NEC Speed Wi-Fi NEXT WX01 User manual

AM1-002697-001
January, 2015
After reading, keep this manual in a safe place for quick
reference. Technically Certified
Precautions upon Use
Do not wrap the USB cable or AC adapter around the unit while they are plugged into
the unit.
Undue force continuously applied to the plug may cause failures.
Refrain from wrapping the cable and remove it instead.
Exemptions
• The Company is not liable for any damages arising from earthquakes, lightning, storms, oods or other natural
disasters, as well as res, actions by third parties, other accidents, intentional or mistaken operation by the
customer, or use under other unusual conditions outside the responsibility of the Company.
• The Company is not liable for any incidental damages (change/disappearance of describing content, loss of
business income, disruption of business, etc.) arising from the use of or inability to use the product.
• The Company is not liable for any damages arising from failure to observe the described content of the
"Instruction Manual".
• The Company is not liable for any damages arising, for example, from malfunction caused by combination with
connected devices or software not related to the Company.
• The settings and other stored data may sometimes be altered or lost due to faults, repair or other handling of the
product. The Company is not liable for any damage or lost income resulting from the loss of data.
• It is recommended you keep a copy of important data on your PC's hard disk, etc. Whatever the cause of the
defect or malfunction may be, the Company assumes no responsibility for alteration or loss of saved data.
* "The Company" as appears in this manual refers to the following companies.
Sold by: KDDI CORPORATION, OKINAWA CELLULAR TELEPHONE COMPANY
Manufactured by: NEC Platforms, Ltd.
Safety Precautions (Observe Strictly)
■Before using this product, thoroughly read these safety precautions for proper use.
After reading, store the precautions in a safe place.
These "Safety Precautions" describe instructions that should be observed to prevent damage
to property or injury to the customer or others using the product.
These instructions are divided into the following categories.
■Explanation of indications used in this manual
DANGER This symbol indicates the potential and imminent danger of death or
serious injury (*1) to a person.
WARNING This symbol indicates the possibility of death or serious injury (*1) to a
person.
CAUTION This symbol indicates the possibility of personal minor injury (*2) to a
person or physical damage (*3).
*1 Serious injury: This refers to loss of sight, injury, burns (high- and low-temperature), electric shock, broken bones,
injuries with residual aftereffects from poisoning, etc., and injuries requiring hospital admission for treatment or long-
term hospital attendance as an outpatient.
*2 Minor injury: This refers to injuries, burns (high- and low-temperature), electric shock, etc. that do not require hospital
admission for treatment or long-term hospital attendance as an outpatient.
*3 Physical damage: This refers to extended damage to buildings, furniture, livestock, or pets.
■Explanation of graphic symbols used in this manual
Prohibited
Indicates an action that is not allowed.
Wet hands prohibited
Indicates that handling with wet hands is not allowed.
Disassembly
prohibited
Indicates that disassembly is not allowed.
Wetting with
water prohibited
Indicates that use in a place where the product is likely to get wet or allowing the product to
get wet is not allowed.
Instruction
Indicates an action that must be done.
Disconnect plug from
power outlet
Indicates that the power plug must be disconnected from the power outlet.
■
Precautions Common to the Main Unit, Battery Pack, Charging equipment, au Micro IC Card (LTE) and Peripheral Devices
DANGER Be sure to read the following hazards before use.
●Be sure to use only the specified peripheral devices. Use of other peripheral
devices might cause overheating, fire, rupture, fault, or leakage of liquid.
●Do not use, store or leave the product in hot places (e.g. by the fire, near a heater,
under a kotatsu, in direct sunlight, in a car in the hot sun). Doing so might cause
ignition, rupture, fault, fire or injury.
●Before entering an area where flammable gas is generated such as a gas station, be
sure to turn off the product and stop charging the battery. Failure to do so might
cause the gas to catch fire.
●Do not put the product in a cooking apparatus such as microwave oven or a
pressure vessel. Doing so might cause ignition, rupture, fault, fire or injury.
●Do not throw the product into a fire or heat it. Doing so might cause fire, rupture or
a fire.
●Do not short-circuit the connection terminals. Do not allow conductive foreign objects
(metal fragments, pencil leads, etc.) to come into contact with or get inside the
connection terminals. Doing so might cause a fire, burns, a fault due to heat generation.
If a foreign object comes into contact with the connection terminal, please contact the
WiMAX operator to whom you subscribe.
●When using metal accessories, etc., make sure not to allow the metal part to come
in contact with the connection terminals or power outlet. Doing so might cause
electric shock, fire, injury or a fault.
●The customer is not allowed to disassemble, modify or repair the product. Doing so might
cause a fault, fire, electric shock, or injury. The Company is not liable even in the event of
any nonconformities arising on the product or peripheral devices as a result of
modification, etc. Modification of the product is in violation of the Wireless Telegraphy Act.
WARNING Be sure to read the following warnings before use.
●Do not drop or subject the unit to strong impact such as throwing. Doing so might
cause a rupture, overheating, fire, or a fault.
●Do not use the unit outside when you can hear thunder. Doing so might risk
lightning strikes and electric shock.
