ASSEMBLY INSTRUCTIONS.
IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
856596 LINCOLN SMALL SIDEBOARD
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple
step by step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of 2 persons is required to assemble this product.
• We recommend the use of the wall attachment bracket for safety reasons.
Helpline
If you have any problems with this
product or require any replacement
fittings please contact Customer
Services Tel: [phone]
Regrettably self assembly items cannot be returned once assembly is part or fully completed
unless the item is found to be faulty. Should you need to return the unassembled product,
please repack in the original packaging.
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Always use a non-silicone based furniture polish. Silicone in furniture polishes can break down
the lacquer finish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
Avoid keeping furniturein direct sunlight or closeto any heat sources as this can cause cracking,
discolouration or warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
All assembly fixings should always be tightened properly and periodically check all fixings and
tighten if necessary.
• The finish will mellow and change colour over time.
CARE INSTRUCTIONS
PRODUCT INFORMATION
Tools Needed
Made in Poland.
GLASS INFORMATION
This item contains glass. Please handle with extreme care.
Batch No: MM-42 , Date of Manufacture: May 2013
This unit contains safety film backed mirrored glass door panels of a nominal thickness of 3 mm
which are not required to be classified to BS 6206.
If a glass component is chipped or broken replace with glass of the type described on this label.
Consult the manufacturer, retailer or agent with regard to obtaining a manufacturing specification
and shape for replacement glass quoting the model number, and batch number or date of
manufacture.
1 of 14 P9--LI 42

2 PERSON ASSEMBLY
ASSEMBLED DIMENSIONS
APPROXIMATE ASSEMBLY TIME
REQUIRED ASSEMBLY TOOLS
REQUIRED ASSEMBLY SPACE
FLOOR AREA
2.0 M x 2.0 M
1.0 hrs
Assembly
Instruction
2
900 mm
380 mm
783 mm
DESCRIPTION:
856596 LINCOLN SMALL SIDEBOARD
of 14 P9--LI 42

PARTS LIST
Assembly
Instruction
3
NO PART LIST QTY
.
(1)
(2)
(3)
(4)
(5)
(6)
(7) RIGHT
(8)
(9)
SIDE L
SIDE R
VERTICAL DIVIDER
TOP PANEL
BOTTOM PANEL
LEFT BACK PANEL
BACK PANEL
DOOR
SHELF
1
1
1
1
1
1
1
2
2
856596 LINCOLN SMALL SIDEBOARD
9
9
67
8
8
1
2
3
5
4
DESCRIPTION:
of 14 P9--LI 42

HARDWARE LIST DO NOT MIX CONTENT OF HARDWARE BOXES
10 20 30 40 50 60 70 80 90 100 mm
Assembly
Instruction
4
5x39
CAM BOLT
A
x12
B
x12
8x28
DOWEL
C
x8
15x12
CAM LOCK
+
D
x8
SHELF
SUPPORT
1:2
F
x4 x8 x17 x7 x10 x4
x8
HINGE PLATE
G
6,3x13
SCREW
E
H I J
x4
NYLON FEET
1:2
K
26
HINGE
L
SCREW
4x13
BAG 1 BAG 1BAG 1 BAG 1
BAG 3 BAG 3BAG 3
BAG 3
BAG 1
BAG 1 BAG 1 BAG 1
3,0x20mm
SCREW METAL PLATE
HANDLE
C1
x4
15x18
CAM LOCK
+
BAG 1
N
x1
Strap
L-250x20
Bag 4
N1
x2
Washer
f18
Bag 4
856596 LINCOLN SMALL SIDEBOARD
PLASTIC
SUPPORT
M
x2
SCREW
3,5x13
BAG 4
O
x2
P
x2
wpm4x22
SCREW
BAG 2 BAG 2 BAG 1
Q
x12
15mm
CAM COVER
R
x2
SILICON PEG
BAG 1
DESCRIPTION:
PIN HOLDER
H1
1x
1:2
Bag 1
of 14 P9--LI 42

Assembly
Instruction
Top Tips before you start!
1. Please check that all parts are present before you start the assembly of your furniture,
as once assembed, the furniture is exempt from our home approval policy.
2. For ease and speed of assembly, we recommend that before you commence each step
of the assembly, that you identify all the parts required for that step.
3. For larger items, please ensure that you have sufficient space and people (as indicated
on page1) to assemble your product safely.
4. We recommend that, where possible, all items are assembled near to the area in which
they will be placed in use, to avoid moving the product unnecessarily once assembled.
5. For the protection of your furniture, particularly items of high gloss finish, we recommend
that the product is placed on a protected surface during assembly to prevent any damage.
6. During assembly please take care not to over-tighten any fittings, as this may damage
the product ..
Care and Maintenance of your Furniture
Please periodically check all fittings and re-tighten as necessary.
Please do not jump on your furniture.
To clean your item, please use a damp cloth and wipe clean.
Never allow any kind of liquid to remain on your furniture.
Absorption can cause wood to warp or
finishes to de-laminate.
5
856596 LINCOLN SMALL SIDEBOARD
DESCRIPTION:
of 14 P9--LI 42

