netsys NT205B User manual
NT205B
5
5
5.
.
.7
7
7M
M
Mb
b
bp
p
ps
s
s
G
G
G.
.
.s
s
sh
h
hd
d
ds
s
sl
l
l
b
b
bi
i
is
s
s
L
L
LA
A
AN
N
N
E
E
Ex
x
xt
t
te
e
en
n
nd
d
de
e
er
r
r
w
w
wi
i
it
t
th
h
h
4
4
4
E
E
Et
t
th
h
he
e
er
r
rn
n
ne
e
et
t
t
U
U
Us
s
se
e
er
r
r’
’
’s
s
s
M
M
Ma
a
an
n
nu
u
ua
a
al
l
l
NT205B User’s Manual
VER_A1
2
Copyright
Copyright © 2011 by National Enhance Technology Corp. All rights reserved.
Trademarks
NETSYS is a trademark of National Enhance Technology Corp.
Other brand and product names are registered trademarks or trademarks of their respective holders.
Legal Disclaimer
The information given in this document shall in no event be regarded as a guarantee of conditions or characteristics. With respect
to any examples or hints given herein, any typical values stated herein and/or any information regarding the application of the
device, National Enhance Technology Corp. hereby disclaims any and all warranties and liabilities of any kind, including without
limitation warranties of non-infringement of intellectual property rights of any third party.
Statement of Conditions
In the interest of improving internal design, operational function, and/or reliability, NETSYS reserves the right to make changes to
the products described in this document without notice. NETSYS does not assume any liability that may occur due to the use or
application of the product(s) or circuit layout(s) described herein.
Maximum signal rate derived form IEEE Standard specifications. Actual data throughput will vary. Network conditions and
environmental factors, including volume of network traffic, building materials and construction, and network overhead lower actual
data throughput rate.
NT205B User’s Manual
VER_A1
3
Safety Warnings
For your safety, be sure to read and follow all warning notices and instructions before device use.
DO NOT open the device or unit. Opening or removing covers can expose you to dangerous high voltage points or other
risks. ONLY qualified service personnel can service the device. Please contact your vendor for further information.
Use ONLY the dedicated power supply for your device. Connect the power cord or power adaptor to the right supply voltage
(110V AC in North America or 230V AC in Europe).
DO NOT use the device if the power supply is damaged as it might cause electrocution. If the power supply is damaged,
remove it from the power outlet. DO NOT attempt to repair the power supply. Contact your local vendor to order a new power
supply.
Place connecting cables carefully so that no one will step on them or stumble over them. DO NOT allow anything to rest on
the power cord and do NOT locate the product where anyone can work on the power cord.
DO NOT install nor use your device during a thunderstorm. There may be a remote risk of electric shock from lightning.
DO NOT expose your device to dampness, dust or corrosive liquids.
DO NOT use this product near water, for example, in a wet basement or near a swimming pool.
Connect ONLY suitable accessories to the device.
Make sure to connect the cables to the correct ports.
DO NOT obstruct the device ventilation slots, as insufficient airflow may harm your device.
DO NOT store things on the device.
DO NOT use the device outside, and make sure all the connections are indoors. There may be a remote risk of electric
shock from lightning.
Be careful when unplugging the power, because the transformer may be very hot.
Keep the device and all its parts and accessories out of children’s reach.
Clean the device using a soft and dry cloth rather than liquid or atomizers. Power off the equipment before cleansing it.
This product is recyclable. Dispose of it properly.
