NEUTRIK NKPH Series User manual

TRUST THE ORIGINAL
Instruction manual
powerCON®TRUE1 Cable
NKPH*
EN

2
2Instruction manual | BDA 686
NEUTRIK IpowerCON®TRUE1 Cable INKPH*
1. General
Product group:
• NKPH*
Intended use
The product is used to connect an electrical consumer.
The product is suitable for connecting equipment
under high loads, both mechanical and thermal. Use
under medium mechanical stress can be in dry and
damp rooms and outdoors. Installation in the ground
is not permitted.
For safety and approval reasons (CE), you may not
modify and/or change the product. If you use the
product for purposes other than those described
above, the product may be damaged. In addition,
improper use can cause hazards such as short-
circuits, fire, electric shock, etc.
Only pass the product on to third parties in its
original packaging or with this operating manual.
For the safe use of the product, the national, legal
regulations and provisions (e.g. accident prevention
and occupational health and safety regulations as
well as environmental regulations) of the respective
country must also be observed.
All company names and product designations
contained herein are trademarks of their respective
owners. All rights reserved.
The product is not intended for use in the medical
field. The product is not intended for use in explosive
or flammable environments.
Please observe the national regulations.
In Germany, this is mobile equipment and
therefore the instructions from DGUV
regulation 3, among others, must be followed.
2. Check delivery
• 1 x cable
• Label with instructions for use
NEUTRIK
®
powerCON®TRUE1 Cable

3
3
Instruction manual | BDA 686
NEUTRIK IpowerCON®TRUE1 Cable INKPH*
3. Safety instructions
Read the operating instructions
carefully and observe the safety
instructions in particular.
If you do not follow the safety
instructions and the information on
proper handling in this operating
manual, we accept no liability for
any resulting personal injury or
damage to property.
Damage to property. In addition,
the warranty/guarantee will
become void in such cases.
• The product is not a toy. Keep it away from
children and pets.
• To avoid clamping injuries and burns at high
ambient temperatures, it is recommended to wear
safety gloves.
• It voids the warranty, in case of manual
modifications of the device.
• Protect the product from extreme temperatures,
direct sunlight, strong vibrations, high humidity,
water jets from any angle, falling objects,
flammable gases, vapors and solvents.
• Do not subject the product to very high mechanical
stress.
• If safe operation is no longer possible, take the
product out of operation and protect it from
unintended use. Safe operation is no longer
guaranteed if the product:
shows visible damage,
no longer functions properly,
has been stored under unfavorable ambient
conditions for an extended period of time or has
been subjected to considerable transport stresses.
• Also observe the safety instructions and operating
instructions of the other devices to which the
product is connected.
• The junction box to which the product is connected
must have been previously checked for proper
condition by a qualified electrician.
• Unwind the cable completely during operation. Do
not place any objects on the cable. Lay the cable
in such a way that no one can trip over it and that
the cable plug is easily accessible. Do not lay the
cable under carpets or similar.
• Make sure that the cable is not crushed, bent or
damaged by sharp edges. A damaged cable can
result in a life-threatening electric shock.
• If the cable is damaged, do not touch it. First
switch off the power to the associated connection
socket (e.g. via the associated protective device)
and then carefully pull the cable plug out of the
connection socket. Do not operate the product in
a damaged condition under any circumstances.
• A damaged cable may only be repaired by the
manufacturer, a workshop authorized by the
manufacturer or a similarly qualified person in
order to avoid hazards.
• Check that the operating voltage and rated
current are not exceeded by connecting the cable.
Use only a proper junction box approved by a
qualified person as the voltage source.
• The operation of the product with a personal
protection switch is recommended.
• Do not operate the product covered! At higher
connected loads, the product heats up, which
can lead to overheating and possibly fire when
covered.
• At higher ambient temperatures, this product
may cause burns. Avoid prolonged direct skin
contact. Ensure the use of appropriate protective
equipment.
• The product is only de-energized when the cable
plug is disconnected.
• The cable plug must be disconnected from the
socket under the following conditions:
before cleaning the product
during thunderstorms
when the product will not be used for an
extended period of time.
• Never pour liquids on or near the product. There
is a high risk of fire or fatal electric shock. If liquid
should nevertheless get into the cable connectors,
immediately switch off all poles of the mains
socket to which the product is connected (fuse/
automatic circuit breaker/FI circuit breaker of the
associated circuit).
• In commercial facilities, the local accident
prevention regulations. For Germany: The accident
prevention regulations of the German Federation
of Institutions for Statutory Accident Insurance
and Prevention (Verband der gewerblichen
Berufsgenossenschaften) for electrical systems
and equipment. In schools, training centers,
hobby and self-help workshops, the handling
of electrical equipment must be supervised by
trained personnel.
• Contact a specialist if you have any doubts about
the operation, safety or connection of the product.
• Have maintenance and repair work carried out
exclusively by a specialist or a specialist workshop.