SCREW IN CAM SCREWS
ONLY D O W N TO F I R S T R I N G.
FLUSH
WITH
PANEL
1
PRESS PANELS TOGETHER ALIGNING
DOWEL WITH H O L E S , C A M S C R E W S W I T H L O C K S .
3
TO SECURE PA N E L S ,
TURN CAM LOCKS 1/2 TURN CLOCKWISE.
4
CAM SH OW N IN
LO CK ED P OS IT IO N.
+
+
PRESS IN CAM LOCKS. A R R O W O N C A M
LOCK MUST FA C E H O L E I N PA N E L EDGE.
DO N O T IN SE R T DO W EL S
IN C A M SC RE W / L OC K HOL ES .
2
+
+
Assembly
Instruction
6
856596 LINCOLN SMALL SIDEBOARD
DESCRIPTION:
of 14 P9--LI 42

a)
B
A
b)
A
c)
C
C
Instructions for hinge adjustment
a) Side adjustment:
b) Depth adjustment:
c) Height adjustment:
Loosen fixing screw "A", adjust gap with screw "B" and retighten
screw "A".
Loosen fixing scerw "A", push hinge arm forwards or backwards,
Loosen screw "C", adjust height, retighten screw "C".
retighten screw "A", fix screw "B" with a 1/4-turn in clock-wise
direction.
Assembly
Instruction
7
856596 LINCOLN SMALL SIDEBOARD
DESCRIPTION:
of 14 P9--LI 42

Assembly
Instruction
1
8
+
A
A
A
x4 C
C
C
C
C
x4
B
B
B
x4 D
D
D
x4 E
E
E
F
F
F
F
x4
FF x8
x4 G
+
+
+
+
+
+
front
F
G
856596 LINCOLN SMALL SIDEBOARD
1
2
DESCRIPTION:
of 14 P9--LI 42

Assembly
Instruction
2
9
A
A
A
x4
C1
C1
C1
x4 D
D
D
x4
+
+
C1
856596 LINCOLN SMALL SIDEBOARD
3
3
DESCRIPTION:
+
+
+
+
of 14 P9--LI 42

Assembly
Instruction
10
3
+
+
+
4
+
+
+
B
B
x6
x2
C
x4
A
x4
B
B
B
F
F
C
C
C
B
856596 LINCOLN SMALL SIDEBOARD
4
5
5
DESCRIPTION:
of 14 P9--LI 42

Assembly
Instruction
5
11
6
+
+
1/2 T URN
CLO CKW ISE .
+
+
856596 LINCOLN SMALL SIDEBOARD
1
2
3
4
5
67
DESCRIPTION:
of 14 P9--LI 42

Assembly
Instruction
7
Ba ck p an el k ee ps
un it s qu ar e.
Tack back panel
fo r co rn er s fi rs t
an d wo rk y ou r
wa y ar ou nd .
o
90
12
H
H
x17
IJ
J
x7 x10
HI
H1
x1
H
H1
856596 LINCOLN SMALL SIDEBOARD
67
DESCRIPTION:
of 14 P9--LI 42

Assembly
Instruction
8
13
9
K
x4
L
x8
Wall fixings are not supplied with this product as different wall materials require different
types of fixing devices( such as Rawl plugs used on brick work).You fixing
devices suitable for the type of wall you intend to mount this product to.
Please ensure that the head of any screw used has a diameter greater than the diameter
of the mounting hole on the product and that the fixing is safe and secure before use.
must use
*
8f
1
KL
856596 LINCOLN SMALL SIDEBOARD
8
8
DESCRIPTION:
NOT SUPPLIED *
2
N1
x2
N
x1
M
x1
3
M
N
N1 N1
N
of 14 P9--LI 42

NEXT Retail Ltd, Desford Road, Enderby Leicester, LE19 4AT
DESCRIPTION:
Assembly
Instruction
10
14
P
x2
O
x2 Q x12 R
R
x2
856596 LINCOLN SMALL SIDEBOARD
+
99
8
8
Q
O
P
