Gyrocopters PLAID User manual

OPERATION
MANUAL :
GYROCOPTERS
PLAID E-SCOOTER
GYROCOPTERS
PLAID
E-SCOOTER

HELMETS
SAVE
LIVES !
Always wear a properly fitted helmet that
complies with CPSC or CE safety
standards when you ride your
Gyrocopters Plaid E-Scooter.
Correct Fit:
Make sure your helmet
covers your forehead.
Incorrect Fit:
Forehead is exposed
and vulnerable to
serious injury.
1

WARNING
As with all mechanical devices, the
Gyrocopters Plaid E-Scooter is subject to wear
and high stresses. Different materials and
components may react to wear or fatigue in
different ways. If the design life of a component
has been exceeded, it may suddenly fail,
possibly causing injuries to the rider. Any form of
crack, scratch, or change of coloring in highly
stressed areas indicate that the life of the
component has been reached and it should be
replaced. Do not ride in an abusive manner.
In this manual, the CAUTION sign indicates
a hazardous situation which, if not avoided, can
cause minor or moderate injury.
CAUTION
WARNING
In this manual, the WARNING sign indicates a
hazardous situation which, if not avoided, can cause
serious injury or death.
Great care should be taken with the
Gyrocopters Plaid E-Scooter while folding and
unfolding it. Moving and folding parts can cut skin
or pinch if mishandled.
DO NOT RIDE YOUR SCOOTER WITHOUT THE
STEERING COLUMN, FOLDING HINGE, AND
HANDLEBARS SECURELY LOCKED IN PLACE.
WARNING
2

PLEASE READ THE OPERATION MANUAL
THOROUGHLY.
Failure to follow the basic instructions and safety precautions
listed in the operation manual can lead to damage to your Gyrocopters Plaid
E-Scooter , property damage, serious bodily injury, and even death.
Thank you for purchasing the Gyrocopters Plaid E-Scooter. Please
read all instructions carefully before using it and retain this manual for
future reference.
•To avoid collisions, falls, and loss of control, please learn how to ride the
Gyrocopter Plaid E-scooter safely.
•You can learn how to ride the Gyrocopters Plaid E- Scooter by reading
the operation manual and watching videos.
•All users are responsible for any consequences caused by violating warning
contents or proper operations. Gyrocopters can not be held liable .
ATTENTION:
1. Use only the supplied charger from Gyrocopters with this E-Scooter.
2. The operating temperature range of the charger is 32°F - 104°F
(0°C - 40°C).
3. The operating temperature range of the Plaid is 32°F - 104°F (0°C
- 40°C).
4. Do not ride on icy or slippery surfaces.
5. Read the operation manual and warning labels before riding.
6. Store the Gyrocopters Plaid E-Scooter in a dry, ventilated
environment.
7. When transporting the Gyrocopters Plaid E- Scooter, avoid violent
crashes or impact.
WARNING
3

PLEASE READ THE OPERATION MANUAL
THOROUGHLY.
Failure to follow the basic instructions and safety precautions
listed in the operation manual can lead to damage to your
Renegade, property damage, serious bodily injury, and even
death.
Thank you for purchasing the Hover-1 Renegade. Please read all
instructions carefully before using it and retain this manual for future
reference.
• To avoid collisions, falls, and loss of control, please learn how to ride
the Renegade safely.
• You can learn how to ride the Renegade by reading the operation
manual and watching videos.
• All users are responsible for any consequences caused by violating
warning contents or proper operations. Hover-1 can not be held liable.
ATTENTION
1. Use only the supplied charger from Hover-1 with this EScooter.
2. The operating temperature range of the charger is 32°F - 104°F
(0°C - 40°C).
3. The operating temperature range of the Renegade is 32°F - 104°F
(0°C - 40°C).
4. Do not ride on icy or slippery surfaces.
5. Read the operation manual and warning labels before riding.
6. Store the Renegade in a dry, ventilated environment.
7. When transporting the Renegade, avoid violent crashes or impact.
LOW TEMPERATURE WARNING
Low temperatures will affect the lubrication of moving parts inside the
E-scooter, increasing internal resistance. Additionally, the discharge
capacity and capacity of the battery will be significantly decreased.
Use caution when riding in cold temperatures (below 40°F/4°C). Doing
so may increase the risk of mechanical failures of the Gyrocopters
Plaid E-Scooter, which may lead to damage to your device, property
damage, serious bodily injury, and even death.
SAFETY INSTRUCTIONS
•Keep the Gyrocopters Plaid E-Scooter away from heat sources, direct
sunlight, humidity, water, and any other liquids.
•Do not operate the Gyrocopters Plaid E-Scooter if it has been exposed
to water, moisture, or any other liquids to prevent electric shock,
explosion, and/or injury to yourself and damage to the E-Scooter.
•Do not use the Gyrocopters Plaid E-Scooter if it has been dropped
or damaged.
•Repairs to electrical equipment should only be performed by the
manufacturer. Improper repairs void the warranty and may place the
user at serious risk.
•Do not puncture or harm the exterior surface of your Gyrocopters Plaid
E-Scooter in any way.
•Keep the device free from dust, lint, etc.
•Do not use your Gyrocopters Plaid E-Scooter for anything other than its
intended use or purpose. Doing so may damage the E-Scooter or lead to
property damage, injury, or death.
•This product is not a toy. Keep out of the reach of children.
•Do not expose the batteries to excessive heat such as direct sunlight or
an open flame.
•Do not allow hands, feet, hair, body parts, clothing, or similar articles to
come in contact with moving parts and wheels while your Gyrocopters
Plaid Electric scooter is running.
4

