Installation Guide
ProSafe® 16-port or 24-port Gigabit Switch JGS516 V2 or
JGS524 V2
Package Contents
Verify that all items are in the box. The package includes:
• ProSafe® 16-port or 24-port Gigabit Switch JGS516 V2 or JGS524 V2
• Power cord with localized plug
• Adhesive feet
• Rack-mount brackets and hardware
• Installation Guide (this document)
Front View
24 Gigabit ports for the JGS524,
LEDs
or 16 for the JGS516
The switch supports 10 Mbps, 100 Mbps, and 1000 Mbps connections. Using
Gigabit Ethernet (1000 Mbps), the switch sends files across the network at speeds
up of to 2000 Mbps due to the full duplex nature of Gigabit Ethernet connections.
The switch supports straight-through or crossover Ethernet cables. Each port on the
switch configures itself based on the cable that you plug into it. Depending on the
model, you can use the switch to connect either up to 24 or 16 Ethernet devices
such as computers, file servers, printers, routers, switches, or hubs.
Installation
Estimated time: 5–10 Minutes
Select a Location
Decide where you want to place the switch. Find a flat horizontal surface or a
19-inch rack.
Make sure that the location is:
• Not in direct sunlight or near a heater or heating vent.
• Not cluttered or crowded. There should be at least 2 inches (5 cm) of clear
space on all sides of the switch.
• Well ventilated, especially if it is in a closet.
Install the Switch
1. For each device that you want to connect to the switch, provide an enhanced
Category 5 (Cat 5e) Ethernet cable with RJ-45 connections. Each Ethernet
cable has to be less than 328 feet (100 meters) long.
2. Install the switch on a flat surface or in a standard 19-inch rack.
• Flat surface. The switch comes with four self-adhesive footpads. Stick one
footpad on each of the four concave spaces on the bottom of the switch. The
footpads cushion the switch against shock and vibrations.
• Rack mounting. Follow the instructions in the 19-Inch Rack Mounting
section.
Verify Cable Connections
Before you apply power, perform the following checks:
1. Inspect the equipment thoroughly.
2. Verify that all cables are installed correctly.
3. Check cable routing to ensure that cables are not damaged and will not create
a safety hazard.
4. Be sure that all equipment is mounted securely.
19-Inch Rack Mounting
Use the rack-mount kit supplied with
your switch.
1. Use the Phillips head screws to
fasten the mounting brackets to
the sides of the switch. Tighten
the screws with a No. 1 Phillips
screwdriver.
2. Align the bracket and rack holes.
Use two pan-head screws with
nylon washers to fasten each
bracket to the rack. Tighten the
screws with a No. 2 Phillips
screwdriver to secure the switch
in the rack.
Troubleshooting
You can use the LEDs to troubleshoot hardware problems.
Power LED Is Off
The switch has no power.
• Make sure that the power cord is securely connected to the switch.
• Make sure that the power cord is connected to a functioning power outlet. If it is
connected to a power strip, make sure that the power strip is turned on. If the
socket is controlled by a light switch, make sure the switch is in the on position.
Port LED Is Off for a Connected Device or Stays On Continuously
There is a hardware connection problem.
• Make sure that the cable connectors are securely plugged in to the switch and
the device.
• Make sure that the connected device is turned on.
• If the Ethernet cable is connected to a network interface card or other Ethernet
adapter, make sure that the card or adapter is installed correctly and is working.
• Make sure the cable is less than 328 feet (100 meters) long.
JGS516_JGS524_IG.fm Page 1 Tuesday, January 3, 2012 4:42 PM

Standards compatibility IEEE 802.3i 10BASE-T Ethernet, IEEE 802.3u, 100BASE-TX
Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet,
IEEE 802.3x flow control, IEEE 802.1p priority, DSCP priority
Network interfaces RJ-45-connectors for 10BASE-T, 100BASE-TX, or 1000BASE-T
Ethernet interfaces
Power 100-240V 1.0A AC, 50/60 Hz internal universal power supply
Power consumption
(full load)
JGS516 12W (cable length > 10 M)
JGS524 18W (cable length > 10 M)
Physical dimensions
(w x d x h)
328 x 169 x 43.2mm (12.91 x 6.65 x 1.70 in)
Weight JGS516: 1.47kg (3.24lbs)
JGS524: 1.65kg (3.64lbs)
Operating environment Temperature: 0° to 50° C (storage: 0° to 70° C)
Humidity: 10% to 90% (storage: 5% to 90%)
Electromagnetic and
safety compliance
CE and CE LVD, Class A; FCC Class A; VCCI Class A; C-Tick;
KCC; CB; CCC; and UL
Frame filter/forward rates 14,880 frames/sec max for 10 M port
148,800 frames/sec max for 100 M port
1,488,000 frames/sec max for 1000 M port
Frame forward rate 14,880 frames/sec max for 10 M port
148,800 frames/sec max for 100 M port
1,488,000 frames/sec max for 1000 M port
Network latency Using 64-byte-packets
• 10 Mbps to 10 Mbps: 35 s max
• 100 Mbps to 100 Mbps: 5.4 s max
• 1000 Mbps to 1000 Mbps: 2.7 s max
Using 1518-byte packets
• 10 Mbps to 10 Mbps: 36 s max
• 100 Mbps to 100 Mbps: 5.5 s max
• 1000 Mbps to 1000 Mbps: 2.9 s max
Filtering address table Up to 8 K entries
Jumbo frame Up to 9 KB
MAC address learning Automatic update
RAM buffer 2 Mb
December 2011
This symbol was placed in accordance with the European Union Directive 2002/96 on the Waste
Electrical and Electronic Equipment (the WEEE Directive). If disposed of within the European Union,
this product should be treated and recycled in accordance with the laws of your jurisdiction
implementing the WEEE Directive.
NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of
NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to
change without notice. Other brand and product names are registered trademarks or trademarks of their
respective holders. © 2011 NETGEAR, Inc. All rights reserved.
Technical specifications Performance specifications Technical Support
Thank you for selecting NETGEAR products.
After installing your device, locate the serial number on the label of your product and
use it to register your product at http://www.NETGEAR.com/register. Registration is
required before you can use the telephone support service. Registration through the
NETGEAR website is strongly recommended.
Go to http://support.netgear.com for product updates and web support.
For complete DoC go to the NETGEAR EU Declarations of Conformity website at
http://support.netgear.com/app/answers/detail/a_id/11621/.
For GNU General Public License (GPL) related information, go to
http://support.netgear.com/app/answers/detail/a_id/2649.
WARNING: Do not stack equipment, or place equipment in tight spaces, in drawers,
or on carpets. Make sure your equipment is surrounded by at least 2 inches of air
space.
