Next BRONX C20753 User manual

C20753
C20753-2022-V1.
BRONX BLACK LARGE SIDEBOARD
H72.5 x W150 x D39cm
Actual product size
Assembly instructions
IMPORTANT -
RETAIN FOR FUTURE REFERENCE
Produced in China for Next Retail Ltd.
Need Help ?
With: Assembly instruction
Missing or damaged parts
CALL: 0333 777 8999

C20753-2022-V1.
Two people are required to assemble this item
Time to assemble : 30 min utes
PH2 X2
BRONX BLACK LARGE SIDEBOARD
C20753
1
Produced in China for Next Retail Ltd.
Do's
We suggest you spend a short time reading through this leaflet before you start.
BEFORE YOU START
Don'ts
Do not drag or pull your furniture.
When you are ready to start, make sure that you have the right tools and plenty of space.
Unwrap all packaging materials and place the components on a clean surface to protect it from damage,
We recommend that the packaging is used to protect the surfaces during assembly.
Carefully check that you have all the parts before beginning assembly.
Due to the size of this product we recommend that it is assembled in the room intended for use.
Ensure the product is fully assembled as illustrated and all fixings fully tightened before use.
Wood will mellow and change colour over time, we recommend that ornaments and items placed on the surface are moved
regularly for the first few months to prevent uneven mellowing.
Wipe occasionally with a soft cloth slightly dampened with water. Then buff with a dry clean soft cloth.
Tools required
Do not rub or scrub the surface when cleaning.
Do not use silicone based furniture polish. Silicone in furniture polishes can break down the finish.
Never allow any kind of liquid to remain on your furniture.
Absorption can cause wood to warp or finishes to de-laminate.
Do not place hot items (e.g. hot drinks) directly on to the wood surface. Please make sure you use a placemat or coaster.
Number of people required to assemble
Assembly instructions
not supplied

C20753
BRONX BLACK LARGE SIDEBOARD
C20753-2022-V1.
Assembly instructions
2
GETTING TO KNOW YOUR PRODUCT
Produced in China for Next Retail Ltd.
11
12
13
10
14
16
17
18
15
1
10
1
2
2
3
4
6
57
8
88
9
20
20
21
19

C20753
BRONX BLACK LARGE SIDEBOARD
C20753-2022-V1.
Assembly instructions
3
Components supplied. Please use this guide if you require replacement parts.
Produced in China for Next Retail Ltd.
1
Ref Dimensions Visual Qty Ctn Ref Dimensions Visual Qty Ctn
2
34x43.5m
3
12
2
1
13
1
1
4
5
6
7
39x150cm 1
1
8
1
9
11.5x35cm
1
1
10
11.5x35cm 1
1
19x49.5cm
11 11.5x42.5cm
1
1
1
1
1
29.5x42.5cm
1
12x38cm 2
3x141.5cm
2
1
14
1
15
1
16 1
17
3
1
48.5x57.5cm
18 1
19
1
20 2 1
35x47.5cm
21 1 1
49.5x56cm
1 1
49.5x56cm
1
37x56.5cm
1
37x56.5cm
1
37x56.5cm
1
37x56.5cm
1
29.5x35cm
29.5x35cm
1
37x49.5cm 1
1
1
39x150cm

Connector
Push connector into housing
to join.
Make sure there is no gap
between the panels.

4
C20753-2022-V1.
BRONX BLACKLARGE SIDEBOARD
C20753
Fixtures and fittings supplied ( not to scale)
Ref Dimensions
Visual
Qty
Fixtures and fittings supplied ( not to scale)
Spare Qty
Produced in China for Next Retail Ltd.
Assembly instructions
T38
N/A
12 2
2
N/A
N/A
C12
2
N/A
N/A
C16
T1
2
T39
2
N/A
N/A
N/A
N/A
E39
N/A N/A
4
10 20 30 40 50
60 70 80 90
100
Ref Dimensions Qty
Spare Qty
Fixtures and fittings supplied (actual size)
S41
Ø4 x 16mm
2 1
V35
Ø6 x 12mm
41
V68
Ø6 x 40mm
8 1
U139
Ø4.5 x 15mm
Ø5 x 14.5mm
81
P3
81

