Internal Front Slot............ 3-34
Installing a 3 1/2-Inch Drive into a Minitower Rear Slot................................ 3-34
Removing the Minitower Front Panel............................................................ 3-36
Installing the Minitower 5 1/4-Inch Device.................................................... 3-38
Replacing the Minitower Front Panel............................................................. 3-40
Adding External Options.............................................................................................. 3-41
Parallel Printer ...................................................................................................... 3-41
RS-232C Device Connection................................................................................. 3-42
Section 4 Maintenance and Troubleshooting
Maintenance ................................................................................................................ 4-1
System Cleaning.................................................................................................... 4-2
Keyboard Cleaning................................................................................................ 4-2
Mouse Cleaning.................................................................................................... 4-3
Troubleshooting........................................................................................................... 4-4
Diagnosing and Solving Problems ......................................................................... 4-4
CMOS Battery Replacement................................................................................. 4-8
Section 5 Desktop Repair
Disassembly and Reassembly........................................................................................ 5-1
System Unit Cover Removal ................................................................................. 5-2
Expansion Board Removal.................................................................................... 5-3
PCI/ISA Backboard Removal................................................................................ 5-5
3 1/2-inch Diskette and Hard Disk Drive Removal ................................................ 5-5
Front Panel Assembly Removal............................................................................. 5-7
Blank Panel Removal ............................................................................................ 5-8

Contents vii
Speaker Assembly Removal .................................................................................. 5-8
SIMM Removal.................................................................................................... 5-9
5 1/4-Inch Device Removal................................................................................... 5-10
Power Supply Removal......................................................................................... 5-11
System Board Removal......................................................................................... 5-13
Illustrated Parts Breakdown.................................................................................. 5-14
Section 6 Minitower Repair
Disassembly and Reassembly........................................................................................ 6-1
System Unit Cover Removal ................................................................................. 6-2
Expansion Board Removal.................................................................................... 6-4
SIMM Removal.................................................................................................... 6-4
Front 3 1/2-Inch Drive Removal............................................................................ 6-6
3 1/2-inch Diskette Drive Removal........................................................................ 6-7
Front Panel Assembly Removal............................................................................. 6-7
Blank Panel and Metal Cover Plate Removal......................................................... 6-8
5 1/4-Inch Device Removal................................................................................... 6-9
Rear 3 1/2-Inch Drive Removal............................................................................. 6-11
Card Guide/Fan Bracket Removal......................................................................... 6-12
Speaker Assembly Removal .................................................................................. 6-13
Power Supply Removal......................................................................................... 6-14
PCI/ISA Backboard Removal................................................................................ 6-15
System Board Removal......................................................................................... 6-15
Illustrated Parts Breakdown.................................................................................. 6-17
Appendix A Connector Pin Assignments
CD Audio Connector Pin Assignments......................................................................... A-3
Serial Interface Connectors.......................................................................................... A-3
Parallel Interface Connector......................................................................................... A-4
VGA Interface Connector Pin Assignments.................................................................. A-5
Speaker Connector Pin Assignments ............................................................................ A-5
Power Supply Connector ............................................................................................. A-6
Keyboard and Mouse Connectors................................................................................. A-6
IRDA Connector.......................................................................................................... A-7
Suspend Button Connector .......................................................................................... A-7
Fan Connector............................................................................................................. A-7
Diskette Drive Interface Pin Assignments..................................................................... A-8