•Do not operate or allow others to operate your Gyrocopters Plaid E-
Scooter until the user understands all instructions, warnings, and safety
features described in this manual.
•Check with your doctor if you have a medical condition that could affect
your ability to use Gyrocopters Plaid E-Scooter.
•Persons with head, back, neck ailments, or prior surgeries
to those areas of the body are not recommended to use
the Gyrocopters Plaid E-Scooter.
•Do not operate if you are pregnant or have a heart condition.
•Persons with any mental or physical conditions that may make them
susceptible to injury or impair their physical or mental capabilities to
recognize, understand, and perform all of the safety instructions and
assume the hazards inherent in operation should not use the
Gyrocopters Plaid E-Scooter.
Prolonged exposure to UV rays, rain, and the elements may damage the
enclosure materials. Store indoors when not in use.
WARNING
5

Gyrocopters Plaid E-Scooter is a personal transporter. Operating the
scooter without following the contents of this manual may lead to
damage to your E-Scooter or bodily injury.
PACKAGE CONTENTS
•Gyrocopters Plaid Electric Folding Scooter
•4 screws, 1 X internal hexagon wrench
•Charger & Charging Cable
•The first rule of safe riding is to use common sense.
•Different localities and countries have different laws about riding electric
transportation devices on public roads. You should check with local officials to
ensure you are complying with local traffic law requirements.
•Gyrocopters is not liable for tickets or violations given to riders who do
not follow local laws and regulations.
•For your safety, always wear a helmet that meets CPSC or CE safety
standards. In the event of an accident, a helmet can protect you from
serious injury and in some cases, even death.
INTRODUCTION
Your Gyrocopters Plaid E-scooter serial number is stamped on
the bottom of the E-Scooter platform.
SAFETY PRECAUTIONS
6

•Obey all local traffic laws. Obey red and green lights, one-way streets,
stop signs, pedestrian crosswalks, etc.
•Ride with traffic, not against it.
•Ride defensively; expect the unexpected.
•Give pedestrians the right-of-way.
•Do not ride too close to pedestrians and alert them if you intend to pass
them from behind.
•Slow down at all street intersections and look to the left and right before
crossing.
•Your Gyrocopter Plaid E-Scooter is equipped with reflectors.
•If you are riding your Gyrocopters E-Scooter in low-visibility conditions,
ensure your LED headlight is turned on, and that you are wearing bright,
reflective clothing.
•Do not ride above your skill level. Ensure you have had enough
practice with all functions and features of your Gyrocopters Plaid
Electric Scooter.
•Do not ride too fast – with increased speed comes increased risk. If
you are moving at a higher speed, small bumps can create strong
impacts, leading to a higher risk of injury.
•Do not ride with pets.
•Before stepping on your Gyrocopters Plaid E-Scooter, make sure it
is placed flat on the level ground.
WARNING
When you ride in low-visibility conditions
such as fog, dusk, or night, you might be
difficult to see, which could lead to a
collision. To increase your level of safety,
be sure to wear bright, reflective clothing
while riding in low-visibility conditions.
7

