NEVA BOARD GLIDE HAPPY User manual
USER MANUAL
USER MANUAL
INTRODUCTION
Thank you for purchasing the Neva Board -
the self-balancing, battery operated, two wheel vehicle.
Before using please read this user manual carefully, taking particular
notice of the safety warnings and precautions.
This manual will introduce you to basic riding skills and how to ride
safely in order to avoid dangers that are caused by collisions, falls
and loss of control.
Users are responsible for any consequences that are caused
by not following the warning contents of this manual.
01
1. Overview
1.1 Description
1.2 User Risk and Precaution
1.3 Preparation Before Use
2. Product Introduction
2.1 Description of Neva Board
2.2 Neva Board Parts
2.3 Working Principles
3. Control and Displays
3.1 Power Button
3.2 Mat Sensor
3.3 Display Unit
3.4 Battery Display
4. Safety
4.1 Weight Limit
4.2 Maximum Range
4.3 Speed Limit
5. Learn to Ride
5.1 Operation Procedure
5.2 Protection
5.3 Practice Riding
6. Safe Riding
7. Battery
7.1 Battery Power
7.2 Charging Process
7.3 Temperature
7.4 Shipping Notes
7.5 Description of Battery
8. Cleaning and Storage
9. Neva Board Specification
10. After Sales
USER MANUAL
CONTENTS 02
3
3
3
4
4
5
6
6
6
6
7
7
7
8
9
9
10
11
11
12
12
12
13
14
15
Losing control or having a collision due to not following user instructions of the Neva Board manual may cause injury
or even death. In order to minimize the risk of accidents please read the guidance on the following pages.
1.1 Description
Safety and warning information to ensure every user can ride their self-balancing board safely and enjoy it.
Familiarize yourself with every part of the self-balancing board manual, reading the warning and cautions will
help you enjoy it more.
1.2 User Risk and Precaution
A self-balancing board is for personal transport. By not adhering or abiding to the user manual instructions you may
cause danger towards yourself and others.
1.3 Preparation Before Use
Any improper action will bring about danger to your personal safety and the safety of others.
USER MANUAL
WARNING
1. OVERVIEW 03
2.2 Neva Board Parts
Mudguard
LED Light
Display Unit Mats
Charging Port
Power Button
Tire & Motor
2.1 Description of Neva Board
Neva Board is a self-balancing high-tech electrical scooter. It is based on a dynamic balance principle,
moving forwards, backwards and stop. It has easy to manage with flexible controls, low carbon output and
green environmental credentials that is suitable for outdoor use.
Self-balancing boards are widely used in leisure walking, scenic tours, security patrol and many other fields.
USER MANUAL
2. PRODUCT
INTRODUCTION
04
USER MANUAL
2. PRODUCT
INTRODUCTION
05
2.3 Working Principles
Neva Board uses gyroscope and acceleration
sensors to control balance intelligently and
dependent on centre of the gravity.
Self-balancing boards also use a servo-control
system to drive the motor accurately so it works in
sync with the human body. When you stand on the
board and tilt your body forward or backwards the
power unit will control the wheels in a forward or
backward direction, adjusting balance when you
need to turn, slow down, or move your body to the
left or right.
The built-in inertia dynamic stabilization system
controls the motion and direction, however it
cannot guarantee the stability of sideways
movements. When you ride the board, shift your
weight in order to overcome the centrifugal force
and the direction will adjust according to the
pressure applied.
Display Unit
3.1 Power Button
To start the board, press and hold this button and the same action to turn the board off.
3.2 Mat Sensors
There are four sensors under the mat which will automatically adjust to the balance mode when the user stands
on the board. It is important that feet are planted evenly across the mats and footplates.
3.3 Display Unit
The display unit is located in the centre
of the Neva Board and is designed to
display the running information.
3.4 Battery Display
The green light on the charger (transformer) indicates that the self-
balancing board is fully charged. If the red light on the charger
(transformer) is still displayed, this indicates that the Neva Board is
not fully charged yet.
USER MANUAL
3. CONTROL
AND DISPLAYS
06
IMPORTANT
When the LED indicator light turns green, you must take off charge straight
away to prevent the charging life of the battery being diminished.
Green LED light - Neva Board is fully charged.
Yellow LED light - Power is down to 50%
Red LED light - Power is approx 20%. Re-charge straight away.
Running LED - When the operator triggers the foot switches, the running LED
will light up. This means that the system enters the motion state. If the system
has an operating error the running LED light will turn to red.
4.2 Maximum Range
Factors that will affect the drive distance:
• Terrain: A smooth, flat surface will increase the riding distance
but inclines and rough uneven surfaces will have a contrary
effect and reduce the overall distance on a single charge.
• Weight: The weight of the driver can affect riding distance.
The heavier the user the quicker the battery usage increases.
• Maintenance: Regular battery charging and maintenance
will increase the distance.
• Speed and riding style: Maintaining a moderate speed will
increase distance, on the contrary, frequent start-stop,
acceleration and deceleration will reduce the distance.