●Do not let your hands, fingers and other parts of the body touch the connection
terminal. Doing so might cause electric shock, injury or a fault.
●If the product is damaged because it is dropped, etc., and its display is cracked or
internal parts are exposed, do not touch the cracked display or exposed parts with
your hands. Doing so might cause electric shock or injury from damaged parts.
Please contact the WiMAX operator to whom you subscribe.
●If the wet product is charged, electric shock, short circuit, or corrosion may occur
and overheating may cause fire, malfunctions or burns.
●Do not splash with water or other liquids. Also, never use in places subject to direct
splashing with water or pet urine, etc. or in humid places such as bath areas, or use with
wet hands. Doing so might cause electric shock or fault from short-circuiting or corrosion
of electronic circuits. In the event that the product is splashed with liquid, immediately
disconnect the AC adapter’s power plug. Faults caused by wetting with water or
humidity are not covered by the warranty and charges will be incurred for repair. Please
contact the WiMAX operator to whom you are subscribed.
●When removing the rear cover, do not apply excessive force. The battery pack
might jump out, for example, and cause injury or a fault.
●Do not operate the product while driving an automobile or motorized bicycle, riding
a bicycle or walking. Doing so may compromise traffic safety and cause an accident.
●If charging is not completed after the specified charging time, stop charging.
Failure to do so might cause leakage of liquid, overheating, rupture or fire.
●Do not leave in places within the reach of small children. Small children might
swallow small parts, etc. by mistake and choke on them, or might drop them by
mistake and cause accidents or injury.
CAUTION Be sure to read the following cautions before use.
●Do not store the product in places subject to direct sunlight (e.g. in automobiles),
places that get hot, places that get extremely cold, and in humid or dusty places.
Doing so might cause overheating, fire, deformation or a fault.
●Do not leave on unstable places such as shaky stands or tilting surfaces. Dropping
the product may cause injury or damage. Also, pay sufficient attention to impact,
etc.
●Do not cover or wrap the product with bedding, etc. while using or charging the
product. Doing so might cause a fire, fault or injury.
●Do not touch the main unit or the specified peripheral devices for a long time
while power is being supplied from an external source. Doing so might cause low-
temperature burns.
●The product may become hot by prolonged use especially in a high-temperature
environment. Be careful when using the product touching your skin for a long
time, as it might cause low-temperature burns.
●Do not use power outlets or a wiring apparatus beyond its rating. Also, exceeding
rating, for example, by connecting multiple devices to a single power strip might
cause overheating and fire.
●Do not use the product with the rear cover removed.
●Do not place near corrosive chemicals or in places where corrosive gas is
generated. Doing so might cause a fault or loss of internal data.
●Do not leave or store the unit with the rear cover removed. Doing so might allow
dust or other foreign objects to get inside and cause a fault. If a foreign object
comes into the unit, please contact the WiMAX operator to whom you are
subscribed.
●Do not use if there is smoke, abnormal odor or noise, excessive overheating, or
other abnormalities. If an abnormality occurs, disconnect the specified charging
equipment (sold separately) from the power outlet, make sure that the product is
not overheating before turning the power off or removing the battery, and contact
the WiMAX operator to whom you are subscribed. Also, if you have dropped or
damaged the product, do not continue to use it in that state, and contact the
WiMAX operator to whom you are subscribed.
●When using an AC adapter or external device, insert/remove the connector straight
to/from the terminal. Verify the orientation of the connector. Unless it’s correct, it
may cause damage or a fault.
■Main unit
WARNING Be sure to read the following warnings before use.
●Do not use this product while driving a car or riding a motorbike or bicycle. It may
cause a traffic accident. Use of this product while driving a car or motorbike is
prohibited by law. Use of this product while riding a bicycle may be punishable by
some regulations.
●Follow the instructions of each medical facility for the use of the product on their
premises. Turn the product off in a place where the use is prohibited. Failure to do so
may affect electronic equipment and electronic medical equipment.
●Use of the product on board is restricted. Follow the instructions of each airline.
Prohibited acts related to the product usage on an airplane may be punished by
law.
●When using the product near an implanted pacemaker, implanted cardioverter-
defibrillator or other electronic medical devices, radio waves might affect these
units and devices. So, please observe the following.
1. Those with an implanted pacemaker or implanted cardioverter-defibrillator
should carry or use the product at least 15 cm away from the pacemaker or
cardioverter-defibrillator.
2. If a separation of at least 15 cm from where you use this product is difficult to
attain due to being stuck physically or for any other reasons, it is advised that
this product is switched off in advance as there may be individuals nearby with
an implantable pacemaker or cardioverter-defibrillator in their body.
3. When a medical institution has laid down designated areas where use of the
product is prohibited or is not allowed to be brought in, abide by the
instructions of that medical institution.
4. When using electronic medical devices other than an implanted pacemaker
and implanted cardioverter-defibrillator outside a medical institution (e.g.
home medical treatment), check individually with the manufacturer of the
electronic medical device regarding the influence of radio waves.
CAUTION Be sure to read the following cautions before use.
●Use of the main unit in an automobile might sometimes affect on-vehicle electronic
devices, though this rarely happens. If this happens, stop its use since this may
impair safe travel.
