Baja motorsports RT50-R 2009 User manual

Always wear a helmet; It could save your Life!
Do not remove this operator’s manual from this vehicle.
Please obtain, review, and follow provincial / municipal government acts and regulations
pertaining to owning and operating this scooter.
Minimum Recommended Age
Requirement 16
Rev. G
030509
RT50-R Retro SCOOTER
Read this manual carefully. It contains important safety information.
No one under the age of 16 should operate this scooter.
OWNER’S MANUAL

II
Congratulations on your purchase of the BAJA INC. RT50-R Retro
Scooter.
Your Scooter is warranted to be free of manufacturing defects in
material and workmanship for a period of 90 days from the date of
purchase. During the warranty period BAJA INC. will at its option,
repair, provide replacement parts or replace your BAJA INC. 50cc
Scooter at no charge. This warranty does not cover normal wear
items or damage caused by neglect or misuse of the product.
Engine Warranty – 90 days
Frame Warranty – 90 days
Warranty is void if:
Frame is bent or broken due to abuse
Wheels are bent or broken
Fender bent or broken due to abuse
Any sign of impact, accident, jumping, spin-outs or roll over.
BAJA INC. is not liable for any damage claim or liability claim
person or otherwise resulting from the operation of this product in
any way.
Should you experience a problem with your vehicle, please call the Baja
INC. customer service line toll free at 1-888-863-2252 between the hours of
7am and 5pm Monday through Friday MST (Mountain Standard Time). MDT
(Mountain Daylight Time) during daylight saving time. You will be instructed
how to proceed.
A COPY OF THE SALES RECEIPT IS REQUIRED.

III
This manual should be considered as a permanent part of the
vehicle and should remain with the vehicle when resold or
otherwise transferred to a new user or operator. The manual
contains important safety information and instructions which
should be read carefully before operating the vehicle. All
operators should obtain, review, and follow provincial and
municipal government acts and regulations pertaining to owning
and operating an on-road vehicle. Children under the age of 16
should never operate this vehicle.
WARNING
!
It is the operators responsibility to know and obey all applicable
local, state and federal laws at all times while operating this
vehicle including but not limited to trafc safety, vehicle
registration, emissions, and noise.
The exhaust from this product contains chemicals known to
the State of California to cause cancer, birth defects or other
reproductive harm. CALIFORNIA PROPOSITION 65
WARNING
!
WARNING
!

1
IMPORTANT ........................................................................................................ 2
GENERAL PRECAUTIONS/WARNINGS ............................................................ 3
NHTSA SAFETY NOTICE.................................................................................... 8
PRE RIDE CHECK LIST...................................................................................... 9
LOCATION OF WARNING LABEL...................................................................... 10
FUEL AND OIL..................................................................................................... 13
OPERATION ........................................................................................................ 14
STARTING THE ENGINE............................................................................. 14
DRIVING SAFELY........................................................................................ 15
SHUTTING OFF THE ENGINE .................................................................... 16
STOPPING THE VEHICLE .......................................................................... 16
PARKING ..................................................................................................... 16
BREAKING IN.............................................................................................. 16
IGNITION SWITCH ...................................................................................... 17
BRAKE LEVERS AND THROTTLE............................................................. 17
RIGHT BRAKE/SWITCH ASSEMBLY......................................................... 18
KICK STARTER ........................................................................................... 19
LEFT BRAKE/SWITCH ASSEMBLY ........................................................... 19
INSTRUMENT PANEL ................................................................................. 20
SEAT LOCK ................................................................................................. 20
FUEL TANK.................................................................................................. 21
MAINTENANCE................................................................................................... 22
CHECKING AND CHANGING ENGINE OIL................................................ 22
CLEANING OIL FILTER.............................................................................. 22
CHANGING TRANSMISSION OIL............................................................... 23
SPARK PLUG............................................................................................. 23
AIR FILTER .................................................................................................. 24
BRAKES ...................................................................................................... 25
IDLE SPEED ADJUSTMENT/FUEL HOSE INSP. ....................................... 26
TIRES ........................................................................................................... 27
BATTERY..................................................................................................... 28
TRANSPORTING................................................................................................. 32
STORAGE PROCEDURE.................................................................................... 33
MAINTENANCE CHART ..................................................................................... 34
TROUBLESHOOTING......................................................................................... 35
SPECIFICATIONS................................................................................................ 37
ELECTRICAL DIAGRAM..................................................................................... 38
SERIAL NUMBER LOCATION ............................................................................ 39
EMISSION CONTROL SYSTEM WARRANTY.................................................... 40
Table of Contents

