3D Reform, Advanced AccuBlend, Autosense and ECO Mode are trade-
marks of NEC Display Solutions. All other brand or product names are
trademarks or registered trademarks of their respective holders.
Product specifications subject to change. 10/08 ver. 4.
©2008 NEC Display Solutions of America, Inc. All rights reserved.
UNIQUE FEATURES
3D Reform™ allows you to square the image by adjusting
horizontally, vertically or diagonally when the projector
cannot be placed parallel or perpendicular to the screen
Advanced AccuBlend™ ensures detailed images when non-
native resolution sources are connected to the projector
Built-in wall color correction presets provide for adaptive
color tone correction to display properly on non-white
surfaces
AutoSense™ automatically syncs with any computer signal
and features one-touch image optimization
Kensington lock slot enables security cable to be
attached to the projector
64-step image magnification with location control
Sleep timer can be set to automatically turn off the
projector
Discreet source keys for source selection
Computer-free presentations via USB drive inserted
directly into the projector allows you to change images
using the wireless remote control provided
Built-in HTTP page for control and monitoring over a LAN
network. E-mail notification of error messages or lamp
end-of-life can be sent to remote locations.
Built-in closed captioning enables decoding and display of
text information from a video
WARRANTY
Registered owners receive a 2-year parts and labor warranty
including the first year of InstaCare. The lamp is covered
for one year or 500 hours, whichever comes first. InstaCare
provides the original owner one year of either limited 3 busi-
ness day repair/return or next business day exchange.
IN THE BOX
Remote control, batteries, power cord, RGB signal cable, lens
cap, user’s manual on CD-ROM, quick start guide, product
registration card, wired network setup guide, carrying case
12.2”
(310mm)
11.4”
(289mm)
4.9”
(125mm)
OPTICAL
Display Technology
Resolution
Native
Maximum
Light Output (lumens)
Contrast Ratio
Lamp Type
Lamp Life (up to)
Screen Size (diagonal)
Throw Ratio
Projection Distance
Projection Angle
Lens
Zoom
Focus
F-number
Keystone Correction
SIGNAL COMPATIBILITY/CONNECTIVITY
Scan Rate
Supported Video Standards
SD/HD Video Signal Compatibility
PC Signal Compatibility
Macintosh Compatibility
Input/Output Terminals
RGB 1 (analog)
RGB2 (analog)
Video 1
Video 2
Video 3
Audio
Audio Out
Monitor Out
Audio
External Control
USB
Sync Compatibility
ELECTRICAL
Power Req.
Input Current
Power Consumption
MECHANICAL
Installation Orientation
Dimensions (WxDxH)
Net Weight
Fan Noise
Regulations
ENVIRONMENTAL
Operational Temp
Humidity
Storage
ACCESSORIES
NP05LP
LEATHERROLLER
SCP100
LEATHERCASE
PWRCRD-PJPX
RGBCBL-PJPX
RMT-PJ27
NP01MR
SPKR30
SC200
NP900ATA
NP01UCM
NP900CM
NECEW1-MP
NECEW2-MP
ADVEXON1-MP
ADVEXON2-MP
NECECO
0.63” LCD with MLA
XGA 1024 x 768
UXGA 1600 x 1200
2700 normal
500:1
210W AC
2500 hours normal / 3500 hours eco
21 to 300 in. / 533 to 7620mm
1.5 to 1.8
2.3 to 36 ft. / 0.7 to 11m
8.3 to 8.6° tele / 9.9 to 10.3° wide
1 to 1.2
Manual
F=1.7 to 2.07, f=18.9 to 22.7mm
+/- 40 degrees horizontal, +/- 30 degrees vertical
Horizontal 15 – 108 kHz / Vertical 48 – 120 Hz
NTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM
1080p, 1080i, 720p, 576p, 576i, 480p, 480i
VGA, SVGA, XGA, SXGA, SXGA+, UXGA
Yes
15 pin
15 pin
RCA
S-Video
HDMI w/ HDCP
(2) L/R RCA, (2) mini stereo
mini VAO
Yes
5W speaker
RS-232, IR
USB 2.0 high speed
Separate Sync / Composite Sync / Sync on G
100 – 240V AC, 50/60Hz
3.7A
310W normal / 260W eco
Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear
12.2 x 11.4 x 4.9 in. / 310 x 289 x 125mm
8.2 lbs. / 3.7 kg
35dB normal / 29dB eco
USA UL 1950 FCC Class B, Canada CSA950 (C-UL), NOM
41° – 104°F / 5° – 40°C
20-80% non-condensing
14° – 122°F / -10° – 50°C
Replacement lamp
Leather rolling case with extension handle and laptop compartment
Suspended ceiling plate
Leather carrying case with laptop compartment
Power cable
RGB cable
Replacement remote
IR receiver for remote control of computer
Amplified 30W speaker
Security cable
Airtight molded plastic shipping case for projector
Universal ceiling mount
Custom ceiling mount with easy access to lamp compartment
Extends term of parts and labor warranty to 3 years
Extends term of parts and labor warranty to 4 years
Extends term of InstaCare service program to 2 years
Extends term of InstaCare service program to 3 years
Projector recycling program, disposal certificate
Specifications for VT800
Additional accessories are available, including screens, carts, mount accessories and replacement cables.
Visit www.necdisplay.com for details.