5
BRONX BLACK LARGE SIDEBOARD
C20753-2022-V1.
Assembly instructions
1
Produced in China for Next Retail Ltd.
C20753
2
1
1
2
2
V35
Ø6 x 12mm
4
V68
Ø6 x 40mm
8
T1
N/A
2
3

6
BRONX BLACK LARGE SIDEBOARD
C20753-2022-V1.
Assembly instructions
3
Produced in China for Next Retail Ltd.
C20753
4
4
6
5
7
888

7
BRONX BLACK LARGE SIDEBOARD
C20753-2022-V1.
Assembly instructions
5
Produced in China for Next Retail Ltd.
C20753
6
9
B
A
A=B

8
BRONX BLACK LARGE SIDEBOARD
C20753-2022-V1.
Assembly instructions
7
Produced in China for Next Retail Ltd.
C20753
not supplied
PH2
T38
N/A
12

9
BRONX BLACK LARGE SIDEBOARD
C20753-2022-V1.
Assembly instructions
8
Produced in China for Next Retail Ltd.
C20753
WALL
We recommend the use of the wall attachment bracket/strap provided for safety reasons.
Secure the strap to the wall with an appropriate screw and wall plug for your wall type (not provided).
To hide the strap behind the unit ,drill the hole lower than the top of unit.
Attach the other end of the strap to the underside of the top panel with screw.
Warning: Always ensure intended wall area to be drilled is free from hidden electrical wires,water and gas pipes.
NB:Wall fixings are not included-Please source suitable fixing for your wall type.
If in doubt please consult a qualified trades person.
Please ensure you secure your product to the wall for your and your family's safety before you use it.
WALL
SCREW
STRAP
TOP
STRAP
SCREW
2not supplied
PH2
S41 Ø4 x 16mm
T39 N/A 2

10
BRONX BLACK LARGE SIDEBOARD
C20753-2022-V1.
Assembly instructions
9
Produced in China for Next Retail Ltd.
C20753
10
SLOTS ALIGNED
11
12
13
10

11
BRONX BLACK LARGE SIDEBOARD
C20753-2022-V1.
Assembly instructions
11
Produced in China for Next Retail Ltd.
C20753
12
14
E39
N/A
1
not supplied
PH2
Note: Drawer will be permanently
assembled once panel 14 is fitted.

12
BRONX BLACK LARGE SIDEBOARD
C20753-2022-V1.
Assembly instructions
13
Produced in China for Next Retail Ltd.
C20753
14
SLOTS ALIGNED
16
17
18
10

13
BRONX BLACK LARGE SIDEBOARD
C20753-2022-V1.
Assembly instructions
15
C20753
16
15
E39
N/A
1
not supplied
PH2
Produced in China for Next Retail Ltd.
Note: Drawer will be permanently
assembled once panel 15 is fitted.

14
BRONX BLACK LARGE SIDEBOARD
C20753-2022-V1.
Assembly instructions
17
Produced in China for Next Retail Ltd.
C20753
Left side
Right side
14
15
18
19
21
E39
N/A
2
not supplied
PH2

15
BRONX BLACK LARGE SIDEBOARD
C20753-2022-V1.
Assembly instructions
19
Produced in China for Next Retail Ltd.
C20753
20
20
20
8
P3
Ø5 x 14.5mm
C12 N/A
N/A
C16
U139 4.5 x 15mm not supplied
PH2
19
21
2
2
8
C16
C12

16
BRONX BLACK LARGE SIDEBOARD
C20753-2022-V1.
Assembly instructions
21
Produced in China for Next Retail Ltd.
C20753
Adjust Hinge Position
19
21

17
BRONX BLACK LARGE SIDEBOARD
C20753-2022-V1.
22
Produced in China for Next Retail Ltd.
C20753
23
To disassemble:
Press down all the back panels so
they are clear of the top panel slot;
Step1: Remove the plastic wedges (T38)
from the back panels and screws
from the rear of the base panel (3);
Step2:
Slide the top panel front to unlock, then lift off.Follow the same
sequence to remove the other panels;

C20753-2022-V1.
H 72.5 xW150xD39 cm
Produced in China for Next Retail Ltd.
Actual product size
C20753
BRONX BLACK LARGE SIDEBOARD
1500mm
390mm
726mm
560mm
497mm
275mm
275mm
427mm
332mm
276mm
368mm
497mm
497mm
188mm
427mm 96mm
332mm