2
Please read this manual and follow all instructions carefully. To emphasize
the special information, the symbol and the words WARNING or CAUTION
have some special meanings. Pay attention to the messages.
NOTE: Indicating special information which is to make maintenance easier or
instructions clearer.
WARNING and CAUTION are arranged like this:
This user’s manual contains important safety and maintenance information.
Read it carefully before riding. Failing to follow the warnings contained in this
manual could result in INJURY or DEATH.
It is important that this manual remain with the vehicle when you transfer it to
another user or owner.
All information, illustrations, photographs and specications contained in
this manual are based on the latest product information available at the time
of publication. Due to improvements or other changes, there will be some
discrepancies in this manual. We reserve the right to make product changes
at any time, without notice and without incurring any obligation to make the
same or similar changes to the vehicle previously built or sold.
WARNING
Indicates a potential hazard that could result in death or injury.
CAUTION
Indicates a potential hazard that could result in vehicle damage.
WARNING-or-CAUTION
The rst part will identify a POTENTIAL HAZARD.
The second part will describe WHAT COULD HAPPEN if you ignore
the WARNING or CAUTION.
The third part will describe HOW TO AVOID THE HAZARD.
Important

3
● Read and follow all instructions in this Owner’s/Operator’s Manual,
any accompanying supplements, Do not discard this owner’s
manual, safety video, or any other material or documentation
included with this vehicle.
● Exhaust fumes are toxic. California Proposition 65 warning:
Gasoline engine exhaust from this vehicle contains chemicals known
to the State of California to cause cancer, birth defects, or other
reproductive harm. The engine exhaust contains carbon
monoxide, which is tasteless, odorless, poisonous gas. Never
operate this vehicle indoors or in an enclosed area with poor
ventilation.
● This vehicle may have been supplied to you completely assembled.
To prevent possible injury or death, read and follow the assembly
instructions to make sure the vehicle was assembled properly.
● Always perform the daily pre-ride inspection specied in this manual
before operating this vehicle.
● Modifying the vehicle and/or removing original equipment and/or
safety decals could make this vehicle unsafe for operation.
● Replace any safety decals that become unreadable or detached from
the vehicle. Decals provide critical warnings about potential hazards
or safety requirements.
● Never use this vehicle for stunt riding, spin outs, donuts, racing , or
any form of competition.
WARNING! FAILURE TO FOLLOW THESE
INSTRUCTIONS CAN RESULT IN SEVERE INJURY OR
DEATH.
CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS
CAN ALSO RESULT IN DAMAGE TO THE VEHICLE AND/
OR OTHER PROPERTY.
General Precautions
!

4
Additional Warnings
Protective Clothing/Equipment
● Most accident fatalities are due to preventable head injuries. Always
wear a properly tting motorcycle type helmet approved by agencies
such as the Department of Transportation (DOT), Safety Helmet
Council of America (SHCA), or Snell Memorial Foundation (SNELL).
● Always wear face shields or goggles, boots, gloves and other
appropriate protective clothing.
● Long hair, loose clothes, or jewelry can get caught in moving parts
below and behind the seat or your surrounding environment.
Remove or tie back anything loose that can reach below and behind
the seat before riding.
Moving Parts
● Never place hands, feet, any body parts or clothing near the engine,
wheels, chain and other rotating parts of the vehicle while riding or
running the engine.
● Use extreme caution when performing required maintenance while
the engine is running.
● Keep guards and pads in place at all times. Prevent accidental
contact by any person whenever the vehicle is running.
● The guards over the brake, clutch, torque-converter, axle and drive
sprockets also help prevent mud and debris from contacting those
components.
Trafc Safety
● ALWAYS FOLLOW THE ENTIRE PRE-RIDE CHECKLIST PRIOR TO
STARTING OR RIDING THE SCOOTER.
● Your safety while riding this vehicle depends entirely on your ability
to exercise proper judgement. You must be of sufcient age,
understanding, mental capacity, and physical capability to safely
operate this vehicle.

