NEC LT157 - XGA LCD Projector Assembly instructions

M
E
N
U
E
N
T
E
R
C
A
N
C
E
L
SELECT
ON
/
STA
ND
SOURCE
AUTO
ADJUS
T
AC IN
C CARD
USB PC CONTROL
VIDEO S-VIDEO RGB AUDIO
LT158/LT157 Quick Connect Guide
M
E
N
U
E
N
T
E
R
C
A
N
C
E
L
PJ
FOCUS ZOOM
OFF
VIDEO
AUTO ADJ.
S-VIDEO RGB1 RGB2
LASER
ON
VOLUME
SHIFT
HELP
POINTER
KEYSTONE MAGNIFY
FREEZE
PIC-MUTE
PC CARD
SLIDE
FOLDER
SLIDE
LIST
SELECT
POWER
Remote Control Features
1. Infrared Transmitter
Direct the remote control toward the remote
sensor on the projector cabinet.
2. Laser Pointer
Beams a laser light when "Laser" button is
pressed.
3. Remote Jack
Not available on this model.
4. LED
Flashes when any button is pressed.
5. Power ON Button
If the main power is applied, you can use this
button to turn your projector on.
6. Power OFF Button
If the main power is applied, you can use this
button to turn your projector off.
NOTE: To turn off the projector, press and hold the
POWER OFF button for a minimum of two seconds.
7. VIDEO Button
Press this button to select an NTSC, PAL,
SECAM or NTSC4.43 compatible video source
from a VCR, DVD player, laser disc player or
document camera.
8. S-VIDEO Button
Press this button to select an S-Video source
from a VCR.
9. RGB 1 Button
Press this button to select a video source from
a computer or component equipment con-
nected to your RGB port (DVI digital on LT158).
10. RGB 2 Button
Not available on the LT157.
For LT158: Press this button to select a DVI
analog signal from a computer.
11. AUTO ADJ Button
Use this button to adjust an RGB source for an
optimal picture. Some signals may not be dis-
played correctly or take time to switch between
sources.
12. LASER Button
Press and hold this button to activate the laser
pointer. When lit, you can use the laser to draw
your audience's attention to a red dot that you
can place on any object.
13. MENU Button
Displays the menu for various settings and ad-
justments.
14. SELECT (▲▼䊴䊳) (Mouse) Button
When you are in the Computer mode, these
buttons work as a computer mouse.
When you are in the Projector mode, which is
indicated by lighting the PJ button:
▲▼:Use these buttons to select the menu of
the item you wish to adjust.
䊴䊳
:Use these buttons to change the level of a
selected menu item.
A press of the
䊳
button executes the se-
lection.
When the pointer is displayed, these ▲▼
䊴
䊳
buttons move the pointer.
15. ENTER (Left Click) Button
When you are in the Computer mode, this but-
ton works as the mouse left button.
When this button is pressed and held for a mini-
mum of 1.5 seconds, the drag mode is set.
When you are in the Projector mode, which is
indicated by lighting the PJ button:
Use this button to enter your menu selection. It
works the same way as the "Enter" button on
the cabinet.
16. CANCEL (Right Click) Button
When you are in the Computer mode, this but-
ton works as the mouse right button.
When you are in the Projector mode, which is
indicated by lighting the PJ button:
Press this button to exit "Menus". It works the
same way as the “Cancel” button on the cabi-
net.
17. PJ Button
Press this button to switch the Select, Cancel,
and Enter buttons between the Projector mode
(lit red) and the Computer mode. Press this
button or any one of the Power ON/OFF, Menu,
Help, Pointer, Magnify, PC Card, Folder List or
Slide List buttons to switch to the Projector
mode and the PJ button lights red. To switch
back to the Computer mode, press the PJ but-
ton again.
18. FOCUS Button
Not available on this model.
19. ZOOM Button
Not available on this model.
20. SHIFT Button
Not available on this model.
21. HELP Button
Provides information about operation and ad-
justment procedures or the set information for
the current menu or adjustment during menu
operation.
22. POINTER Button
Press this button to display one of the eight
pointers; press again to hide the pointer. You
can move your pointer icon to the area you want
on the screen using the Select button.