NT205B User’s Manual
VER_A1
4
Table of Contents
COPYRIGHT........................................................................................................................................................................................................ 2
SAFETY WARNINGS.......................................................................................................................................................................................... 3
CHAPTER 1. DESCRIPTION............................................................................................................................................................................ 6
1.1
P
RODUCT
D
ESCRIPTION
.................................................................................................................................................................................. 6
1.2
S
PECIFICATION
............................................................................................................................................................................................... 7
1.3
A
PPLICATION
.................................................................................................................................................................................................. 8
1.4
SHDSL
SYSTEM COMPONENTS
....................................................................................................................................................................... 8
1.5
F
RONT
P
ANEL
LED
S
I
NDICATORS
................................................................................................................................................................... 8
1.6
R
EAR
P
ANEL
C
ONNECTORS
.......................................................................................................................................................................... 10
CHAPTER 2. PACKAGING ............................................................................................................................................................................. 12
2.1
C
HECKING
P
ACKAGE
C
ONTENTS
.................................................................................................................................................................. 12
2.2
P
REPARE FOR
I
NSTALLATION
........................................................................................................................................................................ 12
CHAPTER 3. LOG ON...................................................................................................................................................................................... 13
3.1
M
ENU
T
REE
.................................................................................................................................................................................................. 15
3.2
M
AIN
M
ENU
................................................................................................................................................................................................. 17
3.3
C
ONSOLE
S
CREEN
C
ONVENTION
.................................................................................................................................................................. 17
CHAPTER 4. CONFIGURATION ................................................................................................................................................................... 19
4.1
C
ONFIGURE
D
EVICE
T
YPE
............................................................................................................................................................................ 21
4.2
C
ONFIGURE
A
NNEX
M
ODE
........................................................................................................................................................................... 21
NT205B User’s Manual
VER_A1
5
4.3
C
ONFIGURE
DSL
R
ATE
................................................................................................................................................................................ 21
4.4
C
ONFIGURE
LAN
I
NTERFACE
....................................................................................................................................................................... 21
4.5
VLAN
SETTING
............................................................................................................................................................................................ 23
4.6
F
ACTORY
D
EFAULT SETTING
........................................................................................................................................................................ 25
4.7
S
AVE CONFIGURATION
................................................................................................................................................................................. 25
CHAPTER 5. PERFORMANCE MONITORING.......................................................................................................................................... 26
CHAPTER 6. INVENTORY.............................................................................................................................................................................. 28
APPENDIX A: COMPLIANCE AND SAFETY INFORMATION................................................................................................................ 29
NT205B User’s Manual
VER_A1
6
Chapter 1.
Description
1.1 Product Description
The NT205B, a SHDSL (Single-pair High-bit-rate Digital Subscriber Line) LAN Extender, provides a broadband transmission with
bandwidth up to 5.696Mbps over a single pair of copper wires for LAN connection between two local area networks. NT205B
provides a console port for users to configure the settings and to monitor the DSL connection status.
NT205B conforms to ITU-T G.991.2, the GSHDSL requirements. Each NT205B can be configured as either STU-C for the central
side or STU-R for the remote side. A pair of NT205B offers a cost effective symmetrical broadband solution for bandwidth-hungry
applications such as LAN-to-LAN connection, Internet, etc.
Features:
ITU G.991.2 Annex A, Annex B and Annex F
Symmetrical downstream and upstream data rates from 192Kbps to 5.696Mbps
Auto-Negotiation for 10/100 BaseT
Auto-MDIX for Auto Ethernet Tx/Rx Swap
NT205B User’s Manual
VER_A1
7
1.2 Specification
G.SHDSL line
Line Coding: 16 TC-PAM or 32 TC-PAM
Line Rate: 192K bps ~ 5696 Kbps
Standard: ITU-T G.991.2, Annex A, Annex B and Annex F selectable
LAN interface
Mac Address filtering bridge up to 2K Mac address learning
Bridge: IEEE 802.1D transport, self-learning
VLAN Tag based & Port Based
Bandwidth Control for Ethernet Port
Physical interfaces
4 x RJ45 10/100Mbs Ethernet ports
1 x RJ-11 port for G.SHDSL connection
One console port: DB-9 Female
DC 5 V power input
NT205B User’s Manual
VER_A1
8
1.3 Application
Following Figure shows a point to point application for user interface LAN
Ethernet Bridging
1.4 SHDSL system components
NT205B modem (CO) or NT205B modem (RT) in a working pair.
1.5 Front Panel LEDs Indicators
There are eight LED indicators on the front panel of NT205B. They show the statuses of the device.
LANLAN
NT205B User’s Manual
VER_A1
9
The functions of LED indicators are described in the following table:
LED
Color Status Meaning
PWR
Orange
Steady
Off The device is on.
The device is off.
CO Orange
Steady The device is configured to CO mode
RT Orange
Steady The device is configured to RT mode
DSL
Orange
Steady
Blinking
Off
The device is Sync Status.
The link is synchronizing - this may take several
minutes.
The device is unplugged or disconnected.
LN1 Orange
Steady Link 1 - The LAN connection is successfully
established.
LN2 Orange
Steady Link 2 - The LAN connection is successfully
established.
LN3 Orange
Steady Link 3 - The LAN connection is successfully
established.
LN4 Orange Steady Link 4 - The LAN connection is successfully established.
NT205B User’s Manual
VER_A1
10
1.6 Rear Panel Connectors
The rear panel connectors connecting the device to the LAN and xDSL network are illustrated as below.
LAN Interface characteristic
LAN Interface ( RJ-45 port ) located in NT205B’s rear panel meets to IEEE 802.3 or IEEE 802.3u request and supports 10/100
Base-T auto test and half/all touble works model operation, bridge can provide up to 128 MAC address and MAC address filtration
function, meets IEEE 802.1d protocol requirement.