●If you feel any abnormality with your skin, immediately consult a dermatologist.
Itching, rashes, eczema, etc. sometimes occurs depending on your physical
constitution and condition. The materials of parts used on the product are as follows.
Component Material <Surface treatment>
<Speed Wi-Fi NEXT WX01 main unit>
Display panel assembly PMMA
Exterior case PC resin <coating>
POWER button PC resin
SET button PC resin
SELECT button PC resin
Rear cover PC resin <coating>
<AC adapter>
Exterior case PC + MBS resin (PC alloy)
Power plug Copper alloy <nickel plated>
USB receptacle (shielded part) Copper alloy <nickel plated>, LCP resin
<microUSB cable>
Cable (jacket) PVC resin
USB plug (shielded part) Iron <nickel plated>, PBT resin
USB plug (resin part) PVC resin
microUSB connector (shielded part) Stainless steel <nickel plated>, LCP resin
microUSB connector (resin part) PVC resin
<Battery pack>
Exterior (resin part) PC resin
Exterior (label) PET
Connection terminal PCB <gold plating>
●Do not allow liquids, metal objects, burnable items, and other foreign matter to get
inside the SIM card slot. Failure to do so might cause fire, electric shock, injury or a
fault. If a foreign object comes into the slot, please contact the WiMAX operator to
whom you are subscribed.
●Do not swing the product around by holding the hand strap, etc. Doing so might
cause an accident or damage.
●Use the product with its rear cover, etc. closed. If the rear cover is open, dirt or
water may get inside causing a fault.
●Do not put the product directly on sand at a beach, etc. Sand or other small
particles might get inside the product through the microUSB port or elsewhere. If
sand gets inside the product’s main unit, it might cause overheating or a fault.
●When using the product for calling or data communication, be careful not to keep
the product in direct contact with your skin for a prolonged period, or not to cover
the product with paper, cloth, bedding, etc. The main unit might get hot, causing
fire, injury, burns or a fault.
■Battery pack
(The battery pack of this product is a lithium-ion battery.)
The battery pack is not fully charged at the time of shipment from the factory.
Charge the battery before using the product.
DANGER Be sure to read the following hazards before use.
●Do not short-circuit the positive (+) and negative (–) terminals of the battery pack.
●Connect the battery pack to this product in the correct orientation. Connecting in
an incorrect orientation might cause a rupture, fire or overheating. Do not try to
forcibly connect the battery pack, instead thoroughly check the connection
terminals carefully before connecting.
●Do not puncture the battery pack with a nail, hit it with a hammer or step on it.
Doing so might cause fire or damage.
●Do not allow metal objects (such as necklaces and hairpins) to come in contact
with the connection terminals when carrying or storing the battery pack. Doing so
might cause a fire, overheating, liquid leakage, or a fault due to a short circuit.
●Do not disassemble, modify or directly solder the battery pack. Doing so might
cause spilling of the battery liquid resulting in an accident such as loss of eyesight if
it gets into the eyes, or cause overheating, injury, fire or rupture.
●Do not use a battery pack that has been dropped, stepped on, damaged, or
leaking battery liquid. Doing so might cause overheating, ignition, liquid leakage,
rupture, fault or injury. Immediately move the battery pack away from fire if you
notice leakage of liquid or unusual odor. Failure to do so might cause the leaked
liquid to catch fire resulting in fire, liquid leakage, injury or rupture.
●Do not wet the battery pack with water, seawater, pet urine, etc. A wet battery pack
might cause overheating, injury, rupture or fire. If you drop the product into water
by mistake, immediately turn off the power, remove the battery pack, and contact
the WiMAX operator to whom you are subscribed. Never charge the wet battery
pack.
●If the leaked liquid gets on your skin or clothes, immediately rinse it off with water
to avoid injury. If the liquid gets into your eyes, do not rub, but after you wash your
eyes with water, and immediately consult a doctor to avoid the risk of losing your
eyesight. If the liquid gets on a device, wipe it off without touching it.
●The battery pack is a consumable item. If the performance of a battery pack does
not recover (e.g. the usable time after each charge has become extremely short),
the battery pack is at the end of service life, so stop its use and buy a new one of
the specified type. Failure to do so might cause overheating, fire, rupture or
leakage. Note that the length of service life varies depending on the usage
condition, etc.
●Be careful not to have the battery pack bitten by your pet. It might cause liquid
leakage, overheating, rupture, fire, injury or ignition of the battery pack.
■Charging equipment
WARNING Be sure to read the following warnings before use.
●Do not use at other voltages than the specified power supply voltage. Doing so
might cause fire, overheating, injury or electric shock. Use only an AC adapter
designed for Japanese household use that is compatible with AC100V to AC240V
(50/60 Hz).
●Firmly insert the plug of the specified charging equipment into the power outlet
down to the base of its pins. Incomplete insertion of the power plug might result in
electric shock or fire caused by overheating, injury and fire. Do not use damaged
adapters or loose power outlets.
●Do not damage, modify, twist, pull or place a heavy object on the power cord of
the specified charging equipment. Do not use a damaged cord. Doing so might
cause an electric shock, injury, short circuit or fire.
