NEUTRIK powerCON TRUE1 TOP User manual

OPERATING INSTRUCTION
®
powerCON TRUE1 TOP
R
A
Page 1BDA 556
1. CONNECTING
BC
Cable Connector
Note:
The proper twist-lock
is achieved when the
silvery tab is in the
position shown in C
and an audibel «click»
is heard.
C
click
Note:
After inserting properly
as in illustration A ,
twist the cable
connector clockwise to
lock.
A
Note:
When connecting, match the notch
on the cable connector to the
corresponding guide slot on the
chassis.
SAFETY WARNING
incorrect insertion may cause electrical contact
misalignment resulting in equipment malfunction
and/or personal injury.
max. 1 Newton

powerCON TRUE1 TOP
®I OPERATING INSTRUCTION
2. UNLOCKING
ABC
www.neutrik.com
Draft. Nr.: BDA 556 V3
Update: 2023-06-28
Neutrik AG LI-9494 Schaan
I
Page 2 A brand of the Neutrik Group
Data subject to change without prior notice. 2023 NEUTRIK . NEUTRIK , powerCON are registered trademark of Neutrik AG.
® ®
©
ALL RIGHTS RESERVED.
Approval based:
Rating:
Cable Type:
Cable O.D.:
VDE
EN 60320-1
250 V ac / 16 A
2
H05VV-F3G 1.0 mm , Length max. 2 m
2
H05VV-F3G 1.5 - 2.5 mm
2
H07RN-F3G 1.5 mm
6.0 - 12.0 mm
UL 60320-1
CAN/CSA-C22.2 No. 60320-1
250 V ac / 20 A
SJTOW, SJOOW 3 x 12 AWG
6.0 - 12.0 mm
NAC3PX-TOP
NAC3MPX-TOP
NAC3MPX-WOT-TOP
NAC3FPX-TOP
NAC3FPX-WOT-TOP
NAC3FPX-ST-TOP
Power OUT
Power OUT
NAC3FX-W-TOP
(Connector)
NAC3MX-W-TOP
(Plug connector)
NAC3FX-W-TOP
(Connector)
NAC3MX-W-TOP
(Plug connector)
Power IN
APPLIANCE INLET APPLIANCE OUTLET APPLIANCE INLET / OUTLET
uCombination
powerCON TRUE1 TOP line is full backward compatible with the preceding powerCON TRUE1 products.
® ®
CONNECTOR ASSIGNMENT:
Power IN
·The powerCON TRUE1 system is certified as a connector with breaking capacity according IEC 60320,
® ®
VDE 0625.
·It is intended for use as an appliance coupler and interconnection coupler.
·It serves to supply power to an appliance and from an appliance to other equipment.
·To be installed by qualified person only.
Application other equipment:
The manufacturer of cord sets and of interconnection cord sets is responsible for the conformity
assessment according to the applicable regulatory documents.
3. APPLICATION INSTRUCTION