23. KEYSTONE (+) (–) Button
Press the (+) or (–) button to correct the key-
stone (trapezoidal) distortion, and make the im-
age square.
24. MAGNIFY (+) (–) Button
Use this button to adjust the image size up to
400%.
When the pointer is displayed, the image is
magnified about the center of the pointer.When
the pointer is not displayed, the image is mag-
nified about the center of the screen.
When the image is magnified, the pointer is
changed to the magnifying icon.
25. FREEZE Button
This button will freeze a picture. Press again to
resume motion.
26. PICTURE MUTE Button
This button turns off the image and sound for a
short period of time. Press again to restore the
image and sound.
NOTE: When the menu is displayed, a press of
this button mutes an image and sound without
turning off the menu.
27. VOLUME (+) (–) Button
Press (+) to increase the volume and (–) to de-
crease it.
28. PC CARD Button
Press this button to select the PC Card Viewer
source.
29. SLIDE (+) (–) Button
Press (+) to select the next folder or slide and
(–) to select the previous folder or slide.
30. FOLDER LIST Button
Press this button to select PC Card Viewer
source to display a list of folders included in a
CompactFlash card.
31. SLIDE LIST Button
Press this button to select PC Card Viewer
source to display a list of slides included in a
CompactFlash card.
*NOTE: The default is the Computer mode, which
allows you to use the Select, Cancel, and Enter but-
tons as your computer mouse. When the POWER
ON/OFF, MENU, HELP, POINTER, MAGNIFY, PC
CARD, FOLDER LIST, or SLIDE LIST button is
pressed, the PJ button lights red to indicate that you
are in the Projector mode. If no buttons are pressed
within 10 seconds, the light goes out and the Projec-
tor mode is canceled.
123
5
9
10
12
14
16
17
19
20
28
29
30
31
4
6
8
7
11
13
15
22
18
21
23
24
25
26
27
Printed in Japan
7N8P1231
Step1 Connect the supplied signal cable.
Connect the supplied power cable.
Step2
Power cable
(supplied)
Always power down before you make any connections.
M
E
N
U
E
N
T
E
R
C
A
N
C
E
L
SELECT
POWER
STATUS
ON
/
STANDBY
SOURCE
AUTO
ADJUST
PCCARD
ACCESS
AC IN
CCARD
PCCONTROL
VIDEO RGB
USB
S-VIDEOAUDIO
RGB
S-VIDEO AUDIO
DEO
RGB INPUT AUDIO
C CARD
PCCONTROL
VIDEODVI-D
USB
S-VIDEO AUDIO
M
E
N
U
E
N
T
E
R
C
A
N
C
E
L
SELECT
POWER
STATUS
ON
/
STAND BY
SOURCE
AUTO
ADJUST
PC CARD
ACCESS
ACIN
EODVI-D
S-VIDEOAUDIO
DVI AUDIO
RGB signal cable
(supplied)
Mini D-Sub 15 pin
connector
LT157
LT158
Audio cable (not supplied)
Audio cable
(not supplied)
DVI-D – DVI-D
signal cable (supplied)
DVI connector ①
DVI-A – VGA signal cable
(supplied)
Mini D-Sub 15 pin
connector ➁
Connection Option ①when using DVI output
Connection Option ➁when using mini D-Sub 15 pin output
M
E
N
U
C
A
N
C
E
L
SELECT
AC IN
C CARD
US
3
4
Step3 Turn on the projector.
NOTE: To turn off the projector, press and hold the Power
(ON/STAND BY) button for a minimum of two seconds.
M
E
N
U
E
N
T
E
R
C
A
N
C
E
L
SELECT
POWER
STATUS
ON
/
STAND BY
SOURCE
AUTO
ADJUST
PC CARD
ACCESS
CARD
PC CONTROL
VIDEO RGB
USB
S-VIDEO AUDIO
M
E
N
U
AC
Step4 Set up the Projector
Focus ring
To adjust the projector's focus or to zoom in and out, use
the Focus ring and Zoom lever on the lens.