4.3 Speed Limit
• Maximum speed is 10 km/h.
• When approaching the maximum speed
the buzzer alarm will ring.
• If the speed exceeds the specified the board will
take the initiative to tilt the driver to make the speed
work within a safe range.
The display board is located in the centre
of the Neva Board and is designed to
display the running information.
4.1 Weight Limit
Maximum load : 100kg. Minimum load : 20kg
USER MANUAL
4. SAFETY 07
We hope every user can enjoy riding Neva Board safely with maximum fun and enjoyment. Learning how to
ride a bicycle, drive a car, ski or similar means of transportation are experiences that can be applied to our
products. We strongly recommend that you read the user manual carefully before riding for the first time. Checking
tyres are damaged or parts have become loose before driving is essential. If in any doubt about abnormal operating
conditions please contact your local dealer for assistance or repair.
Particular attention must be taken when recognizing speed limits, vibration alerts and safety shutdowns etc.
DO NOT modify the parts of self-balancing board as it will affect the performance and could cause serious injuries.
IMPORTANT
Increased pressure on the right
foot plate will move the board
forward by turning left Increased pressure on the left
foot plate will move the board
forward by turning right
If user stands on the board incorrectly
the buzzer will alarm and warning
indicator will light up. Please step off
and start again so that the system can
enter self-balancing status.
USER MANUAL
5. LEARN TO RIDE 08
It is important to learn and remember the related safety instructions before riding the Neva
Board for the first time.
5.1 Operation Procedure
Step 1: Start the board by pressing the power button.
Step 2: Prepare to ride by placing the board on FLAT ground. Put one foot on the pad, which
will trigger the pressure plate and turn on the indicator light, after which the system enters the
self-balancing mode. Then taking care place the other foot on the pad.
Step 3: After standing successfully, keep your balance and centre of gravity by keeping
stationary. Only take small forward or backward movements through the body to start.
Step 4: Control and Turning - Lean your body and the board will turn to the left or right.
Step 5: To dismount keep the board still, step one foot down, then the other foot to leave the
mat quickly.
IMPORTANT
5. LEARN TO RIDE
When the self-balancing board
is switched off the system will halt.
Do not continue riding the board
when the battery is exhausted
or the system issues will auto
terminate and could lead to
poor future performance.
DO NOT turn sharply when
traveling at high speed.
DO NOT ride and turn round
quickly on slopes.
USER MANUAL
09
5.2 Protection Function
During operation if there is a system error or illegal operation the Neva Board will prompt riders in different ways,
normally by entering system protection mode with an alarm indicator buzzer lighting up.
This can occur in the following situations:
• When you get on the vehicle the footplate surface tilts forward or backward more than 10 degrees.
• Battery voltage is too low.
• Riding on excessive uphill terrain causing sustained high discharge of the battery. The board will switch off after 15 seconds.
• Excessive speed.
• Battery is low with insufficient charge and below protection. The board will switch off after 15 seconds.
• Platform moves forward or backward more than 35 degrees.
• Tyres are blocked.
5.3 Practice Riding
• Learn how to ride the self-balancing board on
different terrain but be cautious on unfamiliar terrain.
• The board is designed to be a personal transporter
specifically for fat surfaces so if you drive on different
terrain, please take extra care.
• If you are not confident or experienced in riding
the board it is best to avoid crowded environments.
IMPORTANT
Using the self-balancing board may cause injury due to loss of control, collision and being
involved in falls. To avoid injury carefully read the user manual and ride the self-balancing board
according to the manual instructions. Please make sure to keep the product in good condition. Carefully read and have
a good understanding of the materials provided by our company before using the product.
6. SAFE RIDING 10
This section provides safety knowledge, tips and cautionary statements, letting you learn about safety precautions
before using the self-balancing board. To ensure that you can safely ride the self-balancing board be sure to read this
user manual and comply with the relevant safety instructions. Please note all the warnings and cautions that are
mentioned in the user manual will improve your enjoyment, safety and experience of using your Neva Board.
IMPORTANT
• When you are riding the Neva Board make sure you
take all the safety measures, such as: wearing a helmet,
knee pads, elbow pads and other protective gear.
• Do not allow or encourage children (toddlers), the
elderly or pregnant women ride the board.
• Do not ride after consuming alcohol or drugs.
• Do not carry heavy or awkward items when riding.
• Please comply with local traffic laws and give special
attention to pedestrians.
• Be alert at all time, keeping aware of obstacles and
potential hazards.
• Make sure the feet are always applying pressure to
the pads.
• Please wear suitable sports apparel to drive, so that
you can deal with emergencies better.
• Self-balancing board is only designed to be ridden by
one person at a time.
• Users and their belongings should not exceed the
maximum load (100KG), or it could cause functional
damage to the board operation system. In addition,
the driver should not weigh less thank 20KG.
• If riding with other Neva Board users keep a safe and
sensible distance of at least 5 metres between each
other to avoid a collision
• Do not get distracted when riding by using your mobile
phone, listening to music or engaging in any other
activity.
• Do not ride in the dark or dimly lit areas.
