NEC Speed Wi-Fi NEXT WX01 User manual

AM1-002696-001
January, 2015
Preface
Thank you for buying the Speed Wi-Fi NEXT WX01 (simply called the "product" from here on). Before using the product, be
sure to read the Setup Guide (this manual) and the Notes on Usage to ensure correct use. The Setup Guide (this manual)
handles only basic operations for main features.
As an instruction manual related to the product, the Setup Guide (this manual), the Notes on Usage, and the "取扱説明書詳
細版 (Full Instruction Manual)" (Japanese) are available for download from the WiMAX Support Information website. In this
manual, all such manuals are collectively referred to as the "Instruction Manual".
• The PDF version of the "取扱説明書詳細版 (Full Instruction Manual)" (Japanese) is also included in the product.
Connect the product to a PC or the like by means of wireless LAN (Wi-Fi®) or a microUSB cable, launch the web browser,
type "http://192.168.179.1" in the address and log in to the Advanced Settings on the Quick Setting Webpage to view "情
報(Information)", and access "マニュアル (Manual)".
• The PDF versions of the Instruction Manuals can be downloaded from the WiMAX Support Information website.
http://www.necat.co.jp/wimax/support/uqc/nad31/index.html
• Company names and product names referred to in this manual are trademarks or registered trademarks of the respective
companies.
• The illustrations and screenshots that appear in this manual may not be a precise representation of the actual product.
Furthermore, part of the screenshots used may be omitted.
Disclaimer and Safety Tips
Before using the product, please read through the "Exemptions" and "Safety Precautions (Observe Strictly)" on the "Notes on
usage" to ensure correct handling of the product.
When using the product
• This product can connect with WiMAX 2+ and WiMAX. Although communication will automatically switch between WiMAX
2+ and WiMAX in response to the reception environment, there may be periods of several seconds during switching when
communication will not be possible.
• Keep the product at least 1.5cm away from your body, and make sure that there are no intervening metallic objects when
you communicate.
• Communication is not possible even in the service area in places where the signal does not reach (e.g. tunnels and
basements). Also, communication is sometimes not possible in poor reception areas. Communication is sometimes
interrupted if you move into a poor reception area during communications.
• Since this product uses radio waves, the possibility of communication interception by third parties cannot be eliminated.
(The WiMAX 2+ method and the WiMAX method, however, offer secure communication encryption and secrecy functions.)
• It is presumed that the product will be used in Japan. It cannot be taken out of Japan and used abroad.
• Since this product is a radio station under the Radio Law, you may be asked to temporarily submit the product for
inspection in accordance with the Radio Law.
• Take care not to disturb people around you when you use the product in a public place.
• When the product is used by a child, parents or guardians should thoroughly read the "Instruction Manual" and teach the
child how to use it.
Data Communication Terminal Etiquette
■Use of the product is not allowed in the following places!
• Use of this product on board is restricted. Follow the instructions of each airline.
■ Pay attention to the place of use!
• In a city area, use in a place where you do not bother people walking.
• It is extremely dangerous to walk while looking at the screen of the product. Do not operate the product while walking or
by stopping suddenly.
• Move to a place where you do not disturb others while you are in shinkansen, a hotel lobby, etc.
■ Consider people around you!
• There may be a person with a cardiac pacemaker nearby at a place filled with people such as in a crowded train.
Turn off beforehand.
• When a medical institution has laid down designated areas where use of the product is prohibited or is not allowed to be
brought in, abide by the instructions of that medical institution.
Waiting or Idling
- Waiting: A function to minimize power consumption in order to increase the operating time.
- Idling: A function for prompt start from wireless idling state.
Technically Certied
Preparing for Setup
Attach the au Micro IC Card (LTE)
When attaching the au Micro IC Card (LTE), disconnect the product from the power source and make
sure to turn o.
Remove the microUSB cable and cradle (sold separately) when they are connected.
aInsert the au Micro IC Card (LTE) with its IC
(metal) part facing down until it clicks into
position.
* This product supports only au Micro IC Card (LTE). Other IC
cards besides au Micro IC Card (LTE) are not available.
* Confirm the correct inserting direction of the IC card.
Failure to do so may cause a malfunction or damage.
* Refrain from inserting the SD card and IC card with a
conversion adapter. Doing so may cause failures.
* Be careful not to touch or damage the IC (metal) part of
the au Micro IC Card (LTE).
SIM card slot
Notch
Attach the Battery Pack
a
Slide the battery pack into the end with the
marked surface (Recycling symbol etc.) facing up.
Contact the terminal of the battery pack with
the terminal of this product and then push in.
②
①
Terminal area
Terminal area
bAttach the rear cover
Press the cover onto the unit until the clips of
the Q side of the UQ logo click into position.
* Be sure to firmly press the edges of the cover so that there
are no gaps.
Charging the Product
Explains how to charge using the enclosed AC adapter supplied with this product.