Zoom lever
Adjusting the Tilt Foot
M
E
N
U
C
A
N
C
E
L
SELECT
AC IN
C C
2
1
•If the projected image does not appear square to the
screen then use keystone correction for proper ad-
justment. See page 29 or 34 of the supplied user's
manual.
1. Lift the front edge of the projector.
2. Press the Tilt button on the front of the projector
to extend the Adjustable Tilt Foot.
3. Press and hold the Tilt button.
4. Lower the front edge of the projector to the de-
sired height and release the Tilt button to lock
the Adjustable Tilt Foot.

Menu Tree Troubleshooting
Advanced Menu
Source Select RGB*
1
Picture Video
Volume S-Video Brightness/Contrast/Color/Hue/Sharpness
Image Options
Color Management
PC Card Viewer
Projector Options
Volume
Tools
Help
Keystone Normal/Eco
Lamp Mode Aspect Ratio Normal/Zoom/Wide Zoom/Cinema
Advanced Options Noise Reduction Off/Low/Medium/High
Factory Default
Position/Clock Horizontal/Vertical/Clock/Phase
Resolution Auto/Native
Video Filter On / Off
All Data/Current Signal
Menu Menu Mode (Advanced Menu, Basic/Custom Menu)
Setup
White Balance
Gamma Correction
Color Matrix
Basic/Custom Menu Edit
Language (English/German/French/Italian/Spanish/Swedish/Japanese)
Projector Pointer (Pointer 1-8)
Menu Display Time (Manual/Auto 5 sec/Auto 15 sec/Auto 45 sec)
Message Source Display
Direct Button Volume Bar
Keystone Bar
No input
(On/Off)
(On/Off)
(On/Off)
(On/Off)
Clean Filter (On/Off)
Page 1
Background (Blue/Black/Logo)
Mouse Button(Right Hand/Left Hand)
Sensitivity(Fast/Medium/Slow)
Page 2
Page 1 Orientation (Desktop Front/Ceiling Rear/Desktop Rear/Ceiling Front)
Cinema Position (Top/Center/Bottom)
Page 2 PC Card Viewer Options Show Folder List
(Auto Play/Manual Play)
Interval (5-300 sec)
Capture Options (High Quality/Normal/High Compression)
Page 3 Signal Select RGB*
2
(Auto/RGB/Component)
Video (Auto/NTSC3.58/NTSC4.43/PAL/PAL-M*3/PAL-N*3/PAL60/SECAM)
S-Video (Auto/NTSC3.58/NTSC4.43/PAL/PAL-M*3/PAL-N*3/PAL60/SECAM)
Page 4 Auto Adjust (RGB Only)
Auto Start
Power Management
Power Off Confirmation
Keystone Save
Clear Filter Usage
Clear Lamp Hour Meter
Capture
Page 5 Communication Speed(4800/9600/19200/38400)
PC Card Files
Default Source Select(Last/Auto/Select)
ChalkBoard Control Panel Key Lock (Enable/Disable)
(RGB*
4
/Video/S-Video/PC Card Viewer)
Contents Contents
Information Page1
Source Name/Input Terminal/Horizontal Frequency/Vertical Frequency/Sync Polarity
Page2 Signal Type/Video Type/Sync Type/Interlace/Resolution
Page3 Aspect Ratio/Gamma Correction/Noise Reduction/Color Matrix/Matrix Type
Page4 Remaining Lamp Time/Lamp Hour Meter/Filter Usage/Projector Usage
Select Color Matrix HDTV/SDTV
Normal/Natural 1/Natural 2
Select Color Matrix Type B-Y/R-Y,Cb/Cr,Pb/Pr
Brightness R/G/B, Contrast R/G/B
This section helps you resolve problems you may encounter while setting up or using the projector.
