Next ISABELLA 972213 User manual

ISABELLA LARGE DOUBLE ROBE
Assembly instructions
Actual product size
H204.1 x W141 x D60.9cm
IMPORTANT - RETAIN FOR FUTURE REFERENCE
Produced in Poland for Next Retail Ltd.
972213-2014-V01
972213
Need Help?
With: Assembly instructions
Missing or damaged parts
CALL: 0333 777 8999

BEFORE YOU START
1
Produced in Poland for Next Retail Ltd.
Assembly instructions
Warnings
We suggest you retain these instructions for future reference.
Keep fittings out of children’s reach and keep children well
away from the construction area.
This product should only be used on firm, level ground.
Please periodically check all fittings and re-tighten as
necessary.
Please do not sit or stand on your furniture.
Avoid exposing the furniture to excessive heat or direct
sunlight as this can cause deterioration of the colour.
Number of people required to assemble
Two persons are required to assemble this item.
Time to assemble
3 hours
Tools required
not supplied not supplied
Do’s
We suggest you spend a short time reading through this leaflet
before you start.
When you are ready to start, make sure that you have the
right tools and plenty of space.
Unwrap all packaging materials and place the components
on a clean surface to protect them from damage.
We recommend that the packaging is used to protect the
surfaces during assembly.
Carefully check that you have all the parts before beginning
assembly.
Due to the size of the product we recommend that it is
assembled in the room intended for use.
Ensure the product is fully assembled as illustrated and all
fixings are fully tightened before use.
Wipe occasionally with a soft cloth slightly dampened with
water. Then buff with a dry clean soft cloth.
Wood will mellow and change colour over time, we recommend
that ornaments and items placed on the surface are moved
regularly for the first few months to prevent uneven mellowing.
Don’ts
Do not drag or pull your furniture.
Do not use silicone based furniture polish. Silicone in furniture
polishes can break down the finish.
Never allow any kind of liquid to remain on your furniture.
Absorption can cause wood to warp or finishes to de-laminate.
Do not place hot items (e.g. hot drinks) directly on to the wood
surface. Please make sure you use a placement or coaster.
Missing parts
Home service technicians
You can write to us at
If you are missing any fixtures and fittings for your product
please contact our customer service team on 0333 777 8999
and they will be happy to arrange for a replacement to be sent
to you free of charge.
If you have a fault with your product please contact our
customer service team on 0333 777 8999. If you have had the
product for 28 days or less you may be offered a replacement,
refund or for a fully trained home service technician to visit your
home to assess the fault and repair the product where possible.
If you have had the product for more than 28 days we will send
an independant home service technician to review and repair
the product where possible and recommend further action.
Home Customer Services
Next Retail Ltd,
Desford Road,
Leicester,
LE19 4AT
To View our full furniture range please visit www.next.co.uk
Product supplied with wall fixing straps.
not supplied
ISABELLA LARGE DOUBLE ROBE
972213
972213-2014-V01

GETTING TO KNOW YOUR PRODUCT
2
Produced in Poland for Next Retail Ltd.
Assembly instructions
Ref Demensions Visual Qty
Components supplied. Please use this guide if you require replacement parts.
1174.6 x 52.2cm
Ctn
1 2
Ref Demensions Visual Qty Ctn
9 1 1135.6 x 57.3cm
ISABELLA LARGE DOUBLE ROBE
14
14
2
9
1
12
10
11
4
4
4
4
4
4
3
3
7
13
6
5
8
2174.6 x 52.2cm 1 2
3174.6 x 5.9cm 2 3
45.6 x 4.4cm 6 1
5127 x 9.6cm 1 3
6127 x 46.2cm 1 3
7174.6 x 5.9cm 1 2
844.8 x 9cm 1 3
10 1 3175.5 x 127.8cm
11 1 1141 x 60.9cm
12 1 1126.2 x 3cm
13 1 162 x 3cm
14 2 3170.8 x 59.9cm
972213
972213-2014-V01

3
Fixtures and fittings
supplied (actual Size)
Ref Demensions Qty
Produced in Poland for Next Retail Ltd.
Assembly instructions
mm 10 20 30 40 50 60 70 80 90 100 110 120 130
B 10 x 42mm 26
F 10.5 x 15mm 16
EA 4 x 12mm 4
HR 40 x 18mm 4
H1 2
Fixtures and fittings supplied (not to scale)
Ref Demensions QtyVisual
QA N/A 2
N/A
T N/A 2
LA 3 x 13mm 8
MA 3 x 13mm 8
QB 0.8 x 15mm 4
QC 4 x 14mm 2
RB 4 x 16mm 6
UA 43 x 17mm 4
UB 43 x 11mm 4
CB 15 x 11.5mm 26
EB 4 x 16mm 12
GD 9.5 x 22mm 2
HB 6N/A
HG 6N/A
JE 6,3 x 24mm 6
RD 4 x 27mm 6
ISABELLA LARGE DOUBLE ROBE
AA 73 x 27mm 1
DA 5.8 x 36mm 4
L23 x 22mm 4
WA 7 x 50mm 2
972213
972213-2014-V01

WHEN FITTING CAMS
ENSURE STARTING POSITION IS CORREC T
BEFORE YOU INSERT CONNECTING CAM-PILLA R
TURN CLOCKWISE UNTIL SECURE
CORRECT WRONG
Shoulder
NO GAP
l
enaPlenaP
Tighten until shoulder is flush
with panel. Do not overtighten
or undertighten (see example below)
CAM-LOCK
4
1
2
Produced in Poland for Next Retail Ltd.
Assembly instructions
ISABELLA LARGE DOUBLE ROBE
3
10 x 42mm
B x 8
B
B
B
B
B
B
B
B
3
10 x 42mm
B x 2 15 x 11.5mm
CB x 10
1
CB
CB
CB
CB
CB
CB
CB
CB
CB
CB
B
B
972213
972213-2014-V01

