Next ISABELLA 324212 User manual

Assembly instructions
Need Help?
With: Assembly instructions
Missing or damaged parts
CALL:0333 777 8999
Produced in China for Next Retail Ltd
IMPORTANT - KEEP FOR FUTURE REFERENCE.
MBD 8840
ISABELLA BED
Actual product size
SMALL DOUBLE:H1350 x W2010 x D1283 mm
DOUBLE: H1350 x W2010 x D1433 mm
KING: H1350 x W2110 x D1583 mm
324212/616031

511731
511731
Warnings
Don'ts
BEFORE YOU START
If you are missing any fixtures and fittings for your product
please contact our customer service team on 0333 777 8999
and they will be happy to arrange for a replacement to be sent
to you free of charge.
Home service technicians
If you have a fault with your product please contact our
customer service team on 0333 777 8999. If you have had the
product for 28 days or less you may be offered a replacement,
refund or for a fully trained home service technician to visit your
home to assess the fault and repair the product where possible.
If you have had the product for more than 28 days we will send
an independent home service technician to review and repair
the product where possible and recommend further action.
You can write to us at
Next Retail Ltd,
Desford Road,
Leicester,
LE19 4AT,
To view our full furniture range please visit www.next.co.uk
Home Customer Services
1
Number of
p
e
op
le re
qu
ired to assemble
Missing parts
Produced in China for Next Retail Ltd
30 minutes
MBD8840
We suggest you retain these instructions for future reference.
Keep fittings out of children's reach and keep children well away
from construction area.
Please do not jump or stand on your bed.
Avoid exposing the furniture to excessive heat or direct
sunlight as this can cause cracking of the wood and deterioration
Please periodically check all fittings and re-tighten as necessary.
This product should only be used on firm, level ground.
of the colour.
Keep away from strong heat source.
Do not use this item if components are missing or broken.
Do not drag your assembled bed. Always lift the bed and check
that the centre support rail is securely fixed in place.
Apply adhesive substrates of example, sticky tape to the product.
Do not use silicone based furniture polish. Silicone in furniture
polishes can break down the lacquer finish.
Do's
before you start.
When you are ready to start, make sure that you have the right
tools, plenty of space.
Unwrap all packaging materials and place the components
on a clean surface to protect them from damage. We recommend
that the packaging is used to protect the surface during assembly.
We suggest you spend a short time reading through this leaflet
Carefully check that you have all the parts before beginning
assembly.
Ensure the product is fully assembled as illustrated and all
fixings are fully tightened before use.
Check fixings regulaly to ensure they remain tight.
Always ensure that protectors are used on the legs according to
your flooring type.
When adjusting the support legs ensure that the foot is set 10mm
from the floor surface without the mattress in place. When in use
the legs will create the required support.
To clean your item, please use a soft cloth slightly dampened
with water and wipe clean. Then buff with a dry clean cloth.
ISABELLA BED
324212/616031
Assembly instructions

Visual
Assembly instructions
2
1
2
3
4
5
1
1
2
2
1
Components supplied - Use this guide if you require a replacement part.
（3）
（4）
（4）
（3）
（1）
（5）
（6）
（6）
（7）
（7）
（2）
Produced in China for Next Retail Ltd
MBD 8840
1350*1283*38
1350*1433*38
1350*1583*38
1927*110*45
2027*110*45
1855**50*25
1855**50*25
1216*50*25
1366*50*25
1516*50*25
Ref Dimensions Qty Visual
6
7
2
2
220*25*25
605*62*9*15 pcs
680*62*9*15 pcs
755*62*9*15 pcs
Ref Dimensions Qty
ISABELLA BED
1020*1283*38
1020*1433*38
1020*1583*38
324212/616031

Assembly instructions
3
10 20 30 40 50 60 70 80 90 100 110
mm
R e f
A
B
C
D
E
F
G
H
I
Dim e nsio ns
M 6 x 2 0 m m
M 8 x 4 0 m m
4 m m
5 m m
Ø
Ø
6 x 2 5 mm
62mm
S p a re
1
1
1
1
1
1
Q ty
1 4
1
1 4
8
6
3
1
2
2
Produced in China for Next Retail Ltd
MBD 88 4 0
6*18
6*18
Ø
8*22
ISABELLA BED
324212/616031

Assembly instructions
1
2
4
Produced in China for Next Retail Ltd
MBD 8840
（1）
（2）
（3）
（3）
（4）
（3）（4）
（3）
A x 4 B x 1
m6x20mm 4mm C x 4 Ø6*18
1D
C
C
A
A
B
B
B x 1
A x 8
D x 8
C x 8
4mm
M6x20mm
Ø
Ø6*18
6*18
ISABELLA BED
324212/616031

Assembly instructions
5
3
Produced in China for Next Retail Ltd
MBD 8840
I
I
G
H
x 2 G x 1
m8x40mm 5mm H x 2 Ø8*22
（4）
（5）
（4）
（5）
（6）
（6）
A x 2 B x 1
m6x20mm 4mm C x 2 Ø6*18
1
4
C
A
B
Firmly tighten each of the bolts.
ISABELLA BED
（
324212/616031

E
F
E x 66x25mm
Assembly instructions
6
5
Produced in China for Next Retail Ltd
MBD 8840
（7）
（7）
（7）
（7）
ISABELLA BED
324212/616031

Assembly instructions
Produced in China for Next Retail Ltd
MBD 88 4 0
ISABELLA BED
1283MM
1433MM
1583MM
1350MM
1020MM
2010MM
2110MM
250MM
Actual product size
SMALL DOUBLE:H1350 x W2010 x D1283 mm
DOUBLE: H1350 x W2010 x D1433 mm
KING: H1350 x W2110 x D1583 mm
Inner size
SMALL DOUBLE:L1920 x D1220 mm
DOUBLE: L1920 x D1370 mm
KING: L2020 x D1520 mm
324212/616031
