Neomitis RT7 User manual

RT7
WIRED 7 DAY PROGRAMMABLE
ROOM THERMOSTAT
Pack contains ....................................................................................1
Installation .........................................................................................1
Installing batteries...............................................................................................1
Mounting of wall mounting plate.....................................................................1
Wiring ...................................................................................................................2
Mounting of the thermostat..............................................................................2
Installer settings .................................................................................2
Advanced installer setting ................................................................................2
Troubleshooting .................................................................................4
Technical specications ...................................................................4
RTE7REA NEO ENG FP V02 22 04 2015 1
INSTALLATION INSTRUCTIONS
3- Secure the wall plate with the
two screws provided using the
horizontal and vertical holes.
x2
Screw Anchor
x2
AA Batteries (LR6)
x1
Thermostat
x2
Screws
The digital room thermostat is xed on the wall with the wall plate which
is supplied with the product.
MOUNTING OF WALL MOUTING PLATE
PACK CONTAINS
INSTALLATION
INSTALLING BATTERIES
1- Remove the batteries cover
which is placed on the front of
thermostat.
2- Insert the 2 batteries AA sup-
plied. Note the correct polarity
according to the engraving on
the thermostat when inserting
the batteries.
3- Replace the batteries cover.
1- Unscrew the 2 screws under the
thermostat.
2- Remove the wall plate from the
thermostat.
x2

2
ADVANCED INSTALLER SETTING
Slider
position Icon Installer mode access
1 Set °C/°F temperature unit
2 Set 12 or 24 hours clock
3
Set calibration of the temperature dis-
played
4 Program lock
5 Select the type of control: 2 points or TPI
• Access
Move the mode slider to position.
Select the Programming slider position and press
for 5 seconds to go into the dedicated installer setting.
5 sec.
am
Tu
C
C
• Set °C/°F temperature
The pre-set temperature is Celsius (°C).
2- Then save by pressing or
move the Programming slider.
am
Tu
C
C
1- Rotate the dial to change to
degree Fahrenheit.
Recommended locations for your thermostat.
To ensure that your thermostat provides accurate readings and controls
effectively, it must be installed approximately 1.5 m above oor level on
an inside wall, away from direct sunshine and any other sources of heat
or cold such as radiators, cold draughts, etc.
Important: The thermostat measures the temperature of the place where
it is installed. It does not take into account the temperature differences
that may exist between different locations in the house if the tempera-
ture is not uniform.
INSTALLER SETTINGS
MOUNTING OF THE THERMOSTAT
1- Replace the thermostat on the
wall mounting plate.
2- Secure the thermostat by
screwing the both locking
screws under the thermostat.
x2
WIRING
All wiring must be in accordance with IEE regulations. This product is for
xed wiring only.
NC NOCOM
COM = Live
NC = Normally closed switch out
(Satised)
NO = Normally open switch out
(call for Heat)
All electrical installation work should be carried out by a sui-
tably qualied Electrician or other competent person. If you are
not sure how to install this thermostat consult either with a qua-
lied electrician or heating Engineer. Do not remove or ret the
appliance onto the backplate without the mains supply to the
system being isolated.
NC NOCOM

