New Air G73 User manual

Electric Garage Heater
G73
OWNERS MANUAL
Read and save these instructions.
.

2
http://www.NewAir.com
A Name You Can Trust
Trust has to be earned and we will earn yours. Customer happiness is
the focus of our business.
From the factory to the warehouse, from the sales floor to your home,
the whole NewAir family promises to provide you with innovative
products, exceptional service, and support when you need it the most.
Count on NewAir.
As a proud NewAir owner, welcome to our family. There are no robots
here, real people shipped your product and real people are here to help
you.
Thank you for your purchase and remember NewAir, A Name You Can
Trust.
Call us today at 855-963-9247
Or email [email protected]
For future reference, we recommend you attach a copy of your sales receipt
here and record the following information. You will need this information if it
becomes necessary to contact the manufacturer for service inquiries.
Date of Purchase: ___________________________________
Serial Number: ___________________________________
Model Number: ___________________________________
Connect with us online.

3
A Name You can Trust
READ AND SAVE THESE INSTRUCTIONS.
TABLE OF CONTENTS
Safety Information & Warnings ...................................................... 4
Heater Installation .......................................................................... 6
Operation ........................................................................................ 8
Cleaning & Storage.......................................................................... 8
Specifications .................................................................................. 9
Troubleshooting............................................................................ 10
Limited Manufacturer’s Warranty ................................................ 11
PLEASE READ ALL INSTRUCTIONS BEFORE USING THIS HEATER
Note: There may be a trace of smoke or odor when this unit is first operated.
Don’t be alarmed. This indicates that a drop of oil fell on the heating coil
during the manufacturing process. It will quickly evaporate and should not re-
occur.
Make sure that the room in which the appliance is located is well ventilated
during its operation. It is normal for the appliance to emit small cracking
sounds when you turn it on for the first time. Do not be alarmed.
SAVE THESE INSTRUCTIONS
WARNING –RISK OF FIRE
DO NOT USE AS A RESIDENTIAL
OR HOUSEHOLD HEATER
CAUTION:This appliance is not intended for use by persons (including children)
with reduced physical, sensory, or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.

4
http://www.NewAir.com
SAFETY INFORMATION & WARNINGS
When using any electrical appliance, basic safety precautions must
be followed in order to reduce the risk of fire, electrical shock
and/or injury to persons or property. Be sure to read all
instructions before using this appliance and observe the following
safety tips:
This heater is hot when in use. To avoid burns, do not let bare skin touch the
hot surface. Always use the handle when moving this heater. The trim
around the air outlet grille becomes hot during heater operation. Keep
combustible materials such as furniture, pillows, bedding, papers, clothes,
and curtains at least 3 feet (0.9 m) from the front of the heater.
Extreme caution is necessary when any heater is used by or near children or
invalids, and whenever the heater is left operating and unattended.
Do not install less than 6 feet (1.9 m) from the floor.
Do not operate the heater if the supplied wire is damaged, the heater
malfunctions, or the heater has been dropped or damaged in any manner.
Return heater to authorized service facility for examination, electrical or
mechanical adjustment, or repair.
Do not use the heater outdoors.
This heater is not intended for use in bathrooms, laundry areas and similar
humid indoor locations. Never put a heater where it may fall into a bathtub
or other water container.
Connect to properly grounded outlets only. Check heater voltage and
amperage on the back of the heater to make sure it agrees with the electric
service supplied.
Do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or fire, or damage to the heater.
To prevent a possible fire, do not block air intakes or exhaust in any manner.
Do not use on soft surfaces, like a bed, where openings may become
blocked.
All electrical heaters have hot, arcing, or sparking parts inside. Do not use in
areas where gasoline, paint, or flammable liquids are used or stored or
where the unit will be exposed to flammable vapors.