viii Contents
IDE Interface Connectors ............................................................................................ A-9
SIMM Sockets............................................................................................................. A-10
ISA/PCI-Bus Backboard Connector Pin Assignments...................................................A-11
ISA Expansion Bus Connector Pin Assignments...........................................................A-13
Appendix B System Board Jumpers
Jumper Locations......................................................................................................... B-1
Changing Processor Jumper Settings............................................................................ B-2
Changing the Password................................................................................................ B-4
Clearing CMOS........................................................................................................... B-5
Appendix C Hard Disk Drive Specifications and Jumper Settings
Hard Disk Drive Specifications .................................................................................... C-1
540-MB Hard Disk Drive Jumper Settings................................................................... C-3
850-MB Hard Disk Drive Jumper Settings................................................................... C-4
1.2-GB Hard Disk Drive Jumper Settings..................................................................... C-5
1.6-GB Hard Disk Drive Jumper Settings..................................................................... C-6
Appendix D CD-ROM Reader Specifications and Jumper Settings
CD-ROM Reader Specifications................................................................................... D-1
CD-ROM Reader Connectors and Jumper Settings ...................................................... D-2
List of Figures
1-1 Desktop System Controls and Storage Device Slots....................................... 1-3
1-2 Minitower System Controls and Storage Device Slots.................................... 1-4
2-1 Desktop Voltage Selector Switch................................................................... 2-2
2-2 Desktop Peripheral Connections..................................................................... 2-2
2-3 Desktop Network Board Connections............................................................ 2-3
2-4 Assembling the Microphone Holder................................................................ 2-4
2-5 Connecting the Microphone ........................................................................... 2-4
2-6 Desktop Power Button, Lamps, and Suspend Button ..................................... 2-5
2-7 Minitower Voltage Selector Switch................................................................ 2-6
2-8 Minitower Peripheral Connections.................................................................. 2-7
2-9 Minitower Network Board Connections......................................................... 2-7
2-10 Assembling the Microphone Holder................................................................ 2-8

Contents ix
2-11 Connecting the Microphone ........................................................................... 2-9
2-12 Minitower Power Button, Lamps, and Suspend Button .................................. 2-10
2-13 Typical CD-ROM Reader Controls and Indicators.......................................... 2-11
3-1 Removing Desktop Cover Screws.................................................................. 3-3
3-2 Releasing the Desktop Cover ......................................................................... 3-4
3-3 Removing Minitower Cover Screws............................................................... 3-5
3-4 Releasing the Cover ....................................................................................... 3-6
3-5 Locating Desktop Expansion Slots................................................................. 3-7
3-6 Locating Minitower Expansion Slots.............................................................. 3-8
3-7 Removing a Slot Cover in the Desktop........................................................... 3-9
3-8 Removing a Slot Cover in the Minitower........................................................ 3-9
3-9 Inserting the Board in the Desktop................................................................. 3-10
3-10 Inserting the Board in the Minitower.............................................................. 3-10
3-11 Removing the Slot Cover Support Screws...................................................... 3-11
3-12 Attaching the Slot Cover Support .................................................................. 3-12
3-13 System Board Upgrade Sockets and Connectors............................................ 3-12
3-14 Removing a SIMM......................................................................................... 3-15
3-15 Inserting the SIMM........................................................................................ 3-16
3-16 Aligning the Video DRAM Module with the Socket....................................... 3-17
3-17 Removing the Metal MIDI/Joystick Punch-Out in the Desktop....................... 3-20
3-18 Removing the Metal MIDI/Joystick Punch-Out in the Minitower.................... 3-21
3-19 Locating Device Slots in the Desktop............................................................. 3-22
3-20 Locating Device Slots in the Minitower.......................................................... 3-22
3-21 System Board Cable Connectors.................................................................... 3-23
3-22 Optional Diskette Drive Connector ................................................................ 3-24
3-23 Optional IDE Cable Connector....................................................................... 3-25
3-24 Power Cable Connectors................................................................................ 3-25
3-25 Connecting IDE Device Cables ...................................................................... 3-26
3-26 Connecting 1.2-MB Diskette Drive Cables..................................................... 3-27
3-27 Removing the 3 1/2-Inch Drive Bracket ......................................................... 3-28
3-28 Securing a 3 1/2-Inch Drive............................................................................ 3-29
3-29 Removing the Front Panel.............................................................................. 3-30
3-30 Locating the Blank Panel Tabs....................................................................... 3-30
3-31 Securing the Device ....................................................................................... 3-31
3-32 Aligning the Desktop Front Panel................................................................... 3-32
3-33 Securing the 3 1/2-Inch Drive Bracket............................................................ 3-33

