Next LOCKER ROBE 769852 User manual

Φ6x 5 Φ x2.2
M4x10 145x2
A x 4 B x 2
C x 4 D x 2
140x12 ST 3.9x12 Φ x4
E x 1 F x 1 G x 4
1 x 1 2 x 1 3 x 1 4 x 1 5 x 1 6 x 1
7 x 1 x 1 9 x 1 10 x 1 11 x 1 12 x 1
FITTINGS
PARTS
Page 2 of 7

IMPORTANT:
1. Insert legs 1 & 2 into panels 3 & 4 as shown in the
diagram.
Make sure the holes in leg 2 face towards the back of
the item as shown in the diagram.
STEP ONE
STEP TWO
1. Attach panel 5 to the assembled unit as shown in
the diagram.
1
4
3
1
4
3
2
3
5
4
Page 3 of 7

1. Attach bottom panel 10 to the assembled unit as
shown in the diagram.
1. Attach shelf 11 to panels 3 & 4 as shown in the
diagram
STEP THREE
STEP FOUR
STEP FIVE
1. Attach panel 6 to the assembled unit as shown in
the diagram.
6
4
3
10
4
3
11
3
4
Page 4 of 7

NOTE:
1. Attach panel 9 to the assemlbed unit as shown in
the diagram.
Take care to ensure panel 9 is located correctly
before clicking into place.
STEP SIX
1. Place hanging rail 12 onto the hanging rail
brackets on side panels 3 & 4.
STEP SEVEN
4
3
11
9
12
34
Page 5 of 7

1. Attach 2 x handles (D) to door panels 7 & with 4 x
wing screws (C) & 4 x plastic washers (G). Tighten by
hand.
STEP NINE
1. Attach door panel 7 to the assembled unit with 2 x
hinges (A) & 1 x plastic washer (B) as shown.
2. Bend the hinge pin bracket tabs to fix the hinges
(A) as shown in the diagram.
STEP EIGHT
7
B
A
4
A
A
A
7
78
Page 6 of 7
CG
D
CG

1. Use screw (F) to secure the nylon strap (E) to the
WARNING:
Always ensure the area to be drilled is free from
hidden electrical wires, water and gas pipe.
NOTE:
Wall fixings are not included, please source suitable
fixings for your wall type, if in doubt
please consult a qualified trades person
STEP ELEVEN
STEP TEN
1. Repeat STEP NINE to attach door panel to the
assembled unit.
Next Retail Ltd, Desford Road, Leicester, LE19 4AT
back panel as shown.
2. Secure the other end of strap to the wall with an
approriate screw and wall plug for your wall type.
7
8
F
E
8
Page 7 of 7