3
• Set 12/24 hours clock
The pre-set value is 12 hours clock.
1- Rotate the dial to change to
“24 hr”.
2- Then save by pressing or
move the Programming slider.
am
Tu
C
C
• Set calibration
Important: This operation is reserved for professional installers only; any
wrong changes would result in control anomalies.
Change should only be made if the temperature measured (measured
by a reliable thermometer) is different by at least 1°C compared to the
setpoint temperature of the room thermostat.
The calibration adjusts the temperature measured by the ambient tem-
perature sensor to compensate for a deviation from + 3°C to - 3°C in in-
crements of 0.1°C.
IMPORTANT: Before carrying out the calibration it is recommended to wait
for 4h after a setpoint temperature modication to insure that the ambient
temperature is stabilized.
The pre-set calibration value is 0.
1- Rotate the dial to adjust the
calibration to the desired value.
2- Then save by pressing or
move the Programming slider.
am
Tu
C
C
1- Rotate the dial to ON and
locked.
2- Then save by pressing or
move the Programming slider.
am
Tu
C
C
• Select 2 points/TPI
2 points = ON/OFF regulation.
TPI = Proportional control algorithm.
Note regarding the Advanced installer settings: If MODE slider is moved or
no press/rotation for 15 seconds, it will discard changes and exit installer
mode.
The pre-set control algorithm is TPI.
1- Rotate the dial to change to 2
points control algorithm.
2- Then save by pressing or
move the Programming slider.
am
Tu
C
C
• Program lock
The product is unlocked by default, OFF is displayed.
When program lock function is turned on then following functions will be
disabled:
- Regardless of physical location, Program Slider will always remain as
per RUN mode (except to access Installer settings).
- In Mode Slider AUTO position: Manual override will not work.
- In Comfort Slider position: mode will remain as per AUTO mode.
- BOOST function is disabled.

4
Registered trademarks - All rights reserved
NEOMITIS
®
LIMITED - 4th Floor, Lincoln House, 300 High Holborn, London WC1V 7JH
Registered in England and Wales No: 9543404
NEOMITIS
®
is a registered trademark of CO INTECH - SIRET 42243514900048 RCS ANGERS
Tel: [phone] - Fax: [phone] - E-mail: [email protected]
Creating innovative solutions for ambient comfort
www.neomitis.com
- Power supply: 2 alkaline 1.5 V AA (LR6) batteries.
- Battery life: approx. 2 years.
- Relay outputs: 5(2)A
- Rated impulse voltage: 4000V.
- Micro disconnection: Type 1B.
- Pollution degree: 2.
- Automatic action: 100,000 cycles.
- Class II.
Note: It is recommended to replace annually as part of the normal system
service and before leaving the property empty for a prolonged period.
Standards:
Environment:
- Operation temperature: 0°C to +40°C.
- Manual temperature setting range: from +5°C to +30°C.
- Storage temperature: from -10°C to +60°C.
- Humidity: 80% at +25°C (without condensation)
- Protection rating: IP30.
Manufactured by: IMHOTEP création
The on the product indicates that you must dispose of it at the end of
its useful life at a special recycling point, in accordance with European
Directive WEEE 2012/19/EU. If you are replacing it, you can also return it to
the retailer from which you buy the replacement equipment. Thus, it is not
ordinary household waste. Recycling products enables us to protect the
environment and to use less natural resources.
Display disappears on thermostat.
- Check batteries.
- Replace the 2 batteries. Only use alkaline 1.5V AA (LR6) batteries.
Do not use rechargeable batteries.
The heating does not come on or does not go off.
- Your room thermostat may have been set up close to a source of heat
or on a cold wall – put it in a recommended location (see the “Installing”
section on page 2 for these locations).
- Check that the communication works between the thermostat and the
boiler.
You want to change the operating mode but when you move the mode
slider nothing happens.
- If the lock symbol is being displayed, then the thermostat is locked.
- Unlock the thermostat by following the instructions for doing so in the
"program lock" section (see page 3).
The thermostat is in Auto Mode but programs are not being executed by
the boiler:
- Ensure that the thermostat is in good working condition.
- Change the batteries.
The thermostat does not control properly.
- Thermostat sensor may be inuenced by a source of heat or cold.
- Check that the communication works between the thermostat and boi-
ler.
If the problem persists, contact your installer.
Compliance declaration: we hereby declare under our
sole responsibility that the products described in these
instructions comply with all the main requirements of the LVD
2006/95/CE, EMC 2004/108/EC, RoHS 2011/65/EU and are
manufactured using processes which are certied ISO 9001
V2008.
TROUBLESHOOTING TECHNICAL SPECIFICATIONS
LVD EMC RoHS
EN60730-1
EN60730-2-9
EN62311
EN60730-1
EN60730-2-9 EN50581
