Powerful installation projector equipped to take on the most
demanding integration projects.
FLEXIBILITY ENABLES PERFORMANCE
• High-performance video processing/scaling, utilizing the Hollywood
Quality Video processor, is designed for computer signals as well as
standard or high-denition video. The technology produces superior
video processing using pixel-based, motion-adaptive de-interlacing
to remove undesirable motion artifacts typical of interlaced signals.
This processing creates life-like images in applications such as video
conferencing.
• Bright enough for most applications: 7000 lumens (PX700W), 7500 lumens (PX750U), 8000 lumens (PX800X) with a 6-segment
(RGBYCW) color wheel. For higher video quality color reproduction, BrilliantColor™ technology and a second 6-segment (RGBYCM) color
wheel (included) can dramatically increase color saturation at mid and low video levels, while optimizing color gain across the full color gamut.
• VIDI technology, a Phillips innovation designed to work in conjunction with the color wheel, uses a brilliant pulse to increase the
brightness of the image and a dark pulse to increase the contrast ratio
• Lens memory controls lens attributes (zoom, focus, shift) based on input resolution and input selection
INTEGRATED NETWORKING AND ASSET MANAGEMENT
• Integrated RJ45 connection for quick connection to the LAN
(10/100 base-T capability)
• Optional high-speed wireless LAN IEEE 802.11b/g/n
• Desktop control allows you to securely transmit information wirelessly
to the projector from a docking station or PC in another room
• Image Express Utility (IEU 2.0; compatible with Windows
or Mac operating systems) dedicated projector software
provides wired and wireless data transmission via peer-to-peer or
over the network
• Broadcast mode allows you to send information from one
computer to several projectors
• Windows Network Projector function within Windows Vista
connects directly to networked projectors without the need for
additional proprietary software
• Windows Remote Desktop function allows you to control a
networked computer by connecting a USB mouse and keyboard
directly to the projector’s USB input
• Windows Network Drive Function displays multimedia les (.jpeg,
.bmp, .png, .mpeg2 or .wmv9) in the Windows shared folder on a
local network using the Viewer function—all without bringing your
PC into the conference room
• Windows Media Connection Function displays multimedia les
(.mpeg2, .jpeg or .wmv9) stored on the Windows Media Connect
server or a local network using the Viewer function—all without
bringing your PC into the conference room
• Crestron Roomview Connected™
SECURITY FEATURES PROVIDE PEACE OF MIND
• Cabinet control lock setting enables user to deactivate buttons
on cabinet to prevent unwanted changes to projector settings
• Logo lock restricts changes to logo saved in projector memory
• Password protection restricts unauthorized use of projector
• Email notication informs the system administrator when the lamp approaches the end of its useful life
PX Series
PX700W, PX750U and PX800X digital projectors
Professional
Installation Projectors
necdisplay.com
Lens Shift
Enjoy greater
installation
exibility with
50% vertical
lens shift and
+/- 10% horizontal
lens shift. Ships
lensless with a
complete line of
optional bayonet
style lenses (6)
for quick and easy
exchange. Lens
throw distances range from 2.6 to 179.8 feet.

On a
green wall... BEFORE
auto wall correction
AFTER
auto wall correction
Built-in wall color correction presets
These provide for adaptive color tone correction to display properly on non-white surfaces.
2500-hour filter life
NEC is committed to designing its products to provide
long lifecycles. This commitment even extends to
components within its products, including the improved
lter. This virtually maintenance-free
lter reduces the frequency at which
cleaning is required, thereby decreasing
your total cost of ownership. Filter
replacement is only required at the
time the lamp is replaced.
DESIGNED WITH THE ENVIRONMENT IN MIND
• Extended lamp life with ECO Mode™ technology increases lamp life up to 2500 hours, while lowering power consumption
• Power management enables projector to automatically turn off when an incoming signal is not detected from any of the inputs
• Auto Power On via the RGB (15-pin) input connector when a signal is detected from a computer
• Carbon savings meter calculates the positive effects of operating the projector in ECO Mode, which is encouraged by an optional
message at startup. A green ECO Mode button on the remote control makes the switch easy.
• Quick start (3 to 4 seconds) lets you begin presenting in seconds while quick shutdown (immediate power off with no cooling
required after shutdown) ensures efficient energy usage
• Sleep timer can be set to automatically turn off the projector at set countdown times
• Low power consumption (0.2W in stand-by mode) minimizes energy costs
• Direct power off provides instantaneous shutdown of the projector
Built-in stacking correction
The industry’s rst built-in stacking correction capabilities (up to four projectors) allows
the projectors to boost an image’s brightness up to 32,000 lumens, which is ideal
for larger-sized screens and environments with heavy ambient light. This feature also
prevents the complete loss of an image, which can happen when using only one projector.
PIP/Side-by-Side
This function allows two sources to
be displayed on the screen at one
time in either a picture-in-picture or
side-by-side conguration.
Edge blending
This function seamlessly blends
multiple projected images to display
a single high-resolution image.
