Next 885655 User manual

H101.5 x W34.5 X D32cm
Actual product size
IMPORTANT - RETAIN FOR FUTURE REFERENCE
MODULAR UNIT
885655
Assembly instructions
Produced in China for Next Retail Ltd
Need Help?
With: Assembly instructions
Missing or damaged parts
CALL: 0333 777 8999
885655 - 2014 - V2

Produced in China for Next Retail Ltd 1
BEFORE YOU START
Keep fittings out of children’s reach and keep children
well away from construction area.
Please periodically check all fittings and re-tighten as
necessary.
Avoid exposing the furniture to excessive heat or direct
sunlight as this can cause cracking of the wood and
deterioration of the colour.
Warnings
Important: Retain these instructions for future reference.
Unwrap all packaging materials and place the components on
top of the carton box or on a clean floor to prevent it from
scratching.
This product should only be used on firm, level ground.
Do’s
We suggest you spend a short time reading through this
leaflet before you start.
When you are ready to start, make sure that you have the
right tools, plenty of space and a clean, dry area for assembly.
Check the pack and make sure you have all the parts listed.
During assembly children should be kept away from the
product due to possible risk of injury.
Tools not included.
Due to the size of this product we recommend that it is
assembled in the room intended for use.
Ensure that this product is fully assembled as illustrated
before use.
Don’ts
Do not use power tools to construct this product.
Do not tighten screws until fully assembled.
Do not overtighten screws or bolts.
Do not use this product if parts are missing, damaged or worn.
Never use scourers, abrasives or chemical cleaners.
Number of people required to assemble
One people is required to assemble this product.
Time to assemble
Tools required
Missing parts
If you are missing any fixtures and fittings for your product
please contact our customer service team on 0333 777 8999
and they will be happy to arrange for a replacement to be sent
to you free of charge.
Home service technicians
If you have a fault with your product please contact our
customer service team on 0333 777 8999. If you have had the
product for 28 days or less you may be offered a replacement,
refund or for a fully trained home service technician to visit your
home to assess the fault and repair the product where possible.
If you have had the product for more than 28 days we will send
an independant home service technician to review and repair
the product where possible and recommend further action.
You can write to us at
Home Customer Services
Next Retail Ltd,
Desford Road,
Leicester,
LE19 4AT
To view our full furniture range please visit www.next.co.uk
1 hour
not supplied not supplied not supplied
PH2 7mm
To clean your item, wipe with soft cloth slightly dampened
with water. Then buff with a dry clean cloth.
Routinely check that the fittings are secure and tighten any
fittings using the appropriate tools.
If any parts are missing please contact Next to obtain
replacements. Under no circumstances should missing
parts or hardware be substituted unless obtained from Next.
Do not drag or pull your furniture.
Do not use silicone based furniture polish. Silicone in
furniture polishes can break down the lacquer finish.
MODULAR UNIT
885655
Assembly instructions
885655 - 2014 - V2

GETTING TO KNOW YOUR PRODUCT
Produced in China for Next Retail Ltd 2
1
2R
2L
5
3
4
4
6
5
MODULAR UNIT
885655
Assembly instructions
885655 - 2014 - V2

Components supplied-Use this guide if you require a replacement part.
Ref Dimensions Visual Qty
1
Ctn
34.5 x 32cm 1 1
Produced in China for Next Retail Ltd 3
Ref Dimensions Visual Qty
4
Ctn
32 x 31.3cm 2 1
2L 100.2 x 32cm 1 1
2R 100.2 x 32cm 1 1
332 x 32cm 1 1
533.3 x 33.7cm 2 1
633.3 x 33.7cm 1 1
MODULAR UNIT
885655
Assembly instructions
885655 - 2014 - V2

Produced in China for Next Retail Ltd 4
Fixtures and fittings
supplied (actual size)
6 x 35mm 16
A
Ref QtyDimensions
3 x 12mm 25
C
15 x 9.5mm 16
B
1 20 30 40
10
mm 20 30 40 50 60 70 80 90 100 110 120 130
12 x 1mm 2
E
4 x 19mm 1
F
15 x 40mm 2
D
Fixtures and fittings supplied (not to scale)
Ref Dimensions Visual Qty
G25 x 225mm 1
MODULAR UNIT
885655
Assembly instructions
885655 - 2014 - V2

Produced in China for Next Retail Ltd 5
1
22
Align with long point of cross
Pillar head needs to be in centre
WHEN FITTING CAMS
ENSURE STARTING POSITION CORRECT
BEFORE YOU INSERT CONNECTING CAM-PILLAR
TURN CLOCKWISE UNTIL SECURE
CORRECT WRONG
CAM-PILLAR
Tighten until shoulder is flush
with panel. Do not overtighten
or undertighten (see example below)
Shoulder
Panel Panel
6 x 35mm
A x 12
15 x 9.5mm
B x 6
MODULAR UNIT
885655
Assembly instructions
885655 - 2014 - V2

3
2
Produced in China for Next Retail Ltd 6
4
15 x 9.5mm
B x 6
6 x 35mm
A x 4
MODULAR UNIT
885655
Assembly instructions
885655 - 2014 - V2

5
2
Produced in China for Next Retail Ltd 7
6
15 x 9.5mm
B x 4
3 x 12mm
C x 21
MODULAR UNIT
885655
Assembly instructions
885655 - 2014 - V2

7
Produced in China for Next Retail Ltd 8
We recommend the use of the wall strap provided for safety reasons. Wall fixings are not
included please source suitable fixings for your wall type. If in doubt, please consult a
qualified trades person. WARNING: Always ensure the wall to be drilled is free from hidden
electrical wires, water and gas pipes.
12 x 1mm
E x 2
4 x 19mm
F x 1
25 x 225mm
G x 1
MODULAR UNIT
885655
Assembly instructions
885655 - 2014 - V2
G
G

Produced in China for Next Retail Ltd 9
8
3 x 12mm
C x 4
40 x 15 x 1.5mm
D x 2
MODULAR UNIT
885655
Assembly instructions
885655 - 2014 - V2

Produced in China for Next Retail Ltd 10
885655 - 2014 - V2
Actual product size
MODULAR UNIT
885655
H101.5 x W34.5 X D32cm
320 mm
320 mm
320 mm
313 mm
320 mm