•Do not try to open or modify your Gyrocopters Plaid E-Scooter. Doing so
voids the manufacturer warranty and may cause your scooter to fail,
resulting in injury or death.
•Do not use the Gyrocopters Plaid E-Scooter in a manner that would put
people or property in danger.
•If you are riding near other riders, be sure to maintain a safe
distance between each other to prevent collisions.
•Be sure to keep your feet on the E-scooter at all times. Moving your feet
off while driving is dangerous and may cause the Gyrocopters Plaid to
stop suddenly or veer sideways.
•Do not operate your Gyrocopters Plaid E-Scooter while under the
influence of drugs or alcohol.
•Do not operate the Gyrocopters Plaid E-Scooter when you are restless or
sleepy.
•Use your best judgment to keep yourself out of dangerous situations with
your Gyrocopters Plaid E-Scooter.
•Do not ride your Gyrocopters Plaid E-Scooter off of curbs, ramps, or
attempt to operate in a skate park, empty pool, or in any way similar to a
skateboard. Misuse of your scooter voids the manufacturer warranty and
may lead to injury or damage.
•Do not abuse your Gyrocopters Plaid E-Scooter. Doing so can damage your unit
and cause failure to the operating system, which may lead to injury. Physical abuse,
including dropping your Plaid, voids the manufacturer warranty.
•Do not operate in or near puddles of water, mud, sand, stones, gravel,
debris, or near rough and rugged terrain.
•The E-scooter can be used on paved surfaces that are flat and even. If
you encounter uneven pavement, lift your Gyrocopters Plaid E-Scooter
over and past the obstruction.
•Do not ride in inclement weather: snow, rain, hail, sleet, on icy roads, or in
extreme heat or cold.
•Bend your knees when riding on bumpy pavement to absorb the shock
and vibrations. This will help you keep your balance.
•If you are unsure if you can safely ride on a specific terrain, step off and
carry your Gyrocopters Plaid E-Scooter. Always be on the side of caution.
8

•Do not attempt to ride over bumps or objects greater than ½ inch, even
when prepared and bending your knees.
•Pay attention. Look where you are riding and be conscious of the road
conditions, people, property, and objects around you.
•Do not operate the Gyrocopters Plaid E-scooter in crowded areas.
•Operate your Gyrocopters Plaid E-Scooter with extreme caution when
indoors, especially around people, property, and narrow spaces.
•Do not operate the Gyrocopters Plaid E-Scooter while talking, texting, or
looking at your phone.
•Do not ride your Gyrocopters Plaid E-Scooter where it is not permitted.
•Do not travel up or down steep hills.
•The Gyrocopters Plaid E-Scooteris intended for use by a single individual,
DO NOT attempt to operate the E-Scooter with two or more people.
•Do not carry anything while riding the Gyrocopters Plaid E-Scooter.
•Individuals with lack of balance should not attempt to operate the
Gyrocopters Plaid E-Scooter
•Young children and the elderly should not operate the Gyrocopters Plaid E-
Scooter
•At higher speeds, always take longer stopping distances into
consideration.
•Do not attempt to jump on or off your Gyrocopters Plaid E-Scooter.
•Do not attempt any stunts or tricks with your Gyrocopters Plaid E-Scooter.
•Do not ride the Gyrocopters Plaid E-Scooterin dark or poorly lit areas.
WARNING
Proper use of your brake is vital to ensure safe, efficient
stopping. To avoid misuse and potential injury, do not apply
sudden or excessive force to your brakes. Apply your brakes
gradually and give yourself enough room to come to a
complete stop safely.
9

•Do not ride the Gyrocopters Plaid E-Scooter near or over
potholes, cracks, or uneven pavement or surfaces.
•Do not turn sharply, especially at high speeds.
•Do not exceed the maximum weight limit of 330 lbs (150 kg).
•Avoid driving the Gyrocopters Plaid E-Scooter in unsafe places,
including areas with inflammable gas, steam, liquid, dust, or fiber
that could cause fire and explosion accidents.
•Do not operate near swimming pools or other bodies of water.
•Maintain a safe braking distance during wet conditions.
WARNING
There may be additional risk of injury if you use your E-
Scooter incorrectly. This includes, but is not limited to:
•Jumping your E-Scooter
•Riding over debris or obstacles
•Performing stunts
•Riding fast
•Racing other riders
•Riding in an unusual manner
The aforementioned examples add stress to each part of
your E-Scooter and can lead to long term damage of the
device. Damage to your E-Scooter can lead to an accident
or increase your risk of injury. To decrease your risk of
injury, use your E-Scooter correctly.
10