Dual lamps
The PX Series features dual lamps,
providing up to 8000 lumens of
light output. You can combine
dual lamps for up to four dierent
light congurations (Normal Mode
with dual or single lamp and ECO
Mode with dual or single lamp) and
settings depending on the ambient
lighting conditions.
BUILT-IN SOFTWARE

GET CONNECTED WITH A WIDE SELECTION OF INPUTS
• Dual computer inputs ensure quick switching between presentations
USB Viewer
In instances when you’d prefer to leave
your laptop behind for a presentation, PX
Series projectors can deliver a solution.
Using the presentation conversion
software included with your projector,
simply place your le onto a USB drive
and plug it into the projector’s USB port.
This allows you to display images stored
as .jpgs from optional USB memory.
DisplayPort
This input
provides
PX Series
models with
expanded
connectivity
with
advanced
technology.
Remote control
Easy control from remote
allows you to adjust lamp
mode, aspect ratio, volume
and image all with the
touch of a button.
HDMI™input
Among the PX Series’ wide
selection of inputs is an HDMI w/
HDCP for connecting to high-
denition sources such
as Blu-ray players, cable
boxes, satellite receivers
and personal computers.
Open Pluggable Specification (OPS)
The rst industry-wide standardization in option slots
simplies installation, use and maintenance, while
oering superior input exibility.
ADVANCED SOFTWARE FEATURES
Cornerstone
Enhanced keystone
correction allows for
horizontal, vertical
and diagonal image
correction for aligned
images even when the
projector is set up at
an angle to the screen.
Geometric Correction
Projecting an image isn’t conned to a standard at
screen or wall with the NEC PX Series. Geometric
correction allows these models to project an image
on spheres, cylinders, corner angles and many more
non-standard surfaces.
Virtual Remote™
Used via a network connection (wired/wireless), you can control the projector
directly from a computer without the need for additional control cables.

UNIQUE FEATURES
3D Reform™ allows you to square the image by
adjusting horizontally, vertically or diagonally
when the projector cannot be placed parallel or
perpendicular to the screen
Advanced AccuBlend™ ensures detailed images
when non-native resolution sources are con-
nected to the projector
AutoSense™ automatically syncs with any
computer signal and features one-touch image
optimization
64-step image magnification with location
control
Discreet source keys for source selection
Remote diagnostics enable the user to monitor
and make adjustments to the projector remotely
Built-in HTTP page for control and monitoring
over a LAN network. Email notication of error
messages or lamp end-of-life can be sent to
remote locations.
WARRANTY
Registered owners receive a 3-year parts and
labor warranty including the rst year of Insta-
Care. The lamp is covered for one year or 500
hours, whichever comes rst. InstaCare provides
the original owner one year of either limited 3
business day repair/return or next business day
exchange.
IN THE BOX
Remote control, remote control cable, batteries,
power cord, RGB signal cable, lens cap, user’s
manual on CD-ROM, quick start guide, product
registration card, wired and wireless network
setup guide, lens anti-theft screw
ORDERING MODEL NUMBERS
NP-PX700W
NP-PX750U
NP-PX800X
19.8”
(504mm)
20.3”
(516mm)
7.6”
(192mm)
* Lens does not ship with the projector.
Additional accessories are available, including screens, carts, mount accessories and replacement cables. Visit www.necdisplay.com for details.
necdisplay.com
NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
3D Reform, Advanced AccuBlend, AutoSense and ECO Mode are
trademarks of NEC Display Solutions. HDMI, the HDMI Logo and
High-Denition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC. All other brand or product
names are trademarks or registered trademarks of their respective
holders. Product specications subject to change. 11/11 ver. 5.
©2011 NEC Display Solutions of America, Inc. All rights reserved.