●Do not let your hands, fingers and other parts of the body touch the connection
terminals. Doing so might cause electric shock, injury or a fault.
●If you hear thunder, do not touch the power plug. Doing so might cause an electric
shock as a result of a lightning strike.
●Before cleaning the specified charging equipment, unplug its power plug from the
outlet. If the plug remains plugged in when you clean the equipment, it might
cause an electric shock or short circuit. Also, wipe off the dust on the charging
equipment’s power plug. If the plug is left covered with dust, it might cause a fire.
●Wipe off dust on the power plug. Failure to do so might cause fire, burns or electric
shock.
●When the AC adapter is not to be used for a long time, disconnect the AC adapter’s
power plug from the power outlet. Failure to do so might cause fire or a fault.
●Do not use in places subject to direct splashing of water, pet urine or other liquids.
Doing so might result in faults and injury resulting from overheating, fire, electric
shock, or short-circuiting of electronic circuits. In the event that the product is
splashed with liquid, immediately disconnect the AC adapter’s power plug.
CAUTION Be sure to read the following cautions before use.
●Do not use in humid places such as bath areas, or connect/disconnect the AC
adapter with wet hands. Doing so might cause electric shock, injury or a fault.
●Charge the battery in a stable place. If placed on an inclined surface or wobbly
stand, the product might fall causing injury or damage. In addition, do not cover or
wrap the product with a cloth or bedding. Doing so might cause a fire, injury or a
fault.
●When unplugging the plug of the specified charging equipment from the power
outlet, hold and pull the power plug. If you pull the cord, the cord might be
damaged.
●Do not leave the specified charging equipment connected to the main unit with
the battery pack removed. Doing so might cause fire, injury or electric shock.
00
Instruction Manual

■au Micro IC Card (LTE)
WARNING Be sure to read the following warnings before use.
●Do not put the au Micro IC Card (LTE) in a cooking apparatus such as a microwave
oven or a pressure vessel. Doing so might cause melting, overheating, fuming, loss
of data or a fault.
CAUTION Be sure to read the following cautions before use.
●Be careful not to injure your hand or finger when attaching/removing the au Micro
IC Card (LTE).
●Use only the devices specified by the Company for inserting the au Micro IC Card (LTE).
Using a device not specified by the Company might cause loss of data or a fault.
For the specified devices, contact the WiMAX operator to whom you are subscribed.
●Do not disassemble or modify the au Micro IC Card (LTE). Doing so might cause loss
of data or a fault.
●Do not use or leave the au Micro IC Card (LTE) in hot places such as by the fire or a
heater. Doing so might cause melting, overheating, fuming, loss of data or a fault.
●Do not throw the au Micro IC Card (LTE) into a fire or heat it. Doing so might cause
melting, overheating, fuming, loss of data or a fault.
●Do not touch the IC (metal) part of the au Micro IC Card (LTE) or short-circuit it.
Doing so might cause loss of data or a fault.
●Do not drop the au Micro IC Card (LTE) or subject it to strong impact. Doing so
might cause a fault.
●Do not fold, bend or place a heavy object on the au Micro IC Card (LTE). Doing so
might cause a fault.
●Do not wet the au Micro IC Card (LTE). Doing so might cause a fault.
●Do not scratch the IC (metal) part of the au Micro IC Card (LTE). Doing so might
cause a fault.
●Do not store the au Micro IC Card (LTE) in dusty places. Doing so might cause a fault.
●Do not store the au Micro IC Card (LTE) in places exposed to direct sunlight or hot
and humid places. Doing so might cause a fault.
●Store the au Micro IC Card (LTE) out of reach from small children. Failure to do so
might cause injury or asphyxiation, etc. if they accidentally swallow and choke on it.
Handling precautions
These precautions are provided to ensure that performance can be fully demonstrated.
Thoroughly read these precautions to ensure correct use.
■ Precautions Common to the Unit, Battery Pack, Charging equipment, au
Micro IC Card (LTE) and Peripheral Devices
●Do not apply excessive force to the product during use. Be sure not to put the product
into a tightly packed bag or place a heavy object on the product in a bag. Sitting on the
product in your pocket might damage the display or internal circuit board resulting in a
malfunction. Keeping an external device connected to the external connection terminal
might damage the connector resulting in a malfunction. Such damage and malfunction
are not covered by the warranty, even if there is no external damage.
●Do not use the product in extremely hot, cold or humid places.
(Use within an ambient temperature range of 5°C to 35°C and humidity range of 35% to 85%.)
●Do not use in places subject to lots of dust or vibration.
●Clean the connection terminals with dry cotton swabs, etc. every now and then. Soiled
terminals might cause poor connection. Do not apply strong force when cleaning
connection terminals to prevent deformation.
●Clean the product with a soft dry cloth (such as the type used for eyeglasses). Forceful
rubbing with a dry cloth may scratch the display. The display may be stained if splash or
smear is left attached to the surface. Wiping the product using alcohol, thinner, benzene,
detergent, etc. might erase the printing on the outer casing or cause discoloration.
●Use as far away as possible from landline phones, TVs and radios. Use nearby might
affect them.