x Contents
3-34 Left Side Drive Screws .................................................................................. 3-34
3-35 Removing the Drive Bracket Screws.............................................................. 3-35
3-36 Securing the Drive to the Bracket................................................................... 3-35
3-37 Removing the Front Panel.............................................................................. 3-36
3-38 Locating the Blank Panel Tabs....................................................................... 3-37
3-39 Locating the Slot Cover................................................................................. 3-37
3-40 Attaching the Device Rails ............................................................................. 3-38
3-41 Front and Left Side Device Screws................................................................. 3-39
3-42 Right Side Device Screws .............................................................................. 3-39
3-43 Aligning the Minitower Front Panel................................................................ 3-40
3-44 Connecting a Printer Cable to the Desktop..................................................... 3-41
3-45 Connecting a Printer Cable to the Minitower.................................................. 3-42
3-46 Connecting an RS-232C Cable to the Desktop ............................................... 3-43
3-47 Connecting an RS-232C Cable to the Minitower ............................................ 3-43
4-1 Removing the Mouse Ball Cover.................................................................... 4-3
4-2 Battery Socket Location................................................................................. 4-8
4-3 Battery Removal ............................................................................................ 4-9
4-4 RTC Chip Removal........................................................................................ 4-9
5-1 System Unit Cover Screws............................................................................. 5-3
5-2 Removing the System Unit Cover................................................................... 5-3
5-3 Expansion Slot Screw .................................................................................... 5-4
5-4 Inside Expansion Slot Screw.......................................................................... 5-4
5-5 PCI/ISA Backboard Screws........................................................................... 5-5
5-6 3 1/2-Inch Drive Bracket................................................................................ 5-6
5-7 3 1/2-Inch Diskette and Hard Disk Drive Screws............................................ 5-6
5-8 Front Panel Tabs............................................................................................ 5-7
5-9 Blank Panel Tabs ........................................................................................... 5-8
5-10 Internal Speaker............................................................................................. 5-9
5-11 SIMM Socket................................................................................................ 5-9
5-12 5 1/4-Inch Device Screws............................................................................... 5-10
5-13 Power Button Screws .................................................................................... 5-11
5-14 Power Supply Screws .................................................................................... 5-12
5-15 System Board Connectors and Screws ........................................................... 5-13
5-16 PowerMate V Desktop Illustrated Parts Breakdown....................................... 5-16

Contents xi
6-1 Removing Minitower Cover Screws............................................................... 6-3
6-2 Releasing the Cover ....................................................................................... 6-3
6-3 Removing the Screw in the Minitower............................................................ 6-4
6-4 System Board Upgrade SIMM Sockets.......................................................... 6-5
6-5 Removing a SIMM......................................................................................... 6-5
6-6 Right Side Front Internal Drive Screws.......................................................... 6-6
6-7 Left Side Front Internal Drive Screws ............................................................ 6-6
6-8 Diskette Drive Bracket Screws....................................................................... 6-7
6-9 Removing the Front Panel.............................................................................. 6-8
6-10 Locating the Blank Panel Tabs....................................................................... 6-8
6-11 Locating and Removing the Slot Covers......................................................... 6-9
6-12 Front and Left Side Device Screws................................................................. 6-10
6-13 Right Side Device Screws .............................................................................. 6-10
6-14 Removing the Device Rails............................................................................. 6-11
6-15 Removing the Drive Bracket Screws.............................................................. 6-11
6-16 Securing the Drive to the Bracket................................................................... 6-12
6-17 Removing the Card Guide/Fan Bracket Assembly........................................... 6-13
6-18 Speaker.......................................................................................................... 6-13
6-19 Power Supply Screws .................................................................................... 6-14
6-20 PCI/ISA Backboard....................................................................................... 6-15
6-21 System Board Removal.................................................................................. 6-16
6-22 PowerMate V Minitower Illustrated Parts Breakdown.................................... 6-19
A-1 System Board Layout..................................................................................... A-1
A-2 Detailed Front System Board Connectors....................................................... A-2
A-3 Power Supply Connector Pin Assignments..................................................... A-6
B-1 System Board Jumper Locations .................................................................... B-1
B-2 Processor Settings with One BF Jumper......................................................... B-3
B-3 Processor Settings with Two BF Jumpers (BF0 and BF1) .............................. B-4
C-1 Quantum 540-MB Jumper Settings ................................................................ C-3
C-2 Western Digital 850-MB Jumper Settings....................................................... C-4
C-3 Conner 1.2- and 1.6-GB Jumper Settings ....................................................... C-5