Power/Status Light Messages
Standby
Cooling down
Lamp in Normal mode
Lamp in Eco mode
Retrying lamp turn on
One minute after lamp is turned
on
Lamp has reached its end of life
(Normal: 1500 hours or over)
(Eco: 2500 hours or over)
Lamp life has reached its end of
life
(Normal: 1600 hours or over)
(Eco: 2600 hours or over)
Lamp or filter cover error
Temperature error
Fan error
Lamp error
Condition
Steady orange
Blinking green
Steady green
Steady green
Steady green
Blinking green
Steady green
Steady orange
Steady orange
Steady orange
Steady orange
Steady orange
–
–
–
Steady green
Blinking orange
No light in Normal mode / Steady
green in Eco mode
Steady red
Steady red
Blinking red (1 sec interval)
Blinking red (4 sec interval)
Blinking red (8 sec interval)
Blinking red (12 sec interval)
–
Blinks green for 90 seconds
–
–
The projector retries 3 times at an interval of
15 sec for max. 45 sec)
–
Message appears on screen during 1500-1600
hours (2500-2600 hours: Eco mode) of lamp
usage. The projector reaches its end of life.
Please replace the lamp as soon as possible
The projector is in standby mode and cannot
be turned on.
The projector is in standby mode and cannot
be turned on.
The projector is in standby mode and cannot
be turned on.
The projector is in standby mode and cannot
be turned on.
The projector is in standby mode and cannot
be turned on.
Power Indicator Status Indicator Note
•Is “PC Card Viewer” selected from the Source menu?
•Is the CompactFlash memory card seated in the PC CARD slot completely?
•Is slide data stored in the CompactFlash memory card?
•Have the contents of the CompactFlash memory card been destroyed?
•While an image with over 1024⳯768 dots is projected, several lines of information will be lost. Use
the supplied software to change the image to 1024⳯768 dots in size.
•Use a computer, etc., to repair the data.
Problem Check These Items
When using the PC Card Viewer function
For more information contact your dealer.
No picture
Part of a slide is not displayed
Contents of CompactFlash Card
are damaged
Common Problems & Solutions
Does not turn on
No picture
Image isn’t square to the screen
Picture is blurred
Image is scrolling vertically,
horizontally or both
Remote control does not work
Status indicator is lit or blink-
ing
Cross color in RGB mode
•Check that the power cable is plugged in and that the power button on the projector cabinet or the
remote control is on.
•Ensure that the lamp cover or filter cover is installed correctly. See pages E-48 and E-49.
•Check to see if the projector has overheated or the lamp usage exceeds 1600 hours (up to 2600 hours
: Eco mode). If there is insufficient ventilation around the projector or if the room where you’re
presenting is particularly warm, move the projector to a cooler location.
•Use the menu to select your source [Video, S-Video, RGB (DVI digital or DVI analog on LT158) or
PC Card Viewer]. See pages E-18 and E-33.
•Ensure your cables are connected properly.
•Use menus to adjust the brightness and contrast. See page E-33
•Remove the lens cap.
•Reset the settings or adjustments to factory preset levels using the Factory Default in the Adjustment
Menu. See page E-35
•Reposition the projector to improve its angle to the screen. See page E-25
•Use the Keystone to correct the trapezoid distortion. See page E-29 or E-34
•Adjust the focus. See page E-25
•Reposition the projector to improve its angle to the screen. See page E-25
•Ensure that the distance between the projector and screen is within the adjustment range of the lens.
See page E-16
•Use menus or Source button on the remote control or the cabinet to select the source you want to
input.
•Install new batteries. See page E-13
•Make sure there are no obstacles between you and the projector.
•Stand within 22 feet (7 m) of the projector. See page E-13
•Make sure that you are in the Projector mode and the PJ button lights in red. If not, press the PJ
button.
•See the Power/Status Light messages above.
•If Auto Adjust is off, turn it on. If Auto Adjust is on, turn it off and balance the image with the
Position/Clock in the Image Options. See page E-35 or E-38
Problem Check These Items
NOTE:
1) When menu items are not available, they are indicated in white.
2) For LT158: When DVI (DIGITAL) is selected, making any adjustment executes the
Auto Adjust feature. The AUTO ADJUST button on the remote control is also avail-
able. You can adjust the horizontal and the vertical position for DVI digital signal but
cannot save those adjustments.
NOTE:
*1On LT158, "DVI (DIGITAL)" and "DVI (ANALOG)" are displayed in the Source Select submenu.
*2On LT158, "DVI (ANALOG)" is displayed in the Signal Select on Page 3.
*3LT158 Only.
*4On LT158, "DVI (DIGITAL)" and "DVI (ANALOG)" can be also selected.