4
4Instruction manual | BDA 686
NEUTRIK IpowerCON®TRUE1 Cable INKPH*
• If you have any questions that are not answered
in these operating instructions, please contact
our technical customer service department.
4. Assembly Heat shrink tubing
The shrink tubing serves as an optional protective device
for a label applied to the cable by a third person.
• Shrinking of the shrink tubing is not necessary for
the operation of the cable.
• Shrinking of the heat shrinkable tubing is done at
your own risk.
• The manufacturer is not liable for any damage to
the cable caused by processing the shrink tubing.
• Shrinking of the shrink tubing with open flame and
hot air devices without temperature adjustment is
not permitted.
• Permissible temperature range for shrinking is >
70°C to 90°C.
• The cable must be free of tension during shrinking
5. Maintenance, testing and
Cleaning
Please check the national regulations for product
testing. For Germany:According to DGUV regulation 3,
this test must be carried out by a qualified electrician
or also an electrotechnically instructed person using
suitable measuring and test equipment. A period
of 1 year has proven to be the testing interval. You
must determine the interval in accordance with DGUV
regulation 3 implementation instructions to your
actual operating conditions. The range is between 3
months and 2 years (office).
• Switch off the product before cleaning. Then
disconnect the cable plug from the junction box.
Then disconnect the connected consumer from
the cable.
• A dry, soft and clean cloth is sufficient for
cleaning. Dust can be easily removed with the
help of a long-haired, soft and clean brush and a
vacuum cleaner.
• Never use aggressive cleaning agents
or chemical solutions, as this could
attack the product or impair its function.
6. Disposal
Electronic devices are recyclable
materials and do not belong in
household waste. Dispose of the
product at the end of its service life
in accordance with the applicable
legal regulations.
7. Technical data
General specifications
Operating voltage 250 V/AC, 50/60 Hz
Rated current 16 A (USA: 20 A)
Protection class IP65
IP44 - with Schuko in mated
condition
Operating temperature -25 to +40°C
(USA max. + 40°C)
minimum bending
radius
6 x outer diameter
Cable meter goods H07RN-F 1,5mm² / 2,5mm²
Etikett:
126 45 3
CERTIFIED
IEC 60320-1
EN 60320-1
UL 60320-1

5
5
Instruction manual | BDA 686
NEUTRIK IpowerCON®TRUE1 Cable INKPH*
Pos. Description
1Item description*
2Input connector
3Protection class (IP)
4Serial number / batch number
5Rated voltage
6Part number
Further technical data can be found in the corresponding
data sheets or at
www.contrik.com
8. *Type key Example for article
designation
NKPH04-A2A1-M200
NEUTRIK powerCON TRUE1 Cable
Country Code
H ………… Harmonisiert
LENGTH
001 ………… 1 dm/ft
010 ………… 10 dm/ft
999 ………… 999 dm/ft
Unit of Length
M ………… Meter
F ………… Feet
CABLE TYPE
01 ………… H07RN-F3 (3 x 1.5 mm2)
02 ………… H07RN-F3 (3 x 2.5 mm2)
03 ………… H07RN-F3 (3 x 1.5 mm2)
04 ………… H07RN-F3 (3 x 2.5 mm2)
TERMINATION 1. SIDE
A2 ………… Assembled powerCON TRUE1 male
MF ………… Molded Schuko
TERMINATION 2. SIDE
A1 ………… Assembled powerCON TRUE1 female
MF ………… Molded Schuko

6
6Instruction manual | BDA 686
NEUTRIK IpowerCON®TRUE1 Cable INKPH*

7
7
Instruction manual | BDA 686
NEUTRIK IpowerCON®TRUE1 Cable INKPH*
Imprint
Subject to change due to technical progress! These operating instructions correspond to the state of
the art at the time of product delivery and not to the current development status at Neutrik.
If any pages or sections of these operating instructions are missing, please contact the manufacturer
at the address given below.
Copyright ©
This user manual is protected by copyright. No part or all of this user manual may be reproduced,
duplicated, microfilmed, translated or converted for storage and processing in computer equipment
without the express written permission of Neutrik.
Copyright by: © Neutrik® AG
Document Identification:
Documenten No.: BDA 686 V1
Version: 2023/06
Original Language: German
Manufacturer:
Neutrik AG
Im alten Riet 143
9494 Schaan
Liechtenstein
www.neutrik.com

www.neutrik.com
LIECHTENSTEIN (HEADQUARTERS)
Neutrik AG, Im alten Riet 143,
9494 Schaan, Liechtenstein
T [phone], F [phone], [email protected]
USA
Neutrik USA Inc., 4115 Taggart Creek Road,
Charlotte, North Carolina, 28208
T [phone], [email protected]
GERMANY / NETHERLANDS / DENMARK / AUSTRIA
Neutrik Vertriebs GmbH, Felix-Wankel-Strasse 1,
85221 Dachau, Germany
T [phone], [email protected]
FRANCE
Neutrik© France, 52 Rue d‘aguesseau,
92100 Boulogne
T [phone], [email protected]
GREAT BRITAIN
Neutrik (UK) Ltd., Westridge Business Park, Cothey Way Ryde,
Isle of Wight PO33 1 QT
T [phone], [email protected]
JAPAN
Neutrik Limited, Yusen-Higashinihonbashi-Ekimae Bldg., 3-7-
19
Higashinihonbashi, Chuo-ku, Tokyo 103
T [phone], [email protected]
CHINA
Ningbo Neutrik Trading Co., Ltd., Shiqi Street,
Yinxian Road West
Fengjia Villiage, Hai Shu District, Ningbo, Zhejiang, 315153
T [phone], [email protected]
HONG KONG
Neutrik Hong Kong LTD., Suite 18,
7th Floor Shatin Galleria Fotan, Shatin
T [phone], [email protected]
TRUST THE ORIGINAL
BDA 686 V1 - powerCON TRUE1 Cable - 2023/06– Data subject to change without prior notice. © 2023 Neutrik AG.
