Next CLARO CONSOLE 2 224833 User manual

CLARO CONSOLE 2
224833
Assembly instructions
Actual product size:
H75 x W110 x D35cm
Need Help?
With: Assembly instructions
Missing or damaged parts
CALL: 0333 777 8999
IMPORTANT ─ RETAIN FOR FUTURE REFERENCE
Produced in China for Next Retail Ltd.
673886-2021-V1 2

We suggest you retain these instructions for future reference
Keep fittings out of children’s reach and keep children well
away from construction area
This product should only be used on firm level ground
Avoid exposing the furniture to excessive heat or direct sunlight
as this can cause deterioration of the UV bosses glue. Unwrap
all packaging materials and place the components ontop of the
carton box or on a clean floor to protect it from damage.
Do’s
We suggest you spend a short time reading
through this leaflet before you start
Glass can scratch in normal use there fore protect surfaces
from scratches and marks by using mats and coasters.
When you are ready to start, make sure that you have the right
tools and plenty of space
We recommend that the packaging is used to protect the
surfaces during assembly
Carefully check that you have all the parts before beginning
assembly
Ensure the product is fully assembled as illustrated and all
fixings fully tightened before use. Check fixings regularly to
ensure they remain tight
Please take care when handling or moving the furniture as
careless handling may cause damage or injury
It is recommended that before moving heavy objects to a new
location they are completely dis-assembled to avoid personal
injury or damage to the furniture. Please be careful to retain all
fittings when doing this.
Always wipe dry after cleaning
To clean your item, please use a soft cloth slightly dampened
with water and wipe clean. Then buff with a dry clean cloth.
Don’ts
Do not stand or sit down on your table
Do not use the glass as a chopping surface. Do not strike the
glass with hard or pointed items
If the glass is chipped or broken stop using the product and
consult the manufacturer or supplier.
Numberof people required to assemble
Two people are required to assemble this item.
Time to assemble
Missing parts
If you are missing any fixtures and fittings for your product
please contact our customer service team on 0333 777
8999 and they will be happy to arrange for a replacement
to be sent to you free of charge.
Home service technicians
If you have a fault with your product please contact our
customer service team on 0333 777 8999. If you have had
the product for 28 days or less you may be offered a
replacement, refund or for a fully trained home service
technician to visit your home to assess the fault and repair
the product where possible. If you have had the product for
more than 28 days we will send an independent home
service technician to review and repair the product where
possible and recommend further action.
You can write to us at
Home Customer Services
Next Retail Ltd,
Desford Road,
Leicester,
LE19 4AT
To view our full furniture range pleasevisit
www.next.co.uk
CLARO CONSOLE 2
224833
Assembly instructions
BEFORE YOU START
Produced in China for Next Retail Ltd.
673886-2021-V13
30 mins
Tools required

Ref Dimensions Visual Qty Ctn
1110 x 35 x 2cm 11
2
73 x 35 x 6cm
73 x 35 x 6cm 1 1
3 1 1
CLARO CONSOLE 2
224833
Assembly instructions
GETTING TO KNOW YOUR PRODUCT
Produced in China for Next Retail Ltd.
673886-2021-V14
1
2
3

Fixtures and fittings supplied (not to scale)
Ref Dimensions QtyVisual
5mm 1
72x25x14mm 2
C
D
CLARO CONSOLE 2
224833
Assembly instructions
Produced in China for Next Retail Ltd.
673886-2021-V15
Fixtures and fittings
supplied (actual size)
Ref Dimensions Qty *Extra
AM6 x 10mm 2 1
BM8 X 20mm 8 1
mm 10 20 30 40 50 60 70 80 90 100

Produced in China for Next Retail Ltd.
B x 8
M8 x 20mm
1
Fit the wall bracket (D) to the leg (2) and
leg
(3) using bolts (A) and allen key (C).
1
2
3
CLARO CONSOLE 2
224833
Assembly instructions
673886-2021-V1
6
A x 2
2
C
A
M6 x 10mm
D
Locate the leg (2) and leg(3) using the
bolts (B) and the allen key (C) as shown.
C
B
2
D x 2
3

CLARO CONSOLE 2
224833
Assembly instructions
Produced in China for Next Retail Ltd.
673886-2021-V1
7
3
4
D x 2
Move the console into its loca�on of
intended use next to a wall. The wall
bracket (D) may also require some
adjustment to fit correctly depending on
any obstruc�ons behind the console such
as skir�ng boards, picture rails etc.
With a pencil accurately mark the posi�on
of the screw holes onto the wall. Now
carefully move the shelf unit away from
the wall to create space for drilling.
D
If table is not level, adjust it with
the adjustable feet.

Loosen the allen bolt (A) and remove the
wall bracket (D) from the leg (2) and leg (3)
with the allen key (C)
CLARO CONSOLE 2
224833
Assembly instructions
Produced in China for Next Retail Ltd.
673886-2021-V18
Ax 2
5
6
2
D x 2
Before drilling, ensure the size of hole will be correct to fit the
rawl plug (Not included).
Warning: Ensure the area to be drilled is free from hidden
electrical wires, water and gas pipes. (Not included)
Wall
Floor
Wall
Floor
C
A
D
M6 X 10MM
3

CLARO CONSOLE 2
224833
Assembly instructions
Produced in China for Next Retail Ltd.
673886-2021-V19
7
8
Secure the wall brackets (D) to the wall
using the washers (not included) and
screws (not included). Tighten with the
screwdriver.
D x 2
D
2
CA
D
Locate the console aligned with the wall
bracket (D) as shown below and tighten
with an allen bolt (A) and the allen key (C)
Ax 2
M6 x 10mm
Dx 2

CLARO CONSOLE 2
224833
Assembly instructions
Produced in China for Next Retail Ltd.
673886-2021-V110
1We recommend the use of the wall bracket provided for safety reasons. Wall fixings
are not included please source suitable fixings for your wall type. If in doubt, please
consult a qualified tradesperson.
WARNING: Always ensure the wall to be drilled is free from hidden electrical wires,
water and gas pipes.