* Charge the battery in power o or idle state. If the battery is charged during operation or when temperature of main unit or
battery is high, charging may stop even if the battery is not full in order to keep the battery life long.
aInsert the microUSB connector of the microUSB cable into the microUSB port on the product.
* Plug the microUSB connector straight into the microUSB port of this product with its side bearing the USB mark facing down.
bAttach the other end of the USB connector to the AC adapter and insert the power plug of the AC
adapter into a power outlet.
* Press the POWER button to check the battery status (remaining battery level). The battery level is indicated under the charging
icon as a percentage.
(An indication estimates the remaining battery level. It varies depending on the usage environment or status of this product.)
* Plug the USB connector into the AC adapter with its side bearing the USB mark facing down.
* Make sure that the AC adapter is in a secure position.
* Charging may stop in order to protect the battery from overheating.
For information on how to charge the battery pack on the cradle (sold separately), refer to the
Instruction Manual of the cradle "WX01クレードル(NAD31PUA)取扱説明書" (Japanese).
Switch Power On
Hold down the POWER button until "NEC" appears in the display and this product is turned ON.
* When the "Normal display" (refer to "Displayed Information" on the reverse side) appears, proceed to STEP 2.
* To turn OFF the product, hold down the POWER button until "Power OFF" appears in the product display.
If "New Firmware is released. Do you want to update?" appears on the display when the power is
turned on, update the rmware. (Refer to "Firmware Update" on the reverse side)
Consult the homepage for the latest rmware.
Check the product version on the “Terminal Info” display. (Reference to “Display Menu Operations” on the back surface.)
When “New Program Released” appears on the display of this product, it indicates that a new firmware exists. In that case, refer to the “Firmware
Update” on the back surface of this manual to update the version.
Switching to English display
aLaunch the Quick Setting Webpage and log in (Refer to STEP 4).
b
Click [English] and then click [Save] from the menu on the left of the Quick Setting Webpage screen.
• The display and the Quick Setting Webpage of this product will switch to English.
Verify the following product settings.
Check
• Primary SSID (wx01-xxxxxx)
• Primary key (encryption key) (AES) (13 alphanumeric characters)
Conrm the enclosed“Wireless LAN Setup QR Code (label)”.
How to conrm by the display menu is described below.
1While the product display is in the normal display, press the SELECT button a few
times to display [Wi-Fi Info].
2Press the SET button to display the Primary SSID.
3Press the SELECT button to display the Primary Key.
Primary SSID Primary Key
* Have these available for STEP 2.
* The Primary SSID and Primary key of this product are also indicated on the sticker under the battery pack.
Connecting via Wireless LAN (Wi-Fi®)
Check the Contents of the Package
Before you start using the product, make sure that you have all the following packaged with the product.
Speed Wi-Fi NEXT WX01 (main unit) AC adapter (NAD11PQA)
Use this cable to charge the product. It may also be used to
connect the product to the PC.
AC adapter microUSB cable
つなぎかたガイド
"Setup Guide" (Japanese)
ご利用にあたっての注意事項
"Notes on Usage" (Japanese)
無線LAN設定用QRコード（シール）
"Wireless LAN Setup QR code (label)" (Japanese)
Keep this label safe by placing it on the <Wireless LAN Setup
QR Code> field described in STEP 2 of the enclosed “Setup
Guide” (Japanese).
Warranty card (Japanese)
Battery pack (NAD31UAA)
Rear cover
Names and Functions of Components
5microUSB port
1Display
2POWER
button
3SET button/
RAKURAKU
START button
6SIM card slot
7Strap hole
4SELECT button
Name Function
1Display Lets you view the key settings of
the product.
2POWER button Switches the power ON / OFF.
Used to light up the display that
has been automatically turned o.
Used to recover the product from
a state of waiting or being idle.
3SET button/
RAKURAKU
START button
Used to set display menu and items.
Used to congure the product
with Rakuraku wireless start.
Used to congure WPS-enabled
wireless LAN (Wi-Fi®) devices and
wireless LAN (Wi-Fi®).
Used to light up the display that
has been automatically turned o.
4SELECT button Used to select display menu and
items.
5microUSB port Used to connect the enclosed
microUSB cable to the product or
when placing the product on the
cradle (sold separately).
6SIM card slot Insert the au Micro IC Card (LTE)
into this slot.
7Strap hole Used to put a strap.
Instruction Manual
Windows 8.1/8
This section explains how to establish a wireless
LAN (Wi-Fi®)connection by WPS.
aSelect [デスクトップ (Desktop)] on the [ス
タート (Start)] screen.
bEnable the wireless function of your PC.
* For details on configurations, refer to relevant
documentation such as the instruction manual for your PC.
cClick the network icon appearing in the
notication area (task tray).
dChoose the network name (SSID) of the
product from the list of networks.
