Digital Cinema
Projectors
Digital Cinema Projector Series
NC900C projector
The NC900C is the ideal digital cinema projection
solution for theaters with small screens or
projection booths that are looking for high-
quality cinema projection at an affordable price.
This projector also delivers a solution for art
houses, mobile cinemas, theaters in universities
and public buildings, and even for high-end
home cinemas. The 2K DCI-compliant cinema
quality means an outstanding image that
is bright enough to display 14 ft-L on
screens up to 30 ft./9m* in DCI color.
An “all in one” Integrated Media Server
with 2 TB Raid5 Storage offers versatile
connectivity and savings with less
peripheral devices needed. A host of
integrated features includes a built-in 2
TB Raid5 screen server, 2 x HDSDI 3G
Interfaces, advanced network and built-
in GPIO functions.
Delivering Genuine Benefits
• Compact and lightweight - easy to install in small
projection booths and easy to transport for mobile
cinema
• Enjoy lower TCO - easy lamp replacement, lower
lamp cost and simple servicing. You can enjoy
better quality imaging while experiencing an overall
lower cost of ownership.
• Play captivating 3D content - take your
establishment into the next generation and stay
ahead of the competition with the latest digital
content, an increasingly essential element of the
latest movies and media
• Highly flexible - as no exhaust system is required,
the NC900C is suitable for floor and ceiling
installation and versatile content playback
Outstanding Performance
• A brand new S2K chip set from TI makes the
NC900C the most compact 2K DCI-certified digital
cinema projector on the market
• Improved mobility and easy exchange of lamps
and lenses makes the NC900C perfect for smaller
theaters and venues
• Easy dual lamp system ensures no blackscreen.
In the unlikely event of a single lamp issue, the
projector will continue to operate with a single
lamp. A new lamp can be replaced while the
projector is still operating, ensuring that there is no
interruption to the movie or event. Note: This hot-
swap functionality will be available in spring 2013
via projector software.
* assuming 1.8:1 gain screen

MODEL NC900C
OPTICAL
Projection Method
Throw Ratio
NP-9LS14Z
NP-9LS16Z
NP-9LS20Z
NP-9LS27Z
NP-9LS40Z
Lens Zoom / Focus
F-number, f-number
NP-9LS14Z
NP-9LS16Z
NP-9LS20Z
NP-9LS27Z
NP-9LS40Z
Lens Shift
Resolution
Lamp Bulbs
Supported Screen Size (max)
Contrast Ratio
Cooling Method
DMD Specifications
3-chip DMD reflection method
1.36 - 1.63:1
1.63 - 2.03:1
2.03 - 2.72:1
2.72 - 4.07:1
4.07 - 6.34:1
Motorized
F=2.5, f= 21.2 - 25.8mm
F=2.5, f= 25.5 - 32mm
F=2.5, f= 31.9 - 42.6mm
F=2.5, f= 40.8 - 62.8mm
F=2.5, f= 62.1 - 97.8mm
Motorized -0.5% to +0.55% Vertical, +/-0.11% Horizontal
2048 x 1080
350W (NSH) x 2
Up to 30 ft./9m@14ft-L in DCI color (1.8 gain screen)
1600:1
Air cooling with dust-preventing electrostatic filter
0.69” DLP chip
CONNECTIVITY
Input Terminals
IMS
Projector (Optional Boards)
Output Terminals (IMS)
External Control
IMS
Projector
2 x HDSDI 3G, 3 x USB Type A, 1 x eSATA
NC-80DS01-B: 2 x dual HDSDI, 2 x DVI (HDCP)
NC-80LB01-B: 2 x dual HDSDI, 2 x DVI (HDCP) + Enigma (for cinema server)
2 x RJ45 (16-channel AES3-EBU Digital Audio) / 24 bits up to 96 KHz
2 x RJ45 (4 GPI and 6 GPO) / 2 x RJ45 Gigabit Ethernet
1 x RJ45 Gigabit Ethernet / 1 x GPIO (D-sub 37 pin female) / 1 x GPIO (3D) (D-sub 15 pin female)
ELECTRICAL
Power Requirements
Input Current
Dual Lamp
Power Consumption
Dual Lamp
100 - 240V AC, 50/60Hz Single Phase
100 to 130V: 10.3A to 7.9A / 200 to 240V: 5.1A to 4.3A
1023W / 985W
MECHANICAL
External Dimensions
Weight
Fan Noise
25 x 32 x 13 in. / 621 x 798 x 314mm
97 lbs. / 44 kg
52 dB
ENVIRONMENTAL
Operating Temperature
Humidity
Storage
50° – 95°F / 10° – 35°C
10-85% non-condensing
-14° – 122°F / -10° – 50°C
REGULATIONS
U.S.
Canada
Latin America
UL60950-1 / FCC Part15 Class A (Marking: UL)
CSA60950-1 / ICES-003 Class A (Marking: C-UL)
IEC60950-1 / EN55022 Class A / EN55024 / EN61000-3-2/-3-3 (Marking: CE)
Limited Warranty (parts & labor) 2 years
IMS Integrated Storage Server: 2 TB RAID5
Integrated SMS
Full HFR 3D Support (48 Hz/eye, 60 Hz/eye)
Specifications for NC900C
• MINIMAL MAINTENANCE and trouble-free lamp
replacement. Operater can replace lamps without any
special protection.
• SIMPLE OPERATION One touch operation, ergonomic
keyboard layout and memory functions.
• MANY LENS OPTIONS for easy installation.
• HIGH FRAME RATE (HFR) CAPABILITY for outstanding
picture quality.
• NEC INTEGRATED MEDIA SERVER (IMS) as trouble free
one-stop solution.
• GREAT CONNECTIVITY including 2 HDSDI 3G interfaces.
NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
Recipients of the 2009 Academy Plaque are D. Scott Dewald, Greg Pettitt, Brad Walker
and Bill Werner. DLP Cinema and the DLP Cinema logo are registered trademarks of
Texas Instruments. All other brand or product names are trademarks or registered
trademarks of their respective holders. Product specifications subject to change.
©2012 NEC Display Solutions of America, Inc. All rights reserved.
25.NEC.80.GL.UN.126 rev. 110112
ORDERING MODEL NUMBERS
NP-NC900C-A