5
Additional Warnings (continued)
Traffic Safety (continued)
● Always obtain mature, supervised instruction and sufcient practice
in an decongested area before operating this vehicle on any public
thoroughfare.
● Excessive vehicle speed is a leading cause of accidents, which can
cause death or serious harm to you, other people, and/or property.
Always obey all applicable trafc safety laws while operating this
vehicle, being sure to account for current weather and trafc
conditions and slow down if necessary. DRIVE TO ARRIVE!
● Use extreme caution when riding on wet, slippery, rough or sloped
terrain. There is an increased risk of loss of control, which can result
in injury, death, and/or property damage.
● Always slow down when turning. High-speed turning can cause loss
of control and/or possible death, injury, and/or property damage.
Practice turning in a safe area away from trafc until you are
condent in your ability to control the vehicle at all times.
● Operating this vehicle at an unsafe speed, especially while turning,
can cause death, injury, and/or property damage.
● Never use this vehicle to perform any type of racing, stunt riding,
jumps, spin-outs, donuts, or other maneuvers, You could kill or
injure yourself or others and/or cause property damage.
● Never operate vehicle while under the inuence of alcohol, drugs or
medication of any kind. Such operation is dangerous to yourself
and/or others.
● Check the tire pressure before operating the vehicle using a properly
calibrated tire air pressure gauge.
● Stop the vehicle and shut off the engine immediately if the vehicle
makes unusual noises or vibrations. Check the vehicle for damage.
Excessive noise or vibration is a sign of loose or worn parts.

6
Additional Warnings (continued)
Engine/Motor Safety
● Keep the engine/motor free of dirt and debris, especially in the
throttle linkage area.
● Never start the engine/motor without checking to see that the throttle
control is in the idle position.
● Never start the engine/motor unless you are properly seated with
your hands rmly on the controls.
● Never tamper with, alter, or change the vehicle’s engine/motor
settings. The engine/motor governor is factory set and protects
the engine/motor from damage. Excessive engine/motor speed is
potentially dangerous to the operator, bystanders, and the engine/
motor itself.
● All guards must be in place prior to starting the engine.
● Operating the vehicle in conditions where water, mud, snow, dirt,
sand or other debris can get into the throttle cable conduit and/or the
throttle mechanism can cause the cable or throttle mechanism to
bind, which may lead to throttle sticking, loss of control, and
possible death, injury, and/or property damage.
Fasteners
● Make sure that all screws, nuts, and bolts are properly tightened.
Never over-tighten hardware that is designed to move, such as front
and rear wheels. Restricting moving parts can cause a loss of
control and possible injury or death.
● Always replace torque-type locknuts with new locknuts of the same
type after removing the old locknuts.

7
Additional Warnings (continued)
Fueling
● Check the fuel supply before each use. Never ll the fuel tank while
the engine is running or hot. Always allow at least 1in. of expansion
space at the top of the fuel tank. There should not be any fuel in the
ller neck. Replace the fuel cap tightly after refueling to prevent a
fuel spillage, re, or explosion hazard.
● Always use an original gas cap or an approved OEM replacement.
Never ll fuel tank while the vehicle is inside a building. Gasoline
vapors can cause injury or death and can pose a re or explosion
risk.
● Move the vehicle at least 10 ft. before starting the engine.
● Use extreme caution when starting the engine. Hot engine, mufer,
or drive components can cause serious burns on contact.
Maintenance
● Do not modify the vehicle from the manufacturer’s original design
and conguration.
● Never wash or operate the vehicle in freezing temperatures. Water
can freeze in the throttle cable conduit and/or on the throttle
mechanism, possibly resulting in throttle sticking, which can cause
the engine to continue to run and result in loss of control.
● Assembly, maintenance, and/or repair of this vehicle should only be
performed by designated dealers or authorized repair centers to
ensure quality work and safe vehicle condition.
● Always disconnect the spark plug wire (gasoline vehicles) or
disconnect the battery before commencing any work in the engine
vicinity or where there is a possibility that the vehicle could move
unexpectedly. Keep the spark plug cable away from the spark plug to
avoid accidental starting.
● Avoid contacting the mufer, cylinder head, or any potentially hot
area on or around the engine when working on, around, or restarting
the engine.