* The network name (SSID) of the product can be found by
clicking on [Wi-Fi Info] in the display menu. (See "Check" in
STEP 1.)
eClick on [接続 (Connect)].
f
In the normal display, press the SELECT button a few
times, select [Setup Wi-Fi with Rakuraku/WPS] in the
menu and press the SET button.
* If the display has been turned off, press the SET button to
turn on the normal display.
gSelect [WPS] with the SELECT button, and press
the SET button.
hHold down the SET button as instructed on-
screen with the dialogue of [Starting the
waiting... Press [SET] and Hold it.].
iThe message [Setup completes] will be displayed.
jCheck that a value of "1" or more is displayed
under the icon in the product display.
* This number indicates the number of connected devices.
A value of "0" will be displayed when no connections have
been established.
Mac OS (OS X v10.10)
aIn the Apple Menu, click on [システム環境設
定(System Conguration)] - [ネットワーク
(Network)].
bSelect [Wi-Fi] from the list of services.
cFrom the [ネットワーク名 (Network Name)]
pull-down list, select the network name (SSID)
of the product.
* The network name (SSID) of the product can be found by
clicking on [Wi-Fi Info] on the display menu. (See "Check" in
STEP 1.)
dType the encryption key of the product in the
[パスワード (Password)] eld and click on [接
続(Connect)].
* The network name (SSID) of the product can be found by
clicking on [Wi-Fi Info] in the display menu. (See "Check" in
STEP 1.)
e[
接続済み (Connected)] will be displayed in the
[状況 (Status)].
fClose the window.
gCheck that a value of "1" or more is displayed
under the icon in the product display.
* This number indicates the number of connected devices.
A value of "0" will be displayed when no connections have
been established.
Smartphone / Tablet (Android)
Conguration with Rakuraku QR Start
aSearch the Google Play Store for the "Aterm
らくらくQRスタートforAndroid (Aterm
Rakuraku QR Start for Android)" application to
download and install it.
* This application is also available for download on the
"AtermらくらくQRスタート (Aterm Rakuraku QR Start)"
website listed below (as of January, 2015).
http://qr.aterm.jp
bOn the Home screen, tap the "Atermらくらく
QRスタート (Aterm Rakuraku QR Start)" icon.
cWith the Camera View screen, scan the
enclosed "無線LAN設定用QRコード
(Wireless LAN Setup QR code)".
* The "無線LAN設定用QRコード (Wireless LAN Setup QR
code)" may be attached to the space provided below.
dTap [設定適用 (Apply Changes)].
* Make sure that the power of the product has been turned
ON.
eThe connection will be established.
fTap [終了 (Finish)].
gCheck that a value of "1" or more is displayed
under the icon in the product display.
* This number indicates the number of connected devices.
A value of "0" will be displayed when no connections have
been established.
iPad/iPhone/iPod touch
Conguring with Rakuraku QR start
aSearch the App Store for the "Atermらくら
くQRスタートforiOS (Aterm Rakuraku QR
Start for iOS)" application to download and
install it.
* This application is also available for download on the
"AtermらくらくQRスタート (Aterm Rakuraku QR Start)"
website listed below (as of January, 2015).
http://qr.aterm.jp
bOn the Home screen, tap [設定 (Congure)] to
turn o the [機内モード (Airplane Mode)] and
turn on [Wi-Fi].
cOn the Home screen, tap the "Atermらくらく
QRスタート (Aterm Rakuraku QR Start)" icon
and then tap [OK].
* After a moment upon being activated, Camera View will be
displayed.
dWith the Camera View screen, scan the
enclosed "無線LAN設定用QRコード
(Wireless LAN Setup QR code)".
* The "無線LAN設定用QRコード (Wireless LAN Setup QR
code)" may be attached to the space provided below.
eTap [設定適用 (Apply Changes)].
* Make sure that the power of the product has been turned ON.
fTap [OK].
gTap [インストール (Install)].
hTap [インストール (Install)].
iTap [インストール (Install)].
jTap [完了 (Complete)] - [OK].
kCheck that a value of "1" or more is displayed
under the icon in the product display.
* This number indicates the number of connected devices.
A value of "0" will be displayed when no connections have
been established.
1 2
Read to connect and congure the product
Verifying the Connection Status
3
◆
If or is displayed along with in the display and this product can be connected
to the Internet,
* For an explanation of each icon, see "Displayed Information" on the reverse side
of this manual.
conguration of the product has been completed.
◆
If is displayed along with in the display and this product cannot be connected to the
Internet,
congure the connection destination in STEP 4.
◆
If the Wireless LAN (Wi-Fi®) connection with the product is not established,
Select [Functions Maintenance] - [Wi-Fi Management Frame] in the display menu, set [No
Protection] and reconnect via Wi-Fi in STEP 2.
◆ If "Not available" is displayed,
congure the connection destination in STEP 4.
<Wireless LAN Setup QR Code>
Attach the QR code label to the location described in STEP 2 of the
enclosed つなぎかたガイド “Setup Guide” (Japanese).