RJ-45 wire
Figures separable shows as following :
Power Adapter
RJ-11
Phone Line
(xDSL)
RS-232
Emulator Terminal
VT-100
LAN
RJ-45
PC
Console
Rear Panel and Installation
PC
NT205B User’s Manual
VER_A1
11
RJ-45 pin out
Table1.14: 10/100 Base-T pin out
Pin NO.
Function Data Direction Designati
on
1 TX Transmitting
Data Toward the LAN network
TX+
2 TX Transmitting
Data Toward the LAN network
TX-
3 RX Receiving
Data Toward the LAN
Equipment RX+
6 RX Receiving
Data Toward the LAN
Equipment RX-
8 1
NT205B User’s Manual
VER_A1
12
Chapter 2.
Packaging
2.1 Checking Package Contents
NT205B Desktop is shipped with the following contents:
One 110/220V power adaptor
One NT205B User Manual
2.2 Prepare for Installation
Connecting the NT205B
If configured from the Craft port, your are encouraged to use the virtual terminal emulator from Window / Microsoft and set the COM
Port of PC to the following communication parameters:
DTE speed 38.4Kbps
8 Data Bit
Non – Parity Bit
One Stop Bit
No Flow Control
Selection of “VT100“ for Terminal Configuration
NT205B User’s Manual
VER_A1
13
Chapter 3.
Log On
To access the VT-100 console screen, check that the CID port speed matches the terminal emulation program currently being used.
The default value for the CID port is 38.4k bps, 8 data bit, No Parity, 1 stop bit. The VT-100 console uses a blinking cursor to select
various menus, sub menus and fields within those menus.
To pop up the console, press the “ Enter “ key several times to display the Log On Screen illustrated in the following screen.
\Main
Device Type Line CNT Data Rate Port 1 Port 2 Port 3 Port 4
L:
COT SYNC 4032 kbps LINK DOWN DOWN DOWN
R:
RT SYNC 4032 kbps LINK DOWN LINK DOWN
==========================================================================
1.
Configration <DIR>
2.
Status <DIR>
3.
Inventory <DIR>
---------------------------------------------------------------------------------------------------------------------------------
1..3] Select Item Enter]Accept Item ESC]Escape Ctrl-R] Screen Refresh
Main Screen
NT205B User’s Manual
VER_A1
14
Cursor Operation
To select a specific field or navigate the console screen, refer to the table below for further details.
Keyboard
Command Description
Tab Tabs to previous item.
Space Refreshes the entire screen.
Esc Escapes to previous page
1 …N] Fields enclosed in brackets [ ] offer a list
of selections.
Enter Validates the fields selected..
NT205B User’s Manual
VER_A1
15
3.1 Menu Tree
Viewing from Main Menu, the second layer “ 1. Configuration, 2.Status and 3. Inventory “ and all its tributary parameters are shown in
Figure 3.1.
Figure 3.1: Menu Tree
Main Menu
>> 1. Configuration
>>
1. Device Type COT; RT
>>
2. Annex Annex A; Annex B; Annex F
>>
3. DSL Rate 3~89 (AnnexF) 3~36 (AnnexA, B)
>>
4. LAN Port
>>
1. Speed 10M; 100M
>>
2. Auto Negotiation Disable; Enable
>>
3. Duplex Half; Full
>>
4. Flow control Eable; Disable
>>
5. VLAN setting
>> 1. VLAN Mode Unaware; Aware
>> 2. P-P Segmented Channel Disable; Enable
>> 3. Ingress VID Range Start 0 ( 0 ~ 4096)
>> 4. Ingress VID Range Lenght 0 ( 0 ~ 16)
>> 5. Port 1 Bandwidth Value 1~ 89 , N*64Kbps
>> 6. Port 2 Bandwidth Value 1~ 89 , N*64Kbps
>> 7. Port 3 Bandwidth Value 1~ 89 , N*64Kbps
NT205B User’s Manual
VER_A1
16
>> 8. Port 4 Bandwidth Value 1~ 89 , N*64Kbps
>>
6. Factory Default
>>
7. Save
>> 2. Status
>>
1. Device Type COT; RT
>>
2. Annex Annex A; Annex B; Annex F
>>
3. DSL Rate 64~5696 kbps
>>
4. S/N (0~20dB)
>>
5. DSL Status Idel; SYN; Handshaking;
Trainning
>> 3. Inventory
>>
1. H/W version
>>
2. S/W version
NT205B User’s Manual
VER_A1
17
3.2 Main Menu
The Main Menu Screen, illustrated below,
3.3 Console Screen Convention
The Console Screen Convention contains five user operating areas.