●The product may become warm during data communication or charging etc. depending
on the situation, but this is not abnormal.
●If the product becomes warm when using, it may stop because of a protection feature. In
that case, try to connect after a while.
●When the product is used by a child, parents or guardians should thoroughly read the
“Instruction Manual” and teach the child how to use it.
●Turn off the power before removing the battery pack. If you remove the battery pack
with the power on, saved data might be altered or lost.
■ Main unit
●Do not forcefully press, tap or intentionally subject the display to strong impact. Doing
so might cause scratching or damage.
●Do not forcefully press your fingernails, sharp objects or hard objects against keys or
display surface. Doing so might cause scratching or damage.
●Do not remove the stickers printed with the “Technical Certification Mark ” that can be
seen when the rear cover is removed. These stickers prove that the product and the
communication module you are using complies with the Wireless Telegraphy Act and
Telecommunications Operations Act.
●Never use this product when it has been modified. Use of a modified device violates the
Radio Law.
This product has acquired the certification of conformity with technical regulations for the
specified radio station based on the Radio Law, and the “Technical Conformity Mark ” is
printed on the nameplate on the product as a certificate.
If the screws of the product are removed and modifications are made to the internal
components, the certification of conformity with technical regulations will become invalid.
Never use the product without the valid certification. Doing so violates the Radio Law.
●To prevent unlawful modification, the product has been designed so that it cannot be
easily disassembled. Modifying the product is prohibited by the Radio Law.
●Contents saved in this product might be altered or lost in an accident, fault, repair or
mishandling. Be sure to keep a copy of important contents. Note that the Company assumes
no responsibility for any damages or lost profits resulting from altered or lost contents.
●Although the OLED used on the product is made using high-precision technology, some
pixels (dots) might be lit or out at all times. Or unevenness of brightness may be shown if
looked at from different angles. Note that that is because of the properties of OLED, not
a malfunction.
●Although lightning intensity of OLED can be decreased partly when the same image has
been displayed for a long time, extreme continuous use is performed, etc., it is not
abnormal because that is the characteristic of OLED.
●Exposing the OLED to direct sunlight may cause a malfunction. Take care when putting
the OLED near a window or outdoors.
●A temperature increase in the product or a low charging battery level may adversely
affect the brightness of the display.
●Take care not to disturb people around you when you use the product in a public place.
●Take care not to place magnetized items such as magnetic cards, speakers and TV sets
near the product, as it might cause malfunction. Putting a strong magnetism close to the
product might cause false operation.
●When you put the product in your pocket or bag, take care so that the display does not
come in contact with metal objects or other hard objects, as it might cause scratching or
damage. Also, be careful not to scratch or damage the display by using a strap whose
metal or other hard part comes in contact with the display.
●When suddenly brought into a warm place from a cold place, or when in a humid
location, or when used where temperature suddenly changes (e.g. near the air discharge
port of an air conditioner), water droplets (i.e. condensation) are sometimes formed
inside the product. Note that when used under conditions such as this, the humidity
might cause corrosion or a fault.
●When wiping the display, wipe with a soft, dry cloth. Use of a moistened cloth, glass
cleaner or other similar liquid might cause a fault.
●When connecting/disconnecting the microUSB cable to/from the microUSB connector,
make sure that the microUSB cable connector is straight with the microUSB connector.
●Note that applying unnecessary force with the microUSB cable connected to the
microUSB connector might cause damage.
●Do not discard the product together with regular trash. Please cooperate in the
collection of the product when it is no longer needed to protect the environment and
effectively use resources. Old products are collected at au shops and other places.
●Insert only an au Micro IC Card (LTE) into the SIM card slot on the product.
●Do not apply excessive force when attaching/removing an au Micro IC Card (LTE). Doing
so might injure your hands or fingers.
●While writing/reading data to/from an au Micro IC Card (LTE), do not subject the product
to vibration or impact, remove the battery pack or turn off the power. Doing so might
cause loss of data or a fault.
■ Battery pack
●Use in very hot or cold environments, for example, when left in an automobile with the
windows closed in summer, will cause the battery capacity to drop and shorten the
available battery usage time. This will also shorten the battery pack’s service life. Try to
use the battery pack as far as possible at room temperature.
●When the battery pack is not to be used for a long time, remove the rear cover and
remove the battery pack from the main unit, and store it away from hot and humid places.
●Charge the battery before using the product for the first time after purchase, or if you
have not used the product for a long time.
●The battery pack is a consumable item. If the performance of a battery pack does not
recover after charge, the battery pack is at the end of service life, so buy a new one of the
specified type. Note that the length of service life varies depending on the usage
condition, etc.
●Do not discard battery packs together with regular trash. Please cooperate in the
collection of used battery packs to protect the environment and effectively use
resources. au shops and other retailers collect used battery packs.
●Battery packs sometimes swell up as they approach the end of their service life. This is
due to the properties of lithium-ion batteries, and is not a problem in terms of safety.
■ AC adapter
●When not using the specified charging equipment, remove the plug from the power
outlet.
●Do not wrap the cord of the specified charging equipment around the adapter itself.
Doing so might cause electric shock, fault, injury, overheating or fire.