This QR code contains the default wireless LAN conguration information
(network name (SSID), encryption mode, encryption key) for this product.
Data communication can be performed with this product by connecting wireless LAN (Wi-Fi®) devices such as a PC, game console, smartphone, etc.
Up to 10 wireless LAN (Wi-Fi®) devices can be connected to this product.
However, the wireless LAN (Wi-Fi®) function and the Bluetooth function cannot be used simultaneously.
WiMAX 2+/
WiMAX
Wi-Fi SPOT
PC, game console, etc.
Smartphone
Conguring the Connection Destination
WiMAX 2+/WiMAX / Wi-Fi SPOT Connection
Launch the Quick Setting Webpage
aOpen the web browser on the wireless LAN (Wi-Fi®) device (such as a smartphone) connected to
the Product in STEP 2.
bOpen Quick Setting Webpage for the product.
Type "http://192.168.179.1" into the address bar in the web browser and either tap [実行 (Execute)] or [開
く(Open)], or press the Enter key on the keyboard.
cTap or click on [Advanced Settings Top] in the screen of the Quick Setting Webpage.
[Advanced Settings Top] button
Follow instructions below for detailed settings
d-1 Perform initial congurations for the administrator password.
Type a password (any string of characters) in the [パスワード (Password)] (password reentry) field and tap
or click on [設定 (Set)].
* Numbers 0 - 9, letters a - z and A - Z, hyphens (-) and underscores (_) may be used in the password. A password may be up to 64
single-byte characters.
This password will be required every time you open the "Advanced Settings" in the "Quick Setting
Webpage" for the product.
Make sure that you do not lose this password.
Administrator Password Field
Tap or click
Administrator Password Memo
d-2 Type "admin" for the [名前 (Name)] or [ユーザー名 (User Name)] and the "administrator password"
set in d-1 for the [パスワード (Password)], and then tap [ログイン (Login)] or click on [OK].
admin
Administrator Password
Tap
admin
Click
Administrator Password
《Page for mobile phone》《
Page for PC》
Conguring the Connection Information
● Connecting to WiMAX 2+/WiMAX
Follow procedures below to add proles when information required for internet connection (user name, password
etc.) is specied by your WiMAX operator.
If the WiMAX operator to whom you are subscribed species the preset prole, select the prole in [Functions
Maintenance] - [APN] in the display menu. If there is no such information provided, you can use the prole (Prole
name "Internet") of this product to connect to internet.
When using a smartphone / tablet
(Android) / iPad / iPhone / iPod touch
aTap [ネットワーク設定 (Network Settings)] -
[プロファイル設定 (Prole Settings)].
bAfter selecting [no setup] in the [プロファ
イルリスト (Prole List)], tap [選択 (Select)],
enter the setup information such as the APN
of the WiMAX operator to whom you are
subscribed, and tap [設定 (Apply)].
* The displayed content may be grayed out.
* If you have any question, please check with the WiMAX
operator to whom you are subscribed to.
c
Tap [詳細設定TOPへ (Advanced Settings Top)].
dTap [ネットワーク設定 (Network Settings)] -
[接続設定 (Connection Settings)].
eIn the Prole Selection, select the prole which
you selected in Step b, and tap [設定 (Apply)].
fTap [詳細設定TOPへ (Advanced Settings
Top)], and tap [保存 (Save)].
Try opening a website to verify the connection.
When using a PC
aTap [ネットワーク設定 (Network Settings)] -
[プロファイル設定 (Prole Settings)].
bAfter selecting [no setup] in the [プロファイ
ルリスト (Prole List)], click [選択 (Select)],
enter the setup information such as the APN
of the WiMAX operator to whom you are
subscribed, and click on [設定 (Apply)].
* The displayed content may be grayed out.
* If you have any question, please check with the WiMAX
operator to whom you are subscribed to.
cClick [保存 (Save)].
dClick [ネットワーク設定 (Network Settings)]
- [接続設定 (Connection Settings)].
eIn the Prole Selection, select the prole
which you selected in Step b, and click [設定
(Apply)].
fClick [保存 (Save)].
Try opening a website to verify the connection.
●Connecting to a Wi-Fi SPOT (Public Wireless LAN Service)
When using a smartphone / tablet
(Android) / iPad / iPhone / iPod touch
* Tap [←PC用ページに戻ります。 (To the PC-optimized
page)] and perform congurations by following the steps
in "When using a PC" in the screen for the Quick Setting
Webpage for PC.
When using a PC
aClick on [Wi-Fi スポット設定 (Wi-Fi SPOT
Settings)] - [接続先設定 (Access Point
Settings)].
bClick on [接続先登録 (Access Point
Registration)].
cCongure the connection destination.
aSelect the connection destination in "プロ
バイダ選択 (Provider Selection)".
* Select "-" for connection destinations other than the preset.
bPerform configurations based on
information provided by the provider of the
Wi-Fi SPOT service you will be using.