Specifications for PX700W/PX750U/PX800X
OPTICAL
Display Technology
Light Output (lumens)
Resolution
Native
Maximum
Contrast Ratio (up to)
Lamp Type
Lamp Life (up to)
Screen Size (diagonal)
Throw Ratio
NP06FL
NP07ZL
NP08ZL
NP09ZL
NP10ZL
NP16FL
NP17ZL
NP18ZL
NP19ZL
NP20ZL
NP21ZL
Projection Distance
Projection Angle
Lens*
Zoom
Focus
F-number, f-number
NP06FL
NP07ZL
NP08ZL
NP09ZL
NP10ZL
NP16FL
NP17ZL
NP18ZL
NP19ZL
NP20ZL
NP21ZL
Shift
Keystone Correction
PX700W: 0.65” DMD/PX750U: 0.67” DMD/PX800X: 0.7” DMD
PX700W: 7000 normal / Eco = approx. 80% of normal mode
PX750U: 7500 normal / Eco = approx. 80% of normal mode
PX800X: 8000 normal / Eco = approx. 80% of normal mode
PX700W: WXGA 1280 x 800/PX750U: WUXGA 1920 x 1200/PX800X: XGA 1024 x 768
WUXGA 1920 x 1200
2100:1
(2) 400W AC / 320W eco
2000 hours normal / 2500 hours eco
50 to 300 in. / 1.3 to 7.6m
0.77:1
1.33 - 1.79:1
1.78 - 2.35:1
2.22 - 4.43:1
4.43 - 8.3:1
0.76:1
1.25 - 1.79:1
1.73 - 2.27:1
2.22 - 3.67:1
3.58 - 5.38:1
5.31 - 8.26:1
2.6 to 179.8 ft. / 0.8 to 54.8m
0° tele / 14.6° wide
Power
Power
F=2, f=11.4mm
F=1.8 to 2.3, f=19.3 to 25.8mm
F=1.7 to 1.9, f=26 to 34mm
F=2.1 to 2.9, f=32 to 63mm
F=2.2 to 3.1, f=63.5 to 117.4mm
F=1.85, f=11.6mm
F=1.85 to 2.5, f=18.7 to 26.5mm
F=1.64 to 1.86, f=25.7 to 33.7mm
F=1.86 to 2.48, f=32.9 to 54.2mm
F=1.85 to 2.4, f=52.8 to 79.1mm
F=1.85 to 2.48, f =78.5 to 121.9mm
Power: 50% vertical, +/- 10% horizontal
PX750U: +/- 35° horizontal, +/- 30° vertical
PX700W/PX800X: +/- 40° horizontal, +/- 30° vertical
SIGNAL COMPATIBILITY/
CONNECTIVITY
Scan Rate
Horizontal
Vertical
Supported Video Standards
SD/HD Video Signal Compatibility
PC Signal Compatibility
Macintosh Compatibility
Input/Output Terminals
RGB1 (analog)
RGB2 (analog)
RGB3 (analog)
RGB4 (digital)
RGB5 (digital)
Video 1
Video 2
Option Slot
Monitor Out
External Control
Sync Compatibility
Networking
USB
15 – 108 kHz
48 – 120 Hz
NTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM
480i, 480p, 576i, 576p, 720p, 1080i, 1080p
VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA
Yes
VGA 15-pin D-sub
VGA 15-pin D-sub
5-BNC
HDMI w/ HDCP
DisplayPort w/ HDCP
RCA
S-Video
HD/SD-SDI
VGA 15-pin D-sub
RS-232, IR, Wired LAN, DDC/CI, USB, Wireless LAN (optional)
Separate Sync / Composite Sync / Sync on G
RJ-45 and Wireless LAN (optional)
Viewer
ELECTRICAL
Power Requirements
Input Current
Power Consumption (Normal/ECO Mode/Standby/
Standyby-Power Saving
100 – 240V AC, 50/60Hz
10.8A
1006W / 810W / 33W / 0.2W
MECHANICAL
Installation Orientation
Dimensions (WxDxH)
Net Weight
Fan Noise
Regulations
Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear
19.8 x 20.3 x 7.6 in. / 504 x 516 x 192mm
43.4 lbs. / 19.7 kg
43 dB normal / 39 dB eco
USA: UL60950-1, FCC Part15 Class B / Canada: CSA60950-1, ICES-003 Class B
ENVIRONMENTAL
Operating Temperature
Humidity
Storage
32° – 104°F / 0° – 40°C
20-80% non-condensing
-14° – 122°F / -10° – 50°C
ACCESSORIES
NP06FL
NP07ZL
NP08ZL
NP09ZL
NP10ZL
NP16FL
NP17ZL
NP18ZL
NP19ZL
NP20ZL
NP21ZL
NP02LM1
SB-01HC
PX750CM
PXCase-01
RMT-PJ33
NP01PW1
RGBCBL-PJPX
NP02FT
SCP200
NP22LP
N8000-8830
NECEW2-I
NECEW1-I
ADVEXON1-I
ADVEXON2-I
TBD
TBD
TBD
0.77:1 fixed short throw lens for PX700W/PX800X
1.33 -1.79:1 zoom lens for PX700W/PX800X
1.78 -2.35:1 zoom lens for PX700W/PX800X
2.22 -4.43:1 zoom lens for PX700W/PX800X
4.43 -8.3:1 zoom lens for PX700W/PX800X
0.76:1 fixed short throw lens
1.25 - 1.79:1 zoom lens
1.73 - 2.27:1 zoom lens
2.22 - 3.67:1 zoom lens
3.6 - 5.4:1 zoom lens
5.30 - 8.30:1 zoom lens
Wireless LAN module
HD/SD-SDI input card
Ceiling mount
ATA-certified case for shipping and secure storage
Replacement remote control
Replacement power cable
Replacement RGB signal cable
Replacement filter
Suspended ceiling plate
Replacement lamp
NEC OPS PC with Intel Core i5, 320GB Hard Drive, Windows Embedded Standard 7
Extends term of parts and labor warranty to 5 years
Extends term of parts and labor warranty to 4 years
Extends term of InstaCare service program to 2 years
Extends term of InstaCare service program to 3 years
Maintenance plan
Extends maintenance plan for 3rd year including parts & labor
Extends maintenance plan for 4th year including parts & labor