5
A Name You can Trust
SAFETY INFORMATION & WARNINGS
Do not modify the heater. Use it only as described in this
manual. Any other use not recommended by the manufacturer
may cause fire, electric shock, or injury to persons.
This heater includes a visual alarm (red light) to warn that
parts of the heater are overheating. If the red light turns on, immediately
turn heater off and inspect for any objects on or adjacent to the heater that
may cause high temperatures. DO NOT OPERATE WHEN RED LIGHT IS ON.
Always use a certified electrician should new circuits or outlets be required.
Disconnect all power supply before performing any cleaning, maintenance,
or relocation of the unit.
When transporting or storing the unit, keep in a dry place, free from
excessive vibration, and store so as to avoid damage.
Make sure that no pieces of polystyrene or other packaging material have
been left between one element of the appliance and another. It may be
necessary to clean the appliance with a vacuum cleaner.
Do not run in locations when the heater will be left unattended for long
periods of time.
Do not use attachments or filters. They are not recommended.
Use this heater only as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock or injury
to persons.
SAVE THESE INSTRUCTIONS

6
http://www.NewAir.com
HEATER INSTALLATION
!NOTE:To prevent personal injury always use a licensed electrician to install
new outlets or circuits.
HEATER LOCATION AND CLEARANCES
The heater must be installed in
a fixed location. The discharge
air should wipe the walls
without blowing directly on
them (Figure 1).
Ensure that air discharge is
parallel to or away from walls.
INSTALLATION OF WALL/CEILING HANGER BRACKET
The hanger bracket allows the unit to be rotated approximately 45 degrees in
each direction from center, when attached to a wall and tilted in a 45 degree
range while suspended from a wall or ceiling.
NOTE:The hardware for mounting the hanger bracket to the wall or ceiling is
not included.
!CAUTION: When turning and/or tilting the heater do not block the exhaust
opening.

7
A Name You can Trust
The following steps are shown in Figure 2:
1. Locate a stud or other suitable
support and install hanger
bracket on wall or ceiling. Select a
location where the control knob
on the back of the heater is easily
reachable.
2. Insert carriage bolt into square
opening of heater handle.
3. Slide spacer over the carriage bolt
shaft and insert the hanger
bracket opening and hold them in
position.
4. Slide lock washer and thread nut
onto carriage bolt. Turn and
tighten with wrench.
Do not install less than 6 feet (1.9 m)
from the floor.
ELECTRICAL CONNECTION
WARNING: Consult local electrical codes in addition to the following
requirements:
1. Turn off main power supply at the electrical panel.
2. Route supply wires from circuit breaker to an approved junction box,
located near compact unit heater. These supply wires must be two
conductor non-metallic sheath cable with ground wire. Each heater should
be on an individual, properly fused circuit.
3. Route supply wires from junction box to G73. These supply wires must be
two conductor metallic sheath (BX) cable with ground wire. Alternatively,
appropriate conduit can be used.
4. Remove junction box cover of G73 and remove one knockout hole. Insert
approved bushing into hole and feed wire cable through. Tighten bushing
around cable.

8
http://www.NewAir.com
5. Make electrical connection to G73 according to relevant wire diagram.
Make connections using approved wire nut connectors and secure the
grounding wire to the ground screw on the heater chassis.
6. Replace junction box cover of G73.
OPERATION
SETTING THE THERMOSTAT
1. Before connecting or
disconnecting plug, turn knob
fully counterclockwise (Figure 4).
2. Heater is equipped with a
thermostat. To adjust
temperature to your individual
requirements, turn thermostat
control knob clockwise all the
way to turn heater on.
3. When room reaches desired temperature, turn thermostat knob
counterclockwise until you hear a “click”. Leave in this position to maintain
room temperature at this setting.
4. For additional heat, turn clockwise until you hear “click” again and heater
will turn on.
5. To turn heater to the lowest setting, turn the thermostat knob
counterclockwise all the way.
CLEANING & STORAGE
REGULAR CLEANING:
Before any cleaning:
Make sure the heater is turned off.
Disconnect power supply at source.