The provider to whom you are subscribed
is marked as the supported access point
by selecting in プロバイダ選択 (Provider
Selection).
* From the destination registration screen, up to eight
access points can be registered to the destination list.
* Multiple SSIDs can be saved to the access point with [ア
クセスポイント設定 (Access Point Set)] button.
dClick on [設定 (Set)].
eClick on [保存 (Save)].
fClick on [Wi-Fi スポット設定 (Wi-Fi SPOT
Settings)] - [基本設定 (Basic Settings)].
gPlace a check in "使用する (Enable)" for the
"Wi-Fi スポット (Wi-Fi SPOT)".
* Configure this while you are in a Wi-Fi SPOT service area.
hClick on [設定 (Set)], then on [保存 (Save)].
iCheck that the status of the connection
displayed on the product appears as "(Wi-Fi)".
Try opening a website to verify the connection.
4

Firmware Update
Follow the steps listed below to update the rmware.
aPress the POWER button on the product and set the product in the
normal display.
bWhen "New Firmware is released. Do you want to update?" is displayed,
select [YES] with the SELECT button, and press the SET button.
cWhile the update is in progress, the message "Updating the Firmware...
Please do NOT turn o this product." will be displayed.
dWhen the update has been completed, the product will automatically
reactivate and the display will appear.
Firmware cannot be updated when the product is connected to the cradle (sold separately) and used in wireless LAN Access point mode. Disconnect
the product from the cradle (sold separately) and change to router mode to update the firmware.
Smartphone Application "NEC WiMAX 2+ Tool"
By using "NEC WiMAX 2+ Tool", an application designed exclusively for this product, it is possible to
view information of the product on your smartphone, etc. and perform operations to switch to or
pause Wi-Fi SPOT services.
* The exclusive application enables remote-activation. Search the Google Play or App Store for "NEC WiMAX 2+ Tool" to download
and install this exclusive application.
Be sure to congure the password before activating the exclusive application.
* If the message "管理者パスワードが設定されていません 管理者パスワードを設定しますか (The administrator
password has not been set. Would you like to set the administrator password)" is displayed when the exclusive application is
activated, set the password by following the instruction on-screen.
Administrator Password Memo
O
Take note of the administrator password as it will be required in order to configure the product.
If you have forgotten the administrator password, it will not be possible to access the screen of the
Quick Setting Webpage and it will be necessary to initialize the product and redo all configurations.
Initialization Method
When the product is not operating properly or bringing back to the default setting, perform initialization by
following the steps below. (This will delete all user settings and the screen display will change to Japanese.)
aPress the POWER button and set the display to normal.
bIn the normal display, press the SELECT button a few times, select [Functions Maintenance] in the
menu and press the SET button.
cPress the SELECT button a few times, select [Initialize] and press the SET button.
dSelect [YES] for [Do you want to Initialize?] with the SELECT button, and press the SET button.
eInitialization will be completed once the product has been reactivated.
This product can be used with OSs such as Windows®,
Macintosh, Linux etc. which support TCP/IP protocol stack
(Japanese OS only).
However, the following OSs are supported during USB
connection.
Windows® 8.1, Windows® 8, Windows® 7 Japanese version,
32bit (x86) version and/or 64bit (x64) version, Japanese
version of WindowsVista® (SP2 and later) 32bit (x86)
version and Mac OS X v10.5 (Intel), v10.6 (Intel), v10.7 (Intel),
v10.8 (Intel), v10.9 (Intel), v10.10 (Intel).
The following WWW Browsers are available when
performing settings in Quick Setting Webpage.
Windows® 8.1 supporting;
• Internet Explorer 11.0
• Firefox 34
• Google Chrome 39
• Opera 26
Windows® 8 supporting;
• Internet Explorer 10.0
• Firefox 34
• Google Chrome 39
• Opera 26
Windows® 7 supporting;
• Internet Explorer 8.0/9.0/10.0/11.0
• Firefox 34
• Google Chrome 39
• Opera 26
Windows Vista® (SP2 and later) supporting;
• Internet Explorer 7.0/8.0/9.0
• Firefox 34
• Google Chrome 39
• Opera 26
Mac OS X v10.10 supporting
• Safari 8.0
• Firefox 34
• Google Chrome 39
• Opera 26
Mac OS X v10.9 supporting
• Safari 7.0
• Firefox 34
• Google Chrome 39
• Opera 26
Mac OS X v10.7/v10.8 supporting
• Safari 6.1
• Firefox 34
• Google Chrome 39
• Opera 26
Mac OS X v10.6 supporting
• Safari 5.1
• Firefox 34
• Google Chrome 39
• Opera 26
Mac OS X v10.5 supporting
• Safari 5.0
Android (2.3/3.0/3.1/3.2/4.0/4.1/4.2/4.3/4.4/5.0) supporting
• Android standard browser
iOS (5.0/5.1/6.0/6.1/7.0/7.1/8.0/8.1) supporting
• iOS standard browser
Display Menu Operations
Various congurations can be performed and information can be
conrmed by operating menus with the SELECT/SET buttons in the
display.