xii Contents
List of Tables
1-1 First Release of System Configurations........................................................... 1-1
1-2 Second Release of System Configurations...................................................... 1-2
1-3 System Board Chips....................................................................................... 1-7
1-4 System Memory Map..................................................................................... 1-9
1-5 SIMM Memory Upgrade Path........................................................................ 1-10
1-6 Interrupt Assignments .................................................................................... 1-13
1-7 I/O Address Map ........................................................................................... 1-14
1-8 Parallel Port Addressing and Interrupts .......................................................... 1-16
1-9 Serial Port Addressing and Interrupts............................................................. 1-17
1-10 Specifications................................................................................................. 1-25
2-1 Setup Key Functions ...................................................................................... 2-15
2-2 Main Menu Parameters .................................................................................. 2-17
2-3 IDE Hard Disk Parameters............................................................................. 2-18
2-4 Memory Cache Parameters............................................................................. 2-19
2-5 Boot Parameters ............................................................................................ 2-20
2-6 Numlock Parameters...................................................................................... 2-20
2-7 Advanced Menu Parameters........................................................................... 2-21
2-8 Integrated Peripherals Parameters .................................................................. 2-22
2-9 System Security Options ................................................................................ 2-23
2-10 Power Management Parameters ..................................................................... 2-25
3-1 Recommended Memory Upgrade Path ........................................................... 3-14
4-1 NEC Service and Information Telephone Numbers......................................... 4-1
4-2 Problems and Solutions.................................................................................. 4-4
5-1 PowerMate V Desktop Disassembly Sequence............................................... 5-1
5-2 PowerMate V Desktop Field-Replaceable Parts List....................................... 5-14
5-3 PowerMate V Desktop Options ..................................................................... 5-17
5-4 PowerMate V Desktop Documentation and Packaging................................... 5-17
6-1 PowerMate V Minitower Disassembly Sequence............................................ 6-1
6-2 PowerMate V Minitower Field-Replaceable Parts List.................................... 6-17
6-3 PowerMate V Minitower Options .................................................................. 6-20
6-4 PowerMate V Minitower Documentation and Packaging................................ 6-20

Contents xiii
A-1 System Board Connectors.............................................................................. A-2
A-2 CD Audio in Connector ................................................................................. A-3
A-3 Serial Port Connector Pin Assignments .......................................................... A-3
A-4 Parallel Port Connector Pin Assignments........................................................ A-4
A-5 VGA Interface Connector Pin Assignments.................................................... A-5
A-6 Speaker Connector Pin Assignments .............................................................. A-5
A-7 Keyboard and Mouse Connector Pin Assignments.......................................... A-6
A-8 IRDA Connector Pin Assignments ................................................................. A-7
A-9 Suspend Connector Pin Assignments.............................................................. A-7
A-10 Fan Connector Pin Assignments..................................................................... A-7
A-11 Diskette Drive Connector Pin Assignments .................................................... A-8
A-12 IDE Connector Pin Assignments .................................................................... A-9
A-13 SIMM Socket Pin Assignments......................................................................A-10
A-14 ISA/PCI Backboard Connector Pin Assignments............................................A-11
A-15 ISA Expansion Slot Pin Assignments..............................................................A-13
C-1 Hard Disk Drive Specifications....................................................................... C-1
D-1 CD-ROM Reader Specifications..................................................................... D-1