●Do not forcibly bend the charging equipment’s plug or the connection between the
connector and power cord. Doing so might cause electric shock, fault, injury,
overheating or fire.
■ au Micro IC Card (LTE)
●The au Micro IC Card (LTE) is lent to you by au. In case of loss or damage, the card will be
replaced at your expense. When a malfunction is suspected, or in case of theft or loss,
contact the WiMAX operator to whom you are subscribed.
●Do not forcibly remove or insert the au Micro IC Card (LTE). Be careful not to apply
excessive force when inserting the card into this product.
●You are responsible for any damage caused by inserting your au Micro IC Card (LTE) into
some other IC card reader/writer, etc.
●Keep the IC (metal) part of your au Micro IC Card (LTE) clean. Wipe the card with a dry,
soft cloth (such as for cleaning eyeglasses) for cleaning.
●Do not put stickers, etc. on the au Micro IC Card (LTE).
●Do not use an IC card with the card adapter. Doing so might cause a fault.
■ Copyrights and rights of portrait
●You are not allowed to copy, distribute, publish, modify or edit the data you downloaded
from the Internet using this product without the consent of the copyright holder, except
for personal use, under the copyright law. In addition, do not use or modify portraits or
names of other individuals without their consent, as it might infringe on rights of
portrait.
■ Backup content of the product
●Please back up important content recorded or downloaded on the product to an outside
source. Content recorded to memory on the product sometimes disappears or is altered
by unexpected factors, such as static electricity or a fault, repair, mishandling, etc.
* How to take note of recorded information: Settings recorded in this product can be saved to a PC. Launch the
Quick Setting Webpage and login. Then proceed in the following order [Advanced Settings Top] →
[Maintenance] →[Saving and Restoration of Settings]. Remember, however, that certain kinds of data cannot be
saved in this way.
PIN
■PIN code
●To prevent unauthorized use of the au Micro IC Card (LTE) by a third party, you can set
the product to require PIN code entry every time the power is turned on. You also need
to enter PIN code when setting whether the PIN code entry is required.
●If the PIN code is incorrectly entered three times consecutively, the PIN code will be
locked. You can unlock the PIN code using PUK code.
The PIN code is “1234” and PIN code entry is set not to be required at the time of
purchase. You can change the PIN code to any four- to eight-digit number, and set the
PIN code entry to be required as necessary.
■PUK code
●In case the PIN code is locked, you can unlock it by entering the PUK code.
The PUK code is an eight-digit number given at the time of purchase, which is printed
on the back side of the plastic card on which your au Micro IC Card (LTE) is attached.
After entering the PUK code, you need to set a new PIN code.
If the PUK code is incorrectly entered ten times consecutively, contact the WiMAX
operator to whom you are subscribed.
The “PIN code” is not reset by initializing the product.
Notes on using Bluetooth®/Wireless LAN functions
• Use the Bluetooth® function in Japan. The Bluetooth® function of this product conforms to domestic wireless
standards in Japan, and has been certied. Use overseas may be subject to punishment by law.
• The connections with all Bluetooth® devices are not guaranteed.
• The Bluetooth® function of this product supports the remote startup which recovers this product from dormant
state only.
• Use the wireless LAN function in Japan. The wireless LAN function of this product conforms to domestic wireless
standards in Japan, and has been certied. Use overseas may be subject to punishment by law.
• The 2.4 GHz band used by wireless LAN and Bluetooth® devices is shared by various other devices. For this
reason, the communication speed and connectable range may be decreased, or disconnection may occur, due to
interference from other devices.
• Do not use this product in places where electromagnetic waves are generated or near electric products, AV and
OA equipment, or other magnetized devices.
• Subjecting this product to magnetic or electrical noise might increase noise and prevent it from performing
communications. (This product is particularly susceptible to noise when it used near a microwave oven.)
• Using this product near a TV, radio or similar appliance might cause reception interference and disrupt TV images.
• Searching might not be successful if there are multiple wireless LAN access points near the product or if the same
channel is being used.
• The wireless LAN function cannot be used in airplane. Be sure to turn o the power even in a Wi-Fi compliant
airplane. Some airline companies, however, allow their passengers to use data communication terminals. For
details, contact the airline company you use.
• Use of this product on board is restricted. Follow the instructions of each airline.
• The communication speed and connectable range vary depending on the distance between communication
devices, obstacles and the Bluetooth® devices used.
2.4GHz frequency band precautions
The frequencies used by the Bluetooth® and/or wireless LAN function of this product are in the 2.4 GHz band. In this
frequency band, other similar wireless stations, in-plant wireless stations for mobile unit identication that require
a license to use, such as factory production lines, specic small power wireless stations that do not require licenses,
amateur wireless stations (collectively called "other wireless stations" from here on) are operated in addition to
home electrical appliances such as microwave ovens, devices for industrial, scientic and medical devices.
1. Before using this product, make sure that "other wireless stations" are not in operation nearby.
2. In the event that instances of radio wave interference have occurred between this product and "other wireless
stations", immediately either relocate this product or stop operation of the device (stop the emission of radio waves).