The screen displays are examples of some of the congurations.
Setting Mode
While the display is turned on, using the SELECT/SET buttons switches
the screen as follows.
Switched by pressing the SELECT button
* Returns to normal display when the POWER button is pressed while
switching menus.
Switched by pressing the SET button
Switched by holding down the SET button
Switched automatically
<Setting Menu>
[Normal Display]
If the display has been turned off, press the POWER button to display the screen.
[Switching between WiMAX 2+/WiMAX and a Wi-Fi SPOT]
This menu is displayed when the "Wi-Fi SPOT" is set to "Enable" in the Quick Setting Webpage.
When the product is connected to a Wi-Fi SPOT, "Wi-Fi" is displayed.
■Switching to a Wi-Fi SPOT
■Switching to WiMAX 2+/WiMAX
[Wi-Fi Band]
This menu is displayed when the 5GHz band is set to "Enable" in Quick Setting Webpage, and
not connected to Wi-Fi SPOT.
Note the following points when using the 5GHz band.
• By default, the product is not set to the 5GHz band.
• For 5.2GHz or 5.3GHz band, use indoors only.
• When Outdoor is selected, it takes about one minute to search the channel with the DFS
function for avoiding interference of a meteorological radar, etc. ("Checking channel"
appears on the display.)
* The confirmation of 5GHz
(Indoor) usage may appear
automatically.
[LAN Selection Wi-Fi/Bluetooth]
Selects Wi-Fi or Bluetooth tethering for the wireless function on the LAN side.
[Terminal Info]
Displays information such as the version information of the product and the name of the
Bluetooth device.
Your phone number is
recorded as user
information. However the
product cannot make or
receive voice calls.
[Wi-Fi Info]
Displays the network name (SSID) and the encryption key.
* For the Primary/Secondary key, "Encryption Disabled" is displayed when encryption is disabled in the
wireless LAN (Wi-Fi®) settings.
* Appears when
encryption is
disabled.
[Remote Start]
Sets the Remote Start. If this function is set during the idle state, this
product goes into standby for Remote Start. From the Quick Setting
Webpage, [ECO設定 (ECO Settings)] - [休止状態設定 (Idle State
Settings)] - [リモート起動 (Remote Start)] is also available.
[Functions
Maintenance]
Sets each function.
[APN]
Selects the saved profile.
* When multiple profiles are saved, press
the SELECT button to select and
change the profile.
[Wi-Fi Spot]
[Counter Display]
Displays the communication amount on the display.
[Wi-Fi Management Frame]
This function enhances encryption of wireless LAN (Wi-Fi®)
communication.
[Initialize]
Initializes the product back to its factory settings.
* The screen display will changes to Japanese.
[Reboot]
[Save Energy Set]
This function saves energy by limiting the communication speed of WiMAX 2+ and wireless LAN (Wi-Fi
®
).
[Setup Wi-Fi with Rakuraku/WPS]
Appears when "LAN Selection Wi-Fi/Bluetooth" is set to "Wi-Fi".
This menu is used to setup Rakuraku Wireless and WPS.
Be sure to perform configurations after first activating Rakuraku Wireless Start or WPS on the
wireless LAN (Wi-Fi®) device.
[Bluetooth Pairing Setting]
Displays when "LAN Selection Wi-Fi/Bluetooth" is set to "Bluetooth".
* To cancel, hold down the SET button
[Firmware Update]
This menu is displayed to notify users when a firmware update is available.