xv
Preface
This service and reference manual contains the technical information necessary to set up,
maintain, troubleshoot, and repair the NEC PowerMateV series computer systems. It also
provides hardware and interface information for users who need an overview of the
computer system design. The manual is written for NEC-trained customer engineers, system
analysts, service center personnel, and dealers.
The manual is organized as follows:
Section 1, Technical Information, provides an overview of the computer features,
hardware design, interface ports, internal devices and system unit specifications.
Section 2, Setup and Operation, gives general setup and operation information. Included
is a description of the system Setup utility and the factory default configuration settings. A
procedure is provided for logging onto the NEC Bulletin Board and obtaining the latest
Flash ROM BIOS.
Section 3, Options, provides safety precautions and installation procedures for installing
options.
Section 4, Maintenance and Troubleshooting, includes a list of NEC service information
and telephone numbers that provide access to the NEC Bulletin Board System (BBS),
FastFacts, and Technical Information Bulletins. Recommended maintenance information
and solutions to possible problems that may occur, are also provided.
Section 5, Desktop Repair, provides desktop disassembly and reassembly procedures
along with an illustrated parts breakdown. NEC service and spare parts ordering
information is also provided.
Section 6, Minitower Repair, provides minitower disassembly and reassembly procedures
along with an illustrated parts breakdown. NEC service and spare parts ordering
information is also provided.
Appendix A, Connector Pin Assignments, provides a list of the system board’s internal
connector pin assignments and a list of external pin assignments for the keyboard/mouse,
serial port, parallel port, and video port.
Appendix B, System Board Jumpers, provides jumper information for configuring the
system for a particular requirement.
Appendix C, Hard Disk Drive Specifications and Jumper Settings, provides
specifications and jumper settings for the hard disk drives that ship with the PowerMate V
series systems.
Appendix D, CD-ROM Reader Specifications and Jumper Settings, provides
specifications and jumper settings for the CD-ROM readers that ship with the PowerMate V
series systems.

xvi Preface

xvii
Abbreviations
A ampere
AC alternating current
AT advanced technology (IBM PC)
BBS Bulletin Board System
BCD binary-coded decimal
BCU BIOS Customized Utility
BIOS basic input/output system
bit binary digit
BUU BIOS Upgrade Utility
bpi bits per inch
bps bits per second
C capacitance
C centigrade
Cache high-speed buffer storage
CAM constantly addressable memory
CAS column address strobe
CD-ROM compact disk-ROM
CGA Color Graphics Adapter
CGB Color Graphics Board
CH channel
clk clock
cm centimeter
CMOS complementary metal oxide
semiconductor
COM communication
CONT contrast
CPGA ceramic pin grid array
CPU central processing unit
DAC digital-to-analog converter
DACK DMA acknowledge
db decibels
DC direct current
DIP dual in-line package
DMA direct memory access
DMAC DMA controller
DOS disk operating system
DRAM dynamic RAM
ECC error checking and correction
ECP enhanced capabilities port (ECP)
EGA Enhanced Graphics Adapter
EPP Enhanced Parallel Port
EPROM erasable and programmable ROM
EVGA Enhanced Video Graphics Array
F Fahrenheit
FAX facsimile transmission
FCC Federal Communications Commission
FG frame ground
FIFO first-in/first-out
FM frequency modulation
FRU field-replaceable unit
GB gigabyte
GND ground
HEX hexadecimal
HGA Hercules Graphics Adapter
Hz hertz
IC integrated circuit
ID identification
IDE intelligent device electronics
in. inch
IPB illustrated parts breakdown
ISA Industry Standard Architecture
I/O input/output
IPC integrated peripheral controller
ips inches per second
IR infrared
IRQ interrupt request
K kilo (1024)
k kilo (1000)
KB kilobyte
kg kilogram
kHz kilohertz
lb pound
LED light-emitting diode
M mega