3. If you are unclear on any points or are troubled by anything, contact the WiMAX operator to whom you are subscribed.
The connections between this product and all other Bluetooth® and wireless LAN devices have not been
conrmed. Therefore, connections with all Bluetooth® and wireless LAN devices are not guaranteed.
This product supports security features for wireless communications that are compliant with the Bluetooth® and
wireless LAN standard specications, but the security may not be sucient depending on the usage environment
and conguration. Be careful when making data communication using Bluetooth® or wireless LAN function.
Wireless LAN has the advantage that it can be freely connected anywhere within the radio wave range, as it uses
radio waves for exchanging information. At the same time, there is a risk that a malicious third party may obtain
unauthorized access if security settings have not been congured. You are recommended to congure security
settings before using wireless LAN at your decision and responsibility.
The Company assumes no responsibility for leakage of data or information that may occur during Bluetooth®/
wireless LAN communication.
Since Bluetooth® and wireless LAN functions use the same frequency band, using the both functions at the
same may cause radio wave interference resulting in decreased communication speed or disconnection from
the network. If connection fails, stop using either of the Bluetooth® and wireless LAN functions.
Bluetooth® and wireless LAN functions of this product use frequencies in the 2.4 GHz band.
• Bluetooth® function: 2.4FH1
This product uses the 2.4 GHz band. FH-SS is used as the modulation scheme. The interference distance is about
10 m or less.
• Wireless LAN function: 2.4DS/OF4
This product uses the 2.4 GHz band. DS-SS and OFDM are used as the modulation schemes. The interference
distance is about 40 m or less.
This means that all bandwidths can be used, and that band of mobile unit identication devices can be avoided.
For use in an airplane, check with the airline company in advance.
2.4 : Radio equipment that uses the 2.4GHz band
DS4 : An interference distance of up to 40m assumed for the DS-SS system
OF4 : An interference distance of up to 40m assumed for the OFDM system
FH1 : An interference distance of up to 10m assumed for the FH-SS system
■■■
: This means that the product uses all frequency bands and is incapable of
avoiding the frequency band for mobile device identication equipment.
• If you are using this product in the 2.4 GHz band, you are recommended to set channel setting to any of CH1,
CH6, or CH11 to mitigate interference and increase frequency use eciency.
This shall not apply when you must use a setting other than the recommended CH1, CH6, or CH11 to avoid
system interference other than wireless LAN (Wi-Fi®).
5GHz frequency band precautions
Wireless LAN function of this product uses the 5 GHz band. Using the 5.2 GHz band and 5.3 GHz band outdoors is
prohibited by the Radio Law.
The channels used on the product are as follows.
W52 (5.2GHz band / 36, 40, 44, 48ch)
W53 (5.3GHz band / 52, 56, 60, 64ch)
W56 (5.6 GHz band/100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140 ch)
After-sales service
■Performance parts for repair
The Company retains performance parts for repair of the Speed Wi-Fi NEXT WX01 main unit and its peripherals for 4
years after discontinuation of production. “Performance parts for repair” refers to parts required for maintaining the
functions of the product.
■Warranty card
At the store of purchase, thoroughly check and read the name of the retailer, date of purchase and other necessary
details lled in on the warranty card, and be sure to keep it in a safe place.
■Troubleshooting
If you experience diculty setting up an Internet connection even when the instructions in the "Setup Guide" and
the "取扱説明書詳細版 (Full Instruction Manual)" (Japanese) are followed, please check the following items.
● Unable to connect to the Internet
Make sure that you are located in a service area.
The incoming signal strength may be low. Retry the connection in a location with a higher incoming signal strength.
If the icon [WX2+] or [WX] does not show in the display, launch the Quick Setting Webpage to check that an
Internet connection has been properly set up.
Check to see if a Wi-Fi SPOT is configured or not.
If it is not configured, configure one by referring to STEP 4, “Configuring the Connection Destination”in the "Setup Guide".
● Communication is easily disrupted
The incoming signal strength may be low. Check the radio reception level and move to a location for a higher
incoming signal strength.
Check the remaining battery level. If the remaining battery level is low, recharge the battery pack before
reconnecting the product.
Check to see if this product is properly connected to a PC or the like on a wireless LAN (Wi-Fi®), Bluetooth®, or by a
USB cable.
If the product is connected to a PC or the like on a wireless LAN (Wi-Fi®) or Bluetooth®, reboot the product.
If there is radio interference from other networks, such as multiple access points having been set up in the vicinity,
radio reception may be improved by changing “Channel Assignment” for this product.
● Communication seems slow
The connection destination may be congested. Allow for some time before retrying.
■Introduction of related accessories
The types of peripheral devices that can be used to charge the product and connect it to a PC or the like are listed
in the following table.