Displayed Information
◆Normal display ◆
Message/Data communication amount display
1
2
3
5
6
9
8
9
4
◆Idle state display
7
7
Name Indicator State Explanation
1Reception level
Illuminating Indicates the signal strength of WiMAX 2+ in 5 levels
Illuminating Indicates the signal strength of WiMAX / Wi-Fi SPOT in 6 levels
Illuminating Indicates that the product is connected to the cradle (sold separately) with wireless LAN access point mode
2Connection status
Illuminating Indicates that the product is connected to the Internet with WiMAX 2+
Illuminating Indicates that the product is connected to the Internet with WiMAX
Illuminating Indicates that the product is connected to the Internet with Wi-Fi SPOT
Blinking Indicates that a connection to the Internet is trying to be established with Wi-Fi SPOT
Illuminating Indicates that the device is outside the WiMAX 2+/WiMAX/Wi-Fi SPOT service area
Illuminating
Indicates that the product is connected to the cradle (sold separately) with wireless LAN access point mode,
and connected to the Internet
Illuminating Indicates that LAN is connected via USB
Illuminating Indicates that the product is connected to the the cradle (sold separately) and wired LAN
3Firmware update notication
Illuminating Indicates that the new rmware is released and update is required
4Wireless LAN (Wi-Fi®) band
Illuminating Indicates that the product is connected to the 5GHz band (outdoor)
Illuminating Indicates that the product is connected to the 5GHz band (indoor)
OFF Indicates that the product is connected to the 2.4GHz band
5Wireless status on LAN side
Illuminating Indicates that the wireless LAN (Wi-Fi®) on the LAN side is ON (the number below indicates the connected devices)
Blinking Searching the wireless LAN (Wi-Fi®) band
OFF Indicates that the wireless LAN (Wi-Fi®) on the LAN side is OFF
Illuminating Indicates that Bluetooth is ON (the number below indicates the connected devices)
OFF Indicates that Bluetooth is OFF
6Battery status
Illuminating Indicates the remaining battery level on a scale of 6 levels
Illuminating Appears under the battery icon while Energy-Saving is set
Illuminating Indicates that the battery is being charged
Illuminating Provides an approximate visual indication of the remaining battery level while charging
7Idle state
Illuminating Indicates the idle state (appears when the POWER button is pressed while charging)
Animation Indicates that the remote-activation is set (appears when the POWER button is pressed while charging)
8Messages Indicates various messages
9Data communication amount Indicates when the data communication amount is set
Product Specications
■Main Unit
Physical dimensions (W x H x D) Approx. 109 (W) × 66 (H) × 9.0 (D) mm
Weight Approx. 97g
Interface USB2.0 High Speed (microUSB terminal) *3
Compliant with Bluetooth 4.0 Wireless Technology
Display Organic electroluminescence display (monochromatic), approx. 1.0 inch
Power supply DC5.0V, 1.5A
Battery pack Lithium ion, 3.8V, 2500mAh
Continuous standby time *1
Waiting state: Approx. 35 hours
Idle state (Remote start available): Approx. 400 hours
Idle state (Remote start not available): Approx. 650 hours
Continuous communication time *1*2
(During Wi-Fi connection)
WiMAX 2+ (4x4 MIMO communication): Approx. 400 minutes
WiMAX 2+ (2x2 MIMO communication): Approx. 520 minutes (power saving is set)
WiMAX: Approx. 680 minutes
Continuous Communication Time *1
(During Bluetooth connection)
WiMAX 2+ (4x4 MIMO communication): Approx. 480 minutes
WiMAX 2+ (2x2 MIMO communication): Approx. 620 minutes (power saving is set)
WiMAX: Approx. 810 minutes
Operating environment Operating temperature range: 5°C to 35°C
Operating humidity range: 35% to 85%
Charging time Approx. 180 minutes (using the enclosed AC adapter)
*1: The continuous standby time and continuous communication time may vary depending on the communication network being used.
*2: The continuous communication time when connected to a single wireless LAN (Wi-Fi®) device..
*3: Use of USB2.0 or later is recommended as a sucient transfer rate cannot be achieved with USB1.1. It should be noted that operation is not guaranteed with all computers that
are supported.
■WAN
Communication methods WiMAX 2+, WiMAX, Wi-Fi (compliant with IEEE802.11ac/n/a/g/b)
Supported frequencies WiMAX 2+/WiMAX: 2.5GHz
Wi-Fi: 2.4GHz/5GHz
■LAN
Communication methods Wi-Fi (compliant with IEEE802.11ac/n/a/g/b), compliant with Bluetooth 4.0 Wireless Technology
Supported frequencies Wi-Fi: 2.4GHz/5GHz / Bluetooth: 2.4GHz
Wi-Fi security methods
WEP: 128bit
WPA-PSK: TKIP / AES
WPA2-PSK: TKIP / AES
Maximum number of simultaneous connections Wi-Fi: 10 devices / USB: 1 device / Bluetooth: 7 devices
■AC adapter
AC adapter
Input AC100 to 240V, 50/60Hz
Output DC5.0V, 1.0A
Physical dimensions Approx. 47 (W) × 54 (H) × 19 (D) mm
Weight Approx. 41g
Operating environment Operating temperature range: 5°C to 35°C
Operating humidity range: 35% to 85%
microUSB cable
Length Approx. 1.0m
Weight Approx. 30g
Interface USB plug: Type A
microUSB plug: Type B
■Aterm is a registered trademark of NEC Corporation. ■Rakuraku wireless start and Rakuraku QR start are registered trademarks of NEC Platforms, Ltd. ■Windows is a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries. ■Mac, Macintosh, Mac OS, OS X,
iPad, iPhone and iPod touch are trademarks of Apple Inc. registered in the United States and/other countries. App Store is a service mark of Apple Inc. ■The iPhone trademark is used under license from Aiphone Co., Ltd. ■Internet Explorer is a trademark or registered trademark of Microsoft Corporation in the
United States and/or other countries. ■Firefox® is a trademark or registered trademark of US Mozilla Foundation in the United States and/or other countries. ■Opera is a trademark or registered trademark of Opera Software ASA ■Android and Play Store are trademarks or registered trademarks of Google Inc.