9
A Name You can Trust
CAUTION:Allow at least 30 minutes for the heater to cool before attempting
any maintenance or cleaning.
1. Do not spray cleaning liquid or other chemicals onto the unit.
2. Interior dust can often be removed by using a vacuum cleaner with a
crevice tool attachment.
3. To clean housing, use a clean, soft and lightly damp cloth to gently wipe all
the dirt from the surface of the unit. Be sure not to wet the heating
element and the switches. Allow the unit to dry completely before using it.
Caution: Do not allow water to run into the interior of the heater as this could
create a fire or electric shock hazard, damaging the unit.
STORAGE
1. Perform the cleaning procedures described above.
2. Wipe all parts dry.
3. Pack the heater in a plastic bag and store it in a cool, dry place.
SPECIFICATIONS
MODEL NO.
G73
VOLTAGE:
240 volts
POWER CONSUMPTION:
5000W

10
http://www.NewAir.com
TROUBLESHOOTING
Problem
Possible Causes
Solution
Unit is not heating.
Overheat protection has
temporarily deactivated
the heater.
Turn the heater off; disconnect
the power and allow it to cool.
Inspect and remove any objects
on or adjacent to the heater.
Wait 30 minutes before restoring
power.
Room temperature has
been warmed up to
thermostat setting.
To increase the room
temperature, adjust thermostat
control knob to a higher setting
by turning clockwise.
Heater is not wired
correctly.
Follow the included hardwiring
directions. Contacting a licensed
electrician is recommended.
Breaker/Fuse has been
tripped.
Check your electrical box to
confirm the breaker has not
been blow. This may occur if the
receptacle is shared between
other high consumption
appliances.
The heater is
producing a burning
smell.
A drop of oil fell on the
heating coil during the
manufacturing process. It
will quickly evaporate and
should not occur again.
Ensure room in which heater is
situated is well ventilated.
Check and ensure there are
no combustible materials
within 0.9 meters (3 ft.)
surrounding the heater.
Remove any combustible items
from the heater.
Ensure a minimum
clearance of 5.5 inches (14
cm) from both sides and
rear of heater to adjacent
walls.
Reposition the heater so there is
enough space around the heater
to the adjacent walls.
Please do not attempt to open or repair the heater yourself.
Doing so could cause damage or personal injury.

11
A Name You can Trust
LIMITED MANUFACTURER’S WARRANTY
This appliance is covered by a limited manufacturer’s warranty. For one year
from the original date of purchase, the manufacturer will repair or replace any
parts of this appliance that prove to be defective in materials and
workmanship, provided the appliance has been used under normal operating
conditions as intended by the manufacturer.
Warranty Terms:
During the first year, any components of this appliance found to be defective
due to materials or workmanship will be repaired or replaced, at the
manufacturer’s discretion, at no charge to the original purchaser. The
purchaser will be responsible for any removal or transportation costs.
Warranty Exclusions:
The warranty will not apply if damage is caused by any of the following:
Power failure
Damage in transit or when moving the appliance
Improper power supply such as low voltage, defective household
wiring or inadequate fuses
Accident, alteration, misuse or abuse of the appliance such as using
non-approved accessories, inadequate air circulation in the room or
abnormal operating conditions (extreme temperatures)
Use in commercial or industrial applications
Fire, water damage, theft, war, riot, hostility or acts of God such as
hurricanes, floods, etc.
Use of force or damage caused by external influences
Partially or completely dismantled appliances
Excess wear and tear by the user
Obtaining Service:
When making a warranty claim, please have the original bill of purchase with
purchase date available. Once confirmed that your appliance is eligible for
warranty service, all repairs will be performed by a NewAir™ authorized repair
facility. The purchaser will be responsible for any removal or transportation
costs. Replacement parts and/or units will be new, re-manufactured or
refurbished and is subject to the manufacturer’s discretion. For technical
support and warranty service, please email [email protected].
