New Air AH-600 User manual

1
lease read and save these instructions.
AH-600
Baseboard Heater
Owner’s Manual

2
Important Safety Instructions............................................................................ 3
Parts of the Heater.............................................................................................. 5
Operating Instructions........................................................................................ 6
Safety Features...................................................................................................... 7
Cleaning and Maintenance.................................................................................. 7
Storage.................................................................................................................... 7
Specifications......................................................................................................... 7
Troubleshooting ................................................................................................... 8
Warranty................................................................................................................ 9
TABLE OF CONTENTS

3
PLEASE READ ALL INSTRUCTIONS BEFORE USING THIS HEATER
WHEN USING ELECTRICAL APPLIANCES, BASIC PRECAUTIONS SHOULD
ALWAYS BE FOLLOWED TO REDUCE RISK OF FIRE, ELECTRICAL SHOCK AND
INJURY TO PERSONS OR PROPERTY, INCLUDING THE FOLLOWING:
When switching on the appliance for the first time, allow it to run at full
power for about two hours to get rid of the unpleasant smell. Make sure
that the room in which the appliance is located is well ventilated during
this operation. It is normal for the appliance to emit small cracking sounds
when you turn it on for the first time.
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot
surfaces. Use the handle (if provided) when moving the unit. Keep combustible
materials, such as furniture, pillows, bedding, papers, clothes and curtains at least
3ft. (0.9 meters) from the front and top of the heater and keep them away from
the sides and rear. Keep the rear grille away from walls or drapes so as not to
block the air intake.
3. Extreme and supervision are necessary when any heater is used near children or
pets and whenever the heater is left operating and unattended.
4. Always unplug heater when not in use.
5. Do not operate any heater with a damaged cord or plug, after the heater
malfunctions, or has been dropped or damaged in any manner. Return the heater
to an authorized service facility for examination, electrical or mechanical
adjustment or repair.
6. Do not use outdoors.
7. This heater is not intended for use in any area where there is standing water.
Never locate heater where it may fall into a bathtub or other water container.
8. Do not run cord under carpeting. Do not cover cord with throw rugs, runners or
similar items. Do not route cord under furniture or appliances. Arrange cord
away from high traffic areas where it will not be tripped over.
9. To disconnect the heater, turn controls to OFF, then remove the plug from the
outlet.
10. Connect to properly polarized outlets only.
11. Do not insert or allow foreign objects to enter any ventilation or exhaust opening
as this may cause electric shock, fire or damage to the heater.
12. To prevent possible fire, do not block air intakes or exhaust in any manner. Do
not use on soft surfaces like a bed, where openings may become blocked.
13. A heater has hot, arcing or sparking parts inside. Do not use it in areas where
gasoline, paint or flammable liquids are used or stored.
IMPORTANT SAFETY INSTRUCTIONS

4
14. Use this heater only as described in this manual. Any other use not recommended
by the manufacturer may cause fire, electric shock, injury to persons or other
damage to property.
15. To prevent overload and blown fuses, be sure that no other appliance is plugged
into the same outlet or into another outlet wired into the same circuit.
16. It is normal for the heater’s plug and cord to feel warm to the touch. A plug or
cord which becomes hot to the touch or becomes distorted in shape may be a
result of a worn electrical outlet. Worn outlets or receptacles should be replaced
prior to further use of the heater. Plugging heater into a worn outlet may result in
overheating of the power cord or fire.
17. Ensure the heater is on a stable, secure surface to eliminate the potential of tipping
it over.
18. Be sure that the plug is fully inserted into appropriate outlet. Please remember
that outlets also deteriorate due to aging and continuous use: check periodically
for signs of overheating or deformation of the plug. Do not use the outlet and call
your electrician.
19. Check that neither the appliance nor the power cable has been damaged in any
way during transportation.
20. Make sure that no pieces of polystyrene or other packaging material have been left
between elements of the appliance. It may be necessary to pass over the appliance
with a vacuum cleaner.
21. Always plug heater directly into a wall outlet/receptacle. Never use with an
extension cord or relocatable power tap (outlet/power strip).
CAUTION:This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. SAVE THESE
INSTRUCTIONS
SAVE THESE INSTRUCTIONS

5
G
Features:
A. Low Heat Setting LED E. Timer Increase Button
B. Temperature LED F. Power Button
C. Timer LED G. Timer Decrease Button
D. High Heat Setting LED H. Mode Rotary Knob
NOTE: There may be a trace of smoke or odor when unit is first operated. Do not
be alarmed. This indicates that a drop of oil fell on the heating coil during the
manufacturing process. It will quickly evaporate and should not re-occur.
HIGH modeLOW mode
C
D
E
F
H
B
GETTING TO KNOW YOUR HEATE
R
A