5
3
4
Produced in Poland for Next Retail Ltd.
Assembly instructions
ISABELLA LARGE DOUBLE ROBE
CB
1
3
JE x 3
PH2
6,3 x 24mm
4
3
1
1
3
4
4
4
JE
JE
JE
972213
972213-2014-V01

6
5
6
Produced in Poland for Next Retail Ltd.
Assembly instructions
ISABELLA LARGE DOUBLE ROBE
HG EA
HR
4
HG x 3
PH2
53 x 36mm
HR x 1
40 x 18mm
EA x 1
4 x 12mm
4
4
4
HG
HG
HG
HR
EA
L x 2 23 x 22mm
L
L
L
1
10 x 42mm
B x 2 15 x 11.5mm
CB x 10
2
CB
CB
CB
CB
CB
CB
CB
CB
CB
CB
B
B
972213
972213-2014-V01

7
7
Produced in Poland for Next Retail Ltd.
Assembly instructions
8
ISABELLA LARGE DOUBLE ROBE
CB
2
3
JE x 3
PH2
6,3 x 24mm
2
2
3
4
4
JE
JE
JE
4
3
4
972213
972213-2014-V01

8
Produced in Poland for Next Retail Ltd.
Assembly instructions
9
10
ISABELLA LARGE DOUBLE ROBE
HG EA
HR
4
HG x 3
PH2
53 x 36mm
HR x 2
40 x 18mm
EA x 2
4 x 12mm
4
4
4
HG
HG
HG
L x 2 23 x 22mm
L
2
L
HR
EA
HR
EA
3
L
9
10 x 42mm
B x 6
B
B
B
B
B
B
15 x 11.5mm
CB x 4
CB
CB CB
CB
5
5
972213
972213-2014-V01

9
Produced in Poland for Next Retail Ltd.
Assembly instructions
12
11
ISABELLA LARGE DOUBLE ROBE
1
9
CB
1
5
9
CB
972213
972213-2014-V01

10
Produced in Poland for Next Retail Ltd.
Assembly instructions
14
13
ISABELLA LARGE DOUBLE ROBE
CB
2
9
5
2
9
5
CB
972213
972213-2014-V01

Produced in Poland for Next Retail Ltd.
Assembly instructions
11
16
15
ISABELLA LARGE DOUBLE ROBE
10
9
2
10 x 42mm
B x 6
B
B
B
B
B
B
11
972213
972213-2014-V01

Produced in Poland for Next Retail Ltd.
Assembly instructions
12
18
17
ISABELLA LARGE DOUBLE ROBE
11
CB
CB
6
6
10 x 42mm
B x 1
B
5
972213
972213-2014-V01

Produced in Poland for Next Retail Ltd.
Assembly instructions
19
13
ISABELLA LARGE DOUBLE ROBE
20
8
7
5.8 x 36mm
DA x 4
10 x 42mm
B x 1
15 x 11.5mm
CB x 2
CB
CB
B
DA
DA
DA
DA
8
CB
DA
DA
8
7
CB
8
7
5
5
972213
972213-2014-V01

Produced in Poland for Next Retail Ltd.
Assembly instructions
21
14
ISABELLA LARGE DOUBLE ROBE
22
AA x 1 73 x 27mm WA x 2 7 x 50mm
AA
WA
WA
7
10.5 x 15mm
F x 16
RB x 6 4 x 16mm
RD x 6 4 x 27mm
a)
b)
c)
F
F
F
RB
RB
RB
RB
F
RD
RD
RD
RD
11
10
5
6
RB
RB
RD
RD
F
FFF
F
F
F
F
F
F
F
FFFF
972213
972213-2014-V01

12
Produced in Poland for Next Retail Ltd.
Assembly instructions
23
15
ISABELLA LARGE DOUBLE ROBE
3 x 13mm
MA x 8
43 x 17mm
UA x 4
UA
UA
UA
UA
7
13
HR x 1
40 x 18mm
EA x 1
4 x 12mm
HR
HR
EA
MA
UA
UA
MA
MA
MA
7
HR
972213
972213-2014-V01

Produced in Poland for Next Retail Ltd.
Assembly instructions
24
16
ISABELLA LARGE DOUBLE ROBE
14
86 x 52mm
HB x 6 EB x 12
4 x 16mm
HB
EB
EB
HB
EB
EB
HB
EB
EB
UB
43 x 11mm
UB x 4 LA x 8 3 x 13mm
LA
LA
UB
UB
x2
972213
972213-2014-V01

Produced in Poland for Next Retail Ltd.
Assembly instructions
17
25
14
14
a
b
c
a
b
c
HG
HB
ISABELLA LARGE DOUBLE ROBE
972213
972213-2014-V01

T x 2 N/A
Produced in Poland for Next Retail Ltd.
Assembly instructions
T
T
x2
QA
QB
QB
QC
QA
QB
QB
QC
13 x 152mm
QA x 2
0.8 x 15mm
QB x 4
4 x 12mm
QC x 2
9.5 x 22mm
H1 x 2 N/A GD x 2
T
T
18
26
H1
GD
ISABELLA LARGE DOUBLE ROBE
972213
972213-2014-V01

Produced in Poland for Next Retail Ltd.
ISABELLA LARGE DOUBLE ROBE
Actual product size
