Next IVA BARSTOOL 120490 User manual

IVA BARSTOOL
120490 / 372329 / 392760 / 455221 / 735223 / 946725
Assembly instructions
Actual product size:
H90 x W45 x D48cm
Need Help?
With: Assembly instructions
Missing or damaged parts
CALL: 0333 777 8999
IMPORTANT ─ RETAIN FOR FUTURE REFERENCE
Produced in China for Next Retail Ltd. 2

Warnings
We suggest you retain these instructions for future reference
Keep fittings out of children’s reach and keep children well away
from construction area
This product should only be used on firm level ground
Avoid exposing the furniture to excessive heat or direct sunlight
as this can cause cracking of the wood and deterioration of the
colour
Unwrap all packaging materials and place the components on
top of the carton box or on a clean floor to protect it from
damage
This product is not suitable for outdoor use
Do’s
We suggest you spend a short time reading through this leaflet
before you start
When you are ready to start, make sure that you have the right
tools and plenty of space
We recommend that the packaging is used to protect the
surfaces during assembly
Carefully check that you have all the parts before beginning
assembly
Ensure the product is fully assembled as illustrated and all
fixings fully tightened before use.
Check fixings regularly to ensure they remain tight
Always wipe dry after cleaning
Keep away from strong heat sources
Regularly check that the protective feet on the legs are fitted
before use
Don’ts
Never allow any kind of liquid to remain on your furniture.
Absorption can cause wood to warp or finishes to de-laminate.
Do not stand or lean back on your chairs
Do not use silicone based furniture polish. Silicone in furniture
polishes can break down the lacquer finish.
Do not drag your furniture
Number of people required to assemble
Two people are required to assemble this item.
Time to assemble
Tools supplied
Missing parts
If you are missing any fixtures and fittings for your product
please contact our customer service team on 0333 777
8999 and they will be happy to arrange for a replacement to
be sent to you free of charge.
Home service technicians
If you have a fault with your product please contact our
customer service team on 0333 777 8999. If you have had
the product for 28 days or less you may be offered a
replacement, refund or for a fully trained home service
technician to visit your home to assess the fault and repair
the product where possible. If you have had the product for
more than 28 days we will send an independent home
service technician to review and repair the product where
possible and recommend further action.
You can write to us at
Home Customer Services
Next Retail Ltd,
Desford Road,
Leicester,
LE19 4AT
To view our full furniture range please visit
www.next.co.uk
BEFORE YOU START
3
15mins
Produced in China for Next Retail Ltd.
IVA BARSTOOL
Assembly instructions
120490 / 372329 / 392760 / 455221 / 735223 / 946725

GETTING TO KNOW YOUR PRODUCT
4Produced in China for Next Retail Ltd.
Item
Description
Composition
455221
IVA MNZA GREY BL
80% Polyester 20% Cotton
120490
IVA OPVL ANML BL
100% Polyester
372329
IVA OPVL OCHRE BL
100% Polyester
735223
IVA OPVL BLK GL
100% Polyester
946725
IVA OPVL STEEL BL
100% Polyester
392760
IVA OPVL STEEL CL
100% Polyester
IVA BARSTOOL
Assembly instructions
120490 / 372329 / 392760 / 455221 / 735223 / 946725

5
Fixtures and fittings
supplied (actual size)
Ref
Dimensions
Qty
*Extra
A
M6 x 16mm
4
1
B
M6 x 20mm
4
1
C
M6 x 18mm
4
1
mm 10 20 30 40 50 60 70 80 90 100
Fixtures and fittings supplied (not to scale)
Ref
Dimensions
Visual
Qty
D
4mm
1
Produced in China for Next Retail Ltd.
IVA BARSTOOL
Assembly instructions
120490 / 372329 / 392760 / 455221 / 735223 / 946725

6
1
Produced in China for Next Retail Ltd.
WARNING: Ensure that all fittings are tightened before use.
IVA BARSTOOL
Assembly instructions
2
FRONT
100%
100%
120490 / 372329 / 392760 / 455221 / 735223 / 946725

Produced in China for Next Retail Ltd. 7
90cm
68cm
45cm
48cm
Actual product size:
H90 x W45 x D48cm
IVA BARSTOOL
Assembly instructions
120490 / 372329 / 392760 / 455221 / 735223 / 946725