xviii Abbreviations
mA milliamps
max maximum
MB megabyte
MDA Monochrome Display Adapter
MFM modified frequency modulation
MHz megahertz
MIC microphone
MIDI musical instrument device interface
MPC multimedia PC
mm millimeter
MPEG Motion Picture Experts Group
ms millisecond
NASC National Authorized Service Center
NC not connected
NMI Non-maskable Interrupt
ns nanosecond
NSRC National Service Response Center
PAL programmable array logic
PC personal computer
PCI Peripheral Component Interconnect
PDA personal digital assistant
PFP plastic flat package
PIO parallel input/output
pixel picture element
PROM programmable ROM
RAM random-access memory
RAMDAC RAM digital-to-analog converter
RGB red green blue
RGBI red green blue intensity
ROM read-only memory
rpm revolutions per minute
R read
RTC real-time clock
R/W read/write
S slave
SCSI Small Computer System Interface
SG signal ground
SIMM single inline memory module
SVGA Super Video Graphics Array
SW switch
TAC Technical Assistance Center
TSC Technical Support Center
TTL transistor/transistor logic
tpi tracks per inch
V volt
Vac volts, alernating current
Vdc volts, direct current
VESA video electronics standards
association
VGA Video Graphics Array
VRAM video RAM
W watt
W write

Section 1
Technical Information
The PowerMate®V Series of desktop and minitower systems come standard with an Intel
Pentium™ processor, a 3 1/2-inch 1.44 megabyte (MB) diskette drive, 256 kilobyte (KB)
secondary cache, 8- or 16-MB random access memory (RAM), and 1 MB of video dynamic
random access memory (DRAM).
The first release of the PowerMate V system configurations are listed in Table 1-1. See
Table 1-2 for the PowerMate V configurations released in March of 1996.
Table 1-1 First Release of System Configurations
Configurations PowerMate V75 (75 MHz) PowerMate V90 (90 MHz) PowerMate V100 (100 MHz)
Diskless 3 1/2-Inch diskette
drive onl
y
8 MB of RAM
Not available Not available
Hard disk system 3 1/2-inch diskette drive
540 MB hard disk
with 8 MB of RAM
or
1.2 GB hard disk
with 16 MB of RAM
3 1/2-inch diskette drive
540 MB hard disk
with 8 MB of RAM
or
1.2 GB hard disk
with 16 MB of RAM
3 1/2-inch diskette drive
540 MB hard disk
with 8 MB of RAM
or
1.2 GB hard disk
with 16 MB of RAM
Network-read
y
system 3 1/2-inch diskette drive 1.2 GB hard disk
Network board
8 MB of RAM
3 1/2-inch diskette drive
1.2 GB hard disk
Network board
8 MB of RAM
3 1/2-inch diskette drive
1.2 GB hard disk
Network board
8 MB of RAM
Multimedia 3 1/2-inch diskette drive
1.2 GB hard disk
quad-speed CD-ROM
reader
S
y
stem board w/audio
16 MB of RAM
Speakers
Microphone
3 1/2-inch diskette drive
1.2 GB hard disk
quad-speed CD-ROM
reader
S
y
stem board w/audio
16 MB of RAM
Speakers
Microphone
3 1/2-inch diskette drive
1.2 GB hard disk
quad-speed CD-ROM
reader
S
y
stem board w/audio
16 MB of RAM
Speakers
Microphone

1-2 Technical Information
Table 1-2 Second Release of System Configurations
Configurations PowerMate V75 (75 MHz) PowerMate V100 (100 MHz) PowerMate V133 (133 MHz)
Hard disk system 3 1/2-inch diskette drive
850 MB hard disk
with 8 MB of RAM
or
1.6 MB hard disk
with 16 MB of RAM
3 1/2-inch diskette drive
850 MB hard disk
with 8 MB of RAM
or
1.6 MB hard disk
with 16 MB of RAM
3 1/2-inch diskette drive
850 MB hard disk
with 8 MB of RAM
or
1.6 MB hard disk
with 16 MB of RAM
Network-read
y
s
y
stem
(desktops only)
3 1/2-inch diskette drive
850 MB hard disk
Network board
8 MB of RAM
3 1/2-inch diskette drive
850 MB hard disk
Network board
8 MB of RAM
3 1/2-inch diskette drive
850 MB hard disk
Network board
8 MB of RAM
Multimedia 3 1/2-inch diskette drive
1.6 GB hard disk
six-speed CD-ROM
reader
S
y
stem board w/audio
16 MB of RAM
7 W Speakers
Microphone
3 1/2-inch diskette drive
1.6 GB hard disk
six-speed CD-ROM
reader
S
y
stem board w/audio
16 MB of RAM
7 W Speakers
Microphone
3 1/2-inch diskette drive
1.6 GB hard disk
six-speed CD-ROM
reader
S
y
stem board w/audio
16 MB of RAM
8 W Speakers
Microphone
Each system incorporates power management features, and has factory installed software to
enhance the hardware features. Systems come with a dual operating system requiring that
either Microsoft®Windows for Workgroups™ or Windows 95™ be selected when the
system is first powered on.
The following paragraphs give an overview of the desktop and minitower systems.
Differences between systems are noted as they occur.