■"QR Code" is a registered trademark of DENSO WAVE INCORPORATED. ■Other company names, brand names, service names and so on are trademarks or registered trademarks of their respective owners. TM and the ®mark may be omitted in this manual.
© NEC Platforms, Ltd. 2015 This manual may not be duplicated or updated, or duplicate copies of the manual distributed, without prior written permission from NEC Platforms, Ltd.
January, 2015, 1st Edition
Sold by: KDDI CORPORATION, OKINAWA CELLULAR TELEPHONE COMPANY
Manufactured by: NEC Platforms, Ltd.
Connecting via Bluetooth
Use this product as an access point to connect Bluetooth devices such as a smartphone
and tablet to the Internet. It is ecient for saving the battery.
Up to seven devices can be connected to the product via Bluetooth. (For pairing, up to 10
devices can be registered.)
However, depending on the ambient reception environment, the number of connected
devices may not reach the limit.
Also, the wireless LAN (Wi-Fi®) function and the Bluetooth function cannot be used
simultaneously.
The product
Bluetooth Smartphone
Tablet
WiMAX 2+/
WiMAX
Wi-Fi SPOT
tIf Bluetooth is disconnected after pairing, tap the Bluetooth device name of this
product on the Bluetooth-equipped device screen to reconnect.
tWhen the number of paired devices reaches the limit, "Registration limit. Delete the
pairing information." appears on the display. In that case, delete pairing information
displayed in "Bluetooth Pairing Info" on "Bluetooth Settings" in the screen of the
Quick Setting Webpage.
Checking the Devices
• Your Bluetooth-equipped device supports Bluetooth 2.1 or later.
• Your device supports the prole (PANU) which can connect to the Internet.
For the smartphone models that support PANU, see the manufacturer's website.
Preparing for the Connection
Taking a Note of Bluetooth Device Name
aIn the normal display, press the SELECT button a few times, select [Terminal Info] in the menu
and press the SET button.
bPress the SELECT button to display [Bluetooth Device Name].
The Bluetooth device name of this product is displayed in "Bluetooth Device Name".
Bluetooth Device Name
Memo
Turning Bluetooth "ON"
aIn the normal display, press the SELECT button a few times, select [LAN Selection Wi-Fi/
Bluetooth] in the menu and press the SET button.
bSelect [Bluetooth] with the SELECT button, and press the
SET button.
cCheck that is displayed in the normal display.
Conguring the Connection Information
Smartphone / Tablet (Android)
aIn the normal display, press the SELECT button a few times, select [Bluetooth Pairing Setting] in
the menu and press the SET button.
bSelect [YES] with the SELECT button, and press the SET button.
The message "Wait for Pairing" is displayed on the product.
cTap [設定 (Settings)] - [Bluetooth] on your Bluetooth-equipped device and set to "ON".
dOn your Bluetooth-equipped device, tap the Bluetooth
device name of this product which has been checked in
advance.
eCheck that "******* Start Pairing" is displayed on this
product.
* The Bluetooth-equipped device information, such as the
model name, is indicated in "*******".
fTap [ペア設定する (Pairing)] on your Bluetooth-equipped device.
The displayed item may vary depending on the Bluetooth-equipped device.
gSelect [YES] with the SELECT button, and press the SET button.
hThe message "Pairing Setting succeeds." is displayed on the product.
* If "Pairing Setting fails." is displayed, resume the Step 1.
iOn your Bluetooth-equipped device, tap the Bluetooth
device name of this product.
If the device cannot be connected to the Internet, tap the
icon on the right side of the device name to check that
Internet Access (*) is marked.
(*) Screen display may be different depending on the Bluetooth-
equipped device.
jCheck that a value of "1" or more is displayed under in the product display.
* This number indicates the number of connected devices.
iPad/iPod touch
* This function is unavailable, as iPhone does not support PANU. (As of January 2015)
aIn the normal display, press the SELECT button a few times, select [Bluetooth Pairing Setting] in
the menu and press the SET button.
bSelect [YES] with the SELECT button, and press the SET button.
The message "Wait for Pairing" is displayed on the product.
cTap [設定 (Set)] - [Bluetooth] on your Bluetooth-equipped device and set to "ON".
dOn your Bluetooth-equipped device, tap the Bluetooth
device name of this product which has been checked in
advance.
eCheck that "******* Start Pairing" is displayed on this
product.
* The Bluetooth-equipped device information, such as the
model name, is indicated in "*******".
fSelect [YES] with the SELECT button, and press the SET button.
gThe message "Pairing Setting succeeds." is displayed on the product.
* If "Pairing Setting fails." is displayed, resume the Step 1.
hCheck that "******* 接続済み (Connected)" is displayed on
your Bluetooth-equipped device.
* The Bluetooth device name of this product is indicated in
"*******".
iCheck that a value of "1" or more is displayed under in the product display.
This number indicates the number of connected devices.
