NEC MT1065 - MultiSync XGA LCD Projector User manual

MT1065: An essential element of your communication infrastructure.
The MT Series installation projectors include innovative features and technologies from NEC’s
renowned design labs.
SMART DESIGN MAKES SET-UP AND USE SECOND NATURE.
°Automatic intelligence. The built in image sensor automatically focuses, adjusts color
tones, keystone corrects, and squares the image with the touch of a button.
°Plentyofpower. AutosenseTM intuitively syncs the projector with most computer signals and
features one-touch image optimization.
°USB flexibility. Play back presentations or display images stored as .jpgs from standard
USB keys.
°Adapts for special needs. ADA508 compliant for hearing-impaired and colorblind users
supporting closed caption display and black & white menu options.
°Anything’s a screen. Project on spheres, cylinders, corner angles and more.
MULTI-TALENTED AND ABLE.
°Multiplelenses. Quickly install optional lenses that allow multiple room use from one projector.
°Break the ANSI barrier.4200 ANSI (MT1075) and 3400 ANSI (MT1065).
°Advanced AccuBlendTM. Ensures detailed images even when non-native resolution
sources are connected to the projector.
°Network connectivity.Communicate with the projector with or without wires through an
existing infrastructure or an on-the-fly peer-to-peer connection.
ECONOMICAL AND COST EFFECTIVE.
°Advanced power management. Meets Executive Order 13221 for efficient operation
supporting standby power consumption of <1 watt and a hard power switch to completely
shut down the projector.
°Extendedlamplife. Eco-modeTM technology increases lamp life by up to 50%. An optional
long life lamp is available that doubles normal lamp life.
°Free asset management tools. Networking tools come standard.
°Security features. Enhanced multi-level security features protect your investment.
WIRED OR WIRELESS NETWORKING
CAPABLE
IMAGE SENSOR ENABLES:
• auto focus lens
• automatic 3D Reform keystone
• automatic color (wall) correction
ENHANCED THEFT DETERRENT
SYSTEM
ADA508, EO 13221 COMPLIANT
ECO-MODE LAMP EXTENSION
TECHNOLOGY
VARIABLE AUDIO OUT
HDTV COMPATIBLE
INSTACARE COVERAGE
Everything should be this easy
MT1065 installation projector.
NEC 120523 SPEC_MT1065 12/30/05 1:19 PM Page 1

NEC 120523
For more information, call 1.800.NEC.INFO
or visit www.necvisualsystems.com
NEC is a registered trademark of NEC Corporation.
All other trademarks are the property of their respective owners.
All specifications subject to change without notice.
NEC Solutions (America), Inc.
Visual Systems Division
1250 Arlington Heights Rd., Suite 400
Itasca, IL 60143-1248
OPTICAL
LCD Panel 1.0” p-Si TFT w/ MLA
Resolution 1024x768 pixels up to UXGA with Advanced AccuBlend
Lens Power zoom and Power AUTO focus F=1.74-2.18, f=30.8-41.6mm
Light Output 3400/2700 normal/eco
(ANSI, typical)
Optional Extended 1900 super-eco
life lamp
Lamp 275W/220W/160W NSH, normal/eco/extended
Lamp Life Optional Extended lamp 4000H
(up to) Standard lamp Eco-mode 3000H; Normal mode 2000H
Contrast Ratio 800:1
Image Size 25 - 500 inches diagonal
Keystone Correction ±40 degree (Vertical), ±35 degree (Horizontal)
Projection Distance 2.46-68.9ft, 0.75-21m
Projection Angle TELE: 10.3 – 10.7 degree; WIDE: 13.7 – 14.4 degree
ELECTRICAL
Inputs 1 DVI-D, 1 5-BNC, 1 RGB, 1 S-Video, 1 Video, 2 PC Card, 2 L/R RCA Audio, 3 Stereo Mini
Audio, 1 USB A, 1 Remote
Outputs 1 RGB, 1 Stereo Mini Audio, 1 L/R RCA Audio, 1 USB B, 1 9-Pin PC Control, 1 Mouse
Video Compatibility NTSC, NTSC 4.43, PAL, PAL-M, PAL-N, PAL-60, SECAM, HDTV: 1080p, 1080i, 720p,
SDTV: 480p, 480i (w/optional cable), Y/Cb/Cr component (w/optional cable)
Scan Rate Horizontal: 15 to 100 kHz (non-interlaced) Vertical: 48 to 120 Hz
Video Bandwidth RGB 80MHz
Pixel Clock Freq 102MHz
Color Reproduction 16.7 million colors simultaneously, Full color
Horizontal Resolution NTSC, NTSC4.43, PAL/PAL-M/PAL-N/PAL-60 - 600TV lines
S-video (NTSC/PAL) – 650TV lines
SECAM - 350TV lines, Y/Cb/Cr - 800TV lines,
RGB -1024dots (H) x 768dots (V)
External Control RS232, USB, LAN, IR, (AMX/Crestron compatibility)
Sync Compatibility Separate Sync / Composite Sync / Sync on G
Built-in Speakers 5Wx2 with volume, bass, treble control
Fan Noise Normal mode <39
Eco-Mode <34
Super Eco-Mode <29
Power Requirements 100-120VAC/200-240VAC, 50/60Hz
Input Current 4A (100-120VAC), 2A (200-240VAC)
Power Consumption 390W
MECHANICAL
Installation Orientation: Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear
Dimensions (WxDxH) 13.15x12.72x4.53, 334x323x115mm (Not including protrusions)
Net Weight 13.lb. (5.9 Kg)
Environment Operational Temp. 32° to 95°F / 0° to 35°C
Humidity: 20-80% non-condensing
Storage: 14°to 122°F / -10° to 50°C
Regulations USA UL 60950 FCC Class B
Canada CSA60950 (C-UL)
Accessories Users manual, wired/wireless addressable remote control with laser pointer, power cable,
remote cable, signal cable, quick connect guide, registration card, application CD-ROM
Warranty Registered owners receive a 2-year limited, parts and labor warranty including InstaCare.