• Avoid riding in/on:
- slippery roads or in the rain.
- hazardous conditions e.g. snow, ice or slippery floors.
- narrow spaces.
- steep slopes.
- unsafe environments, e.g. inflammable gas, steam,
liquid, dust or fire which could cause explosive reactions.
USER MANUAL
7. BATTERY 11
This section provides safety knowledge, tips and cautionary statements, letting you learn about safety
precautions before using the self-balancing board. To ensure that you can safely ride the self-balancing board
be sure to read product manuals and comply with the relevant safety instructions. Please note all the warnings and
cautions that are mentioned in the product manuals will improve your enjoyment, safety and experience of using your
Neva Board.
7.1 Battery Power
You must stop riding the board when the displays shows low
power (red LED light) or it may affect battery lifetime and
cause on-going problems. Don't use the battery if the
following occur:
• Emits an odour or overheats.
• Don't touch any leaking materials.
• Children and animals are forbidden to touch the battery.
• Make sure the air vent fan of the battery is left UNCOVERED.
• The charger must be taken out before installing or riding the
Neva Board.
• Battery contains dangerous substances therefore do not
open the battery and do not insert anything into the battery.
• ONLY use the charger provided with your product .
• Don't charge the battery that has over discharged.
• It should be abandoned for safety.
7.2 Charging Process
• Ensure charging port is dry.
• Open the charging port.
• Plug the charging cable into the board making sure
the green indicator light lights up, then connect the
cable with the power supply (100V - 240V; 50, 60 Hz).
•The red light on the battery (transformer) indicates it
has begun to charge, otherwise check whether the
cable is connected.
• When the indicator light changes from red to green
the power is fully charged. At this point stop charging
as over-charging will affect lifetime performance.
• The charging time is approx. 2-3 hours.
Battery
Charging time
Voltage
Initial Capacity
Working Temperature
Charging Temperature
Storage Time (-20°C - 25°C)
Storage Humidity
Contents Parameters
Lithium Battery
2-3 hours
36 V
2-4Ah
-15°C ～- 50°C
0°C ～- 40°C
12 months
5% - 95%
USER MANUAL
7. BATTERY 12
7.3 Temperature
The best charge temperature is 0-40
degrees Celsius.
7.5 Description of Battery
7.4 Shipping Notes
Lithium batteries can be a dangerous article. Shipping lithium should be
allowed by local law.
Please contact our authorized agent to deal with your requirements.
• Disconnect the charger and turn of the board.
• Wipe the cover.
• Fully charge your battery before storing away.
• If you store the board away for more than one month, please remove the battery and charge it at least every 3 months.
• If the storage ambient temperature is below 0 degrees, please do not charge. You need to bring the board into a warm
environment (above 10 degrees) for charging. Store your Neva Board indoors in a dry and suitable temperature.
If you do not use it for a long period of time do not
connect the power.
USER MANUAL
8. CLEANING
AND STORAGE
13
IMPORTANT
Avoid using water, detergents or other liquids on the board for cleaning. The IP is 54. If water or other liquids seep into the
board it will cause permanent damage to the internal electronics. It should be abandoned for safety.
Users who disassemble self-balancing board without permission will invalidate their right of warranty.
Net Weight
Load
Maximum speed limit
Range
Max climbing limit
Minus turning radius
Battery
Power requirement
Dimensions
Ground clearance
Platform height
Tire
Battery Capacity
Battery voltage
10kg
20-100kg
10 km/h
15-20km
15°
0°
Lithium-ion
AC 1 00-240V /50-60Hz
584*186*178mm
30mm
110mm
Non-pneumatic hollow tire
4.4AH
36V
Style Parameter Remark
Including rider and belongings
Load will effect the climbing limit
Applied to the global
Including rider and belongings
Terrain, riding style and
payload may effect range
USER MANUAL
9. NEVA BOARD
SPECIFICATION
14
ENJOY YOUR NEVA BOARD
Please contact our service department to request any additional Information.
Distributed by: Debut Sports & Leisure Ltd
Unit 1.9 Paintworks, Bath Road, Bristol, BS4 3EH. UK
Customer Service Helpline: 0117 977 1100
Product number: 1598
Protective equipment should be worn at all times: Helmet, hand/wrist protection, elbow & knee pads.
Wear sensible shoes.
Boarding is fun but can be dangerous, caution must be used with this balance board as it requires skill.
Choose to use your Neva Board in places which allow you to improve your skills. Not on pavements or streets,
it’s not recommended to use in or around crowded areas where accidents have happened to boarders and other people.
Please read the enclosed instructions carefully before use. Please keep all the relevant information for future reference.
Batteries must be recycled or disposed of properly. If at any time in the future you should need to dispose of this product
please note that waste electrical products should NOT be disposed of with household waste. Please recycle where facilities
exist. Check with your local authority or retailer for recycling advice. (Waste electrical and electronic equipment directive).
USER MANUAL
10. AFTER
SALES SERVICE
15
WARNING
SAFETY NOTICE
PRODUCT BATTERIES
Table of contents