•To avoid damage to the Plaid's internal circuitry, do not expose it to liquid,
moisture, or humidity.
•Do not use abrasive cleaning solvents to clean the Plaid.
•Do not expose the Gyrocopters Plaid E-Scooterto extremely high or low
temperatures, as this will shorten the life of the device, destroy the battery,
and/or distort certain plastic parts.
•Do not dispose of the Gyrocopters Plaid E-Scooterin fire as it may explode
or combust.
•Do not let the Gyrocopters Plaid E-Scooter come into contact with sharp
objects, as this will cause scratches and damage.
•Do not let the Gyrocopters Plaid E-Scooter fall from high places, as doing
so may damage the internal circuitry.
•Do not attempt to disassemble the Gyrocopters Plaid E-Scooter.
•Use only the charger provided by Gyrocopters.
•Use only the manufacturer’s authorized replacement parts.
CARE & MAINTENANCE
WARNING
To reduce the risk of injury, adult supervision is
required. Never use in roadways, near motor vehicles,
on or near steep inclines or steps, swimming pools, or
other bodies of water. Always wear shoes, and never allow
more than one rider at a time.
WARNING
Avoid using water or other liquids for cleaning. If water
or other liquids enter the Plaid, it will cause permanent
damage to the internal components.
WARNING
Users who disassemble the Plaid without permission
from Gyrocopters will void the warranty.
11

BATTERY SPECIFICATIONS
Battery Type: Rechargeable lithium-ion
battery Charge Time: Up to 5 hours
Battery Voltage: 48V
Battery Capacity: 10Ah
Working Temperature: 32°F - 104°F
Charging Temperature: 32°F - 104°F
Storage Time: 1 year
Storage Temperature: 32°F - 104°F
Storage Humidity: 5% - 95%
BATTERY MAINTENANCE
•The lithium-ion battery is built into the Gyrocopters Plaid E-Scooter. Do
not disassemble the E-Scooter to remove the battery or attempt to
separate it from the E-Scooter.
•When charging the E-Scooter, only use the enclosed charger provided by
Gyrocopters. Use of any other charger or cable may lead to damage to the
E-Scooter, overheating, and risk of fire. Use of any other charger or cable
voids the manufacturer warranty.
•Do not connect or attach the Gyrocopters Plaid E-Scooteror the battery to
a power supply plug or directly to a car’s cigarette lighter.
•Do not place the Gyrocopters Plaid E-Scooter near a fire or leave it out in
direct sunlight. Heating the E-Scooter can break or ignite the battery inside the
device.
•Do not continue charging the battery if it does not recharge within the
specified charging time. Doing so may cause the battery to become hot,
rupture, or ignite.
•To preserve natural resources, please recycle or dispose of batteries
properly. This product contains lithium-ion batteries. Local, state, or federal
laws may prohibit disposal of lithium-ion batteries in ordinary trash. Consult
your local waste authority for information regarding available recycling
and/or disposal options.
BATTERY CARE / MAINTENANCE
WARNING
Failure to follow the safety precautions
listed below could lead to serious bodily
injury or death.
12

•Do not attempt to modify, change, or replace your battery.
•Do not use your device if the battery begins to emit odor, overheats, or
begins to leak.
•Do not touch any leaking materials or breathe fumes emitted.
•Do not allow children or animals to touch the battery.
•The battery contains dangerous substances. Do not open the battery or
insert anything into the battery.
•Do not attempt to charge the device if the battery has discharge or emits
any substances. In that case, immediately distance yourself from the
battery in case of fire or explosion.
•If the Gyrocopters Plaid Electric Scooter is not used for a long time, the
battery should be fully charged every 90 days. Otherwise the battery will
discharge itself and be damaged.
WARNING
SEEK IMMEDIATE MEDICAL ASSISTANCE IF
YOU ARE EXPOSED TO ANY SUBSTANCE
THAT IS EMITTED FROM THE BATTERY.
13