Battery pack NAD31UAA (sold separately)
WX01 cradle (*1) NAD31PUA (sold separately)
Common AC adapter 03 0301PQA (sold separately)
Common AC adapter 03 navy 0301PBA (sold separately)
Common AC adapter 03 green 0301PGA (sold separately)
Common AC adapter 03 pink 0301PPA (sold separately)
Common AC adapter 03 blue 0301PLA (sold separately)
Common AC adapter 05 0501PWA (sold separately)
AC adapter JUPITRIS (white) L02P001W (sold separately)
AC adapter JUPITRIS (red) L02P001R (sold separately)
AC adapter JUPITRIS (blue) L02P001L (sold separately)
AC adapter JUPITRIS (pink) L02P001P (sold separately)
AC adapter JUPITRIS (champagne gold) L02P001N (sold separately)
microUSB cable 01 0301HVA (sold separately)
microUSB cable 01 navy 0301HBA (sold separately)
microUSB cable 01 green 0301HGA (sold separately)
microUSB cable 01 pink 0301HPA (sold separately)
microUSB cable 01 blue 0301HLA (sold separately)
Portable charger 02 (*2) 0301PFA (sold separately)
(*1)When connecting this product to the WX01 cradle (sold separately), refer to the "Instruction Manual" supplied with
the cradle "WX01クレードル (NAD31PUA) 取扱説明書" (Japanese).
(*2)Portable charger 02 (sold separately) may not charge this product suciently.
* For an updated list of supported peripheral devices, please check with the WiMAX operator to whom you are subscribed.
■au Micro IC Card (LTE)
The au Micro IC Card (LTE) is lent to you by au. In case of loss or damage, the card will be replaced at your expense.
When a malfunction is suspected, or in case of theft or loss, contact the WiMAX operator to whom you are
subscribed.
■After-sales service
Please contact the WiMAX operator to whom you are subscribed.
Software used in this product
This product includes software licensed under GNU General Public License (GPL) and/or GNU Lesser General Public
License (LGPL). The user can obtain the source code of such software, and copy, distribute and modify the software
according to the GPL and/or LGPL.
Refer to the WiMAX Support Information website for details.
Specic Absorption Rate (SAR) of data communication terminal
This model Speed Wi-Fi NEXT WX01 conforms to a state-formulated technical standard relating to the human body
absorption of radio waves and international guidelines for radiation protection.
This data communication terminal is designed to conform to a state-formulated technical standard (*) relating to
the human body absorption of radio waves, and tolerable limits for radiation protection that are recommended
by equivalent international guidelines. These international guidelines have been worked out by the International
Commission on Non-Ionizing Radiation Protection (ICNIRP), a partner to the World Health Organization (WHO), and
their tolerable limits allow for an adequate factor of safety, regardless of the user’s age or health conditions.
The state-formulated technical standard and international guidelines establish such tolerable limits for
radiation protection in terms of a specic absorption rate (SAR), which represents the average rate at which
energy is absorbed by the human body. This data communication has a SAR limit setting of 2.0W/kg. If this data
communication terminal is used under the conditions of normal use dened in this Instruction Manual, the
maximum SAR limit is 0.211 W/kg. Individual product models all address their respective SAR limits, which may vary
slightly from one model to another.
Because data communication terminals are designed to ll the minimum transmitting power requirement for
communicating with base stations for cellular phones, etc., their SAR normally gets lower while they carry on
communication actually. Generally, the closer to a base station a data communication terminal is located, the lower
its output becomes.
When you communicate using this product, keep it at least 1.5 cm apart from your body, with no intervening
metallic objects. This procedure has been veried to allow this data communication terminal to conform to the
specications of the state-formulated technical standard and the international guidelines for radiation protection.
The World Health Organization states: “A large number of studies have been performed over the last two decades to
assess whether mobile phones pose a potential health risk. To date, no adverse health eects have been established
as being caused by mobile phone use.”
For more details, please visit the World Health Organization website.
http://www.who.int/docstore/peh-emf/publications/facts_press/fact_japanese.htm
To nd out more about SAR, please visit the following websites.
Ministry of Internal Aairs and Communications website http://www.tele.soumu.go.jp/j/sys/ele/index.htm
Association of Radio Industries and Businesses website http://www.arib-emf.org/index02.html
NEC Platforms, Ltd. website
http://www.necat.co.jp/wimax/support/uqc/nad31/index.html
au website
http://www.au.kddi.com/
* The technical standard is stipulated in Ordinance related to Radio Act (Radio Station Regulations Article 14-2).
Export Administration Regulations
The products and accessories may be subject to the application of the Foreign Exchange and Foreign Trade Act and
other related laws and regulations in Japan.
In addition, the Export Administration Regulations (EAR) of the United States may be applicable.
In cases of exporting or reexporting the products and accessories, customers are requested to follow the necessary
procedures at their own responsibility and cost. Please contact the Ministry of Economy, Trade and Industry of
Japan or the Department of Commerce of the United States for details about procedures.
Trademark Notice
Wi-Fi®, Wi-Fi Alliance®, Wi-Fi CERTIFIED®, WPA™, WPA2™, Wi-Fi Protected Setup™ and their logos are trademarks or
registered trademarks of Wi-Fi Alliance.
All other company names and product names are trademarks or registered trademarks of respective companies
referred to in this manual.
The ®mark and the TM mark may be omitted in this manual.
Contact
Please contact the WiMAX operator to whom you are subscribed.
January, 2015, 1st Edition
Sold by: KDDI CORPORATION, OKINAWA CELLULAR TELEPHONE COMPANY
Manufactured by: NEC Platforms, Ltd.
