ASSEMBLY INSTRUCTIONS.
IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Helpline
If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: [phone]
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found
to be faulty. Should you need to return the unassembled product, please repack in the original packaging.
428418 MOLLY MIDI BED
M5 M4
810088 WHITE MIDI BED
High beds and the upper bed of bunk beds are not suitable
for children under six years due to the risk of injury from falls.
: 2007

Step 3
Step 2
Step 1
2 of 17
19A11
B
BC
D
19A24
06G03
A1
A1
A1
INCORRECT
CORRECT
D
D
Push pole B into leg A1.
Place part C as shown. Attach to leg A1
using two screws (19A11) with the Allen key provided.
Attach bar D to leg A1 using
screw (19A24) and washer (06G03)
with the Allen key provided.
CORRECT
INCORRECT
C
C

Step 6
Step 5
Step 4
3 of 17
INCORRECT
CORRECT
19B07
E
06G01
A1
Attach bar E to leg A1 using
screw (19B07) and washer (06G01)
with the Allen key provided.
INCORRECT
CORRECT
19A11
19B07
E
CD
B
19A24
06G01
06G03
F2
Push pole B into leg F2.
Attach part C, bars D and E to leg F2
using four screws (19A24, 19B07,
19A11) and washer (06G03, 06G01)
with the Allen key provided.
21H01
E
Insert parts (21H01) to each end of bar E.

4 of 17
Step 8
Step 7
21H01
19A23
D
G
H
A1
F2
CORRECT
INCORRECT
D
D
G
G
Attach bar G using three of screw (19A23)
with the Allen key provided.
Insert parts (21H01) to each end of bar H.

Step 10
Step 9
5 of 17
INCORRECT
CORRECT
19B07
19A24
H
B
I
D
B
06G03
F2
A1
A2
06G01
Attach bars I and H to the
assembly from step 7
using three of screw
(19A24, 19B07) and
washer (06G03, 06G01)
with the Allen key provided.
Push pole B into leg A2.
I
I

Step 13
Step 12
Step 11
6 of 17
21H01
19A11
C
E
D
19A24
06G03
A2
A2
INCORRECT
CORRECT
Place part C as shown. Attach to leg A2
using two screws (19A11) with the Allen key provided.
Attach bar D to leg A2 using
screw (19A24) and washer (06G03)
with the Allen key provided.
Insert parts (21H01) to each end of bar E.
CORRECT
INCORRECT
C
C

Step 16
Step 15
Step 14
7 of 17
INCORRECT
CORRECT
INCORRECT
CORRECT
19B07
19A23
E
G
D
06G01
19A11
19B07
E
CD
B
19A24
06G01
06G03
A2
F1
CORRECT
INCORRECT
D
D
G
G
Attach bar E to leg A2 using
screw (19B07) and washer (06G01)
with the Allen key provided.
Push pole B into leg F2.
Attach part C, bars D and E to leg F1
using four screws (19A24, 19B07,
19A11) and washer (06G03, 06G01)
with the Allen key provided.
Attach bar G using three
of screw (19A23)
with the Allen key provided.

Step 17
8 of 17
19A24
INCORRECT
CORRECT
19B07
H
I
06G01
06G03
F1
A2
Join the assembly from step 10 and step 16
using three of screw (19A24, 19B07) and
washer (06G03, 06G01) with the Allen key provided.
I
I
F1
F1

9 of 17
Step 19
Step 18
19A24
06G03
CORRECT
INCORRECT
CORRECT
INCORRECT
Attach bar J to the assembly from step 17 using
four of screw (19A24) and washer (06G03)
with the Allen key provided.
Place the slats with the hooks
facing downward.
Start from one end inserting
the hooks into the holes on
each rail and pushing into place.
JJ
J
J
K

10 of 17
Step 21
Step 20
I
L
06G01
19B09
19A11
L
INCORRECT
CORRECT
Attach barrier L.
Fix barrier L using six of
screw (19A11, 19B09)
and washer (06G01)
with the Allen key provided.
I

11 of 17
Step 23
Step 22
OPTION 2(Step 30~35) OPTION 1(Step 24~29)
Fix barrier L using two screws (19A23) and
washer (06F06) with the Allen key provided.
06F06
19A23
L

12 of 17
Step 25
Step 24
19A11
INCORRECT
CORRECT
OPTION 1
(For Right Side)
Attach front barrier N to the end using
screws (19B09, 19A11) and washer (06G01)
with the Allen key provided.
Fix barrier N through the side rail J using
screws (19A23, 19B09) and washer (06F06)
with the Allen key provided.
19B09
06G01
N
F2
N
J
06F06
19A23 19B09

13 of 17
Step 27
Step 26
Fix ladder P in place using
two of screws (19A18) and
washer (06F06) with the Allen
key provided.
J
P
19A18
06F06
A2
Use two of screw (19A11) to fill unused holes on
poles A2 with the Allen key provided as shown.
Use plastic cap (02R03) to fill all unused holes.
02R03
19A11

14 of 17
Step 29
Step 28
Warning label:
Maximum of the mattress
must not come above this level
t
M
.
i
g
x
h
a
h
e
o
s
m
s
f
t
t
r
a
e
INCORRECT
CORRECT
OPTION 2
(For Left Side)
Attach front barrier N to the end using
screws (19B09, 19A11) and washer (06G01)
with the Allen key provided.
19A11
06G01
19B09
N

15 of 17
Step 31
Step 30
Fix barrier N through the side rail J using
screws (19A23, 19B09) and washer (06F06)
with Allen key provided.
J
N
06F06
19B09 19A23
J
P
06F06
19A18
Fix ladder P in place using
two of screws (19A18) and
washer (06F06) with the Allen
key provided.

16 of 17
Step 33
Step 32
J
Warning label:
Maximum of the mattress
must not come above this level
F2
t
M
.
i
g
x
h
a
h
e
f
o
a
e
s
m
s
t
t
r
Use two of screw (19A11) to fill unused holes on
poles F2 with the Allen key provided as shown.
Use plastic cap (02R03) to fill all unused holes.
19A11 02R03

17 of 17
