Necta Krea Espresso User manual

KREA ESPRESSO
u3685EN00 12-2012
selection keyboard
s ome simple instructions are supplied here
below to load and clean your machine w arnings
display
upper
panel
coffee
bean canister
instant
powder canister
liquid
waste tray
solid
waste tray
nozzles
mixer
tray
brew
unit cover
door
mixer
lock
cup
support
reflector
cup
sensor

KREA ESPRESSO
2
1 2
3 4
1
a
b
Product load
• Openthemachinedoor
• Lifttheupperpanel
Clean the waste trays
• Assoonthemessage“FULLWASTE”appears,openthemachine
door
• Takethetraybyitssizes,liftslightlyandpull
• PushonhookBtoreleasecoverAoftheliquidwastetray
• Emptyandwashthetray
Clean the waste trays
• Openthemachinedoor
• Taketheliquidwastetraybyitssizes,liftslightlyandpull
• Removethesolidwastetray,emptyandwashit
• Re-positionthetraysbyfollowingthereverseorder
• Closethemachinedoorandresetthewaste
Password and closed-door operations
• Themachineisreadytocarryoutclosed-dooroperations.Youcan
resetthesolidwastecountandwashthemixer.
• Closed-dooroperationsareautomaticallycarriedoutafterthepas-
swordentry.
• Pressandholddownthelastkeyatthebottomontheright(9)for5
seconds.
• Themachinedisplaysthemessage“PASSWORD”.
Product load
• Loadthecoffeebeansfromthemouth(A)
• Load the instant powder by opening the canister cover (B) and
makesurethattheloadedpowderisnotcompressed
• Re-closethecanistersandlowertheupperpanel
• Closethedoorandwashthemixerbymeansofapassword
Make sure that the products to be loaded have been
properly preserved and used before their expiration
date
EMPTY THE TRAY
PASSWORD
Password entry
Use the machine keyboard to enter the password; each key has the
numericvalueshownbythefigure.
Thewasteresetorthemixerwashcycleisautomaticallydoneafterthe
relativepasswordentry.
b
a
load the products
clean the traysclosed-door operations
12
2
1
1
2
3
WASTE CONT.
FULL
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
write the mixer wash
password
write the waste reset
password

KREA ESPRESSO
2
1 2
3 4
1
Disassemble the mixer
• Lifttheinstantpowderdispensingmouth(D)
• Detachthetube(A)fromthemixer
• Turnthelever(B)counterclockwise
• Takethemixerunit(C)andpull
Disassemble the mixer
Detachallcomponents:funnel(A),mixerring(B),waterconveyor(C)
Disassemble the mixer impeller
Exercisealighttractiontodisassemblethemixerimpeller
Disassemble the nozzles and the mixer tray
• Detachthetubesfromthenozzles
• Detachthenozzlesfromthesupport
• Unscrewtheknurl(A)fromthemixertray(B)
• Removethemixertray
Sanitisation of components
• Washallcomponentswithasanitisingsolutionandmakesurethat
allvisibleresiduesandfilmsaremechanicallyremovedbymeans
ofpipecleanersand/orbrushes.
• Rinseanddrythepartscarefully
Assemble the mixer impeller
• Re-positionandpushthemixerimpeller
• Makesurethatyouhaveinsertedittothebottom,untilyouheara
click.
a
a
bb
c
c
d
To avoid altering the taste of drinks, never use detergents
that are too much flavoured and/or solvents
complete cleaning
34
56
a
b
1
3
2
13
2

KREA ESPRESSO
2
1 2
3 4
1
N&W GLOBAL VENDING S.p.A.-ViaRoma,24-24030Valbrembo(BG)Italy-Tel.+39035606111-Web:www.nwglobalvending.com
Assemble the mixer
• Re-assemblethecomponentsandre-positionthemixer
Make sure that couplings are properly inserted into the mixer
Assemble the mixer
• Rotatethelever(A)clockwisetosecurethemixertothemachine
• Re-connectthetubestothemixers
• Lowertheinstantpowdermouths
Disassemble and clean the brew unit
• Removethecoverfromthebrewunit
• Rotatethecoffeeoutletnozzle(A)by90°andpullit
• Operatetheunitretaininglever(B)androtateittoarrangeithori-
zontally
• Extractthecoffeeunit
Clean the brew unit
• Wheneveryouloadoratleastonceaweek,cleanaroundthebrew
unitandremoveallcoffeeresidues
• Removeallpowderbymeansofabrushorasmallvacuum-cleaner
• Rinsethebrewunitbeneathawaterjet
• Re-positionthebrewunitbycarryingoutalloperationsintherever-
seorder
To avoid any risk of chemical oxydation or cor-
rosion in general, use neutral detergents and
avoid any solvent
Clean the dispensing compartment
Tocleanthedispensingcompartmentandthecupsupport,useasoft
pieceofcloth,dampenedwithadetergentsolution.
Foracorrectoperationofthecupsensor,keepthesensorwindowand
thereflectorinthefrontclean.
complete cleaning
7
10
11 12
9
8
Disassemble the nozzles and the mixer tray
• Re-positionthemixertray(B)
• Screwtheknurl(A)
• Re-positionthenozzlesandconnecttherelativetubes
• Close the door and wash the mixer by means of a password to
removeanydetergentresidue.
a
b
a
b
a
2
1
31
2
1
3
2
4
5