SPECIFICATIONS
PARTS LIST
PLAID E-SCOOTER
54. 2 lbs (23.6 kg) 330
lbs (150 kg)
44 lbs (20 kg)
Up to 18 mph (45 km/h)
Up to 40 km (varies based on riders
weight
Lithium-ion
800W brush-less motor
48 V
10 Ah
49" x 26.5" x 21.8"
49" x 26.5" x 46"
Air-filled tires
Front and rear mechanical disc brake
Handle-activated rear disc brake
UL2272 certified
Model:
Net Weight:
Max Supported Weight: Min
Supported Weight: Max
Speed:
Max Range:
Battery Type:
Motor Power:
Battery Voltage: Battery
Capacity: Power
Requirement: Folding Size:
Open Size:
Tire Type:
Brake:
UL Certification:
B
C
A
A. Plaid E-Scooter
B. Screws x 4
C. Charger + Charging Cable
D. Hex Key D
14

FEATURES/PARTS
15
GYROCOPTERS PLAID DIAGRAM

LCD DISPLAY
1. Battery Indicator: Six led light bars on the display show the battery level. It is
recommended not to drain the battery by 100%and charge it before use.
2. Left and Right Turn Signal: The left and right turn signals indicate the
corresponding lower turn light flash while you are steering left or right.
3. Double-drive mode: Double-click headlight switch to shift to a dual-drive mode.
[Applicable only for Dual Motor Models]
4. Bluetooth connection: The Display board has a Bluetooth symbol, indicating
the scooter is connected to mobile Bluetooth and app functions are active.
5. Cruise Control: Turn on the cruise speed function by holding down the
accelerator till you hear a beep. Once the cruise control is active you can release
the acceleration handle, the vehicle will continue to ride at a uniform speed.
Cruise Control gets deactivated if you brake or press the acceleration bar again.
6. Light Symbol: After the vehicle is powered on, press the headlight switch once
to switch on all the lights. A light symbols appear on the display when all the
lights of the vehicle are turned on.
7. Pedestrian mode: Walking mode symbols on the instrument display when the
vehicle speed is less than 6km/h.
8. Maximum speed: It shows the top speed of the whole ride.
9. Current speed: The Display shows the current speed.
10. Single Mileage: Show the current mileage during the ride, and automatically
return to zero after turning off the power supply.
16

1. On/Off Switch: Press 2 seconds to turn the scooter
On or Off.
2. Lights Switch: Click the switch to turn on all lights
and click twice to turn off all the lights.
3. Horn Switch: Press and hold the horn switch for
horn sound, and release the horn switch to stop the sound.
4. Speed Switch: Click the speed switch one to shift
from Eco to standard speed mode. Click twice to switch to
sports mode.
5. Mode Settings: Click on the mode switch to shift
between metric and imperial modes.
6. Turning Switches: Press the left and right turning
switches to turn on the corresponding turn indicator lights.
CONTROL BUTTONS

•Ensure that the charging port is clean and dry.
•Make sure that there is no dust, debris or dirt inside the port.
•Plug the charger into a grounded wall outlet.
•Connect the cable with the power supply (100V˜240V; 50 Hz/60 Hz).
•Align and connect the charging cable into the charging port of the Plaid
(DO NOT FORCE OR BEND THE CHARGING CABLE AS IT MAY
CAUSE THE PRONGS TO BEND OR BREAK).
•The charging indicator light on the charger itself should change to red,
indicating that your device is now being charged.
•When the red indicator light on your charger changes to green, then your
device is fully charged.
•After fully charging your Plaid E-Scooter, unplug the charger from your
device and from the power outlet.
Only use the included charging
cable and charger to charge
your Plaid. Using any other
charger may damage your Plaid.
CAUTION
CHARGING YOUR GYROCOPTERS PLAID E-SCOOTER
PREPARING YOUR GYROCOPTERS PLAID E-SCOOTER
PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY
ATTACHING THE HANDLEBARS AND BRAKE HANDLE
18

Some parts of your Plaid can injure you if mishandled. Moving and
folding parts can cut skin. Clamps and pivoting parts such as brake
levers can pinch. When folding and unfolding your Plaid, please watch
for pinch points where injury may be sustained. Do not leave your
hand in these areas during the folding or unfolding process.
PINCH POINTS
19
For safety reasons, the Gyrocopters Plaid E-Scooter
will not accelerate unless it is already moving at least
1.8 mph (3 km/h). You must first kick off the ground and
then press the throttle in order to ride the E-Scooter.