6
Be sure to plug into a 120 V AC, 60 Hz outlet.
1. Turning unit ON/OFF
a. Press the button once and rotate the mode knob once: the heater will
be on at the low output setting and the “LOW” indicator will light. At this
setting, the heater output is 750 W.
b. Press the button again to turn heater off.
2. Select working MODE:
You can select the mode by rotating the mode knob.
a. (LOW) MODE: heater will work continuously and the output will be
750 W at all times.
b. (HIGH) MODE: heater will work continuously and the output will be
1500 W at all times.
c. Comfort Setting mode (64℉, 70℉, 75℉):
Rotate mode knob to your desired temperature. There are three distinct
settings: 64℉, 70℉and 75℉.In this mode, the heater will automatically
select the output power to accommodate your temperature setting. When
the room air temperature reaches your desired temperature, the unit will
automatically lower the output power to maintain your space at the desired
temperature.
1. Room temp less than Setting temp, output power is 1500 W at all times.
2. Setting temp equal to Room temp less than Setting temp +2℉, output
power changes from 1500 W to 750 W
3. Setting temp + 2℉ equal to Room temp, heater will stop heating.
3. AUTO-OFF TIMER ( and button)
When the heater is in use, you can set the timer for turning off the unit. Press
the or button to set the timer between 0.5 and 7.5 hours in 0.5 hour
intervals. When the time runs out, the heater will turn off automatically.
OPERATING INSTRUCTIONS

7
Overheat shut-off protection system: Your heater includes a protection
system that shuts off the heater if it overheats for any reason.
Environment air overheat protection system: This heater will automatically
shut off if the environment air becomes overheated.
1. Before any cleaning, make sure that:
a. Heater is turned OFF
b. Power supply is disconnected by removing plug from power outlet.
2. Regular cleaning:
a. Interior dust can often be removed by using a vacuum cleaner with a
crevice tool attachment.
b. Do not spray cleaning liquid or other chemicals on the unit.
c. To clean enclosure, use a clean, soft and damp cloth to gently wipe off
the dirt from the surface of the unit. Be sure not to wet the heating
element and the switches. Allow the unit to dry completely before using
it.
CAUTION: DO NOT ALLOW WATER TO RUN INTO THE
INTERIOR OF THE HEATER AS THIS COULD CREATE A FIRE OR
ELECTRIC SHOCK HAZARD.
1. Perform the cleaning procedures described in “Cleaning and Maintenance” above
2. Wipe all parts dry
3. Pack the heater in a plastic bag and store it in a cool, dry place
WARNING:Any other servicing needed must be performed by an authorized
service representative. Do not attempt to service the unit yourself.
Product Specifications
Model No.: AH-600
Voltage: 120V, 60Hz
Current: Maximum continuous draw: 12.5 amps
Output: 5120 BTU
Power: 1500 Watts
Enclosure: Metal Body; Plastic end cover
SAFETY FEATURES
CLEANING AND MAINTENANCE
STORAGE

8
If your heater fails to operate, please follow these procedures:
Problem Probable Cause
Solution
Unit is not
heating.
Overheat protection has
temporarily deactivated the
heater.
Turn the heater OFF; unplug it and
ALLOW IT TO COOL. Inspect and
remove any objects on or adjacent to
the heater. Wait 30 minutes before
plugging unit back in.
Room temperature has been
warmed up to thermostat setting.
To increase the room temperature,
adjust MODE control knob to a higher
setting by turning clockwise.
Heater is not plugged into a 120V
grounded outlet/receptacle.
Ensure unit is in OFF position. Plug in
unit and attempt to turn on again.
Breaker/Fuse has been tripped.
Check your electrical box to
confirm the breaker has not been
blown. This may occur if the
receptacle is shared between
other high consumption
appliances.
Ensure unit is in the OFF position.
Plug in unit and attempt to turn on
again.
The heater is
producing a
burning smell.
A drop of oil fell on the heating
coil during the manufacturing
process. It will quickly evaporate
and should not occur again.
Ensure room in which heater is situated
is well ventilated.
Check & ensure there are no
combustible materials within 0.9
meters (3 feet) surrounding the
heater.
Remove any combustible items from the
heater.
Ensure a minimum clearance of
5.5 inches (14 cm) from both
sides and rear of heater to
adjacent walls.
Reposition the heater so there is enough
space around the heater to the adjacent
walls.
PLEASE DO NOT ATTEMPT TO OPEN OR REPAIR THE HEATER YOURSELF.
DOING SO COULD CAUSE DAMAGE OR PERSONAL INJURY.
TROUBLESHOOTING

9
This appliance is covered by a limited manufacturer’s warranty. For one year from the
original date of purchase, the manufacturer will repair or replace any parts of this
appliance that prove to be defective in materials and workmanship, provided the
appliance has been used under normal operating conditions as intended by the
manufacturer.
Warranty Terms:
During the first year, any components of this appliance found to be defective due to
materials or workmanship will be repaired or replaced, at the manufacturer’s
discretion, at no charge to the original purchaser. The purchaser will be responsible
for any removal or transportation costs.
Warranty Exclusions:
The warranty will not apply if damage is caused by any of the following:
•Power failure
•Damage in transit or when moving the appliance
•Improper power supply such as low voltage, defective household wiring or
inadequate fuses
•Accident, alteration, misuse or abuse of the appliance such as using non-
approved accessories, inadequate air circulation in the room or abnormal
operating conditions (extreme temperatures)
•Use in commercial or industrial applications
•Fire, water damage, theft, war, riot, hostility or acts of God such as
hurricanes, floods, etc.
•Use of force or damage caused by external influences
•Partially or completely dismantled appliances
Obtaining Service:
When making a warranty claim, please have the original bill of purchase with purchase
date available. Once confirmed that your appliance is eligible for the warranty service,
all repairs will be performed by a NewAir™ authorized repair facility. The purchaser
will be responsible for any removal or transportation costs. Replacement parts and/or
units will be new, re-manufactured or refurbished and is subject to the manufacturer’s
discretion.
For technical support and warranty service, please call 1-855-9Newair or email
[email protected].
LIMITED MANUFACTURER’S