Menu Sequence: The one-line top most
area that shows sequence for
bringing the menu to the current hierarchy.
Status/ Alarm
message: This is the two-line area above the double dotted
line that provides network and user interface status
and alarm message.
Sub-Menu or Result This is the area above the single dotted line that
\Main
Device Type Line CNT Data Rate Port 1 Port 2 Port 3 Port 4
L:
COT SYNC 4032 kbps LINK DOWN DOWN DOWN
R:
RT SYNC 4032 kbps LINK DOWN LINK DOWN
==========================================================================
1.
Configration <DIR>
2.
Status <DIR>
3.
Inventory <DIR>
---------------------------------------------------------------------------------------------------------------------------------
1..3] Select Item Enter]Accept Item ESC]Escape Ctrl-R] Screen Refresh
NT205B User’s Manual
VER_A1
18
Display: provides content of sub-menu or display of
performance data and testing result.
Input field: The area beneath the dotted line
that shows options
specific to menu or sub-
menu items and allows user
to enter value desired.
Function Keys: The area right beneath the input field that lists the
function keys specific to the operation of the menu
currently displayed.
Function Key
Input Field
Sub-Menu
Result Display
Status Message
Menu Sequence
\Main\ Cfg
Device Type Line CNT Data Rate Port 1 Port 2 Port 3 Port 4
L: COT SYNC 4032 kbps LINK DOWN DOWN DOWN
R: RT SYNC 4032 kbps LINK DOWN LINK DOWN
==========================================================================
1.
Device Type : COT
2.
Annex : Annex A
3.
DSL Rate : 03
4.
LAN port <DIR>
5
VLAN Setting <DIR>
6.
Factory Ddfault <CMD>
7.
Save <CMD>
---------------------------------------------------------------------------------------------------------------------------------
1). COT, 2) RT
Input: 1
1..6] Select Item Enter]Accept Item ESC]Escape Ctrl-R] Screen Refresh
NT205B User’s Manual
VER_A1
19
Chapter 4.
Configuration
This chapter provides instructions on how to access and configure your NT205B, displaying configuration options, restoring to
factory default and saving the configuration.
In other words, the provisioning parameters for each SHDSL unit could also only be provided through the CID and NT205B Desktop
functioning as STU-C. or as STU-R. In case of STU-R is connected to STU-C successfully then the DSL rate of STU-R will be
changed as same as STU-Cs automatically. Please pay attention to the following notice.
1. Regional DSL modes -Annex A/B/F of STU-C and STU-R shall be set as the same. Otherwise the DSL can not get sync.
2. Given the same speed under 2304kbps, the transmission distance working in Annex A (or Annex B) is around 300 meters longer
than working in Annex F atAWG26 wire. This is the testing result in a specific environment, for your reference only. User shall
carefully set the regional mode for optimizing DSL reach or speed.
The first Item on the Main Menu Screen is “ Configuration “ option. The Configuration Screen below allows you to view, set or make
changes to certain specific parameters about the unit in service.
The following Screen allows you to view and change the parameters of NT205B.
NT205B User’s Manual
VER_A1
20
\Main\ Cfg
Device Type Line CNT Data Rate Port 1 Port 2 Port 3 Port 4
L:
COT SYNC 4032 kbps LINK DOWN DOWN DOWN
R:
RT SYNC 4032 kbps LINK DOWN DOWN DOWN
==========================================================================
1.
Device Type : COT
2.
Annex : Annex A
3.
DSL Rate : 03
4.
LAN port <DIR>
5
VLAN Setting <DIR>
6.
Factory Ddfault <CMD>
7.
Save <CMD>
---------------------------------------------------------------------------------------------------------------------------------
1). COT, 2) RT
Input: 1
1..6] Select Item Enter]Accept Item ESC]Escape Ctrl-R] Screen Refresh
Table
5.1
Configure Parameters Screen Content
Item Description
1. Device Type Specifies whether the unit is configured as COT, or RT.
Entry: COT; RT
2. Annex Sets the transmission mode for SHDSL.
Entry: Annex A; Annex B; Annex F
3. DSL Rate Specifies data rate for DSL. Data rate could be configured in
multiple of 64k. For Annex A or B ,N= 3 ~ 36, For Annex F,
N=3~89.
4. LAN Port Configure LAN Port
5. VLAN Setting Configure the VLAN and Bandwidth control of 4 LAN port
6. Factory Default Sets SHDTU03B-ET100BS to factory default
7. Save Save the parameters to SHDTU03B-ET100BS
Table of contents
Other netsys Extender manuals