Technical Information 1-3
DESKTOP SYSTEM CHASSIS
The desktop chassis provides an enclosure for the system board, power supply, four
expansion slots, a five-connector PCI/ISA backboard, and four storage device slots. The
expansion slots include two 8-/16-bit ISA slots, one dedicated 32-bit PCI slot, and one
shared PCI/ISA (32-bit PCI or 8-/16-bit ISA) slot. For network-ready configurations, one
slot has a network board installed and the remaining slots are open.
The four storage device slots accommodate up to three accessible devices and one internal
hard disk drive device. The accessible devices include the standard one-inch high 3 1/2-inch
1.44-MB diskette drive and up to two 1.6-inch high 5 1/4-inch storage devices. The non-
multimedia hard disk systems ship with an accessible 3 1/2-inch diskette drive and an
internal 3 1/2-inch hard disk drive, leaving two accessible 5 1/4-inch storage device slots
available for optional devices. The multimedia systems ship with an accessible 3 1/2-inch
diskette drive, an internal 3 1/2-inch hard disk drive, and an accessible 5 1/4-inch CD-ROM
reader, leaving one accessible 5 1/4-inch storage device slot available for an optional device.
Figure 1-1 shows front panel features and locations of the accessible storage devices in a
desktop system. Multimedia systems come with a CD-ROM reader installed in the top
accessible device slot.
3 1/2-Inch
Diskette Drive 5 1/4-Inch Accessible
Device Slots
3 1/2-Inch Internal
Hard Drive Slot
(behind panel)
IR Window
System Controls
and Lamps
Power Button
Figure 1-1 Desktop System Controls and Storage Device Slots

1-4 Technical Information
MINITOWER SYSTEM CHASSIS
The minitower chassis provides an enclosure for the system board, power supply, five
useable expansion slots, a six-connector PCI/ISA backboard, and seven storage device
slots. The expansion slots include three 8-/16-bit ISA slots, one shared PCI/ISA slot, and
one 32-bit PCI slot. For network-ready configurations, one slot has a network board
installed and the remaining slots are open.
The seven storage device slots accommodate up to four accessible devices and three
internal hard disk drive devices. The accessible devices include the standard one-inch high
3 1/2-inch 1.44-MB diskette drive and up to three 1.6-inch high 5 1/4-inch storage devices.
The internal device slots support up to three 3 1/2-inch hard disks; one in the standard front
slot. The other two install into a drive bracket that ships with the system. The bracket
attaches to the inside rear of the system.
The non-multimedia hard disk systems ship with an accessible 3 1/2-inch diskette drive and
an internal 3 1/2-inch hard disk drive, leaving three accessible 5 1/4-inch storage device
slots and two internal slots available for optional devices. The multimedia systems ship with
an accessible 3 1/2-inch diskette drive, an internal 3 1/2-inch hard disk drive, and an
accessible 5 1/4-inch CD-ROM reader, leaving two accessible 5 1/4-inch storage device
slots and two internal slots available for optional devices.
Figure 1-2 shows the front panel features and the locations of the accessible storage devices
in a minitower system. Multimedia systems come with a CD-ROM reader installed in the
top accessible device slot.
5 1/4-Inch
Accessible Device
Slots
3 1/2-Inch
Diskette Drive
3 1/2-Inch Internal
Hard Disk Slots
(behind cover)
Power Button
System Controls
and Lamps
IR Window
3 1/2-Inch Internal
Hard Drive
(behind cover)
Figure 1-2 Minitower System Controls and Storage Device Slots