InstaCare provides the original owner either limited 3 business day repair/return or next
business day exchange. The lamp when used under normal operating conditions is covered
for 500 hours or 3 months, whichever comes first.
BUILT-IN IMAGE SENSOR ENABLES
Auto Focus lens Automatically have the projector focus to the screen. Allows for the use of multiple screens
and easily switch between them with minimal user interface
Automatic Wall Provides for true color reproduction when projecting onto non-
Color Correction standard screens or colored walls
Automatic 3D Reform Horizontal, vertical and diagonal keystone correction
PRODUCT/ACCESSORIES
Order Code Description
MT1075 MT1075, XGA, 4200 ANSI projector
MT1065 MT1065, XGA, 3400 ANSI projector
MT60-10RL 1:1 Short throw lens, MT1075, MT60 Series
MT60-26ZL 2.7-4.2:1 power zoom and power focus lens, MT1075, MT60 series
MT70LP Replacement lamp for MT1075
MT60LP Replacement lamp for MT60 series
MT60LPS Optional Extended life lamp for MT1075, MT60 Series
MT60CM Ceiling mount kit MT1075, MT60 Series
MT60TC Local transport/storage case w/wheels for MT1075, MT60 Series
MT60ATA ATA shipping case for MT1075, MT60 Series
SWL-2100N Wireless network card
WARRANTY OPTIONS
Order Code Description
VLMPL-01 1 year limited parts and labor extension
VLMIC-01 2nd year limited InstaCare coverage
VLMIC-02 3rd year limited extended warranty plus 2nd and 3rd year limited InstaCare coverage
VLMTC-02 For duration of the standard warranty (2 years), loaner or repair services are available in EU
countries, Japan, and Australia (for U.S. and Canadian residents traveling abroad)
ADDITIONAL FEATURES
Wireless or Wired With optional network cards, access your projector to handle
Networking remote diagnostics or provide for real time display. Also,
provides email notification selection.
Government ADA508 closed caption and black/white menu settings and
Compliance Executive Order 13221 less than 1W standby power consumption
Security • User can enable projector to become inoperable if keyword or
Enhancements PCMCIA card are not input.
• Cabinet Control Panel Lock–lock cabinet control keys to prevent
unauthorized access and adjustments
•Password protected–Logo and menu enable to further eliminate
unauthorized use
• Kensington Lock slot
Geometric Correction Display a square image on cylinder or spherical screen or at 90° corner
Utility shots
VORTEX Technology Provides uncompromising display of video and data. Improves white
Plus™ level, color accuracy, dynamic range, and display of varying levels of
black in an image. Color correction system enables six-axis adjustment
of CMY and RGB for display of personal color preferences
Eco-Mode™ Increase lamp life through light output adjustments and provides for
total cost of ownership
Long life Lamp Optional long life lamp provides for up to 4,000 hours of lamp life
that enables best cost of operation
Sleep Timer Timer can be set to automatically turn off the projector at selected
intervals up to 16 hours
Advanced AccuBlend™ Ensures detailed images when non-native resolution sources
are connected to the projector
AutoSense™ Automatic set-up and one touch adjustments for ease of use
Built-in Presentation Download your presentation onto a PC Card and present
Viewer directly from the projector
Image magnification 64-step magnification with location control
Chalkboard/ When a USB mouse is connected the presenter can make on
USB input screen annotations
Everything should be this easy
MT1065 installation projector.
4.53”
(115mm)
13.15”
(334mm)
12.72”
(323mm)
NEC 120523 SPEC_MT1065 12/30/05 1:19 PM Page 2
